  • Page 1 Please purchase “Secure Digital (SD) Memory Cards” or “Multi-Media Cards*” (MMC) for use with this camera. These cards are referred to in these User’s Manuals as “Memory Cards.” * MultiMediaCard is a registered trademark of Infineon Technologies AG (Germany), licensed to MMCA (MultiMediaCard Association). Faites l’acquisition de “Cartes Mémoire Secure Digital”...

  • Page 2: Introduction

    Thank you for purchasing this Kyocera product. The KYOCERA Finecam L4 and Finecam L3 are digital cameras equipped with a 3x optical zoom lens for high performance and high quality digital still photography. For the operation of the camera, please read this User’s Manual carefully and follow its instructions to assure proper use.

  • Page 3: How To Use This Manual

    The section “Basic Operations” describes basic operations of the digital camera such as shooting, viewing, and erasing images. If you use a digital camera for the first time, read these sections carefully in order to learn how to use it properly.

  • Page 4: Table Of Contents

    Introduction...2 Check the Contents... 2 How to Use this Manual ... 3 Handling Precautions ... 8 Functions of this Camera ... 11 Camera... 11 System Around the Camera ... 12 Names of Parts ... 13 ■ Attaching the Hand Strap... 13 Preparation of Camera ...14 1 Loading the Memory Card and Inserting the Battery Pack...
  • Page 5 Using the Camera “s” Mode and Movie “m” Mode Functions ...45 Using Flash Functions... 45 What is red-eye phenomenon? ... 47 ] Macro and Landscape Photography... 48 Avoiding Camera Shake... 49 What is Parallax? ... 49 [t] Using the Self-Timer ... 50 ] Selecting Image Dimensions (Pixels)...
  • Page 6 Introduction Using Setup “SET UP” Mode Functions...80 [BRIGHT CNTRL] Setting Brightness of the LCD Monitor ... 80 [INSERT DATE] Setting to Write the Date in the Image ... 81 [FORMAT] Formatting the Memory Card ... 82 [POWER SAVE] Saving Power by Turning Power Off Automatically ... 82 [MODE LOCK] Preserving the Mode Settings ...
  • Page 7 FCC COMPLIANCE STATEMENT FOR AMERICAN USERS DIGITAL STILL CAMERA CONTAX Tvs DIGITAL Tested To Comply With FCC Standards FOR HOME OR OFFICE USE FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 8: Caution And Warning Symbols

    Introduction Caution and Warning Symbols These Operating Instructions feature the following caution and warning symbols to indicate items of special importance. Be sure to read the contents of these warnings carefully, and use the features correctly. This symbol indicates procedures which have a high likelihood of resulting in death or serious personal injury if not followed properly.
  • Page 9 Make sure to read this page carefully. ● Interference may occur in recorded or played back images when the camera is used in areas subject to strong electromagnetic interference (e.g., near a television set or stereo speakers). ● Do not direct the camera lens directly toward the sun when shooting, since the CCD element may be damaged.
  • Page 10 USB DIRECT-PRINT ● This digital camera supports the USB DIRECT-PRINT function and can directly be connected to the printer supporting the USB DIRECT-PRINT by a USB cable. After that, you can select an image on the monitor of the digital camera and operate the monitor to start printing.

  • Page 11: Functions Of This Camera

    Functions of this Camera Shooting Connecting to a PC Connect the camera to a PC using the supplied USB cable. Depending on the operating system, you need to install the USB driver. In this case, install the USB driver first, then connect the camera to a PC.

  • Page 12: Camera

    E-mail Card reader Memory card (supplied) Printer Printer USB cable (supplied) Digital camera Finecam L3 Finecam L4 Photo lab Digital print E-mail Notebook PC Card adapter USB DIRECT-PRINT * This function is supported only by the EPSON PM- 860PT Printer.

  • Page 13: Names Of Parts

    Names of Parts ■ Attaching the Hand Strap Attach the supplied hand strap as shown. Introduction 1Mode select dial (page 16) 2Shutter release button (page 19) 3Speaker 4POWER button (page 16) 5Self-timer LED (red) (page 99) 6Light sensor 7Viewfinder 8Connector cover 9USB connector (page 31) 0Power supply input socket ALens/lens cover...

