SPLIT-TYPE AIR CONDITIONERS

OUTDOOR UNIT

SERVICE MANUAL

Models
MUZ-FH09NA
MUZ-FH12NA
MUZ-FH15NA
MUZ-FH09NA
MUZ-FH12NA
NOTE:
RoHS compliant products have mark on the spec name plate.
MUZ-FH09NAH
MUZ-FH12NAH
MUZ-FH15NAH
MUZ-FH09NAH
MUZ-FH12NAH
Revision A:
• 3. SPECIFICATION has been modified.
• 10. TROUBLESHOOTING has been modified.
Please void OBH684.
HFC
utilized
R410A
Indoor unit service manual
MSZ-FH•NA Series (OBH683)
CONTENTS
1. TECHNICAL CHANGES ··································· 2
2. PART NAMES AND FUNCTIONS ····················· 3
3. SPECIFICATION ················································ 4
4. OUTLINES AND DIMENSIONS ························ 6
5. WIRING DIAGRAM ············································ 8
6. REFRIGERANT SYSTEM DIAGRAM ··············11
7. DATA ································································ 13
8. ACTUATOR CONTROL ··································· 21
9. SERVICE FUNCTIONS ··································· 22
10. TROUBLESHOOTING ····································· 23
11. DISASSEMBLY INSTRUCTIONS ···················· 44
PARTS CATALOG (OBB684)
No. OBH684
REVISED EDITION-A
