  • Page 1 INSTRUCTION HANDBOOK...
  • Page 2 Legal Restriction On Copying...
  • Page 3 Please read the instruction handbook before using the copier. Keep it in the des- ignated location for easy reference. The sections of this handbook and parts of the copier marked with symbols are safety warnings meant to protect the user, other individuals and surrounding objects, and ensure correct and safe usage of the copier.

  • Page 4: Table Of Contents

    Finisher (Optional) ... 2-17 Paper Feed Unit (Optional)... 2-18 Large-Capacity Cabinet (Optional) ... 2-19 Printer Controller FIERY X3e ... 2-19 Names of Control Panel Parts and Their Functions... 2-20 Names of Control Panel Parts and Their Functions ... 2-20 Using the Touch Panel... 2-22 Description of Touch Panel ...
  • Page 5 To enter an access code...2-28 Printing From the Computer...2-28 Scanning From the Computer ...2-28 Power Switch and Default Settings ...2-29 Turning the copier on and off ...2-29 To turn the copier on ...2-29 To turn the copier off ...2-29 Turning On the Copier...2-30 Default Settings...2-30 Copy Paper Paper Specifications...3-1...
  • Page 6 Positioning the Document on the Original Glass... 4-10 Manual Feeding (Sheet Documents)... 4-11 To make copies using manual feeding (sheet documents) ... 4-11 Manual Feeding (Transparent or Translucent Documents) ... 4-12 To make copies using manual feeding (transparent or translucent documents)...
  • Page 7 Double-Sided Ö Single-Sided: ...6-2 Double-Sided Ö Double-Sided:...6-2 Book (Separation) Ö Single-Sided: ...6-2 Book (Spread) Ö Single-Sided:...6-3 Book (either Standard Book or RightBound) Ö Book Erase: ...6-3 To make settings for single- or double-sided documents and copies...6-4 To make settings for copying a book ...6-5 Finishing (“Sort”...
  • Page 8 6.10 Specifying Different Vertical and Horizontal Scaling Proportions (“X/Y Zoom” Function) ... 6-32 To specify the vertical and horizontal scaling proportions ... 6-32 6.11 Reducing the Document to Postcard Size and Printing Multiple Copies on One Page (“Postcard” Function) ... 6-33 To set the “Postcard”...
  • Page 9 Adjusting the Gradation Levels (“Gradation Adjust” Function)...8-13 To adjust the gradation levels ...8-13 Turning off the Sleep function (“Disable Sleep Mode” Function)...8-15 To turn off the Sleep function ...8-15 Erasing Copy Edges (“Erase” Function) ...8-18 To set the “Erase” function...8-18 Specifying the Expert Settings (“Expert User’s Mode”...
  • Page 10 10.2 When the Copier Is Not Operating Correctly ... 10-3 11 Appendix 11.1 Specifications ... 11-1 Copier KM-C1530... 11-1 Duplexing Document Feeder RADF-11... 11-3 500-sheet Paper Feed Unit ST-530... 11-3 Large-capacity Cabinet ST-2500... 11-4 Duplex Unit AD-35... 11-4 10-Mailbin Sorter AS-M4110 ... 11-5 Finisher F-8430 ...

  • Page 11: Important! Please Read First

    IMPORTANT! PLEASE READ FIRST CAUTION LABELS Caution labels have been attached to the copier at the following locations for safety purposes. BE SUFFICIENTLY CAREFUL to avoid fire or electric shock when removing a paper jam or when replacing toner. KM-C1530...

  • Page 12: Km-C1530

    IMPORTANT! PLEASE READ FIRST KM-C1530...
  • Page 13 IMPORTANT! PLEASE READ FIRST KM-C1530...

  • Page 14: Installation Precautions

    IMPORTANT! PLEASE READ FIRST 55 (1,397) 20 (510) 31 (787) 8-1/4 (210) (100) Unit: inch (mm) KM-C1530...
  • Page 15 Handling of plastic bags WARNING • Keep the plastic bags that are used with the copier away from children. The plastic may cling to their nose and mouth causing suffocation... KM-C1530...

  • Page 16: Precautions For Use

    Then contact your service representative..• DO NOT remove or connect the power plug with wet hands, as there is a danger of electrical shock..• ALWAYS contact your service representative for maintenance or repair of internal parts... IMPORTANT! PLEASE READ FIRST KM-C1530...
  • Page 17 To maintain the appropriate environment for copy work, it is suggested that the room be properly ventilated. KM-C1530...
  • Page 18 • Store consumables in a cool, dark location. • If the copier will not be used for an extended period of time, remove the paper from the cassette, return it to its original package and reseal IMPORTANT! PLEASE READ FIRST KM-C1530...
  • Page 19 This device must be used with shielded interface (Parallel) cable and shielded network (10/100Base-T) cable. The use of non-shield cables is likely to result in interference with radio communications and is prohibited under CISPR 22 and local rules. KM-C1530...
  • Page 20 CAUTION Install this machine so that it can quickly be unplugged from the electrical outlet in case of an emergency. § The socket-outlet shall be installed near the machine and shall be easily accessible. 1-10 IMPORTANT! PLEASE READ FIRST KM-C1530...

  • Page 21: Led Radiation Safety

    During copying, paper is supplied from the right side of the copier and fed into the copy tray on the top or the output option at the left with the printed surface of the copy facing down. The paper feed direction is shown by the arrows in the diagram below. KM-C1530 1-11...

  • Page 22: Width" And "Length

    The icons shown below are displayed when the corresponding paper is loaded or copy is made. : Overhead projector transparencies : Thick paper 1 : Second side of a double-sided copy : Second side of a double-sided copy on thick paper 1-12 IMPORTANT! PLEASE READ FIRST KM-C1530...

  • Page 23: Before Making Copies

    The main copy settings available with this copier are listed below. For details on their operation, refer to the pages indicated. Orig. Ö Copy (Refer to page 6-1.) Single-Sided Ö Single-Sided Single-Sided Ö Double-Sided Double-Sided Ö Single-Sided Double-Sided Ö Double-Sided Single-Sided Ö Single–2in1 KM-C1530...
  • Page 24 The “Double-Sided” and the “Double–2in1” Copy settings are only available if the duplex unit and the memory are installed. Zoom settings (Refer to page 5-14.) Reduced/Full Size/Enlarged Finishing (Refer to page 6-8, page 6-12, and page 6-15.) “Sort” setting Before Making Copies KM-C1530...
  • Page 25 The “Sort” and “Group” settings are only available if the 10-mailbin sorter is installed. The “Staple” and “Hole-Punch” settings are only available if both the finisher and the printer controller are installed, and the print job is sent from the computer. KM-C1530...
  • Page 26 Applications “OHP Interleaving” function (Refer to page 6-30.) “Frame Erase” function (Refer to page 6-19.) “Mirror Image” function (Refer to page 6-21.) “X/Y Zoom” function (Refer to page 6-32.) “Postcard” function (Refer to page 6-33.) Before Making Copies KM-C1530...
  • Page 27 The “X/Y Zoom”, “Postcard” and “Image Repeat” functions are only available if the memory is installed. “Mixed Orig Detection” function (Refer to page 6-17.) Mixed originals Note The “Mixed Orig Detection” function is only available if the duplexing document feeder is installed. KM-C1530...

  • Page 28: Components And Their Functions

    Original cover PLATEN COVER TYPE C(optional) Presses down on the loaded document Duplexing document feeder RADF- 11 (optional) Automatically feeds and scans one document sheet at a time, and automatically turns over double- sided documents and scans them Before Making Copies KM-C1530...
  • Page 29 When printing from the computer, finishes pages according to the mode (sorting, grouping, stapling or hole-punching) selected at the computer, then feeds out the pages Duplex unit AD-35 (optional) Automatically turns over copies, allowing double-sided copies to be made KM-C1530...
  • Page 30 (AS-M4110) or an optional finisher (F-8110/F-8430) is installed without an optional paper feed unit Copy table (optional) Used when the optional 10-mailbin sorter (AS-M4110) or an optional finisher (F-8110/F-8430) is installed with two optional paper feed units installed Before Making Copies KM-C1530...
  • Page 31 Before Making Copies Printer controller FIERY X3e (optional) Internal printer controller that allows the copier to be used as both a color printer and a color scanner on a network Memory (256 MB: 128 MB × 2) (recommended with KM-C1530)

  • Page 32: Parts Names And Their Functions

    Parts Names and Their Functions Outside of Copier 2-10 Before Making Copies KM-C1530...
  • Page 33 Scanner power cord socket (outlet) Scanner connector Printer power cord socket Sorter/finisher connector KM-C1530 Description Holds copies fed out of the copier Opened when adding toner Opened when replacing the imaging unit See p. 9-43. Holds 250 sheets of paper The paper size can be adjusted freely.

  • Page 34: Inside Of Copier

    Imaging unit removing bracket Upper right-side door 2-12 Before Making Copies Description Opened when adding toner Used to install and replace the imaging unit Used to remove the imaging unit Opened when replacing the fusing unit or clearing misfeeds KM-C1530...

  • Page 35: Supplies And Parts

    Oil-coating unit Fusing web unit Fusing unit Ozone filter LED cleaning tool KM-C1530 Description Generates the copied image Layers onto the image transfer belt each of the single colors of the image generated by the imaging unit in order to create a full-color image...

