Specifications

X-program
Number of channels
Power output, 4 ohm (0,1% THD)
Power output, 2 ohm (0,2% THD)
Power output 1 ohm
Power output, 4 ohm bridged
Signal to noise ratio, A-weighted
Damping factor
Frequency response
Input impedance, low level
Input impedance, high level
High level input with auto start
Line output (RCA)
Input sensitivity
Bass boost adjustable gain
Filter high pass /subsonic
Filter low pass
* can be switched in/out
Phase control 0-180 o cont.
Power consumption, idle
Fuse
Dimensions HxWxD(mm)
Dimensions (inch)
Weight
X-program
Number of channels
Power output, 4 ohm (0,1% THD)
Power output, 2 ohm (0,2% THD)
Power output, 4 ohm bridged
Power out mono sub ch. 4 ohm
Power out mono sub ch. 2 ohm
Signal to noise ratio, A-weighted
Damping factor
Frequency response
Input impedance, low level
Input impedance, high level
High level input with auto start
Line output (RCA)
Input sensitivity
Variable phase shift control
Filter high pass all channels
Filter low pass, all channels
Filter high pass front channels
Filter low pass, sub channel
Subsonic filter stereo channels
Subsonic filter mono channel
* can be switched in/out
Bass boost adjustable gain
Power consumption, idle
Fuse
Dimensions HxWxD(mm)
Dimensions (inch)
Weight
We follow a policy of continuous advancement in
development.
For this reason all or part of specifications & designs
may be changed without prior notice.
X-D10 X-D20
1 2
180 W 2 x 120 W
330 W 2 x 200 W
590 W
N/A 1 x 400 W
>95 dB >100 dB
>100 >100
15 Hz - 350 Hz 10 Hz - 35 kHz
33 kohm 33 kohm
1 kohm 1 kohm
Yes Yes
Yes Yes
0,3 - 6V 0,3 - 6V
0 - 18 dB 0 - 18 dB
built-in 15-150 Hz*
50-500 Hz 50-500 Hz*
Yes Yes
1,2 A 0,9 A
2 x 25 A 1 x 25 A
50x298x250 50x258x250
2x11,8x10 2x10,1x10
3,2 kg 2,8 kg
X-D30 X-D40
3 4
2 x 120 W 4 x 110 W
2 x 200 W 4 x 180 W
1 x 310 W 2 x 380 W
1 x 220 W N/A
1 x 330 W N/A
>100 dB >100 dB
>100 >100
10 Hz - 35 kHz 10 Hz - 35 kHz
33 kohm 33 kohm
1 kohm 1 kohm
Yes Yes
No No
0,3 - 6V 0,3 - 6V
0-180 degrees -
- 50 - 500 Hz*
- 50 - 500 Hz*
50 - 500 Hz -
30 - 150 Hz -
Fixed 25 Hz / 18 dB Fixed 25 Hz / 18 dB
Fixed 25 Hz* -
- 0 - 18 dB
1,8 A 1,6 A
2 x 25 A 2 x 25 A
50x338x250 50x318x250
2x13,3x10 2x12,5x10
4,1 kg 3,8 kg
X-D25
2
2 x 180 W
All above output power
2 x 280 W
ratings at 14,4 VDC
1 x 550 W
>100 dB
>100
10 Hz - 35 kHz
33 kohm
1 kohm
Yes
Yes
0,3 - 6V
0 - 18 dB
15-150 Hz*
50-500 Hz*
Yes
1,6 A
2 x 25 A
50x298x250
2x11,8x10
3,5 kg
15
