Sanyo VCC-ZM400P Service Manual page 13
Colour ccd camera
Hide thumbs
Also See for VCC-ZM400P
:
Instruction manual
(67 pages)
1
2
3
4
5
6
7
8
9
10
11
12
13
Table Of Contents
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
page
of
31
Go
/
31
Contents
Table of Contents
Bookmarks
Advertisement
Enlarged version
LOCATION PARTS NO.
DESCRIPTION
R5014
401 105 5301
MT-GLAZE 4.7K JA 1/16W
R5015
401 105 5301
MT-GLAZE 4.7K JA 1/16W
R5016
401 105 1204
MT-GLAZE 120K JA 1/16W
R5017
401 105 0702
MT-GLAZE 100K JA 1/16W
R5018
401 105 7909
MT-GLAZE 0.000 ZA 1/16W
R5201
401 105 0603
MT-GLAZE
R5202
401 105 0603
MT-GLAZE
R5203
401 105 2805
MT-GLAZE 2.2K JA 1/16W
R5207
401 105 0603
MT-GLAZE
R5208
401 105 0603
MT-GLAZE
R5211
401 105 2805
MT-GLAZE 2.2K JA 1/16W
R5420
401 105 0603
MT-GLAZE
R5421
401 105 0702
MT-GLAZE 100K JA 1/16W
R5422
401 105 6001
MT-GLAZE 5.6K JA 1/16W
R5423
401 105 4205
MT-GLAZE
R5424
401 105 1600
MT-GLAZE
R5425
401 105 0603
MT-GLAZE
R5426
401 105 7909
MT-GLAZE 0.000 ZA 1/16W
R5427
401 105 6001
MT-GLAZE 5.6K JA 1/16W
R5428
401 105 0504
MT-GLAZE
R5429
401 105 0405
MT-GLAZE
R5430
401 105 0603
MT-GLAZE
R5431
401 105 7404
MT-GLAZE 8.2K JA 1/16W
(SWITCHES)
S5001
645 023 3715
SWITCH,PUSH
S5002
645 023 3333
SWITCH,PUSH 1P-1T
(FUSE)
F5001
423 030 0800
FUSE 125V 2A
(CONNECTORS)
CN501
645 024 8115
PLUG,28P
CN511
645 005 0237
SOCKET,BNC 1P (N.S.P)
CN513
645 054 1070
TERMINAL 5P
CN514
645 040 6027
TERMINAL 3P
(MISCELLANEOUS)
Y5001
645 053 7189
SPACER
FLEXIBLE FLAT CABLE
W0001
645 054 1087
FLEXIBLE FLAT CABLE
10K JA 1/16W
10K JA 1/16W
10K JA 1/16W
10K JA 1/16W
10K JA 1/16W
33K JA 1/16W
15K JA 1/16W
10K JA 1/16W
1K JA 1/16W
100 JA 1/16W
10K JA 1/16W
(N.S.P)
13
