Land Pride Ditcher DT55 Features And Benefits

Ditchers
Features and Benefits
Ditchers
Features
HP range
Cat. 2 & 3
Quick-Hitch adaptable
Formed tubing hitch
540 & 1000 rpm models
20" Impeller
6 Blades on impeller
3/8" Hardened blades
Blades can be rotated when
worn and are replaceable.
3/8" Hardened cutting edge
Double 80 chain
Spring loaded chain idler
Hardened tooth sprockets
2 Greasable flange bearings
4-Bolt cast iron flanges
Cat. 5 Shear-bolt driveline
Depth controlling skid shoe
(optional)
Material control chute
(optional)
Depth control wheel (optional)
Ripper shank (optional)
Designs, specifications, features and information are subject to change without notice.
6/22/11
Table of Contents
DT55 & DTM55 Series
70 - 120 HP
Fits wide variety of tractors.
Quickly and easily attach tiller to tractor with one person.
Formed tubing with 1/4" wall offers greater strength vs. plate steel hitch.
Allows fitting larger tractors that are 1000 rpm only. Driveline available in 1 3/8" or 1 3/4".
20" Impeller digs a nice size drainage or irrigation ditch up to 10" deep with each pass.
6 Blades make digging easier and smoother than fewer blades.
Heavy-duty blades made out of AR400 material for long life.
Each blade has four cutting edges to extend blade life. When one edge is worn, rotate
o
blade 90 to a new cutting edge. Replace blades when all four cutting edges are worn out.
Impeller blades feature a replaceable hardened edge to take on rough and rocky
conditions. Easier and more cost effective to replace edge vs. using hard faced material on
impeller.
Double 80, high tensile roller chain keeps stretching to a minimum and has the strength
needed to take shock loads posed by extreme digging conditions.
Chain idler is spring loaded to keep constant tension on chain during tough digging
conditions, which also makes for smoother digging operations.
Hardened tooth sprockets have the strength needed to take the load of the double 80 chain
and rigorous digging conditions.
Input and output shafts feature 2 1/4" ID ball type bearings. Ball bearings offer smooth and
quiet operation. Bearings are greasable to keep properly lubricated and purge dirt out.
Bearings are housed in a heavy-duty 4-bolt cast iron flange. Heavy-duty casting offers full
protection under extreme use.
Heavy-duty driveline with shear-bolt protects the unit when obstructions are encountered.
Replaceable 3/8" thick skid shoe for long life and uniform depth control.
Material control chute allows the operator to place material just outside the tractor path, or
as far away as the tiller will throw it. Control the throwing distance by raising or lowering the
chute with either a 2" x 8" hydraulic cylinder or ratchet jack.
16.5 x 6.50-8 Pneumatic gauge wheel keeps digging depth constant from just skimming
the ground to 10" deep.
For hard packed soils, the Shank rips up the ground just ahead of the impeller, allowing the
impeller to take in the soil vs. bouncing on hard packed soil. Shank has 3 height
adjustments from cutting edge depth to 5" below cutting edge.
Benefits
29
324-053F