  • Page 36: Duplexing Document Feeder (Optional)

    See p. 4-4. Load the documents to be copied face up. See p. 4-4. Opened when clearing a misfed document Open to feed one sheet of the document at a time KM-C1530...

  • Page 37: Duplex Unit (Optional)

    Before Making Copies Duplex Unit (Optional) Part Name Duplex unit door KM-C1530 Description Opened when clearing paper misfed within the duplex unit 2-15...

  • Page 38: 10-Mailbin Sorter (Optional)

    Horizontal transport unit cover 2-16 Before Making Copies Description Collects copies that are sorted Opened when clearing paper misfed within the sorter Transports copies to the sorter or finisher Opened when clearing paper misfed within the horizontal transport unit KM-C1530...

  • Page 39: Finisher (Optional)

    Lower paper output tray Front door Right-side door (Finisher F-8430 only) KM-C1530 Description Opened when clearing paper misfed within the finisher Collects copies that are not sorted (made with the “Non- Sort” setting) Collects copies that are sorted Opened when clearing paper misfed within the finisher...

  • Page 40: Paper Feed Unit (Optional)

    Paper Feed Unit (Optional) Part Name 3rd drawer 4th drawer 2-18 Before Making Copies Description Holds 500 sheets of paper The paper size can be adjusted freely. As many as two units can be installed. See p. 3-13. KM-C1530...

  • Page 41: Large-Capacity Cabinet (Optional)

    Before Making Copies Large-Capacity Cabinet (Optional) Part Name 3rd drawer Printer Controller FIERY X3e For more details, refer to the manual of the printer controller. KM-C1530 Description Holds 2,500 sheets of paper See p. 3-15. 2-19...

  • Page 42: Names Of Control Panel Parts And Their Functions

    • Full Color: The copier makes a full-color copy of the document. • Black: The copier makes a black-and-white copy regardless of the color of the document. Before Making Copies KM-C1530...
  • Page 43 Energy Saver key Access key Copy key Scan key Keypad KM-C1530 Description • Press to start the copy operation. • If this key is pressed while the copier is warming up, the copy job is delayed until the copier is finished warming up.

  • Page 44: Using The Touch Panel

    Note The screen illustrations in this manual may be slightly different from the screens that appear on your copier’s touch panel. Organization of Screens 2-22 Before Making Copies Screen tabs Message display Available functions/settings Selected settings KM-C1530...
  • Page 45 Screen tabs Message display Available functions/ settings Selected settings KM-C1530 Description These are the tabs for the Basic, Orig. Ö Copy, Finishing, and Auxiliary screens. Touch a tab to display the corresponding screen. Example) The Auxiliary screen is selected above.

  • Page 46: Operating The Touch Panel

    CAUTION Be careful not to damage the touch panel. § Never push on the touch panel, and never push on it using a hard or pointed object. 2-24 Before Making Copies KM-C1530...

  • Page 47: Useful Operations

    The length of time until the copier automatically resets itself can be set between 1 and 9 minutes. The “Auto Panel Reset” parameter can even be turned off. For more details, refer to “Specifying Default Settings (“User’s Choice” Function)” on page 7-8 and page 7-15. KM-C1530 2-25...

  • Page 48: Energy Saver Mode

    Sleep Mode When the printer controller is not installed: If the copier is not used for a set length of time, it can automatically turn itself off in order to save energy. The default length of time is 30 minutes.

  • Page 49: Interrupting Copy Jobs

    If the large-capacity cabinet (ST-2500) is also installed, up to 3,250 sheets of “LetterC” paper can be fed continuously. KM-C1530 2-27...

  • Page 50: Access Codes

    After you are finished making your copies, press the [Access] key. Printing From the Computer If the optional printer controller is installed, the copier can be used as an 11 × 17 in. full-color printer configured into a computer network.

  • Page 51: Power Switch And Default Settings

    OFF (O). If it will not be used for an ex- tended period of time (vacations, etc.), remove the power plug from the outlet for safety purposes during the time the copier is not in use. KM-C1530 2-29...

  • Page 52: Turning On The Copier

    Number of copies: 1 Original Image Type: Text&Photo Zoom: Full Size (×1.000) Paper: Auto Paper Orig. Ö Copy: Single-Sided Ö Single-Sided Finishing: Non-Sort The default settings can be customized using the “User’s Choice” function. (Refer to page 7-1.) 2-30 Before Making Copies KM-C1530...

  • Page 53: Copy Paper

    2: If the optional duplex unit is used to make double-sided copies, only certain types of paper can be used. 3: If the optional 10-mailbin sorter is used to sort or group copies, only certain types of paper can be used. KM-C1530 Special Paper Thick Thick...

  • Page 54: Paper Sizes

    — Executi LetterC LegalL — — — — Copy Paper Paper Length 5-1/2 in. to 18 in. (140 mm to 457 mm) — — Executi 12-1/4 11 × 17 × 18L — — — — — — — — KM-C1530...
  • Page 55 3: If the optional 10-mailbin sorter is used to sort or group copies, only certain types of paper can be used. 4: The size should be entered using the “User’s Choice” function. 5: The paper size should be changed by your service representative. KM-C1530 8-1/4 × 8-1/2 × 8-3/4 ×...

  • Page 56: Recommended Paper

    Recommended Paper Hammermill Laser Print New Radiant White 24 lbs. Hammermill tidal DP NS 700 NS 1000C V558 JE001 Copy Paper Overhead Projector Postcards Transpare ncies 1 sheet 1 sheet 20 sheets 20 sheets — — — — — — KM-C1530...

  • Page 57: Paper Types To Be Avoided

    Overhead transparencies that have already been fed through the copier (even if the transparency is still blank) Paper that has been printed on by a heat-transfer printer or an inkjet printer Paper that is either extremely thick or extremely thin...

  • Page 58: Print Area

    A margin 0.12 in. (3 mm) on both sides of the paper (C) When using the printer controller to print from a computer, the image cannot be printed within the area 0.2 in. (5 mm) from all edges of the paper.

  • Page 59: Loading Paper

    Slide the lateral guides to fit the size of paper to be loaded. For paper of a non-standard size, first load the paper, and then adjust the lateral guides to the size of the loaded paper. KM-C1530 Paper take- up roller...
  • Page 60 § We recommend replenishing the paper only after all of the paper in the drawer has been used. Copy Paper KM-C1530...
  • Page 61 § When loading postcards, load them as shown. § Do not load postcards cross- wise, as shown. Are the recommended overhead projector transparencies loaded? § When loading the recommended overhead projector transparencies, load them as shown in the illustration. KM-C1530...
  • Page 62 Setting the Paper Size The default setting for the paper size of the 1st drawer is “Auto Detect”. For postcards, non-standard or metric paper sizes, change the paper size according to the procedure in the following section. 3-10 Copy Paper KM-C1530...

  • Page 63: To Set The Paper Size For The 1St Drawer

    Copy Paper To set the paper size for the 1st drawer Press the [Utility] key to enter Utility mode. Touch [User’s Choice]. Touch [2/2] to view the next page. Touch [1st Drawer Paper Select]. KM-C1530 3-11...
  • Page 64 [Custom Size], touch to specify the desired size, and then touch [Enter]. In the Input Size screen, touch [Enter]. In the 1st Drawer Paper Size screen, touch [Enter]. In the User’s Choice screen, touch [Exit]. 3-12 , and Copy Paper KM-C1530...

  • Page 65: To Load Paper Into The 2Nd Drawer Or The 500-Sheet Paper Feed Unit

    Remove the trailing-edge guide, and then re-install it for the size of paper to be loaded. Slide the lateral guides to fit the size of paper to be loaded. KM-C1530 Paper take- up roller 3-13...
  • Page 66 Slide the lateral guides against the edges of the paper. Make sure that the paper is not curled when it is loaded. Check that the lateral guides are pushed up against the edges of the paper. Close the paper drawer. 3-14 Copy Paper KM-C1530...

  • Page 67: To Load Paper Into The Large-Capacity Cabinet

    § We recommend replenishing the paper only after all of the paper in the drawer has been used. KM-C1530 3-15...
  • Page 68 § We recommend replenishing the paper only after all of the paper in the drawer has been used. Close the paper drawer. 3-16 Copy Paper KM-C1530...

  • Page 69: To Load Paper Into The Manual Bypass Tray

    § Feed only one sheet of paper at a time. § Copies will be made on the surface of the paper facing down when it is loaded into the manual bypass tray. KM-C1530 3-17...
  • Page 70 When loading a postcard, load it as shown. § Do not load the postcard crosswise, as shown. Is the recommended overhead projector transparency loaded? § When loading the recommended overhead projector transparency, load it as shown in the illustration. 3-18 Copy Paper KM-C1530...
  • Page 71 Do you wish to specify a non-standard paper size? § Touch touch [Enter]. Touch [Paper Type], select the setting for the type of paper loaded, and then touch [Enter]. KM-C1530 , and to select the desired size, and then 3-19...
  • Page 72 Copy Paper 3-20 KM-C1530...

