  • Page 1 34 K3 5 0 Z OPERATORS MANUAL...
  • Page 3 Z34 Operation......................C Section Maintenance Information ..................D Section Service Locator Chart .................... D-1 Electrical ......................... E Section 34K350Z, 34K15Z Wire Harness Schematic ............E-1 Notes ........................F Section  WARNING: THE ENGINE EXHAUST FROM THIS PRODUCT CONTAINS CHEMICALS KNOWN IN THE STATE OF CALIFORNIA TO CAUSE CANCER, BIRTH DEFECTS OR OTHER REPRODUCTIVE HARMS.
  • Page 4 As the new equipment owner, you are expected to see that the form is completed To the new owner and forwarded to ENCORE MFG. CO., INC. at time of delivery. The purpose of this manual is to assist owners...
  • Page 5 General Informaton Z34 Kawasaki Quick Reference Sheet Engine 15hp Kawasaki FH430V-AS23 Blades Torque Specs 423029 14.25" blade 14 1/8" 65 ft-lbs blade bolt 423014 low lift blade 14 1/4" 90 ft-lbs nut on top of spindle 423173 mulch blade 13 7/8" 50 ft-lbs clutch bolt 423210...
  • Page 6 LIMITATION OF REMEDIES 90 days from the date of purchase against defects in In no case shall Encore Mfg. Co., Inc. be liable for any special, workmanship and materials for all parts, excluding normal incidental, or consequential damages based upon breach of wear items such as batteries, tires, and belts.
  • Page 7 REFUEL WITH THE ENGINE OFF. KEEP FUEL AWAY 17. The Encore Rider is NOT designed for towing. FROM SPARKS OR FLAMES. WIPE AWAY any fuel spillage BEFORE starting unit. Never 18. Only factory approved Grass Collection fill the fuel tank indoors.

  • Page 8: Starting Engine

    ENCORE Before Operatng - STARTING ENGINE Remnders Throttle control, ignition switch and choke control are located between motion control levers on the front Fill engine crankcase as per engine manufacturer’s panel under the front of the seat. manual. ENGINE DOES NOT HAVE OIL IN Because of a built-in safety interlock system, your CRANKCASE FROM THE FACTORY.

  • Page 9: Safety Interlock System

    ENCORE CORRECT TRANSMISSION SAFETY INTERLOCK SYSTEM OPERATION TO GO Your Encore Rider is equipped with a Safety Interlock FORWARD OR REVERSE System that is designed to help prevent possible serious injuries. Understanding and maintaining this system is vital, for maximum safe operation.
  • Page 10 ENCORE SER VICE LOCATOR CHAR T Front Caster Wheel Bearings (2) Front Caster Pivot Bearing Zerks (2) Engine Oil Fill & Dipstick Engine Oil Filter Engine Air Filter Battery Fuel Tank Engine Fuel Filter Fuel Shut-off Valve Fender w/ Cup Holder...

  • Page 11: Tire Pressure

    Front Tires - 14 PSI Rear Tires - 20 PSI NOTES: The Encore Rider is driven and steered by the rear wheels. REAR TIRE CIRCUMFERENCE DIRECTLY EFFECTS THE TRACKING OF THE MACHINE. If the machine will not drive in a straight line, check...

  • Page 12: Belt Adjustment

    ENCORE Belt Adjustment BATTERY Remove key from the ignition switch. The blade The battery is located under the right hand fender drive belt and the deck drive belt may be accessed to the rear of the machine. The gel-cell battery is by raising the foot plate.
  • Page 13 ENCORE Trackng Adjustment The Encore Z34 riding lawnmower comes from the factory with the neutral setting already adjusted; however, the full-speed tracking will require checking. The full-speed tracking may be checked by operating the machine on a smooth level surface. If the machine tends to travel more to one side rather than in a straight line, the tracking requires adjustment.

  • Page 14: Mower Blades

    ENCORE Mower Blades Bypass Valve Check sharpness of mower blades after every 10 hours In some applications, it is desirable to move the of operation. To sharpen blades proceed as follows: machine for short distances at low speeds without operating the engine. Using (A) push the lever forward ...
  • Page 15 ENCORE ENCORE PART #: 343077 WIRE HARNESS FOR 34K350Z ; 15 HP KAWASAKI WIRE HARNESS FOR 34K15Z ; 15 HP KAWASAKI BLACK 18 GA. LT. BLUE/RED 18 GA. LT. BLUE 14 GA. LT. BLUE/RED 18 GA. PURPLE 18 GA. YEL / LT. BLUE 18 GA.
  • Page 16 Notes...
  • Page 17 Notes...
  • Page 18 Notes...
  • Page 19 Notes...
  • Page 20 0811 A ,ENCORE MANUFACTURING CO., INC. 34K350Z - OPERATORS MANUAL All rights reserved. Contents subject to change. Z SERIES 933236 umber...
