DLS BRXAMPEN Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

OWNERS MANUAL
CAR AUDIO AMPLIFIERS
DS 100
DQ 200
DLS Svenska AB
Box 13029
SE-402 51 Göteborg
Sweden
Phone +46 31 84 00 60
Fax +46 31 84 40 21
E-mail: info@dls.se
www.dls.se

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BRXAMPEN and is the answer not in the manual?

Questions and answers

Related Manuals for DLS BRXAMPEN

Summary of Contents for DLS BRXAMPEN

  • Page 1 OWNERS MANUAL CAR AUDIO AMPLIFIERS DS 100 DQ 200 DLS Svenska AB Box 13029 SE-402 51 Göteborg Sweden Phone +46 31 84 00 60 Fax +46 31 84 40 21 E-mail: info@dls.se www.dls.se...

  • Page 2: Table Of Contents

    Congratulations, you have just purchased the finest auto stereo amplifier that today´s technology can offer. DLS offers a series of high quality car audio products for real music lovers, and we are sure that you will enjoy a high class car sound for many years.

  • Page 3: General Product Information

    16 mm (5AWG). tests. Mount a fuse holder (DLS FH 1 or similar) on the DC Only the best components are used in this product. -cable near the positive battery terminal. Use the To ensure maximum performance and reliability,...

  • Page 4: Signal Cables

    SPEAKER LOADS Most car audio speakers have a 4 ohm impedance. 2.4 SPEAKER CONNECTION DLS amplifiers can be loaded down to 2 ohm on each stereo channel. The gold plated terminals will directly recieve In mono bridge mode operation the speaker load must speaker cables up to 6 mm (9AWG).

  • Page 5: Bridge Mode - Multimode Operation

    SPEAKER LOAD, BRIDGE MODE OPERATION SPEAKER CONNECTION EXAMPLES MULTIMODE OPERATION Multimode operation means that you connect one or two systems in normal stereo mode and then add TWO 4 OHM SPEAKERS IN PARALLEL. one or more subwoofers in mono bridge mode to the same speaker terminals.

  • Page 6: Passive Crossovers

    PASSIVE FILTERS, LEVEL SETTING, FINAL SYSTEM SETUP 2.6 PASSIVE CROSSOVERS 12 dB highpass crossover: For maximum use of the DLS amplifiers it´s useful to 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 know a little about passive crossover design.

  • Page 7: Internal Filters

    2. Check quality of earth strap connection from battery broken change to new ones with the sama value. negative terminal to chassis. If short circuiting continues, contact your local DLS dealer. A fault may exist in the amplifier. 3. Disconnect signal cables from amplifier to see if 5.

  • Page 8: Connection Diagrams Ds 100

    Make your own tests for best result. 5.1 One speaker pair connected in stereo. HP-filter LP-filter LP-filter LEVEL 2,5V You can use all DLS coaxial, 2-way or 3-way systems in this example. 5,5V 0,3V 200 50 200 The speaker impedance must be 4 ohm.
  • Page 9 CONNECTION DIAGRAMS DS 100 5.2 Two speaker pairs connected in parallel stereo HP-filter LP-filter LP-filter LEVEL 2,5V You can use all DLS coaxial, 2-way or 3-way 5,5V 0,3V 15 200 50 200 systems in this example. The speaker impedance must be 4 ohm.
  • Page 10 300 F capacitor in parallel with the subwoofer. The components used are shown in the drawing. The coil must have a low inner resistance to avoid losses. Use the DLS 10 mH, 0,47 ohm coil with art. no 10- 42310.

  • Page 11: Connection Diagrams Dq 200

    PROTECT POWER GND RMT BATT 25 A x 2 You can use all DLS coaxial, 2-way or 3-way speaker systems in this example. Speaker impedance must be 4 ohm. If the head unit has only one pre out a Y-cable Fuse must be used.
  • Page 12 CONNECTION DIAGRAMS DQ 200 6.2 Connection of a front system in stereo and a subwoofer in mono bridge mode. You can use all DLS coaxial, 2-way or 3-way speaker systems in this example. Speaker POWER INPUT FUSE impedance must be 4 ohm.
  • Page 13 300 F capacitor in parallel with the subwoofer. The components used are shown in the drawing. The coil must have a low inner resistance to avoid losses. Subwoofer Use the DLS 10 mH, 0,47 ohm coil with art. no 10-42310. 4 ohm - 12 -...
  • Page 14 CONNECTION DIAGRAMS DQ 200 6.4 Connection of a front systerm in stereo connected in bridge mode on all four channels. You can use all DLS coaxial, 2-way or 3-way speaker systems in this example. Speaker POWER INPUT FUSE PROTECT POWER impedance must be 4 ohm.
  • Page 15 CONNECTION DIAGRAMS DQ 200 6.5 Connection of a 3-way system using active crossover between woofer and midrange. You can use all DLS 3-way systems in this example. For example DLS R 36, R 38, U35 & U36. POWER INPUT FUSE PROTECT POWER...

  • Page 16: Specifications

    SPECIFICATIONS 7. SPECIFICATIONS FACTS ABOUT DLS AMPLIFIERS MODEL DS 100 DQ 200 Channels Mode Output power at 13,5 Volt, 20 Hz - 20 kHz with 0,1% THD max: 4 ohm nominal power RMS 2 x 50 Watts 4 x 50 Watts...

  • Page 17: For Your Own Notes

    FOR YOUR OWN NOTES Notes about the product: Model no:_________________________________ Serial number:_______________________________ Retailer:______________________________________________________________________________ Date of purchase: _________________________ Date of installation: ___________________________ Make your own installation notes about connections, crossover setup or just draw your own system schematic. - 16 -...
