Rotary Cutters
RCB6010 & RCB6015 (540 RPM) and
RCMB6010 & RCMB6015 (1000 RPM)
Table of Contents
318-263M
Operator's Manual
!
Read the Operator's manual entirely. When
you see this symbol, the subsequent
instructions and warnings are serious - follow
without exception. Your life and the lives of
others depend on it!
© Copyright 2008 Printed
Cover photo may show optional equipment
not supplied with standard unit.
23584
9/04/08