  • Page 73: Original Documents

    Document Feed Method Multi-sheet feeding Single-sheet feeding Manual feeding KM-C1530 Features Using the duplexing document feeder, a multi-page document can be fed automatically. This feed method can also be used with double-sided documents, and is best with multi-page double-sided documents.

  • Page 74: Document Paper Types

    Document width: 5-1/2 in. to 11- 3/4 in. Document length: 8-1/4 in. to 17 Document width: 5-1/2 in. to 11- 3/4 in. Document length: 8-1/4 in. to 17 Document width: Less than 11-3/ 4 in. Document length: Less than 17 KM-C1530...

  • Page 75: Precautions For Manual Feeding

    Scan without closing the original cover or duplexing document feeder. In addition, do not press down extremely hard on the document, otherwise the copier may be damaged. (The original glass can only resist a weight of up to 4-1/2 lbs.) KM-C1530...

  • Page 76: Feeding The Document Through The Duplexing Document Feeder

    Be sure to adjust the paper guide to the size of the document, otherwise the documents may not be fed in straight. Slide the adjustable document guide to fit the size of the documents. Load the documents face up into the document feed tray. Original Documents KM-C1530...

  • Page 77: Multi-Sheet Feeding (Documents Of Mixed Sizes)

    Multi-Sheet Feeding (Documents of Mixed Sizes) With this feature, a stack of documents of different sizes can be copied as a set using the duplexing document feeder. (For more details, refer to “Feeding Documents of Different Sizes (“Mixed Orig Detection” Function)” on page 6-17.) KM-C1530...

  • Page 78: To Make Copies Using Multi-Sheet Feeding (Documents Of Mixed Sizes)

    Slide the adjustable document guide to the edge of the largest document. Press the [Start] key to start feeding and copying the documents from the top page. Original Documents KM-C1530...

  • Page 79: Single-Sheet Feeding (Standard Paper/Thick Paper)

    Zoom setting and the number of copies). Do you need more information about the settings? § Refer to “5 Basic Operations” and “6 Advanced Operations”. Open the single-sheet feed tray, and then slide the adjustable document guide to fit the size of the document. KM-C1530...
  • Page 80 Insert the document pages one at a time. § Be sure the documents are not folded or curled when they are fed. Make sure the indicator on the [Start] key lights up in green before feeding the next page of the document. Original Documents KM-C1530...

  • Page 81: Single-Sheet Feeding (Thin Paper)

    (such as the zoom ratio and the number of copies). For more details, refer to “5 Basic Operations” and “6 Advanced Operations”. Continue with steps 2 through 4 of “Single-Sheet Feeding (Standard Paper/Thick Paper)” on page 4-7. KM-C1530...

  • Page 82: Positioning The Document On The Original Glass

    15° or more, otherwise the document size will not be detected and the correct paper size or zoom ratio may not be selected automatically. CAUTION DO NOT leave the document feeder open as there is a danger of personal injury. 4-10 Original Documents KM-C1530...

  • Page 83: Manual Feeding (Sheet Documents)

    Close the original cover, or the duplexing document feeder if it is installed. Select the desired settings. Do you need more information about the settings? § Refer to “5 Basic Operations” and “6 Advanced Operations”. Press the [Start] key to copy the document. KM-C1530 4-11...

  • Page 84: Manual Feeding (Transparent Or Translucent Documents)

    Place a blank sheet of paper of the same size as the document over the document. Close the original cover, or the duplexing document feeder if it is installed. 4-12 Original Documents KM-C1530...

  • Page 85: Manual Feeding (Books)

    Close the original cover, or the duplexing document feeder if it is installed. Is a thick book or object being copied? § Make the copy without closing the original cover or duplexing document feeder. KM-C1530 ) on the 4-13...

  • Page 86: Manual Feeding ("12-1/4 × 18" Paper)

    “12-1/4 × 18” mark on the top document width scale as shown in the illustration. Close the original cover, or the duplexing document feeder if it is installed. 4-14 Original Documents KM-C1530...
  • Page 87 Original Documents Select the desired settings. Do you need more information about the settings? § Refer to “5 Basic Operations” and “6 Advanced Operations”. Press the [Start] key to copy the document. KM-C1530 4-15...
  • Page 88 Original Documents 4-16 KM-C1530...

  • Page 89: Basic Operations

    Type set to “Text&Photo”, Zoom set to “×1.000”, Paper set to “Auto Paper”, and the number of copies set to “1”. Press the [Copy] key to enter Copy mode. Position the document(s) to be copied. (Refer to page 4-1 for more details.) KM-C1530...
  • Page 90 Does the wrong number of copies appear? § Press the [C] (clear) key, and then enter the correct number of copies. § The number of copies can only be set to a number between 1 and 100. Basic Operations KM-C1530...
  • Page 91 Basic Operations Press the [Start] key. The set number of copies are made. Do you wish to stop copying before the set number of copies are made? § Press the [Stop] key. KM-C1530...

  • Page 92: Selecting The Paper Source

    Original Image Type (Refer to page page 5-18 for more details.) Density (Refer to page 5-20 for more details.) Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. Basic Operations KM-C1530...

  • Page 93: Making Copies On Paper Loaded Into The 1St Drawer (Multipurpose Paper Drawer)

    Paper types: Standard paper (thickness: 17 to 24 lbs.) Thick paper 1 (thickness: 24-1/4 to 43-1/4 lbs.) Overhead projector transparencies Second side of a double-sided copy on standard paper Second side of a double-sided copy on thick paper 1 KM-C1530...

  • Page 94: To Copy A Document

    Zoom (Refer to page 5-14 for more details.) Original Image Type (Refer to page 5-18 for more details.) Density (Refer to page 5-20 for more details.) Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. Basic Operations KM-C1530...

  • Page 95: Feeding Paper Manually

    Minimum size: 3-9/16 × 5-1/2 in. (90 × 140 mm) To feed the paper manually Position the document(s) to be copied. (Refer to page 4-1 for more details.) Select the desired color mode. (Refer to page 2-20 for more details.) Open the manual bypass tray. KM-C1530...
  • Page 96 Copies can also be made by loading paper into the manual bypass tray after selecting the paper size by touching [Paper] in the Basic screen, then touching [Bypass]. , and until the cursor moves below the fraction that Basic Operations KM-C1530...

  • Page 97: To Make Copies Onto Overhead Projector Transparencies

    Position the document(s) to be copied. (Refer to page 4-1 for more details.) Select the desired color mode. (Refer to page 2-20 for more details.) Open the manual bypass tray. KM-C1530...
  • Page 98 [Enter]. Specify any other necessary settings. Zoom (Refer to page 5-14 for more details.) Original Image Type (Refer to page 5-18 for more details.) Density (Refer to page 5-20 for more details.) Press the [Start] key. 5-10 Basic Operations KM-C1530...

  • Page 99: To Make Copies Onto Postcards

    [4 × 6]. The “Paper Type” setting automatically changes to “Thick Paper 2”. (* Setting the paper size for the manual bypass tray to “4 × 6” automatically changes the “Paper Type” setting to “Thick Paper 2”.) KM-C1530 5-11...

  • Page 100: To Make Copies Onto Thick Paper

    Make sure that the screen that allows you to select the manual bypass tray paper size is displayed, check that the desired paper size is selected, and then touch [Paper Type]. 5-12 Basic Operations KM-C1530...
  • Page 101 [Enter]. Specify any other necessary settings. Zoom (Refer to page 5-14 for more details.) Original Image Type (Refer to page 5-18 for more details.) Density (Refer to page 5-20 for more details.) Press the [Start] key. KM-C1530 5-13...

  • Page 102: Specifying A Zoom Setting

    0.001 increments. Keep touching the arrow to change the zoom ratio more quickly. This setting makes a copy the same size as the document (×1.000). With this setting, the keypad can be used to enter a zoom ratio. Basic Operations KM-C1530...

  • Page 103: To Specify The Zoom Ratio Before Copying

    Original Image Type (Refer to page 5-18 for more details.) Density (Refer to page 5-20 for more details.) Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. KM-C1530 to select 5-15...

  • Page 104: To Record A Zoom Ratio

    Do you know what is the range for the “Minimal” zoom ratio? § The zoom ratio of the “Minimal” setting can be set between × 0.900 and × 0.999. Touch [Enter]. 5-16 Basic Operations KM-C1530...

  • Page 105: To Recall A Recorded Zoom Ratio

    The recorded zoom ratios can be recalled whenever they are needed. In the screen that allows you to select the zoom ratio, touch [CustomZoom]. Touch the zoom ratio that you wish to recall (“1”, “2” or “Minimal”). Touch [Enter]. KM-C1530 5-17...

  • Page 106: Selecting The Original Image Type

    If moiré effects should occur in copies containing lines or shading, reduce their effects by selecting the appropriate setting. “Gradation” is the default setting; however, “Resolution” is also available. These settings are only available if “Text&Photo”, “Photo Image” or “Printed Image” are selected. 5-18 Basic Operations KM-C1530...

  • Page 107: To Select The Document Type Before Copying

    Paper (Refer to page 5-4 for more details.) Zoom (Refer to page 5-14 for more details.) Density (Refer to page 5-20 for more details.) Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. KM-C1530 5-19...

