Wide IDP2130HB User Manual

1600 x 1200 tft lcd monitor 21.3" color display
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Page No.
Title
IDP2130HB / IDP2130TS
1 / 45
(AL21NUX)
USER'S MANUAL
IDP2130HB
IDP2130TS
1600 x 1200 TFT LCD MONITOR
21.3" COLOR DISPLAY
Proprietary Data Notice:
This document as well as all reports, drawings, data, information, or other material, whether accompanying it are the property of
WIDE Corporation, are disclosed by WIDE only in confidence, and, except as WIDE may otherwise permit in writing, are to be
used, disclosed, or copied only to the extent necessary for the evaluation thereof by recipient, or higher-tier contractor or
subcontractor.
Information in this document is subject to change without prior notice.
Issued Date
Revision Status
2009-04-07
V2.3

Advertisement

Table of Contents
loading

Related Manuals for Wide IDP2130HB

Summary of Contents for Wide IDP2130HB

  • Page 1 This document as well as all reports, drawings, data, information, or other material, whether accompanying it are the property of WIDE Corporation, are disclosed by WIDE only in confidence, and, except as WIDE may otherwise permit in writing, are to be used, disclosed, or copied only to the extent necessary for the evaluation thereof by recipient, or higher-tier contractor or subcontractor.

  • Page 2: Table Of Contents

    Page No. Title IDP2130HB / IDP2130TS 2 / 45 (AL21NUX) Table of Contents SAFETY INSTRUCTIONS ......................... 3 VCCI ..............................5 BRIEF DESCRIPTION ........................6 GENERAL ............................6 TECHNICAL SPECIFICATIONS ..................7 ELECTRO-OPTICAL SPECIFICATIONS ................7 1.1.1 Screen Specifications ......................7 1.1.2...

  • Page 3: Safety Instructions

    Page No. Title IDP2130HB / IDP2130TS 3 / 45 (AL21NUX) SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
  • Page 4 Page No. Title IDP2130HB / IDP2130TS 4 / 45 (AL21NUX) Do not clean the front panel with keton-type materials(e.g., acetone), ethyl alcohol, toluene, ethyl acid, methyl or chloride – these may damage the panel. ON REPACKING Do not throw away the carton and packing materials. They make an ideal container which to transfer the unit.

  • Page 5: Vcci

    Page No. Title IDP2130HB / IDP2130TS 5 / 45 (AL21NUX) FCC INFORMATION USER INSTRUCTIONS The Federal Communications Commission Radio Frequency Interference Statement includes the following warning: NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

  • Page 6: Brief Description

    The 0.270mm pixel pitch LCD provides the most accurate and crisp images on the screen for mission critical applications. The IDP2130HB provides 16.7 million colors per pixel. Each pixel is divided into Red, Green and Blue sub pixels which are arranged in vertical stripes and each sub-pixel is controlled in 256 grey levels.

  • Page 7: Technical Specifications

    Page No. Title IDP2130HB / IDP2130TS 7 / 45 (AL21NUX) TECHNICAL SPECIFICATIONS ELECTRO-OPTICAL SPECIFICATIONS 1.1.1 Screen Specifications 1.1.1.1 Panel Technologies AMLCD (Active Matrix Liquid Crystal Display) technology  Amorphous silicon TFT (Thin Film Transistor) technology  1.1.1.2 Screen Dimensions Aspect ratio 4:3 ...

  • Page 8: Input Signal Specifications

    IDP2130HB / IDP2130TS 8 / 45 (AL21NUX) 1.1.3 Input Signal Specifications IDP2130HB provides maximum five (5) input signal interfaces, 2 x Analog(BNC,D-sub) Input(separate/  composite/SOG),1x Digital Input, 1xCVBS input and 1xS-video(interlaced NTSC and PAL). Standard input resolution is UXGA(1600 x 1200 pixels) ...

  • Page 9: Controls Of The Display

    Page No. Title IDP2130HB / IDP2130TS 9 / 45 (AL21NUX) Manual: Operator can select the input manually using control panel.  1.1.4 Controls of the Display 1.1.4.1 Control via OSD(On Screen Display) Control block with the push buttons is available: Menu, Select, ◀ and ▶.

  • Page 10: Connection & Pin Assignment

    Page No. Title IDP2130HB / IDP2130TS 10 / 45 (AL21NUX) 1.1.7.2 Input signal connectors Analog Input: 15p Dsub and 5 Coaxial BNC connectors for R, G, B, HS and VS  Digital input: DVI-D connectors  CVBS input: RCA connectors ...
  • Page 11 Page No. Title IDP2130HB / IDP2130TS 11 / 45 (AL21NUX) Digital Input ● Connection Type : 29p DVI-I Female (Digital only support) 1. TMDS Data 2- 2. TMDS Data 2+ 3. TMDS Data 2/4 Shield 4. TMDS Data 4- 5. TMDS Data 4+ 6.
  • Page 12 Page No. Title IDP2130HB / IDP2130TS 12 / 45 (AL21NUX) Control Interface Touch screen serial control (option) ● Touch screen serial control(female) 1. –DCD("carrier detect", handshake='0' when controller power on) 2. RXD (serial data from controller to host) 3. TXD (serial data from host to controller) 4.