  • Page 14: Preparation Of Camera

    Loading the Memory Card and Inserting the Battery Pack Clipped edge Battery cover release lever Preparation of Camera Open the memory card door. Slide the memory card door and open it. Insert the memory card. Make sure the label side is toward the LCD monitor side.

  • Page 15: Removing The Memory Card

    Removing the memory card Write Protect Switch (SD Memory Cards only) Write protect switch Slide down to lock. WRITE PROTECT The AA batteries may also be used. You can also use 2 nickel metal hydride rechargeable battery and 2AA nickel batteries other than the supplied lithium battery pack (CR-V3).

  • Page 16: Turning The Power On

    Preparation of Camera Turning the Power ON ■ Battery indicator and replacing time Fully charged Setting the Date and Time If the camera has been left for a long time without a battery pack, the date and time will be reset.
  • Page 17 DISP. MENU When a picture is taken, the digital camera saves image data to the memory card with its date and time information. As shooting date and time are saved, it is practical to organize image data in an album, etc.

  • Page 18: Basic Operations

    These are the basic operations of a digital camera. Please learn how to use this digital camera by shooting some trial images first. In addition, try to enjoy the special functions for the digital camera. For example, process images using the PC or print the digital image.

  • Page 19: Take A Picture

    Check the exposure and bring the camera into focus. “Beep” When exposure and focus are not set: Take a picture. “Beep” Lightly depress the shutter release button halfway to set exposure and focus. Pressing the shutter release button halfway down (page 20.) When exposure and the focus are properly set: The electronic beep is heard and the standby LED and focus mark come on.

  • Page 20: Holding The Camera Steady

    Basic Operations Holding the Camera Steady Relax your shoulders. Hold your elbows close to your body. LED Displays after Shooting When the caution LED and card access LED flash after shooting, the messages to be noted are as follows: For the LED display, see page 99 Alarm LED (Red) If the card access LED flashes after shooting, the images are being recorded into the memory card.

  • Page 21: Using (+) And (-) Buttons

    Using (+) and (–) buttons The (+) and (–) buttons are used as follows: ● Using these buttons in camera or movie modes, the brightness on the LCD monitor can be changed (Brightness range: 9 levels). The brightness on the LCD monitor can easily be controlled just before shooting.

  • Page 22: Let's Shoot Movies Too

    Basic Operations Let’s Shoot Movies too Set the Mode to “m” movie mode. Compose your picture and bring it into focus. Take a picture. “Beep” Set the mode select dial to “m”, then press the POWER button to turn on the camera power. 1 Compose your picture while watching the LCD monitor.

  • Page 23: Checking The Pictures (Playback Of Images)

    Checking the Pictures (Playback of Images) Set the Mode to “p” playback mode. DISP. DISP. MENU Playing Back a Still Picture DISP. MENU Basic Operations Set the mode select dial to “p” and turn on the camera power. The image that you have taken is displayed on the LCD monitor.

  • Page 24: Checking Image Information

    Basic Operations Checking Image Information You can check information such as aperture value, picture quality and shutter speed used for shooting. Press the display button. The information will be displayed. Folder name and file name Image quality setting Shutter speed Aperture Date of shooting ●...

  • Page 25: Erasing Unwanted Images

    Erasing Unwanted Images Set the Mode to “p” playback mode and select “ erase. DISP. MENU MULTI DISP. MENU ERASE ERASE IMAGE? DISP. MENU EXECUTE CANCEL Select the image you want to erase. Press Right or Left on the directional keypad to display the image to be erased. ●...

  • Page 26: Using The Directional Keypad And Execute Button

    Basic Operations Delete the image. ERASE IMAGE? EXECUTE CANCEL ERASE IMAGE? EXECUTE CANCEL Complete the operation. Press the MENU button to exit the operation. Using the directional keypad and execute button To select the item from the menu icon or menu, use the directional keypad and execute button.

  • Page 27: When The Memory Card Is Full

    When the Memory Card is Full MEMORY CARD FULL It is necessary to either replace the memory card with a new one or to save images to a PC and erase some of the images currently on the memory card. Use the supplied PC cable to save images to a PC.

  • Page 28: Connecting To A Pc

    Basic Operations Connecting to a PC If you connect the camera to a PC, the images shot can be viewed, copied, processed and sent by e-mail. First check your PC environment or operating system. If the operating system you are using is Windows 98/98SE or Mac OS 8.6 Caution: Be sure to install the USB driver before connecting the camera to the PC with the USB cable.