  • Page 108: Specifying The Copy Density

    Position the document(s) to be copied. (Refer to page 4-1 for more details.) Select the desired color mode. (Refer to page 2-20 for more details.) Make sure that the Basic screen is displayed, and then touch [Original/ Density]. 5-20 Basic Operations KM-C1530...
  • Page 109 Paper (Refer to page 5-4 for more details.) Zoom (Refer to page 5-14 for more details.) Original Image Type (Refer to page 5-18 for more details.) Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. KM-C1530 5-21...

  • Page 110: Interrupting A Copy Job

    When the [Interrupt] key is pressed, all functions and settings are reset to their defaults. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key to copy the other document. 5-22 Basic Operations KM-C1530...
  • Page 111 After the other document is copied, press the [Interrupt] key. The indicator on the [Interrupt] key goes off. Reposition the document for the interrupted copy job that was removed in step 2. Press the [Start] key. The interrupted copy job continues. KM-C1530 5-23...
  • Page 112 Basic Operations 5-24 KM-C1530...

  • Page 113: Advanced Operations

    Single-Sided Ö Ö Ö Ö Single–2in1: Important) This setting is only available if both the duplexing document feeder (RADF-11) and the memory (128MB × 2) are installed. § This setting makes a single-sided copy of two pages side-by-side from two single-sided documents. KM-C1530...

  • Page 114: Single-Sided Ö Double-2In1

    (RADF-11) and the memory (128MB × 2) are all installed. § This setting makes a double-sided copy from a double-sided document. Book (Separation) Ö Ö Ö Ö Single-Sided: § This setting makes a single-sided copy of each of the two pages of an open book. Advanced Operations KM-C1530...

  • Page 115: Book (Spread) Ö Single-Sided

    Book (either Standard Book or RightBound) Ö Ö Ö Ö Book Erase: § This setting erases the area around the text (frame erase) or the binding of the book (center erase) so that it does not appear in the copy. KM-C1530...

  • Page 116: To Make Settings For Single- Or Double-Sided Documents And Copies

    9-45.) Since copy quality will decrease when Compress Mode is changed, the setting should normally not be changed. Specify any other necessary settings. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. Advanced Operations KM-C1530...

  • Page 117: To Make Settings For Copying A Book

    (center erase) so that it does not appear in the copy, touch [Book Erase]. The Book Erase screen appears. Is frame erasing and center erasing unnecessary? § If frame erasing and center erasing are unnecessary, skip to step KM-C1530...
  • Page 118 In the Original Size screen, touch specify the desired size, and then touch [Enter]. The Book Erase screen reappears. (center erase). to specify the width that is to be erased. Advanced Operations × 0.5 20 mm 10 mm , and KM-C1530...
  • Page 119 In the Book screen, touch [Enter]. Specify any other necessary settings. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. KM-C1530...

  • Page 120: Finishing ("Sort" And "Group" Settings)

    Sort: Important) When used as a copier, the 10-mailbin sorter (AS-M4110) must be installed. § The copies are automatically divided into sets with each set containing a copy of each page. Advanced Operations KM-C1530...

  • Page 121: Group

    When used as a copier, the 10-mailbin sorter (AS-M4110) must be installed. § The copies are automatically divided into stacks containing copies of the same page. Note The orientation in which the copies are fed out depends on the selected settings. KM-C1530...

  • Page 122: Sorting/Grouping

    How pages are fed depends on whether the following options are installed and on whether the pages are being copied or printed. - 10-Mailbin sorter (AS-M4110) and a printer controller - Finisher (F-8430 or F-8110) and a printer controller Setting Options Installed...

  • Page 123: To Select The Finishing Settings

    Group 10-Mailbin Sorter (AS- M4110) * A print job is a print command sent from a computer to the optional printer controller, then printed by this machine. To select the finishing settings Position the document(s) to be copied. (Refer to page 4-1 for more details.)

  • Page 124: Staple Binding

    Staple Binding If an optional finisher (F-8110 or F-8430) and a printer controller are installed, grouped or sorted printouts from a computer can be stapled together. The type of stapling depends on the model of the finisher installed. Note If finisher F-8110 is installed, the pages can only be stapled in the corner.

  • Page 125: Staple Position

    Printed image: Landscape; Paper orientation: Crosswise Possible paper sizes: LetterC, ExecutiveC Possible paper types: Standard paper (F-8430: 17 to 24 lbs.) *Only with finisher F-8430 installed KM-C1530 LetterC, ExecutiveC LetterL, LegalL, ExecutiveL 11 × 14L, 11 × 17L LetterL, LegalL, ExecutiveL 11 ×...
  • Page 126 (17 to 24 lbs.) For more details on selecting the stapling settings, refer to the manual for the printer controller. 6-14 Advanced Operations 11 × 14L, 11 × 17L LetterC, ExecutiveC 11 × 14L, 11 × 17L LetterC, ExecutiveC KM-C1530...

  • Page 127: Hole Punching ("Hole-Punch" Setting)

    Advanced Operations Hole Punching (“Hole-Punch” Setting) If an optional finisher (F-8430) and a printer controller are installed, holes for filing the pages in binders can be punched in printouts sent from a computer. Types of hole punching The number of holes punched (either two or three) is automatically selected according to the paper size and the paper feed method.
  • Page 128 Possible paper sizes: LetterL, LetterC, LegalL, 11 × 14L, 11 × 17L For more details on selecting the “Hole-Punch” setting, refer to the manual for the printer controller. 6-16 Advanced Operations 11 × 14L, 11 × 17L LetterL LegalL LetterC KM-C1530...

  • Page 129: Feeding Documents Of Different Sizes ("Mixed Orig Detection" Function)

    Select the desired color mode. (Refer to page 2-20 for more detail.) KM-C1530 (If Paper is set to “Auto Paper”) (If Zoom is set to “Auto Size”) Copies...
  • Page 130 Specify any other necessary settings. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. 6-18 Advanced Operations KM-C1530...

  • Page 131: Erasing Edges ("Frame Erase" Function)

    Example) When using the “Frame Erase” function while copying an 11 × 17-size document with a zoom ratio of “× 0.500” KM-C1530 to specify the 11 × 17 1/2 in. 5-1/2 × 8-1/2 × 0.5 1/4 in.
  • Page 132 [Enter]. In the Frame Erase screen, touch [Enter]. Specify any other necessary settings. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. 6-20 Advanced Operations to specify the KM-C1530...

  • Page 133: Creating Mirror Image Copy ("Mirror Image" Function)

    (otherwise, skip to step 8): To specify the document size, touch [Original Size]. In the Original Size screen, touch specify the desired size, and then touch [Enter]. KM-C1530 , and 6-21...
  • Page 134 In the Mirror Image screen, touch [Enter]. Specify any other necessary settings. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. 6-22 Advanced Operations KM-C1530...

  • Page 135: Improving Copy Quality ("Color Adjustment" Function)

    Position the document(s) to be copied. (Refer to page 4-1 for more detail.) Select the desired color mode. (Refer to page 2-20 for more detail.) Touch [Auxiliary]. The Auxiliary screen appears. Touch [Color Adjustment]. Touch the parameter that you wish to change. KM-C1530 6-23...

  • Page 136: To Make Test Prints

    The paper for the test print is automatically selected in the following order: A4C, LetterC, A3L, 11 ×17L. While referring to the test prints, touch the arrows to select the desired setting for the current parameter, and then touch [Enter]. Correctly position the document for normal printing. 6-24 Advanced Operations KM-C1530...

  • Page 137: To Adjust The Hue

    In the Color Adjustments screen, touch [Hue]. Touch the arrows to select the desired setting, and then touch [Enter]. To adjust the saturation This parameter can be used to adjust the vividness of the colors. In the Color Adjustments screen, touch [Saturation]. KM-C1530 6-25...

  • Page 138: To Adjust The Brightness

    [Enter]. To adjust the brightness This parameter can be used to adjust the brightness of the image. In the Color Adjustments screen, touch [Brightness]. Touch the arrows to select the desired setting, and then touch [Enter]. 6-26 Advanced Operations KM-C1530...

  • Page 139: To Adjust The Sharpness

    [Sharpness]. Touch the arrows to select the desired setting, and then touch [Enter]. To adjust the contrast This parameter can be used to make an image either lighter or darker. In the Color Adjustments screen, touch [Contrast]. KM-C1530 6-27...

  • Page 140: To Adjust The Color Balance

    Change the color balance of the image by adjusting the concentration of each color (cyan, magenta, yellow and black). In the Color Adjustments screen, touch [Color Balance]. Select the color that you wish to adjust, touch specify the desired setting, and then touch [Enter]. 6-28 Advanced Operations KM-C1530...

  • Page 141: To Adjust The Density

    To adjust the density This parameter can be used to make an image either more rich or more pale. In the Color Adjustments screen, touch [Density]. Touch the arrows to select the desired setting, and then touch [Enter]. KM-C1530 6-29...

  • Page 142: Inserting Pages Between Copies Of Overhead Transparencies ("Ohp Interleaving" Function)

    Load the overhead transparencies into the 1st drawer, and then set the media type selection dial on the drawer to “OHP”. Select the desired color mode. (Refer to page 2-20 for more detail.) Touch [Auxiliary]. The Auxiliary screen appears. Touch [OHP Interleaving]. 6-30 Advanced Operations KM-C1530...
  • Page 143 Advanced Operations Select the drawer loaded with the interleaves, and then touch [Enter]. Specify any other necessary settings. Press the [Start] key. KM-C1530 6-31...

