This workshop manual is intended primarily
for all repair shops and their workers
concerned with repairs of our model 210
moped. It does not contain servicing jobs
and repairs described in the Rider's Manual
but only repairs for which special assembly
tools and jigs are required.
The purpose of this manual is to facilitate
the work of the repairmen and to improve
servicing of our products. Any changes and
deviations from standard procedures will be
announced in our Service Bulletins.
ZVL concern, Povazske strojarne
Klementa Gottwalda works
sales and technical service department
CONTENTS
I. Moped specifications
II. General technical data
1. Assembly tools and jigs
2. Moped lubrication - Lubrication Chart
3. List of bearings, sealing rings and bushes
3. Grading of cylinders and pistons
IV. Frame
1. Front, telescopic fork
2. Front, and rear wheel
3. Rear wheel telescopic suspension
2. Ignition system
4. Diagnosing electronic ignition defects
WORKSHOP MANUAL
moped model 210
I. MOPED SPECIFICATIONS
Engine type
Swept volume
Cylinder bore x piston stroke 39 x 41 mm
Engine power output
Clutches
Gearbox
Engine to rear wheel
transmission ratio
Primary transmission
Secondary transmission
Pedal drive transmission ratio1 : 0.692
Pedal-actuated starting gear overall ratio 1 : 0.0504
Front suspension
Rear suspension
Brakes
Brake dimensions
Tyres
Wheels
Inflation pressures - front tyre
Moped dry weight
Moped running weight
Road speed - sustained
Fuel tank filling capacity
Fuel reserve
Maximum climbable gradient
with rider weighing 75 kg
Noise
Ignition system
Spark plug
Headlamp
Tail lamp
Speedometer lighting
Fuel consumption
Load capacity, maximum
Note:
When exceeding the load capacity, it is necessary to decrease the
maximum speed proportionally
ZVL model 210 Workshop Manual Pages 1, 2 & 3
air cooled, two-stroke single-cylinder unit
49 cc
1.75 kW at 5,000 rpm ± 8 %
automatic, dry, centrifugal
two-speed unit
st
1
. speed overall ratio --- 1 : 24.4231
nd
2
. speed overall ratio --- 1 : 13.7305
indented belt
link chain
telescopic fork without shock absorbers
60 mm stroke
telescopic suspension units without shock
Absorber -- 60 mm stroke
internal expanding shoe -- brakes controlled
by levers on handlebars
85 x 20 mm
2¼ x 16"
1.60" (WH1) x 16"
196 kPa
- rear tyre
245 kPa
51 kg
54 kg
35 km/hr.
- maximum
40 km/hr ± 5 %
4 litres
0,7 litres
25 %
70 decibels
6 volt, contactless with semiconductor
elements
PAL N 7 R
[ Champion L89CM L85 L86 ]
[ NGK B6HS
6 v 21 w
6 v 5 w
6 v 2 w
1.8 litres/100 km at 27 km/hr
90 kg including 5 kg luggage on carrier
www.jawamoped.com
(2 atm)
[ 28 psi ]
(2.5 atm.)
[ 36 psi ]
Bosh W7AC ]
