Rotary Tillers
RTA2064, RTA2072, RTR2064 & RTR2072
25590
Table of Contents
311-328M
Operator's Manual
Read the Operator's manual entirely.
!
When you see this symbol, the
subsequent instructions and
warnings are serious - follow without
exception. Your life and the lives of
others depend on it!
© Copyright 2007 Printed
Cover photo may show optional equipment not supplied
with standard unit.
7/03/07