  • Page 144: Specifying Different Vertical And Horizontal Scaling Proportions ("X/Y Zoom" Function)

    Touch [X] or [Y], and use the keypad to enter the desired zoom ratio, and then touch [Enter]. Specify any other necessary settings. Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. 6-32 Advanced Operations KM-C1530...

  • Page 145: Reducing The Document To Postcard Size And Printing Multiple Copies On One Page ("Postcard" Function)

    To set the “Postcard” function Position the document(s) to be copied. (Refer to page 4-1 for more details.) Select the desired color mode. (Refer to page 2-20 for more details.) Touch [Auxiliary]. The Auxiliary screen appears. Touch [Postcard]. Touch [Original Size]. KM-C1530 6-33...
  • Page 146 Using the keypad, enter the number of copies you wish to make, and then press the [Start] key. Note To purchase postcard paper, contact the sales representative for this copier. 6-34 , and Advanced Operations KM-C1530...

  • Page 147: Tiling Copies ("Image Repeat" Function)

    Select the desired color mode. (Refer to page 2-20 for more details.) Touch [Auxiliary]. The Auxiliary screen appears. Touch [Image Repeat]. Make sure that [Zoom] is selected, and then use the keypad to enter the desired zoom ratio. KM-C1530 6-35...
  • Page 148 [Enter]. The appropriate size of loaded paper for the set zoom ratio, number of copies, and document size is selected. Check the selected paper size, and then touch [Enter]. 6-36 , and Advanced Operations KM-C1530...
  • Page 149 Advanced Operations To manually select the paper source, touch [Paper Size]. Select the tray or drawer containing the paper that you wish to use, and then touch [Enter]. Press the [Start] key. KM-C1530 6-37...
  • Page 150 Advanced Operations 6-38 KM-C1530...

  • Page 151: Utility Mode Operations

    Press the [Utility] key to enter Utility mode. Touch [Default Settings]. Select the desired setting, and then touch [Enter]. Do you wish to record the current settings as the default settings? § Touch [Current Settings]. In the Utility screen, touch [Exit]. KM-C1530...

  • Page 152: Viewing Counters ("Meter Count" Function)

    Black: Number of copies or printouts made using the “Black” color mode Copy: Number of copies made Print: Number of pages printed from the computer through the printer controller Large: Number of copies/printouts made on paper registered as large-size paper...

  • Page 153: To View The Meter Counts

    Do you wish to print out the meter counts? § As described by the instructions that are displayed, load paper (Letter key. When you are finished viewing the meter counts, touch [Exit]. KM-C1530 ) into the first paper drawer, and then press the [Start]...

  • Page 154: Storing And Recalling Jobs ("Job Memory Input" Function)

    First, specify the copy settings that you will store as a job. Press the [Utility] key to enter Utility mode. Touch [Job Memory Input]. Touch [Input], and then touch the number where you wish to store the job. Utility Mode Operations KM-C1530...

  • Page 155: To Delete A Job

    Check that the name for the selected job is typed correctly, and then touch [Exit]. To delete a job Press the [Utility] key to enter Utility mode. Touch [Job Memory Input]. KM-C1530...

  • Page 156: To Recall A Stored Job

    After the entered job name is erased to indicate that the job was deleted, touch [Exit]. To recall a stored job Press the [Copy] key to enter Copy mode. Press the [Job Recall] key. Touch the number of the job that you wish to recall. Utility Mode Operations KM-C1530...
  • Page 157 Do you wish to select a different job instead? § Touch [Next]. Position the document(s) to be copied. Do you need more information on feeding the document? § Refer to “4 Original Documents” on page 4-1 for more details. Press the [Start] key. KM-C1530...

  • Page 158: Specifying Default Settings ("User's Choice" Function)

    [Panel Reset] key is pressed. To change the User’s Choice settings Press the [Utility] key to enter Utility mode. Touch [User’s Choice]. Touch the parameter that you wish to change Utility Mode Operations KM-C1530...

  • Page 159: To Set The "Language Selected" Parameter

    This parameter can be used to change the language of the touch panel. The default setting is “English”. In the User’s Choice screen, touch [Language selected]. Select the desired language, and then touch [Enter]. In the User’s Choice screen, touch [Exit]. KM-C1530...

  • Page 160: To Set The "2In1Copy Zoom" Parameter

    “ON”. In the User’s Choice screen, touch [2in1copy zoom]. Select whether the recommended zoom ratio will be used (“ON”) or not (“OFF”), and then touch [Enter]. In the User’s Choice screen, touch [Exit]. 7-10 Utility Mode Operations KM-C1530...

  • Page 161: To Set The "Intelligent Sorting" Parameter

    The “Sort” setting is only available if the optional 10-mailbin sorter (AS- M4110) is installed. In the User’s Choice screen, touch [Intelligent Sorting]. Select whether intelligent sorting will be used (“ON”) or not (“OFF”), and then touch [Enter]. In the User’s Choice screen, touch [Exit]. KM-C1530 7-11...

  • Page 162: To Set The "Acs Determination Level Adjust." Parameter

    The default setting is “3 (Std.)”. In the User’s Choice screen, touch [ACS Determination level Adjust.]. Touch [Black] or [Full Color] to specify the standard detection level, and then touch [Enter]. In the User’s Choice screen, touch [Exit]. 7-12 Utility Mode Operations KM-C1530...

  • Page 163: To Set The "Confirmation Beep" Parameter

    The default setting is “ON”. In the User’s Choice screen, touch [Confirmation Beep]. Select whether the confirmation beep is sounded (“ON”) or not (“OFF”), and then touch [Enter]. In the User’s Choice screen, touch [Exit]. KM-C1530 7-13...

  • Page 164: To Set The "Mail Bin Assignment" Parameter

    This parameter allows you to set whether or not mailbins are allocated to receive printouts from computers when the 10-mailbin sorter (AS-M4110) and the printer controller are installed on the copier. Bins 2 through 10 of the 10-mailbin sorter can be used to receive printouts. The default setting is “OFF”.

  • Page 165: To Set The "Auto Panel Reset" Parameter

    Do you wish to change the number of minutes entered? § Press the [C] (clear) key to erase the entered number, and then use the keypad to enter the correct number of minutes. In the User’s Choice screen, touch [Exit]. KM-C1530 7-15...

  • Page 166: To Set The "Energy Save Mode" Parameter

    Do you wish to change the number of minutes entered? § Press the [C] (clear) key to erase the entered number, and then use the keypad to enter the correct number of minutes. In the User’s Choice screen, touch [Exit]. 7-16 Utility Mode Operations KM-C1530...

  • Page 167: To Set The "Sleep Mode" Parameter

    Utility Mode Operations To set the “Sleep Mode” parameter If the printer controller is not installed, this parameter can be used to specify the length of time after the last operation until the copier automatically turns off. If the printer controller is installed, this parameter can be used to specify the length of time after the last operation until the copier automatically enters a standby mode (Energy Saver mode).

  • Page 168: To Set The "1St Drawer Paper Select" Parameter

    [Input Size], select the desired paper size, and then touch [Enter]. To specify a paper size other than those listed, touch [Custom Size], touch to specify the desired size, and then touch [Enter]. 7-18 , and Utility Mode Operations KM-C1530...
  • Page 169 Utility Mode Operations In the Input Size screen, touch [Enter]. In the 1st Drawer Paper Size screen, touch [Enter]. In the User’s Choice screen, touch [Exit]. KM-C1530 7-19...
  • Page 170 Utility Mode Operations 7-20 KM-C1530...

  • Page 171: Administrator Mode Operations

    Be sure to write down this number and store it in a safe place. If the administrator access code has been change, be sure to notify the appropriate service representative. To change the Administrator Mode settings Press the [Utility] key to enter Utility mode. Touch [Administrator Mode]. KM-C1530...
  • Page 172 Using the keypad, enter the four- digit administrator access code. Touch [Copy Track]. The Copy Track screen appears. Touch [ON], and then touch the parameter that you wish to change. Administrator Mode Operations KM-C1530...

  • Page 173: To Register Access Codes

    Has registration of the entered access code been cancelled? § If the entered access code is the same as one that has already been registered, registration is cancelled. Try again using a different access code. KM-C1530 to select the desired...

  • Page 174: To Change The Account Numbers Registered

    A maximum of 99 account numbers can be registered at one time. Additional accounts cannot be added. In the Copy Track screen, touch [ON], and then touch [Access # Input]. The Access # Input screen appears. Administrator Mode Operations KM-C1530...
  • Page 175 § If a previously registered account number is registered again, the previous one is deleted. Touch [Enter] in the Copy Track screen. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. KM-C1530 to select the desired...

  • Page 176: To Reset Copy Track Mode

    In the Copy Track screen, touch [OFF]. The All Accounts Data Reset screen appears. Touch [Yes], and then touch [Enter] to reset the data for all accounts. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. Administrator Mode Operations KM-C1530...

  • Page 177: To Check The Number Of Copies Made By Each Account

    [Start] key again to print the counter table. In the Counter Status screen, touch [Enter]. In the Copy Track screen, touch [Enter]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. KM-C1530 to select the...

