Baffle and Shredder Kits
For RC(M)5020 Rotary Cutters
Before You Start
When you see this symbol, the subsequent
!
instructions and warnings are serious - follow
without exception. Your life and the lives of
others depend on it!
IMPORTANT: Before you begin, read these
instructions and check to be sure all parts and tools
are accounted for. Please retain these installation
instructions for future reference and parts ordering
information.
The Baffle Kit and Shredder Kit are exclusively designed
for your 20' Land Pride Rotary Cutter. Please read these
installation instructions and your Rotary Cutter
Operator's Manual thoroughly before beginning.
Especially read information relating to safety concerns.
Also included in the Operator's Manual is important
information on operation, adjustment, troubleshooting,
and maintenance for this attachment (some manual
sections do not apply to all accessories).
A separate Rotary Cutter Parts Manual is available free
of charge at www.landpride.com or can be purchased
from your nearest Land Pride dealer. Have the model
and serial numbers of your cutter handy when placing an
order.
Manual Part Numbers:
• Operator's Manual . . . . . . . . . . . . . . . . . 318-474M
• Parts Manual . . . . . . . . . . . . . . . . . . . . . 318-474P
General Information
These assembly instructions apply to the Baffle and
Shredder Kits listed below:
330-309A SHREDDER/FIXED BLADE/BAFFLE
330-114A BAFFLES, FRONT
330-308A SHREDDER/FIXED BLADE
330-585A BAFFLES, REAR
Tools required:
•
Safety Glasses
•
Work Gloves
•
Two 3/4" wrenches . . . . . . . . . . . . . . . . . Baffle Kit Only
•
Two 1 1/2" wrenches . . . . . . . . . . . . Shredder Kit Only
•
One 55mm wrench . . . . . . . . . . . . . . Shredder Kit Only
© Copyright 2010 Printed
All manuals and user guides at all-guides.com
3/11/10
Further Assistance
Your dealer wants you to be satisfied with your new
Baffle and Shredder Kits. If for any reason you do not
understand any part of this manual or are not satisfied
with the service received, the following actions are
suggested:
1. Discuss the matter with your dealership service
manager making sure he is aware of any problems
you may have and that he has had the opportunity to
assist you.
2. If you are still not satisfied, seek out the owner or
general manager of the dealership, explain the
problem and request assistance.
3. For further assistance write to:
Land Pride Service Department
1525 East North Street
P.O. Box 5060
Salina, Ks. 67402-5060
E-mail address
lpservicedept@landpride.com
Safety Information
!
DANGER
Always disconnect main driveline from tractor PTO before
servicing cutter deck. Cutter can be engaged if tractor is
started resulting in cutter damage, bodily injury and/or death.
!
WARNING
Never work under equipment supported by hydraulics.
Hydraulics can drop equipment if controls are actuated or if
hydraulic lines burst. Either situation can drop the cutter
instantly even when power to the hydraulics is shut off.
Assembly Instructions
A detailed listing of parts for the Baffle and Shredder Kits
is provided on pages 10 & 11. Use the list as a checklist
to inventory parts received. Please contact your local
Land Pride dealer for any missing hardware.
IMPORTANT: Read all "Safety Information" above
before working on and around the cutter decks.
1. Cutters with Serial No. 536742 and lower:
Lower cutter and wings to the lowest position.
Cutters with Serial No. 536743 and above:
Raise wings fully up and lock into position with
transport locks.
Manual No. 330-148M
1