  • Page 29: Installing The Usb Driver

    Installing the USB Driver The USB driver is included in the CD-ROM supplied with the camera. 1 Turn on the PC and start Windows or Mac. 2 Put the supplied CD-ROM into the CD-ROM drive on your PC or Mac. For Windows 98 and Windows 98 SE users 1 In the [My Computer] window, double-click the [Cd_41(D:)] or [Cd_40(D:)] folder to open it.
  • Page 30 Basic Operations 3 When a message “InstallShield Wizard Completed” is displayed, click “Finish” to stop the Wizard. After that, restart the computer. Caution: If you failed in installation, uninstall the USB driver following the procedure shown in page 37 and reinstall it. For Mac OS 8.6 users 1 Double-click the CD-ROM icon [CD_41] or [CD_40] displayed on the screen to open the CD-ROM window.

  • Page 31: Connecting The Usb Cable To Your Pc

    After the copy completes, restart the computer. When the computer is restarted, n is completed. the installatio Connecting the USB Cable to your PC Exclusive USB cable To the USB port To the USB port Camera Push until the jack click.
  • Page 32 Basic Operations PC display after connecting the camera Windows: New [Removable Disk] icon appears in [My Computer] window. ● The alphabetical letter in the parentheses varies with the PC you are using. ● For Windows XP users: The following Window will appear. Macintosh: [Untitled Folder] icon appears on the Desktop.

  • Page 33: Viewing The Images On Your Pc

    Viewing the Images on Your PC The software for viewing the images has already been installed on your PC (to replay the movies, you need to install QuickTime 4.1 or later). For Windows users: New [Removal Disk] icon appears by clicking the icon of [My Computer] window ●...

  • Page 34: For Macintosh Users

    Basic Operations For Macintosh users: 1 [Untitled folder] icon appears on the desktop. Double-click the icon to open it. Untitled folder ● The 100 in the folder [100KCBOX] means the number from 100 to 999. For the sequential number reset, see page 91. DISP.

  • Page 35: For Windows 2000

    3 Select [Kyocera Finecam L4 USB device]*, then click [OK]. ● If [Kyocera Finecam L4 USB device] won't appear, a different unit was selected. Click [Cancel] in this step, and return to step 2. Then select another [USB Mass Storage Device].

  • Page 36: For Macintosh

    Basic Operations For Macintosh: Click and drag the [Untitled Folder] folder on the Desktop to the garbage can. If you confirm that a message ìRemoving safelyî or the like appears, or that the [Untitled folderî does not appear, disconnect the USB cable and turn off the power switch of the camera. Cautions to be taken when the PC and the camera are connected ●...

  • Page 37: Removing The Driver

    1 Right-click the [My Computer] icon, then click [Properties]. 2 On the [System Properties] window, click the [Device Manager] tab. 5 Click [Other Devices] and click [Delete] of [? Kyocera Finecam L4] or [? Kyocera Finecam L3] with “?” mark.

  • Page 38: Printing Digital Images With A Dedicated Printer

    For printers supporting USB DIRECT – PRINT (only EPSON printers) Through this function, you can connect the digital camera to the printer using the USB cable to print an image. ● The printer is not available in some regions.
  • Page 39 “Single Print” : You can print the image one by one while checking the images displayed on the LCD monitor. “DPOF Print” : You can print a few images together. ● This instruction manual describes how to use the camera. For use of the printer, refer to the instruction manual of the printer.
  • Page 40 Basic Operations Select the direct print menu. Press Up or Down on the directional keypad to select the menu, and then press the execute button. To use [Single Print], select the image you want to print. Use the directional keypad to display the image you want to print.

  • Page 41: Shooting Technique

    Shooting Technique When you have learned in the section Basic Operation how to take a picture learn how to use this camera more effectively with the following techniques. Shooting Images Using Focus Lock Focus lock is a useful function when the subject you wish to bring into focus is not in the center of the LCD monitor, or when you wish to compose a picture away from the center.

  • Page 42: Subjects That Are Hard To Bring Into Focus

    Shooting Technique Subjects that are Hard to Bring Into Focus The following types of subjects are hard to bring into focus. Use the focus lock function to first focus on another subject at the same distance, then shoot the desired subject. ●...