  • Page 178: To Reset The Counters For Each Account

    § Touch [All Accts.]. Touch [Yes], and then touch [Enter]. To reset the counters for other accounts, repeat steps 2 and 3. In the Counter Reset screen, touch [Enter]. Administrator Mode Operations to select the KM-C1530...

  • Page 179: To Limit The Type Of Copies For An Account

    The Permission Level screen appears. Touch account whose copies you wish to limit. Select whether color copying and black-and-white copying are allowed (“Allow”) or not (“Prohibit”). To limit the copies for other accounts, repeat steps 2 and 3. KM-C1530 to select the...
  • Page 180 In the Permission Level screen, touch [Enter]. In the Copy Track screen, touch [Enter]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 8-10 Administrator Mode Operations KM-C1530...

  • Page 181: To Limit The Number Of Copies For An Account

    2 through 4. Do you wish to change the number entered? § Press the [C] (clear) key to erase the entered number, and then use the keypad to enter the correct number. KM-C1530 to select the 8-11...
  • Page 182 In the Account Copy Limitations screen, touch [Enter]. In the Copy Track screen, touch [Enter]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 8-12 Administrator Mode Operations KM-C1530...

  • Page 183: Adjusting The Gradation Levels ("Gradation Adjust" Function)

    If the gradation levels are adjusted, the “Card and Transparency Image Density” parameter of the Expert User’s Mode must be reset. To adjust the gradation levels Press the [Utility] key to enter Utility mode. Touch [Administrator Mode]. Using the keypad, enter the four- digit administrator access code. KM-C1530 8-13...
  • Page 184 When the color gradation has been adjusted, the Administrator Mode screen appears. Repeat steps 5 through 8 three times. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 8-14 Administrator Mode Operations KM-C1530...

  • Page 185: Turning Off The Sleep Function ("Disable Sleep Mode" Function)

    Setting this function to “Yes” turns off the Sleep function. The default setting is “No”. To turn off the Sleep function Press the [Utility] key to enter Utility mode. Touch [Administrator Mode]. Using the keypad, enter the four- digit administrator access code. KM-C1530 8-15...
  • Page 186 Touch [Disable Sleep Mode]. The Disable Sleep Mode screen appears. Touch [Yes], and then touch [Enter]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [User’s Choice]. 8-16 Administrator Mode Operations KM-C1530...
  • Page 187 If the time in the Sleep Mode screen (displayed by pressing the [Utility] key, touching [User’s Choice], then touching [Sleep Mode]) is set, the Sleep function will again be enabled. For more details, refer to “To set the “Sleep Mode” parameter” on page 7-17. KM-C1530 8-17...

  • Page 188: Erasing Copy Edges ("Erase" Function)

    To set the “Erase” function Note) Discuss any changes to this function with your service representative. Press the [Utility] key to enter Utility mode. Touch [Administrator Mode]. Using the keypad, enter the four- digit administrator access code. 8-18 Administrator Mode Operations KM-C1530...
  • Page 189 Administrator Mode Operations Touch [2/2], and then touch [Erase]. The Tip Erase screen appears. Select the desired setting, and then touch [Enter]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. KM-C1530 8-19...

  • Page 190: Specifying The Expert Settings ("Expert User's Mode" Function)

    Discuss any changes to the Expert User’s Mode settings with your technical representative. To change the Expert User’s Mode settings Note) Discuss any changes to this function with your service representative. Press the [Utility] key to enter Utility mode. Touch [Administrator Mode]. 8-20 Administrator Mode Operations KM-C1530...
  • Page 191 Administrator Mode Operations Using the keypad, enter the four- digit administrator access code. Touch [2/2], and then touch [Expert User’s Mode]. The Expert User’s Mode screen appears. Touch the parameter that you wish to change. KM-C1530 8-21...

  • Page 192: To Set The "Thick Paper And Ohp Film Image Density" Parameter

    (cyan, magenta, yellow and black), and then touch [Enter]. In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 8-22 Administrator Mode Operations to select the KM-C1530...

  • Page 193: To Set The "Color Shift Correction" Parameters

    [Enter]. If there is a shift, touch for “ ”, and then repeat steps 2 and 3 until there no longer is a shift. KM-C1530 to specify the desired adjustment 8-23...
  • Page 194 The example below shows the adjustment for cyan; however, the other colors should be adjusted in the same way. If the lines are shifted in the X- direction: Touch [X], and then align on the black grid. 8-24 Administrator Mode Operations to specify the desired KM-C1530...
  • Page 195 Touch [ ], and then align the A2 shift on the A1 shift. If necessary, touch [X], and then make the necessary adjustment. In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. KM-C1530 8-25...

  • Page 196: To Set The "Stabilizer" Parameter

    In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. Copy a document, and then compare the copy to the original document. Check that the copy is correct. 8-26 Administrator Mode Operations KM-C1530...

  • Page 197: To Set The "Prt Area (Top Margin)" Parameter

    Load paper (11 × 17L) into the 1st drawer, and then press the [Start] key to print out the test pattern. The screen at the right is displayed if the paper type dial on the 1st drawer is set for normal paper. KM-C1530 8-27...
  • Page 198 2. In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 8-28 Administrator Mode Operations a: 5.0 mm ± 1.0 mm KM-C1530...

  • Page 199: To Set The "Prt Area (Left Margin)" Parameter

    Load paper (11 × 17L) into the third paper drawer. In the Expert User’s Mode screen, touch [2/2], and then touch [PRT Area (Left Margin)]. The Left Margin screen appears. Touch [3rd Drawer], and then press the [Start] key to print out the test pattern. KM-C1530 8-29...
  • Page 200 In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 8-30 Administrator Mode Operations b: 3.0 mm ± 1.0 mm KM-C1530...

  • Page 201: To Set The "Prt Area (Dup. Left Margin)" Parameter

    Load paper (11 × 17L) into the fourth paper drawer. In the Expert User’s Mode screen, touch [2/2], and then touch [PRT Area (Dup. Left Margin)]. The Dup. Left Margin screen appears. Touch [4th Drawer], and then press the [Start] key to print out the test pattern. KM-C1530 8-31...
  • Page 202 In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. 8-32 Administrator Mode Operations to adjust it, and c: 3.0 mm ± 1.0 mm KM-C1530...

  • Page 203: To Set The "Thin Orig." Parameter

    [2/2], and then touch [Thin Orig.]. The Thin Orig. screen appears. Touch [ON], and then touch [Enter]. In the Expert User’s Mode screen, touch [Exit]. In the Administrator Mode screen, touch [Exit]. In the Utility screen, touch [Exit]. Touch [Orig. Ö Copy]. KM-C1530 8-33...

  • Page 204: Registering Scan Save Locations ("Scanner Addr. Input" Function)

    Touch [Thin Orig.]. Specify any other necessary settings. Registering Scan Save Locations (“Scanner Addr. Input” Function) This function can be used when the printer controller is connected. For more details, refer to the manual for the printer controller. 8-34 Administrator Mode Operations...

  • Page 205: Touch Panel Messages

    Follow the procedure below to load more paper. Loading paper into the 1st drawer (250-sheet multipurpose paper drawer) --> page 9-2 into the 500-sheet paper feed unit --> page 9-3 into the large-capacity cabinet --> page 9-5 KM-C1530...

  • Page 206: To Load Paper Into The 1St Drawer (250-Sheet Multipurpose Paper Drawer)

    Do you wish to load a paper size or type different from that previously loaded? § For more details on changing the paper size and type, refer to “Loading Paper” on page 3-7. Touch Panel Messages Paper take- up roller KM-C1530...

  • Page 207: To Load Paper Into The 500-Sheet Paper Feed Unit

    Be careful not to touch the surface of the paper take-up roller with your hands. If the roller has been touched, wipe it with a dry cloth. Press down on the paper-lifting plate until it locks into place. KM-C1530 Paper take- up roller...
  • Page 208 Slide the lateral guides against the edges of the paper. Make sure that the paper is not curled when it is loaded. Check that the lateral guides are pushed up against the edges of the paper. Close the paper drawer. Touch Panel Messages KM-C1530...

  • Page 209: To Load Paper Into The Large-Capacity Cabinet

    (the side facing up when the package was unwrapped) faces up. Have you loaded too much paper into the drawer? § Do not load so much paper that the top of the stack is higher than the Ä mark. Close the paper drawer. KM-C1530...

  • Page 210: When The Message "Please Add Toner." Appears

    Do not refill the toner until the message indicating that the toner be refilled appears on the touch panel. In addition, do not refill the toner of any color other than the one indicated in the message on the touch panel. Touch Panel Messages KM-C1530...
  • Page 211 Precaution for the disposal of the used toner bottle: § Do not throw away the used toner bottle; instead, keep it to be col- lected by your technical representative. WARNING Do not incinerate toner and toner containers. Dangerous sparks may cause burns. KM-C1530...

