Summary of Contents for Encore Premier HydroPro 48K250WT
- Page 1 4 8K 2 5 0 W T OPERATORS MANUAL...
- Page 2 ENCORE Your mower is only as safe as the operator! Operator carelessness or error may result in serious bodily injury. Improper maintenance of the machine may also result in injury. Please read and follow these instructions on Safe Operation and be certain that anyone using this mower fully understands and follows these instructions.
-
Page 3: Specifications
9.5 quarts (9.01) w/filter change (2 inches below the top of the fill neck) Filter Encore P/N 453048 (Units Prior SN 31078) Encore P/N 423063 (Units After SN 31078) A High quality 20W50 API CD Rated NOTE: 20W20 oil is acceptable in cooler conditions Assembly Instructions 1. - Page 4 ENCORE Assembly Instructions handle for operator comfort.) Route the wiring harness along the handle, plugging it into the blade control switch, o.p.c. and speed control switch located under the speed control plate. There is not a specific color code for hooking up the harness.
-
Page 5: Final Check / Adjustment
ENCORE speed control arm speed control arm BEFORE OPERATING Know your machine top to bottom. Make certain all safety standards and instructions have been fully read and understood. gas tank gas tank Be acquainted with all “SAFETY INSTRUCTIONS” in this manual – to... -
Page 6: Safety Decals
PLEASE BE CAREFUL ! SAFETY DECALS In order to promote safe operation, Encore Mfg. Co., Inc. supplies safety decals on all products manufactured. Because damage can occur to safety decals through shipment, use or reconditioning, Encore will, upon request, provide safety decals for any of our products in the field at No Charge. -
Page 7: Lubrication / Maintenance
ENCORE HEIGHT ADJUSTMENT REAR DECK MOUNT IN LOWEST POSITION REAR DECK MOUNT IN HIGHEST POSITION (5) spacers on top of caster arm = 1 7/8" to 3 1/8" (5) spacers on top of caster arm = 1 1/2" to 2 3/4"... - Page 8 ENCORE LUBRICATION / MAINTENANCE LUBRICATION New Blade (Units After Serial Number 33333) Grease Daily: When Notch Starts Dangerous! 25 Degrees Idler Arm Discard Blade Caster Wheels and Caster Pivots Mower Blades: Check sharpness of Drive Wheels mower blades after every 10 hours of Grease Every 100 Hours: operation.
- Page 9 ENCORE BLACK / WHITE 18 GA. BLACK / WHITE 18 GA. ENCORE PART #: 363344 ENCORE PART #: 363344 WIRE HARNESS FOR 32B100E ; 12 HP BRIGGS WIRE HARNESS FOR 32B100E ; 12 HP BRIGGS WIRE HARNESS FOR 36B100E ; 12 HP BRIGGS WIRE HARNESS FOR 36B100E ;...
- Page 10 ENCORE ENCORE PART #: 363373 ENCORE PART #: 363373 WIRE HARNESS FOR 48K450EWT ; 17 HP KAWASAKI WIRE HARNESS FOR 48K450EWT ; 17 HP KAWASAKI BLACK / WHITE 18 GA. BLACK / WHITE 18 GA. WIRE HARNESS FOR 48K550EWT ; 19 OR 20 HP KAWASAKI WIRE HARNESS FOR 48K550EWT ;...
- Page 11 ENCORE ENCORE PART #: 453029 ENCORE PART #: 453029 NOTE CHANGES AT CONN .red wire was at B slot NOTE CHANGES AT CONN .red wire was at B slot WIRE HARNESS FOR 48B350WT ; 16 HP BRIGSS WIRE HARNESS FOR 48B350WT ; 16 HP BRIGSS...
- Page 12 ENCORE ENCORE PART #: 453160 ENCORE PART #: 453160 NOTE CHANGES AT CONN .red wire was at B slot NOTE CHANGES AT CONN .red wire was at B slot WIRE HARNESS FOR 36K450 ; 17 HP KAWASAKI WIRE HARNESS FOR 36K450 ; 17 HP KAWASAKI...
- Page 13 ENCORE ENCORE PART #: 453164 ENCORE PART #: 453164 WIRE HARNESS FOR 32K250 ; 14 HP KAWASAKI WIRE HARNESS FOR 32K250 ; 14 HP KAWASAKI WIRE HARNESS FOR 36K250 ; 14 HP KAWASAKI WIRE HARNESS FOR 36K250 ; 14 HP KAWASAKI...
- Page 14 Notes:...
-
Page 15: Encore Warranty
All warranty work must be performed by an authorized Encore service dealer. This warranty is limited to two years from the date of original retail purchase for any Encore mower that is used for commercial purposes or 90 days rental. This warranty DOES NOT cover any Encore mower that has been subject to misuse, neglect, negligence, accident or that has been operated in any way contrary to the operating instructions as specified in the Operator’s... - Page 16 0303 A ,ENCORE MANUFACTURING CO., INC. 48K250WT - OPERATORS MANUAL All rights reserved. Contents subject to change. PREMIER HYDROPRO 933042 umber...