  • Page 43: Saving Power By Shooting Images Using The Viewfinder

    Saving Power by Shooting Images Using the Viewfinder It is recommended to turn off the LCD monitor and shoot images using the viewfinder when you wish to save battery power. DISP. MENU Shooting Technique Pressing the “DISPLAY” button twice turns off the LCD monitor.

  • Page 44: How To Use The Display Button

    Shooting Technique How to Use the Display Button When setting functions in s or m mode, icons representing other than default settings are displayed on the LCD monitor. Although this is convenient for checking current settings, it may be difficult to use during shooting. Press the “DISP.” button to turn off icon displays if necessary.

  • Page 45: Using The Camera "S" Mode And Movie "M" Mode Functions

    Using the Camera “s” Mode and Movie “m” Mode Functions This camera is equipped with many functions for shooting. Use these functions to shoot images in accordance with surrounding conditions. Using Flash Functions This camera is equipped with an automatic flash function that judges the surrounding light conditions and determines whether or not flash is necessary.
  • Page 46 Using the Camera “s” Mode and Movie “m” Mode Functions Types of Flash Modes Auto Flash Mode (default) The camera judges surrounding light conditions to determine whether or not a flash is necessary. Red-Eye Reduction / Auto Flash Mode When people’s eyes appear red in images, it is called “red-eye” phenomenon. (See “What is red-eye phenomenon?”...

  • Page 47: What Is Red-Eye Phenomenon

    Using the Camera “s” Mode and Movie “m” Mode Functions Using Flash Functions (continued) What is red-eye phenomenon? Red-eye is a phenomenon where the pupils appear red due to reflection (retina reflection) of light entering the eye. Operation — setting to [ Turn on the power and set the mode select dial to “s”.

  • Page 48: ] Macro And Landscape Photography

    Using the Camera “s” Mode and Movie “m” Mode Functions ] Macro and Landscape Photography Use the macro mode when taking pictures of small subjects such as flowers or coins from a close distance. You can take pictures from a distance as close as about 20 cm (from the surface of the lens).

  • Page 49: Avoiding Camera Shake

    Using the Camera “s” Mode and Movie “m” Mode Functions Avoiding Camera Shake DISP. MENU What is Parallax? <Shift in the composition of the shot> Composition as viewed through Image actually the viewfinder recorded Shaking of the camera while taking a picture may cause the image to break up.

  • Page 50: [T] Using The Self-Timer

    Using the Camera “s” Mode and Movie “m” Mode Functions ] Using the Self-Timer The self-timer is a convenient function when you wish to include yourself in your pictures. The shutter is released 10 seconds or 2 seconds after pressing the shutter release button.

  • Page 51: ] Selecting Image Dimensions (Pixels)

    ● Since the setting for this mode is saved even if the power is turned off, it is necessary to reset the setting depending on the scene and subject to be shot. Movies Finecam L4 and Finecam L3 320x240 (default) 160x120...

  • Page 52: ] Setting Image Quality (File Compression)

    Using the Camera “s” Mode and Movie “m” Mode Functions [ ] Setting Image Quality (File Compression) Two compression ratios can be selected for the image quality: high compression [NORMAL] and low compression [FINE]. Although a lower compression ratio results in better picture quality, it also increases the size of files, thus reducing the number of images which can be recorded.

  • Page 53: Recording Capacity Based On Image Dimensions (Pixels) And Quality

    Using the Camera “s” Mode and Movie “m” Mode Functions Recording Capacity Based on Image Dimensions (Pixels) and Quality Image Dimensions Quality (Pixels) 2304x1728 Camera (L4 only) mode (still 2048x1536 images) (L3 only) 1600x1200 1280x960 640x480 320x240 Movie 160x120 mode F (fine) or N (normal) File size differs depending on the subject conditions.

  • Page 54: ] Exposure Compensation

    Using the Camera “s” Mode and Movie “m” Mode Functions [ ] Exposure Compensation Exposure compensation is used when you want to adjust brightness. Compensation up to 2.0EV is possible in steps of 0.3EV in both the “+” and “–” directions. Custom Exposure Compensation Operation —...

  • Page 55: [Wb] White Balance Setting

    Using the Camera “s” Mode and Movie “m” Mode Functions [WB] White Balance Setting The color of a subject varies depending on the light source. The color white is particularly affected by the light source. The adjustment used to make white look white is called “white balance.”...