  • Page 212: To Add Toner

    Is the toner within the bottle hard? § The toner within the bottle may become compacted. If it does, be sure to shake the bottle until the toner is mostly broken up before adding it to the hopper. Touch Panel Messages KM-C1530...
  • Page 213 Do you know what precautions should be taken when refilling the toner? § Do not tap on the toner bottle while refilling the hopper; otherwise, the toner may spurt out. Push the toner hopper shutter closed. KM-C1530...
  • Page 214 Tilt the toner bottle backward, and then pull the opening of the bottle up and toward you to remove it. Close the toner hopper lid, and then close the toner supply door. 9-10 Touch Panel Messages KM-C1530...

  • Page 215: When The Message "Replace Staple Cartridge X." Appears

    When finisher F-8110 or F-8430 is installed and is about to run out of staples, the message shown below appears. Follow the procedure below to replace the staple cartridge. To replace the staple cartridge Slide the finisher away from the copier. If finisher F-8430 is installed, open right-side door FN7. KM-C1530 9-11...
  • Page 216 Since finisher F-8430 is equipped with two staple holders, which staple holder should be pulled out? § The message on the touch panel indicates which staple holder should be pulled out. 9-12 Touch Panel Messages Stapler 1 Stapler 2 Stapler 1 KM-C1530...
  • Page 217 (Finisher F-8430) Remove the empty staple cartridge from the staple holder. (Finisher F-8430) Insert the new staple cartridge into the staple holder, and then carefully remove the stopper. (Finisher F-8110) Remove the empty staple cartridge from the staple holder. KM-C1530 9-13...
  • Page 218 Insert the new staple cartridge into the staple holder, and then carefully remove the stopper. Insert the refilled staple holder until it locks into place. Finisher F-8430 Finisher F-8110 If finisher F-8430 is installed, close right-side door FN7. 9-14 Touch Panel Messages KM-C1530...
  • Page 219 Touch Panel Messages Slide the finisher back against the copier. Note Be sure to replace the staple cartridge only after this message appears. Injuries may occur if the staple cartridge is removed before the message appears. KM-C1530 9-15...

  • Page 220: When The Message "Misfeed Detected." Appears

    A flashing “2” indicates the location of the paper misfeed. In addition, a lit “2” indicates areas where paper may have been misfed and that should be checked. 9-16 Touch Panel Messages KM-C1530...
  • Page 221 Touch Panel Messages 10-mailbin sorter/ Finisher p. 9-34 Copier p. 9-24 Duplex unit p. 9-21 KM-C1530 Duplexing document feeder p. 9-28 Duplex unit p. 9-21 Manual bypass tray p. 9-19 Copier p. 9-24 Paper drawers p. 9-22 Paper feed unit p. 9-22 Manual bypass tray p.
  • Page 222 Duplexing document feeder p. 9-28 10-mailbin sorter p. 9-34 9-18 Touch Panel Messages Finisher F-8110/F-8430 p. 9-30 KM-C1530...

  • Page 223: Paper Misfeed In The Manual Bypass Tray

    CAUTION The copier’s fixing unit is extremely hot. Take sufficient care when working in this area, as there is a danger of getting burned. KM-C1530 9-19...
  • Page 224 Pull up the lock release lever to open the right-side door. Carefully pull out the paper. Close the right-side door. 9-20 Touch Panel Messages KM-C1530...

  • Page 225: Paper Misfeed In The Duplex Unit

    Touch Panel Messages Paper Misfeed in the Duplex Unit To clear a paper misfeed in the duplex unit Open the duplex unit door. Carefully pull out the paper. Close the duplex unit door. KM-C1530 9-21...

  • Page 226: Paper Misfeed In The Paper Feed Unit

    Paper Misfeed in the Paper Feed Unit To clear a paper misfeed in the paper feed unit Open the lower right-side door. Turn the green wheels to feed the paper so that it can be easily removed. 9-22 Touch Panel Messages KM-C1530...
  • Page 227 Has the paper take-up roller been touched? § Be careful not to touch the surface of the paper take-up roller with your hands. If the roller has been touched, wipe it with a dry cloth. KM-C1530 Paper take-up roller 9-23...

  • Page 228: Paper Misfeed In The Copier

    CAUTION The copier’s fixing unit is extremely hot. Take sufficient care when working in this area, as there is a danger of getting burned. 9-24 Touch Panel Messages KM-C1530...
  • Page 229 While moving the green lever on the inside of the upper right-side door in the direction of the arrow, carefully pull out the paper. Carefully pull out the paper. KM-C1530 9-25...
  • Page 230 While holding the levers on the ends of the oil-coating unit, move the unit back to its original position. Fully move the two lock release levers for the oil-coating unit in the direction of the arrows. 9-26 Touch Panel Messages KM-C1530...
  • Page 231 Touch Panel Messages Close the upper right-side door. Close the right-side door. CAUTION The copier’s fixing unit is extremely hot. Take sufficient care when working in this area, as there is a danger of getting burned. KM-C1530 9-27...

  • Page 232: Paper Misfeed In The Duplexing Document Feeder

    To clear a paper misfeed in the duplexing document feeder Open misfeed clearing cover F1. Remove all documents from the document feed tray, and then carefully pull out any other documents. Open misfeed clearing cover F2, and then carefully pull out any documents. 9-28 Touch Panel Messages KM-C1530...
  • Page 233 Remove any documents on the original glass, and then close the duplexing document feeder. Close misfeed clearing covers F1 and F2. Reload the documents according to the instructions that appear on the touch panel. KM-C1530 9-29...

  • Page 234: Paper Misfeed In Finisher F-8110/F-8430

    Be careful about a protrusion on the backside of the horizontal transport unit cover. It can hurt you! (Part indicated is Step 3.) To clear a paper misfeed in finisher F-8110/F-8430 Slide the finisher away from the copier. 9-30 Touch Panel Messages KM-C1530...
  • Page 235 Touch Panel Messages Open the cover of the horizontal transport unit. Remove any paper, and then close the cover of the horizontal transport unit. If finisher F-8430 is installed, open right-side door FN7. KM-C1530 9-31...
  • Page 236 If finisher F-8430 is installed, close right-side door FN7. Open front door FN4. Turn knobs FN5 at the same time to feed out any paper. Close front door FN4. Open upper cover FN1. 9-32 Touch Panel Messages KM-C1530...
  • Page 237 While holding misfeed clearing guide FN2 open, remove any paper While holding misfeed clearing guide FN3 open, remove any paper. Close upper cover FN1. While holding misfeed clearing guide FN6 open, remove any paper. Slide the finisher back against the copier. KM-C1530 9-33...

  • Page 238: Paper Misfeed In The 10-Mailbin Sorter

    It can hurt you! (Part indicated in Step 4.) To clear a paper misfeed in the 10-mailbin sorter Slide the 10-mailbin sorter away from the copier. Remove any paper from the mailbins. 9-34 Touch Panel Messages KM-C1530...
  • Page 239 Touch Panel Messages Open the cover of the horizontal transport unit. Remove any paper, and then close the cover of the horizontal transport unit. Open the upper door and the lower door. KM-C1530 9-35...
  • Page 240 Remove any paper. Close the upper door and the lower door. Slide the 10-mailbin sorter back against the copier. 9-36 Touch Panel Messages KM-C1530...

  • Page 241: When The Message "Cannot Staple." Appears

    When finisher F-8110 or F-8430 is installed and the staples are jammed, the message shown below appears. Follow the procedure below to clear the jammed staples To clear jammed staples Slide the finisher away from the copier. If finisher F-8430 is installed, open right-side door FN7. KM-C1530 9-37...
  • Page 242 § The message on the touch panel indicates which staple holder should be pulled out. Push the staple holder guide up, and then pull out one sheet of staples. 9-38 Touch Panel Messages Stapler 1 Stapler 2 Stapler 1 KM-C1530...
  • Page 243 Touch Panel Messages Move the guide back to its original position. Insert the staple holder until it locks into place. Finisher F-8430 Finisher F-8110 If finisher F-8430 is installed, close right-side door FN7. KM-C1530 9-39...
  • Page 244 Slide the finisher back against the copier. Are the staples still jammed, even after performing the above procedure? § Contact a qualified technical representative. 9-40 Touch Panel Messages KM-C1530...

  • Page 245: When The Inspection Mark " " Appears

    (“P-7” in the example below) listed in the screen that appears. Touching [Exit] in the top-right corner displays the Basic screen. KM-C1530 ) in the lower-left corner of the touch panel ) that appears in the touch panel 9-41...

  • Page 246: When The Message "Malfunction Detected." Appears

    If this message appears, contact your technical representative. Note When contacting the technical representative, inform them of the code (“C0400” in the example above) in the screen that appears. 9-42 Touch Panel Messages KM-C1530...

  • Page 247: When The Message "Need To Replace Xxxxx." Appears

    “Need to Replace XXXXX.” appears in the touch panel followed by instructions for replacing the unit. Replace the unit according to the instructions that appear. Disposing of Used Parts Dispose of used units according to your local regulations, or contact your technical representative. KM-C1530 9-43...

  • Page 248: Other Messages

    Clear the paper misfeed. occurred, the copier is p. 9-16 unable to make copies. Since the maximum amount Remove all copies from the of copies for the indicated indicated tray. finisher tray has been exceeded, the copier is unable to make copies. KM-C1530...
  • Page 249 Please Select a Compress in Compress Mode. Your account has reached its maximum allowance. KM-C1530 Cause Remedy The indicated bin of the 10- Remove all copies from the mailbin sorter has reached indicated bin. its maximum capacity, so the copy operation cannot continue.
  • Page 250 Touch Panel Messages 9-46 KM-C1530...

