2. Click the Disconnect button.
3. Click Yes in the confirmation dialog to disconnect all audio stream connections.
Disconnect a Single Audio Stream Connection
1. Click to select the audio stream connection you want to disconnect.
2. Click the Disconnect button.
3. Click Yes in the confirmation dialog to disconnect all audio stream connections.
21.13

View/Edit/Delete Programs

Important Notes: You cannot edit or delete a program when it is currently loaded in the
codec; ensure you have unloaded a program prior to editing the current configuration.
To view configuration settings for an existing program, or edit settings:
1. Open the web-GUI and click the Programs
Programs panel.
2. Click to select a program in the left-hand pane.
© Tieline Pty. Ltd. 2014
Merlin PLUS Manual v1.2
symbol at the top of the screen to display the
123