  • Page 56: [Sm]/[Mm] [Color Mode] - Selecting Color, B/W Or Sepia Mode

    Using the Camera “s” Mode and Movie “m” Mode Functions [sM]/[mM] [COLOR MODE] — Selecting Color, B/W or Sepia Mode This function sets colors similar to photographs shot using sepia or monochrome film. No icon COLOR (default) [B/W] [SEPIA] SEPIA Operation —...

  • Page 57: [Sm][Chroma] - Changing The Contrast

    Using the Camera “s” Mode and Movie “m” Mode Functions [sM][CHROMA] — Changing the Contrast The [CHROMA] setting allows to shoot images with enhanced or reduced contrast. No icon STANDARD (default) – –1] Operation — setting to [+] Turn on the power and set the mode select dial to “s”. Press the MENU button to display the menu icons.

  • Page 58: [Sm][Sharpness] - Sharpening The Outline

    Using the Camera “s” Mode and Movie “m” Mode Functions [sM][SHARPNESS] — Sharpening the Outline Use this mode to enhance or soften the outline of the subject. No icon STANDARD (default) –1 –1] Operation — setting to [+2] Turn on the power and set the mode select dial to “s”. Press the MENU button to display the menu icons.

  • Page 59: [Sm]/[Mm][Wb Preset] - Setting White Balance Manually

    Using the Camera “s” Mode and Movie “m” Mode Functions [sM]/[mM][WB PRESET] — Setting White Balance Manually Use this mode if there are multiple light sources or you want to set white absolutely. Operation Prepare an object such as a piece of white paper for setting the standard for “white”. Turn on the power and set the mode select dial to “s”...

  • Page 60: [Sm][Ae Mode] - Selecting The Exposure Mode

    Using the Camera “s” Mode and Movie “m” Mode Functions [sM][AE MODE] — Selecting the Exposure Mode This function can be set to [PROGRAM] so that the camera automatically determines the aperture value and the shutter speed or to [F2.8] or [F7.5] so that the aperture value is fixed and the shutter speed is left up to the camera.

  • Page 61: [Sm]/[Mm][Focusing] - Selecting The Focus Mode

    Using the Camera “s” Mode and Movie “m” Mode Functions [sM]/[mM][FOCUSING] — Selecting the Focus Mode This function allows you to select the focus mode. You can select automatic focus modes [WIDE AF*] or [SPOT AF*] and manual focus mode [MF]. * AF: Auto focus WIDE AF SPOT AF...
  • Page 62 Using the Camera “s” Mode and Movie “m” Mode Functions Deciding the Focus Distance General guidelines for the focus distance ● Since the setting for this mode is saved even if the power is turned off, it is necessary to reset the setting depending on the scene and subject to be shot.

  • Page 63: [Sm][Long Exp.] - Slowing The Shutter Speed

    Using the Camera “s” Mode and Movie “m” Mode Functions [sM][LONG EXP.] — Slowing the Shutter Speed Slow the shutter speed when taking a shot of a starry night sky or small light (such as a candle) in the middle of darkness. The shutter speed is the length of time the shutter is open.

  • Page 64: [Sm][Iso] - Changing Iso Sensitivity To Shoot Subjects

    Using the Camera “s” Mode and Movie “m” Mode Functions [sM][ISO] — Changing ISO Sensitivity to Shoot Subjects [ISO] refers to sensitivity to light equivalent to the ISO sensitivity of film. The settings include [AUTO], [80], [160] and [320]. Sensitivity to light increases to allow shots in dark places or using a high-speed shutter.

  • Page 65: [Sm][Metering] - Selecting The Area To Be Exposed

    Using the Camera “s” Mode and Movie “m” Mode Functions [sM][METERING] — Selecting the Area to be Exposed In this mode, it is possible to select the area to be exposed. Three settings are available: [EVALUATION], [CENTER] and [SPOT AREA]. Use these settings depending on the subject.

  • Page 66: [Sm][Digital Zoom] - Using Digital Zoom Or Not

    Using the Camera “s” Mode and Movie “m” Mode Functions [sM][DIGITAL ZOOM] — Using Digital Zoom or Not When composing your picture, first press the “ ” button until the optical zoom is maximized, release and press it again to begin digital zooming. (page 42) Select [OFF] for not using digital zoom.

