- Page 1 Automatic Blood Pressure Monitor Gebrauchsanweisung Instruction manual Mode d’emploi Gebruiksaanwijzing closing date: july 2003 © by ibp innovative business promotion gmbh, Germany...
-
Page 3: Table Of Contents
table of contents 1 introduction ....................... 2 preliminary remarks ....................3 about blood pressure 3.1 blood pressure values ..................3.2 measures affecting your blood pressure positively ..........3.3 how to obtain accurate readings ................. 4 the unit / accessories ....................5 display / symbols ...................... -
Page 4: Introduction
1 introduction dear customer, we are glad that you have decided for this blood pressure monitor. The product you have bought is state of the art, of highest quality and has many advanced features. This unit measures blood pressure at the wrist extremely accurately and is ideal for regular monitoring of blood pressure. With a memory that can store up to 60 values, you can keep close track of your heart rate and inform your physician of any significant changes as early as possible. -
Page 5: Preliminary Remarks 2
It also confirms with the EU Council Directive “93/42/EEC of 14th June 1993 on Medical Products“. ibp hereby confirms that the product delivered together with this Instruction Manual complies with this Directive. The appropriate conformity declaration is available with ibp. -
Page 6: About Blood Pressure
3 about blood pressure More than half the number of people suffering from high blood pressure are unaware of it. The most common cause of death in today's society is from diseases that are directly related to the problem of high blood pressure. This Blood Pressure Monitor allows you to measure your blood pressure at home. - Page 7 about blood pressure 3 Remember that only the physician can interpret your blood pressure values. Never venture self- diagnosis or self-treatment. We recommend you to discuss your blood pressure values with your physician. He can advise you on any measures that may be good to take. blood pressure mmHg...
-
Page 8: Measures Affecting Your Blood Pressure Positively
3 about blood pressure 3.2 measures affecting your blood pressure positively If your blood pressure is high or you want to avoid high blood pressure, your lifestyle should generally be conducive to this goal. Existing diseases: Strictly follow the instructions of your doctor to treat existing diseases e.g., diabetes, gout, disturbed lipid metabolism, etc.. - Page 9 about blood pressure 3 Here are a few helpful tips to obtain accurate readings: Wait one hour before measuring the blood pressure after a substantial meal. Do not smoke or drink alcohol before measuring the blood pressure. You should not do physical work one hour before taking a reading. It is important that you relax.
-
Page 10: The Unit / Accessories
4 the unit - accessories identification accessories of the unit included : keeping box display (without ill.) Memory key Battery cover instruction Memory Timer key polling key manual including warranty ON/OFF key Start key batteries Wrist cuff 2 “AAA” size 1,5 V alkaline batteries... -
Page 11: Display / Symbols 5
display / symbols 5 display symbols month hour minute The memory sign appears when you save data to the memory and during memory polling. mmHg systolic pressure The pump sign appears when you inflate the cuff. When this sign appears the diastolic batteries should be replaced. -
Page 12: Befoe Using The Device
6 before using the device 6.1 battery installation battery replacement The enclosed batteries must be fitted before use. The battery cover is on the left-hand side of the unit. Push it in the arrowed direction and remove it. Insert the 2 supplied “AAA“ size, 1.5 V alkaline batteries. -
Page 13: Setting The Timer
before using the device 6 6.2 setting the timer To enter the timer mode, press the TIMER key longer than 3 seconds and release it. The year number flashes. To increment the flashing digit, press the MEMO/+ key; to decrement, press the RCAL/- key. Press the TIMER key. -
Page 14: Making A Blood Pressure Measurement
7 making a blood pressure measurement 7.1 attaching the wrist cuff fig. 1 Remove the wristwatch and all jewelry. Put the blood pressure monitor on the inside of your left wrist (fig. 1). Place the cuff around your wrist, make sure that the bottom fig. - Page 15 making a blood pressure measurement 7 Hold the bottom part of the wrist cuff as illustrated in fig. 3. fig. 3 Pull the cuff tight and wrap it upwards so that there is no gap between the cuff and your wrist. While you wrap the cuff upwards, hold the cuff cover with your thumb.
-
Page 16: The Measuring Accuracy
7 making a blood pressure measurement 7.2 the measuring accuracy The new stepping valves mean a dramatic improvement of the measuring accuracy. Your new wrist blood pressure monitor is equipped with state-of-the-art valve technology for extreme accuracy. The mechanical valves have been replaced by electronic valves so that the user can recognize even small pressure changes and compensate them by means of the cuff pressure. -
Page 17: The Right Measuring Position
making a blood pressure measurement 7 7.3 the right measuring position measure values: 1 to low 2 correct Have yourself on a seat in a comfortable position, breathe 3 to high deeply several times and relax. Measure the blood pressure the same time every day. To get a correct picture of the blood pressure changes during the day, make the measurements at home daily at the same time. -
Page 18: The Measuring Method
7 making a blood pressure measurement 7.4 the measuring method Place the cuff around your arm as described (pages 12 - 13). mmHg Start the Monitor by pressing one of the ON /OFF (POWER) key. When the ON /OFF (POWER) key is pressed, all digits will light up (fig. - Page 19 making a blood pressure measurement 7 Press the START key. The pump begins to inflate the cuff automatically. The pump icon displays during the inflation procedure. If the cuff pressure is low, the unit interrupts the measuring and increases the cuff pressure to an acceptable level.
-
Page 20: Switching Off Automatically
7 making a blood pressure measurement The cuff will deflate when the unit completes the measuring. The LCD then shows the systolic and diastolic pressures, and the pulse rate. mmHg 7.5 switching off automatically Pressing the ON /OFF (POWER) key ends the measuring and turns off the power. -
Page 21: The Memory Function 8
the memory function 8 Up to 60 measurements can be saved in the memory. The values (blood pressure and pulse rate) can be saved in the memory of the unit, together with the time and date. Just press the MEMORY key while the values are shown on the mmHg LCD. -
Page 22: An Error Is Displayed
9 an error is displayed Error display Possible reason Remedy The cuff position is not correct. Put on the cuff correctly. The unit interrupts the measuring Do not move and increases the cuff pressure. while the measuring You have moved during continues. -
Page 23: Other Important Notes 10
other important notes 10 The unit contains high-precision assemblies. Therefore avoid extreme temperatures, humidity, direct sunlight. Do not give strong shock. Do not try to open the blood pressure monitor. This will destroy the calibrated factory settings. Protect from ingress of dust. Do not bend the preformed cuff inside out. -
Page 24: Specifications
11 specifications Model : ibp A 40 Measuring method : Oscillometric method Indicator : LCD Measuring range : 20 - 280 mmHg (blood pressure) : 40 - 180 pulse/min. (pulse rate) Measuring resolution : ± 3 mm Hg (blood pressure) : ±... -
Page 25: Guarantee
International Business Products Limited 6 Newfield Court West Houghton Bolton BL5 3SA England Phone: +44 -(0) 19 42- 81 96 95 Distributed by: ibp gmbh, Head Office, Botzstraße 6, D-07743 Jena, Germany www.ibp-info.de Manufactured by: Rossmax ® International Ltd., Taipei, Taiwan...
