  • Page 1 NTG-1 Instruction Manual www.rodemic.com ( EMC, LVD )
  • Page 2 The NTG-1 has many uses; It can be mounted on video cameras using either the on-board camera mic mounts or the optional shock mount. The NTG-1 is also suitable as a boom mounted mic for fi...
  • Page 3 Specifi cations Acoustic Line plus gradient Principle: Directional Super-Cardioid Pattern: (see graph) Frequency 20Hz ~ 20,000Hz Range: selectable HPF@80Hz/12dB octave (see graph) Output 50Ω Impedence: Sensitivity: -36dB re 1V/Pa @ 1kHz (15mV/Pa @ 94dB SPL) ±2dB @ 1kHz Equivalent Noise: 18dBA SPL (per IEC651) Maximum +6.9dBu...
  • Page 4 Specifi cations Frequency Response Polar Response – – – Accessories Stand mount Zip pouch Wind shield - 4 -...
  • Page 5 • Designed & manufactured in Australia • Full 10 year guarantee* Supplying Power • The NTG-1 requires power to operate. This needs to be supplied via P48V phantom power supply which is available from most professional video cameras or mixing consoles.
  • Page 6 Install as shown by pushing the mic in on an angle coming from the back. You will notice the holder is quite fi rm, and this is intentional so that the the NTG-1 will not come out easily, which could damage the mic. •...
  • Page 7 • The NTG-1 is supplied with a foam windshield. This windshield should be used even in the slightest breeze, as this can cause sound interference.
  • Page 8 Warranty microphones are warranted for one year from date of purchase. You can extend that to a full ten years if you register online at www.rodemic.com. The warranty covers parts and labour that may be required to repair the microphone during the warranty period.