  • Page 67: Using Playback "P" Mode Functions

    Using Playback “p” Mode Functions Playback Mode is used to check images that have been shot. Playback Mode also includes functions for rotating images by 90°. [MULTI] Multiple Image Playback With multiple image display, it is possible to display six thumbnail images on the LCD monitor.
  • Page 68 Using Playback “p” Mode Functions Multiple Image Display and Operations Lock mark: Appears when the image is protected. To the previous image (in reverse order) Menu icons DPOF icon: Appears when the print setting is made for an image. Image No./Total images: Indicates the No.
  • Page 69 Erasing an Image on the Multiple Image Display. Press the MENU button to display the menu icons. Press Left or Right on the directional keypad to select [ERASE], then press the e button. Use the directional keypad to move the cursor to the image you wish to erase.

  • Page 70: [Protect] Protecting Images From Being Erased

    Using Playback “p” Mode Functions [PROTECT] Protecting Images from being Erased Important images can be protected against accidental erasure. ● You cannot use this operation while the SD memory card is write-protected. For write protect, see page 15. To protect images Turn on the power and set the mode select dial to “p”.

  • Page 71: [Erase All] Erasing All Images

    Use the directional keypad to select then press the e button. Press Left or Right on the directional keypad to select the image you wish to erase. Press Up on the directional keypad to select [EXE- CUTE], then press the e button to erase the image.

  • Page 72: [Resize] Resizing And Trimming Images

    Using Playback “p” Mode Functions [RESIZE] Resizing and Trimming Images You can change (resize) image dimensions and clip (trim) images. Since an image that has been resized or trimmed is saved as a new image, it is possible to keep the original image.
  • Page 73 Press Up or Down on the directional keypad to select the image size, then press the e button. The name of the resized image will be displayed. Press the e button after checking the name. Press the MENU button to finish the operation. Confirming and Deleting the Resized Image Resized images cannot be displayed in normal playback mode.

  • Page 74: [Rotate] Rotating Images

    Using Playback “p” Mode Functions [ROTATE] Rotating Images Images can be rotated 90° to either right or left. ● You cannot use this operation while the SD memory card is write-protected. For write protect, see page 15. To Rotate the Image to [ Turn on the power and set the mode select dial to “p”.

  • Page 75: [Auto Play] Automatic Playback

    [AUTO PLAY] Automatic Playback This function plays back images automatically at set intervals. Operation Turn on the power and set the mode select dial to “p”. Press the MENU button to display the menu icons. Press Left or Right on the directional keypad to select [AUTO PLAY], then press the e button.

  • Page 76: [Print] Digital Print Order Format (Dpof) Setting

    Using Playback “p” Mode Functions [PRINT] Digital Print Order Format (DPOF) Setting Digital Print Order Format (DPOF) is a standard used when printing digital photographs on a home printer or by a commercial printing service. The function is a simple way of specifying the number of copies to be printed, the need for date imprinting, and so on.
  • Page 77 Set the number of prints. 1 Press Up or Down on the directional keypad to select [PRINT QTY], then press Right on the directional keypad. 2 Press Up or Down on the directional keypad to set the number of prints, then press the e button. Set to print the date or not.
  • Page 78 Using Playback “p” Mode Functions Setting an Index Print You can print an index of images recorded in the memory card. Before proceeding, perform steps 1 to 3 of “Setting the DPOF”. Press Up or Down on the directional keypad to select [INDEX], then press Right on the directional keypad.

  • Page 79: A Useful Way To Erase Images Using The Protect And All Erase Functions

    A Useful Way to Erase Images Using the Protect and All Erase Functions If, for example, you have recorded 100 images and you only want to keep 5 or 6 of them, erasing the unwanted images one at a time is difficult work. If you have recorded a lot of images and only wish to keep a few, use [PROTECT] and [ERASE ALL] to make the operation easier.

  • Page 80: Using Setup "Set Up" Mode Functions

    Using Setup “SET UP” Mode Functions such as setting the date and formatting the memory card are only performed infrequently, but they are convenient and important functions. Such functions are included in “SET UP” mode. [BRIGHT CNTRL] Setting Brightness of the LCD Monitor This function adjusts brightness of the LCD monitor.

  • Page 81: [Insert Date] Setting To Write The Date In The Image

    [INSERT DATE] Setting to Write the Date in the Image Use this function if you want the date to be written in the image. Once the function is set to [WITH DATE], the date is written in images when shooting. [WITH DATE] The date is written in images when shooting.

