Land Pride Disc Harrows DH25 Datasheet

DH25
SERIES
40 - 100 HP — 72" 96"
• Cat. 1 & 2 hitch
• 20" or 22" Notched blades
• 3" Square frame tube
• 7-1/2" Blade spacing
• Angle front and rear gangs up to 21 degrees
• Adjustment handle to aid in angling
• 1/2" Thick bearing hangers with two 5/8" U-bolts
• Self aligning, sealed ball bearings
• 1-1/8" Square, high carbon steel gang axle
• 4" x 3" Gang tube
• Optional disc scrapers are adjustable
• Optional 9" center sweep shank
* Wider cutting may be obtained by adjusting
complete gang on gang tube. Adjusting too wide
can leave strip in center of unit. Center sweep can
help alleviate this.
Disc scrapers are
available to reduce
build-up on discs.
Heavy-duty 1/2" thick bearing
hangers resist the high torque
from two 5/8" U-bolts.