  • Page 13: Mechanical Specifications

    Weight (kg / lbs) 11.5 / 25.35 16.0 / 35.27 The following figures show a chassis version mechanical dimension. IDP2130HB basically provides three input connectors and all connectors are located the bottom side of monitor. < IDP2130HB/TS Front View : unit mm >...
  • Page 14 Page No. Title IDP2130HB / IDP2130TS 14 / 45 (AL21NUX) < IDP2130HB Bottom View > < IDP2130TS Bottom View > < IDP2130HB Bottom View (DC power option)> Issued Date Revision Status 2009-04-07 V2.3...
  • Page 15 Page No. Title IDP2130HB / IDP2130TS 15 / 45 (AL21NUX) < IDP2130HB Rear View > Issued Date Revision Status 2009-04-07 V2.3...
  • Page 16 Page No. Title IDP2130HB / IDP2130TS 16 / 45 (AL21NUX) < IDP2130TS Rear View > Issued Date Revision Status 2009-04-07 V2.3...
  • Page 17 Page No. Title IDP2130HB / IDP2130TS 17 / 45 (AL21NUX) < IDP2130HB Rear View (DC power option)> Issued Date Revision Status 2009-04-07 V2.3...
  • Page 18 Page No. Title IDP2130HB / IDP2130TS 18 / 45 (AL21NUX) < IDP2130HB/TS Side View : unit mm> Issued Date Revision Status 2009-04-07 V2.3...

  • Page 19: Mounting

    The weight for the unit shall not exceed 11.5 kg (25.35 lbs)  Fixing: using 4 captive M6 bolts in front bezel  IDP2130HB can be Standard rack mounted with an optional adapter plate 1.2.3 Finishing  Standard Bezel color is Black (Rack mount type) ...

  • Page 20: Emc

    1.4.2 Maintainability MTTR (Mean Time Between Repair)  IDP2130HB is defined as a Line Replaceable Unit (LRU) and the unit is designed to allow for an MTTR less than 0.5 hour (30 minutes). 1.4.3 Use of toxic materials Cold Cathode Fluorescent Lamp (CCFL) in the backlight assemblies contains a small amount of mercury. The backlight assembly is placed inside of the monitor and is not exposed to user.

  • Page 21: User Controls

    Page No. Title IDP2130HB / IDP2130TS 21 / 45 (AL21NUX) 2 User Controls LED indicator Up / Increase / Hot Key3 Operation Hot Key2 MENU Down/ Decrease/ SELECT/Hot Key1 Soft Power Switch Brightness Knob SOFT POWER SWITCH Power ON: To turn the display on, press the power switch. The power light indicator will turn green.

  • Page 22: User Control Access

    Page No. Title IDP2130HB / IDP2130TS 22 / 45 (AL21NUX) USER Control Access 1: Press the ”MENU” button. The OSD menu will show all the available functions you can adjust or control. 2: You can move to the next icon by pressing “◀ and ▶”.

  • Page 23: Adjustment

    Page No. Title IDP2130HB / IDP2130TS 23 / 45 (AL21NUX) 2.3.1 Adjustment The “Adjustment” menu is for controlling the brightness, contrast, positions, sharpness, clock and phase. 2.3.1.1 BRIGHTNESS The function is able the user to adjust brightness for the display, 50 is default value.
  • Page 24 Page No. Title IDP2130HB / IDP2130TS 24 / 45 (AL21NUX) 2.3.1.2 CONTRAST The function is able the user to adjust contrast for the display, 50 is default value. “Contrast” is the submenu of “Adjustment”, which sets up the gain of output video signal to panel. Its adjustment range is 0 to +100.
  • Page 25 Page No. Title IDP2130HB / IDP2130TS 25 / 45 (AL21NUX) 2.3.1.4 V.POSITION The function is able the user to adjust vertical position of the display. “V-Position” is the submenu of “Adjustment”, which controls the vertical position of image, Its adjustment range is 0 to +100 and default is 50. When the V-position of the submenu of “Analog adjustment”...

  • Page 26: Color Adj

    Page No. Title IDP2130HB / IDP2130TS 26 / 45 (AL21NUX) 2.3.1.6 CLOCK The function is able the user to adjust the number of sampling clock. The “Clock” is the menu for the setting of the number of pixels corresponding to the pixel rate of the applied analog input signal.
  • Page 27 Page No. Title IDP2130HB / IDP2130TS 27 / 45 (AL21NUX) 2.3.2.1 COLOR TEMPERATURE The function is able the user to modify the color temperature of the picture for the Display. Higher temperature : “cooler” picture. Lower temperature : “warmer” picture.
  • Page 28 Page No. Title IDP2130HB / IDP2130TS 28 / 45 (AL21NUX) When all white levels are on the points of OSD 50, the amount of color is the same each other. But, if the level is moved closed to OSD 100, the amount of color to adjust is more, so, the color to adjust looks like strong.