  • Page 82: [Format] Formatting The Memory Card

    Using Setup “SET UP” Mode Functions [FORMAT] Formatting the Memory Card Use this function before using a new memory card or when erasing all data including images. Operation to format a memory card. Turn on the power and set the mode select dial to “SET UP”.
  • Page 83 Operation — setting to [1MIN.] Turn on the power and set the mode select dial to “SET UP”. Press Up or Down on the directional keypad to select [POWER SAVE], then press Right on the directional keypad. Press Up on the directional keypad to select the length of time before power is turned off, then press the e button to complete the setting.

  • Page 84: [Mode Lock] Preserving The Mode Settings

    Using Setup “SET UP” Mode Functions [MODE LOCK] Preserving the Mode Settings This function preserves the camera mode functions set in the “s”, “m” or "SET UP" mode when the power is turned OFF. (page 99) [ON] Mode settings are preserved even if the power is turned off. [OFF] Mode settings will be returned to their default values when the (default)

  • Page 85: [Custom Set.] Setting A Function To The (+) And (-) Button

    [CUSTOM SET.] Setting a function to the (+) and (–) button. You can set the functions for handling any of the [LCD BRIGHT], [EX COMP] or [W BALANCE] to the + and – buttons. By pressing these buttons on [Multiple Image Display] in camera modes “s” or in movie modes “m”, the function set just before shooting can be controlled.
  • Page 86 Using Setup “SET UP” Mode Functions Operations when [LCD BRIGHT] is selected You can use this function in camera modes or in movie modes. Operation Turn on the power first and set the [CUSTOM SET.] in Setup modes to [LCD BRIGHT].
  • Page 87 Select the exposure compensation value by pressing the (+) or (–) button. By pressing the (+) button, you can increase the exposure to +2.0 in +0.3 (EV) increments. By pressing the (–) button, you can decrease the exposure to –2.0 in –0.3 (EV) increments.

  • Page 88: [Color Select] Setting The Color Of Menu Display

    Using Setup “SET UP” Mode Functions Operation Turn on the power first and set the [CUSTOM SET.] in Setup modes to [W BALANCE]. Set the mode select dial to “s” or “m”. Select the white balance type by pressing the (+) or (–) button. When pressing the (+) button When pressing the (–) button AUTO...

  • Page 89: [Start Screen] Selecting The Startup Screen

    [START SCREEN] Selecting the Startup Screen There are three types of startup screen. KYOCERA logo screen Customized screen [OFF] Operation Turn on the power and set the mode select dial to “SET UP”. Press Up or Down on the directional keypad to select [START SCREEN], then press Right on the directional keypad.

  • Page 90: [Rec Review] Reviewing The Image Just After Shooting

    Using Setup “SET UP” Mode Functions [REC REVIEW] Reviewing the Image Just after Shooting You can display the image for a few seconds immediately after shooting. [OFF] [2SEC] (default) [4SEC] Operation — setting to [OFF] Turn on the power and set the mode select dial to “SET UP”. Press Up or Down on the directional keypad to select [REC REVIEW], then press Right on the directional keypad.

  • Page 91: [File No.] Resetting The File Number To 0001

    [FILE NO.] Resetting the File Number to 0001 The images are stored as files with consecutive numbers in the order images have been shot. These files are stored in the “100KCBOX” folder. If the consecutive file number is reset, a new folder is created on the memory card and a consecutive number starting from 0001 is attached to the new files placed in the new folder.

  • Page 92: [Mode Reset] Restoring Default Settings Of Functions

    Using Setup “SET UP” Mode Functions [MODE RESET] Restoring Default Settings of Functions Use this mode when restoring modes and menus to default settings. Operation — Restoring the default settings Turn on the power and set the mode select dial to “SET UP”.

  • Page 93: Appendix

    Troubleshooting Symptom Battery power is depleted or the battery pack is not inserted. The auto-off function has operated to turn power off. (page 82) Setting of power-save function may cause camera to enter sleep mode when it is inactive for set period. LCD doesn’t appear.
  • Page 94 Appendix Symptom The camera feels hot. Caution LED flashes slowly. Caution LED flashes rapidly. Focus can’t be set. Standby LED flashes. Focus mark flashes. Everything appears as a white screen. Image cannot be rotated, set for DPOF, protected or resized. The message “WRITE PROTECT”...
  • Page 95 Messages and Remedies Message “MEMORY CARD FULL” The memory card has insufficient free memory available. “NO CARD” No memory card is loaded. “WRITE PROTECT” The write protect switch is activated (SD memory card). The inserted memory card has been formatted in a different camera or information device.

