Post Hole Digger Storage Stand
Assembly Instructions
For PD10, PD15, PD25 & PD35 Post Hole Diggers
20856
PD10 Storage Stand
Figure 1
Before You Start
When you see this symbol, the subsequent
!
instructions and warnings are serious - follow
them without exception. Your life and the lives of
others depend on it!
IMPORTANT: Before you begin, read these
instructions and check to be sure all parts and tools
are accounted for. Please retain these installation
instructions for future reference and parts ordering
information.
Your Storage Stand is exclusively designed for your
Land Pride PD10, PD15, DP25 & PD35 Post Hole
Diggers. Please read these installation instructions and
your Post Hole Digger Operator's Manual thoroughly
before beginning. Especially read information relating to
safety concerns. Also included in the Operator's Manual
is important information on operation, adjustment,
troubleshooting, and maintenance for this attachment
(some manual sections do not apply to all accessories).
A separate Parts Manual for your digger is available free
of charge at www.landpride.com or can be purchased
from your nearest Land Pride dealer. Have the model
and serial number of your Storage Stand handy when
placing an order.
Manual Part Numbers:
• Operator's Manual . . . . . . . . . . . . . . . . 317-048M
• Parts Manual . . . . . . . . . . . . . . . . . . . . . 317-048P
© Copyright 2008 Printed 10/06/08
Manual No. 317-189M
20776
PD15, 25, and 35 Storage Stand
Figure 2

General Information

These assembly instructions apply to the following
Storage Stand Accessories listed below:
317-166A PD10 Storage Stand
317-142A PD15, PD25, & PD35 Storage Stand

Tools required:

•
Safety glasses
•
Work gloves
•
Two 9/16" box end or open end wrenches
•
Two 3/4" box end or open end wrenches
Further Assistance
Your dealer wants you to be satisfied with your new
Mower Jack. If for any reason you do not understand any
part of this manual or are not satisfied with the service
received, the following actions are suggested:
1. Discuss the matter with your dealership service
manager. Make sure he has had time to assist you.
2. If you are still not satisfied, seek out the owner or
general manager and explain the problem.
3. For further assistance write to:
Land Pride Service Department
1525 East North Street
P.O. Box 5060
Salina, Ks. 67402-5060
E-mail address
lpservicedept@landpride.com
1
