Settings Panel
Feature
1 Network tab
2 Options tab
3 Audio tab
4 SIP tab
5 Modules tab
6 ISDN Answer tab
7 Firmware tab
8 Licensing tab
9 Reset tab
10 DNS Pane
11 Maximize/Minimize
12 Close button
13 Network Interface
14 Network
Identifier
15 IPv6 details
16 MAC Address
17 IPv4 details
18 Save Settings button Saves all configuration settings
© Tieline Pty. Ltd. 2014
Description
Click to edit or view codec network configuration settings
Click to configure RS232 and QoS data settings, Session Port
settings and SNMP.
Click to configure the AES Output Clock sample rate
Click to edit or view SIP configuration settings
Click to edit hardware module configuration
Click to configure ISDN Answering settings
Click to view software versions and perform an upgrade
Click to select a license file and install it into the codec
Click to reset codec default settings and perform backup/restore
of codec programs and settings
Activate to specify DNS addresses and domains to search.
Click to maximize a panel to view it in full-screen mode, or click
to minimize back to the default panel size
Click to close the panel
Select a network interface for configuration options
Interface Control and streaming configuration options for each network
interface, e.g. Ethernet Port 1 or 2.
IPv6 addressing details and configuration
Device MAC address
IPv4 addressing details and configuration