  • Page 96: List Of Menus And Icons Displayed On The Lcd Monitor

    Appendix List of Menus and Icons Displayed on the LCD Monitor Display when the Camera “s” or Movie “m” mode is selected Camera mode 2048 1Flash mode (page 45) 2White balance mode/color mode (page 55/page 56) 3Metering mode (page 65) 4Focus mark (lights green when focus is set.

  • Page 97: Display When Playback "P" Mode Is Selected

    Display when [SET DETAILS] in Camera “s” or Movie “m” mode is selected Menus appear. Camera mode (page 56) (page 57) COLOR MODE COLOR CHROMA STANDARD (page 58) SHARPNESS STANDARD WB PRESET (page 59) AE MODE PROGRAM SETTINGS (1/2) (page 60) (page 61) (page 63) FOCUSING...
  • Page 98 Appendix Display when “SET UP” mode is selected The setup menu is displayed. BRIGHT CNTRL STANDARD DATE INSERT DATE FORMAT POWER SAVE MODE LOCK BEEP CUSTOM SET. COLOR SELECT START SCREEN REC REVIEW LANGUAGE ENGLISH FILE NO. MODE RESET (page 80) SET UP(1/3) (page 16) 2003.01.01...

  • Page 99: Led Indication And Camera Status

    LED Indication and Camera Status There are 5 LEDs on the camera. Each LED indicates the status of the camera depending on how it lights or flashes. Front illumination (Blue / Red) Self-timer LED (Red) Flashes Lights Each LED lights after the power of the camera is turned on, after a mode is selected or when the camera is connected to the PC.

  • Page 100: Caution Led (Red)

    Appendix Memory card access LED (orange) ISP. Flashes Standby LED (green) Camera “s” mode /Movie “m” mode Caution LED (red) Camera “s” mode Flashes while the camera is accessing the memory card, such as recording images to memory card or reading data. ●...

  • Page 101: List Of Menu Modes That Can Be Locked And Default Settings

    List of Menu modes that can be locked and default settings Mode s Flash s/m Macro/Landscape s/m SELF TIMER s PIXELS (L4) s PIXELS (L3) m PIXELS s QUALITY s/m EXP.COMP “s” Camera s/m WHITE BALANCE Mode/ s/m SET DETAILS → COLOR MODE “m”...

  • Page 102: Optional Accessories

    ● The AC adapter has been designed for exclusive use with this camera. To prevent the danger of fire and electrical shock, do not use the adapter with products other than the specific digital camera for which it was designed.

  • Page 103: Pay Attention To Your Selection Of [Long Exp.] And [Iso]

    There are 4-type AC cables. Shape of Plug Socket Type Terminal front ● If you use the adapter other than the countries specified in the table, check the voltage and shape of plug socket for the country. ● In some regions, more than one type of plug sockets can be used. (For example, you can use C type as well as BF type in a certain area of England.) Pay attention to your selection of [LONG EXP.] and [ISO].

  • Page 104: Specifications

    Video feedback auto focusing and manual focusing True image zoom viewfinder Field of view ratio: 80% or more (within 3 m) Magnification: About 0.3x (wide angle) to about 0.8x (telephoto) L4: Finecam L4 L3: Finecam L3 to 64.5 cm* (fixed to wide-...
  • Page 105 Flash: Built-in flash, recycling time about 8 seconds(with new batteries, at room temperature, based on our testing standards). Flash range (from CCD) about 64.5 cm* wide). :About 20 cm away from the front side of the lens :About 60 cm away from the front side of the lens Camera modes: Flash modes (auto flash, red eye reduction, fill in flash, flash off, night backdrop, *...
  • Page 106 Appendix <Display> LCD monitor display: Self-timer LED (red): Card access LED (orange): Standby LED (green): Caution LED (red): Front illumination: <Input, Output> Input output connector: <Battery Power> Power: Battery capacity: <Other> Ambient operating temperature:0°C to 45°C Dimensions: Weight: *All descriptions and specifications are subject to change without notice. Remaining battery capacity;...

This manual is also suitable for:

Finecam l3

Table of Contents