  • Page 251: Troubleshooting

    The image is too light. The image is too dark. The copy is blurry. There are dark specks or spots throughout the entire copy. KM-C1530 Possible Cause Remedy The copy density is set too Select a darker copy density light.
  • Page 252 The document guides are not Slide the document guides positioned along the edges against the edges of the of the paper. paper. Curled paper was loaded into Flatten the paper before the paper drawer. loading it. Troubleshooting KM-C1530...

  • Page 253: When The Copier Is Not Operating Correctly

    Even though the Start Key is pressed, no copies are made Keys on the control panel do not respond. The copier cannot be turned KM-C1530 Cause Remedy If only the indicator on the Press any key to cancel Start key is lit, the copier is in Energy Saver mode.
  • Page 254 Troubleshooting 10-4 KM-C1530...

  • Page 255: Appendix

    Appendix Appendix 11.1 Specifications Copier KM-C1530 Specification Type Platen Photo conductor Copying system Developing system Fusing system Resolution Document Paper types Paper sizes Paper sizes Warm-up time Lost image KM-C1530 KM-C1530 Desktop Stationary Digital Full-Color Copying 2- component system Belt-fixing Scanning: 600 dpi;...
  • Page 256 24-1/2 in. (width) × 27-3/4 in. (depth) × 6 in. (height) Printer: 23-1/2 in. (width) × 28-3/4 in. (depth) × 20-1/2 in. (height) 25-1/4 in. (width) × 31 in. (depth) (with the scanner rack installed) Scanner: 57-1/4 lbs. Printer: 187-1/2 lbs. (with all four imaging units installed) Appendix KM-C1530...

  • Page 257: Sheet Paper Feed Unit St-530

    Paper sizes Capacity Power source Power consumption Dimensions Weight KM-C1530 • Standard paper: Single-sided and double-sided documents • “Mixed Orig Detection” function: Various sizes of single-sided and double-sided documents • Single-sheet feeding: Single-sided documents Single-sided: 13-1/4 to 29-1/4 lbs. Double-sided, Mixed Org Detection: 16 to 24 lbs.

  • Page 258: Duplex Unit Ad-35

    21 in. (width) × 22-1/4 in. (depth) × 11-1/4 in. (height) About 36-3/4 lbs. Standard paper (17 to 24 lbs.) 11 × 17L to 5-1/2 × 8-1/2L Supplied from copier Less than 17 W 5-1/2 in. (width) × 17-1/4 in. (depth) × 14-1/4 in. (height) About 6-3/4 lbs. Appendix KM-C1530...

  • Page 259: 10-Mailbin Sorter As-M4110

    Capacity of bins Power source Power consumption Dimensions Weight KM-C1530 Non-sort, Sort, Group • “Non-sort” setting: Standard paper (17 to 24 lbs.), thick paper (24-1/4 to 55-1/2 lbs.), overhead projector transparencies, postcards • “Sort/Group” setting: Standard paper (17 to 24 lbs.) •...

  • Page 260: Finisher F-8430

    Paper size: 11 × 17L to Letter Holes punching: 2 or 3 holes Supplied from copier Less than 63 W 21-1/4 in. (width) × 24-3/4 in. (depth) × 38-1/2 in. (height) About 86-1/2 lbs. 2 staple cartridges (5,000 staples) Appendix KM-C1530...

  • Page 261: Finisher F-8110

    “Staple” setting Power source Power consumption Dimensions Weight Accessories KM-C1530 Upper paper output tray, Lower paper output tray • When copying: Non-sort • When printing from the computer: Non-sort, Sort, Group, Staple • Upper paper output tray “Non-sort” setting: Standard paper (17 to 24 lbs.), thick paper...

  • Page 262: Operation Panel

    Original glass § Clean the original glass by wiping it with a soft, dry cloth. Operation panel § Clean the operation panel by wiping it with a soft, dry cloth. 11-8 Appendix KM-C1530...

  • Page 263: Document Transfer Belt

    Clean the newly exposed surface of the belt by wiping it with a soft cloth dampened with a mild household detergent (as in step 1). Repeat the above steps until the entire surface of the document transfer belt has been wiped clean. KM-C1530 11-9...

  • Page 264: Function Combination Table

    11.3 Function Combination Table Function combination table 11-10 Appendix KM-C1530...
  • Page 265 Appendix KM-C1530 11-11...

  • Page 266: Function Combination Code Keys

    When making “Single-sided Ö Double-sided” copies while manually placing the documents on the original glass, the copy job cannot be interrupted by pressing the [Interrupt] key. * 1: The “Staple” and “Hole-Punch” settings are only available if both the finisher and printer controller are installed. 11-12...

  • Page 267: Paper Size And Zoom Ratio Tables

    Foolscap Foolscap 8-1/4 in. × 11-3/4 in. Letter Government Letter Quarto Statement KM-C1530 Metric size 311 mm × 457 mm 297 mm × 420 mm 210 mm × 297 mm 148 mm × 210 mm 105 mm × 148 mm 257 mm ×...
  • Page 268 × 0.500 × 0.866 × 0.610 × 1.414 × 1.224 × 0.707 × 0.866 × 1.414 × 2.000 × 1.733 × 1.224 × 2.000 × 1.414 × 1.733 × 1.224 × 0.816 × 0.577 × 0.707 × 0.500 × 1.154 KM-C1530...
  • Page 269 279.4 mm × 381 mm 11 in. × 14 in. 279.4 mm × 355.6 mm Legal 11 in. × 17 in. 215.9 mm × 355.6 mm KM-C1530 Desired paper size Zoom ratio × 0.816 × 0.577 × 0.707 × 1.640 ×...
  • Page 270 × 0.647 11 in. × 17 in. × 1.294 11 in. × 14 in. × 1.272 11 in. × 17 in. × 2.000 11 in. × 14 in. × 1.647 Legal × 1.545 Foolscap × 1.529 Letter × 1.294 KM-C1530...
  • Page 271 Background ...5-20 Basic operations ...5-1 “Book Erase” function ...6-5 Books Copying ...6-5 Positioning ...4-13 Cancelling settings ... 2-21 Care of the copier ...11-8 “Color Adjustment” function ...6-23 Brightness ...6-26 Color balance ...6-28 Contrast ...6-27 Density ...6-29 KM-C1530 2-16 11-5 2-25 Index-1...
  • Page 272 Delayed copy jobs ... 2-26 Deleting a stored copy job ... 7-5 Density ... 5-20 “Disable Sleep Mode” function ... 8-15 Document scale ... 2-11 Document type ... 5-19 Documents of mixed sizes ...4-5 Index-2 2-28 2-27 2-25 2-22 6-17 KM-C1530...
  • Page 273 “Full size” zoom setting ...5-14 Function combination ...11-10 Fusing unit ...2-13 Fusing web unit ...2-13 “Gradation Adjust” function ...8-13 Hole punching ...6-15 Punched hole position ...6-15 Types of hole punching ...6-15 KM-C1530 2-15 11-4 2-14 11-3 2-17 11-6 11-7 Index-3...
  • Page 274 Memory ... 2-9 Messages ... 9-44 “Mulfunction detected.” ... 9-42 “Need to Replace XXXXX.” ... 9-43 “Meter Count” function ... 7-2 “Minimal” zoom setting ... 5-14 “Mirror Image” function ... 6-21 Index-4 2-27 5-22 2-19 11-4 4-11 4-12 4-13 4-14 KM-C1530...
  • Page 275 Manual bypass tray ...9-19 Paper feed unit ...9-22 Paper orientation ...1-12 Paper replenishing ...9-1 Paper sizes ... 3-2 Paper source ...5-4 Paper type dial ...5-6 Paper types ...3-1 “Postcard” function ...6-33 KM-C1530 4-12 2-16 2-15 2-14 2-17 2-19 2-18 2-11...
  • Page 276 Storing a copy job ... 7-4 Supervising copier use ... 8-1 Thin paper ... 4-9 Toner hopper lid ... 2-12 Toner refilling ... 9-6 Toner supply door ... 2-11 Troubleshooting ... 10-1 Turning the copier on and off ... 2-29 Index-6 2-29 2-19 11-2 KM-C1530...

  • Page 277: Zoom Ratios

    “Mail Bin Assignment” parameter ...7-14 “Sleep Mode” parameter ...7-17 Utility mode ...7-1 Waste toner bottle ...2-13 “X/Y Zoom” function ...6-32 Zoom ratio Recalling a recorded zoom ratio ...5-17 Recording a zoom ratio ...5-16 Zoom ratio settings ... 5-14 KM-C1530 11-13 Index-7...
  • Page 279 * For best copy results and machine performance, we recommend that you use only KYOCERA MITA original supplies for your KYOCERA MITA copier.
  • Page 280 KYOCERA MITA AMERICA, INC. Headquarters: New York Show Room: Northeastern Region: Midwestern Region: KYOCERA MITA CANADA, LTD. KYOCERA MITA MEXICO, S.A. DE C.V. Western Region: Southeastem Region: Southwestern Region: Dallas Parts Distribution Center & National Training Center:...

Table of Contents
