Work Pro W4 PRO DMX User Manual

Hide thumbs Also See for W4 PRO DMX:
Table of Contents

Advertisement

Quick Links

English
USER'S MANUAL
POWER INPUT:
AC 230V~50Hz
FUSE:
F6.3A 250V 5x20mm
OUTPUT:
1.5A / Channel, 6A / Total.
FUSES
CAUTION
CH1
CH2
POWER INPUT:
AC 220V~50Hz
CHINA
FUSE:
F6.3A 250V 5x20mm
RISK OF ELECTRIC SHOCK
DISCONNECT INPUT POWER
OUTPUT:
5A /Channel, 20A / Total.
BEFORE OPENING
CH3
CH4
N'OUVREZ PAS..RISQUE DE CHOC ELECTRIQUE
FUSE(Internal): F0.315A 250V
WARNING: THIS APPARATUS MUST BE EARTHED
MADE IN PRC
24-005-0544
Please read before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W4 PRO DMX and is the answer not in the manual?

Questions and answers

Related Manuals for Work Pro W4 PRO DMX

Summary of Contents for Work Pro W4 PRO DMX

  • Page 1 English USER'S MANUAL POWER INPUT: AC 230V~50Hz FUSE: F6.3A 250V 5x20mm OUTPUT: 1.5A / Channel, 6A / Total. FUSES CAUTION POWER INPUT: AC 220V~50Hz CHINA FUSE: F6.3A 250V 5x20mm RISK OF ELECTRIC SHOCK DISCONNECT INPUT POWER OUTPUT: 5A /Channel, 20A / Total. BEFORE OPENING N'OUVREZ PAS..RISQUE DE CHOC ELECTRIQUE FUSE(Internal): F0.315A 250V...

  • Page 2: Table Of Contents

    Contents Features 1 General Instructions 2 1. Overview 3 2. Operation Guide 5 2.1 Mode Select 5 2.2 DMX Mode 5 2.3 Master Mode 6 2.3.1 Chase Mode 6 2.3.2 Channel Dimmer 7 2.4 Preset Functions 7 2.5 Chase Direction 9 2.6 Cross and Normal Dimmer 9 2.7 Initialization 10 Technical Specifications 11...

  • Page 3: Features

    Features Thank you for your purchase. This product features include: 4 channel chaser with 16 built-in programs 4 channel DMX dimmer pack with 4 individual DMX addresses Normal/Cross dimmer Forward/Reverse chasing direction Fade Time control Preheat function Manual override Built-in microphone for Music triggering Power failure memory...

  • Page 4: General Instructions

    General Instructions Read the instruction in this manual carefully and thoroughly , as they give important information regarding safety during use and maintenance. Keep this manual with the unit, in order to consult it in the future. If the unit is sold or given to another operator, make certain that it always has its manual, to enable the new owner to...

  • Page 5: Overview

    1. Overview POWER INPUT: AC 230V~50Hz FUSE: F6.3A 250V 5x20mm OUTPUT: 1.5A / Channel, 6A / Total. FUSES CAUTION POWER INPUT: AC 220V~50Hz CHINA FUSE: F6.3A 250V 5x20mm RISK OF ELECTRIC SHOCK DISCONNECT INPUT POWER OUTPUT: 5A /Channel, 20A / Total. BEFORE OPENING N'OUVREZ PAS..RISQUE DE CHOC ELECTRIQUE FUSE(Internal): F0.315A 250V...
  • Page 6 1. Overview Control this unit via these function buttons. 1. Control Board F6.3A 250V 5x20mm 2. Channel Fuse 1.5 A/CH., Total 6 A max.(CE) 3. Channel Output Connect to an appropriate power outlet. 4. Power Cable This connector sends DMX signal. 5.

  • Page 7: Operation Guide

    2. Operation Guide 2.1 Mode Select Press and hold down F button first, tap the Signal Select button causing the Segment Display shows "IN", DMX LED lights indicating DMX mode is active, this unit serves as a 4 channel DMX dimmer pack. While holding down F button, tap Signal Select button, when the Segment Display shows"OUT", Master LED lights indicating...

  • Page 8: Master Mode

    2. Operation Guide 2.2 DMX Mode 2. Tap the Up/Down button to select your desired DMX address from 001 to 512. 3. Once you've set the DMX address, tap the channel button a second time to store your setting into memory. 4.

  • Page 9: Channel Dimmer

    2. Operation Guide 2.3.2 Channel Dimmer 1. When Manual Dimmer mode is active, tap the channel button, the corresponding channel LED blinks indicating your selection and the Segment Display shows the intensity of last change. 2. Tap the Up/Down button to adjust the channel intensity.
  • Page 10 2. Operation Guide 2.4 Preset Functions Master The Segment Display shows "d" Dimmer followed by two numbers 00-FF. Tap Up/Down button to adjust intensity from fully off(00) to fully on(FF). Preheat The Segment Display shows "E" followed by two numbers 00-25. Tap Up/Down button to adjust from 0% intensity to 25% intensity.

  • Page 11: Chase Direction

    2. Operation Guide 2.5 Chase Direction Keep pressing F button, tap button to select chase direction, the Segment Display shows "L--" or "R--". "L--" indicates the programs will chase from left to right, and "R--" indicates the programs will chase from right to left. 2.6 Cross and Normal Dimmer Keep pressing F button, tap D/S button to select dimmer mode from Cross / Normal dimmer.

  • Page 12: Initialization

    2. Operation Guide 2.7 Initialization Press F, Signal Select and Reset buttons at a time, this unit will initialize its memory, the Segment Display shows "888". Release all three buttons, this unit will return to default setting, the Segment Display shows "IN", and Manual Dimmer LED lights.

  • Page 13: Technical Specifications

    3. Technical Specifications Power Input ............. AC 230V~50Hz (CE) Channel Output .......... 1.5A/CH., Total 6A (CE) Channel Fuse ..........F6.3A 250V 5x20mm DMX In/Outt ......3 pin female & male XLR socket x1 Dimensions ............1320x78x78mm Weight(appro.) ................ 4.0 kg...
  • Page 14 Equipson, S.A. www.equipson.es support@equipson.es...