  • Page 29: Pip(Picture In Picture)

    Page No. Title IDP2130HB / IDP2130TS 29 / 45 (AL21NUX) 2.3.3 PIP(Picture In Picture) This function is for displaying the video image window on the image from PC. CVBS or S-Video is possible to display on PIP window. The image from PC over DVI, BNC and D sub connector is unable to display on the window.
  • Page 30 Page No. Title IDP2130HB / IDP2130TS 30 / 45 (AL21NUX) 2.3.3.2 PIP SIZE This function is able the user to configure PIP window size. <PIP Size: Small> <PIP Size: Large> Issued Date Revision Status 2009-04-07 V2.3...
  • Page 31 Page No. Title IDP2130HB / IDP2130TS 31 / 45 (AL21NUX) 2.3.3.3 PIP LOCATE The function is able the user to the configure PIP horizontal and vertical position <Left Top> <Right Top> Issued Date Revision Status <Left Bottom> <Right Bottom> 2009-04-07...

  • Page 32: Setup Menu

    Page No. Title IDP2130HB / IDP2130TS 32 / 45 (AL21NUX) 2.3.3.4 PIP SOURCE The function is able the user to configure PIP input source. CVBS = manual select composite video signal only SVIDEO = manual select S-Video signal only. 2.3.4 SETUP MENU In this menu, user can set up the setting values.
  • Page 33 Page No. Title IDP2130HB / IDP2130TS 33 / 45 (AL21NUX) 2.3.4.1 INPUT SELECT The function is able the user to select one of Analog RGB(D-sub), Digital RGB, BNC,CVBS and S-Video 2.3.4.2 COMMUNICATION (Maintenance only(available for qualified technician)) “Communication” represents the communication setting between monitors or between the control...
  • Page 34 Page No. Title IDP2130HB / IDP2130TS 34 / 45 (AL21NUX) 2.3.4.2.1 This assigns the monitor’s number, range Zero to fifteen, in order to identify the monitors, and it must be unique for distinguishing from each other. And, In the case of chaining several monitors thru communication port, the ID of monitor to be connected with control system must by Zero.

  • Page 35: Osd Setup

    Page No. Title IDP2130HB / IDP2130TS 35 / 45 (AL21NUX) 2.3.4.2.3 Communication This assigns the communication mode. The monitor connecting with the control system is assigned the RS232 or RS422 and it connecting with other monitor is assigned to the RS485. So, one of three must be chosen as input communication mode.
  • Page 36 Page No. Title IDP2130HB / IDP2130TS 36 / 45 (AL21NUX) 2.3.4.3.1 H.Position This function is able to adjust the horizontal position of OSD. 2.3.4.3.2 V.Position This function is able to adjust the vertical position of OSD. 2.3.4.3.3 TIME OUT “OSD Timeout” is the submenu of “OSD Set Up”, which controls the time to display the OSD menu 20, 30, 50, and 100 : When the user don’t touch...

  • Page 37: Factory Recall

    Page No. Title IDP2130HB / IDP2130TS 37 / 45 (AL21NUX) 2.3.4.4 FACTORY RECALL “Factory Recall” is the menu for restoring to the factory setting values. The settings with which the display leaves factory are stored in a factory settings storage area on main control board.
  • Page 38 Page No. Title IDP2130HB / IDP2130TS 38 / 45 (AL21NUX) 2.3.4.5.1 Serial NO. “Serial No.” describes the serial number of monitor. The serial number is unique on every monitor. 2.3.4.5.2 SW ver. “S/W ver.” describes the version of software installed on monitor.

  • Page 39: Appendix A: Touch Screen Driver Installation(Only For Idp2130Ts)

    Page No. Title IDP2130HB / IDP2130TS 39 / 45 (AL21NUX) Appendix A: Touch screen driver installation(only for IDP2130TS)  How to install the touch screen driver (see the below figure) 1. Dsub (DB9pin) cable connecting between a computer and the Touch screen serial control port 2.
  • Page 40 Page No. Title IDP2130HB / IDP2130TS 40 / 45 (AL21NUX) 2. Touch screen driver install Issued Date Revision Status 2009-04-07 V2.3...
  • Page 41 Page No. Title IDP2130HB / IDP2130TS 41 / 45 (AL21NUX) Issued Date Revision Status 2009-04-07 V2.3...
  • Page 42 Page No. Title IDP2130HB / IDP2130TS 42 / 45 (AL21NUX) Issued Date Revision Status 2009-04-07 V2.3...
  • Page 43 Page No. Title IDP2130HB / IDP2130TS 43 / 45 (AL21NUX) Push this point with a finger or a gloved hand Issued Date Revision Status 2009-04-07 V2.3...
  • Page 44 Page No. Title IDP2130HB / IDP2130TS 44 / 45 (AL21NUX) 3. Touch screen calibration Issued Date Revision Status 2009-04-07 V2.3...
  • Page 45 Page No. Title IDP2130HB / IDP2130TS 45 / 45 (AL21NUX) Push this point with a finger or a gloved hand Issued Date Revision Status 2009-04-07 V2.3...
