These instructions are provided as a quick start for programming the PDI-P23LCDC television.
The instructions assume you have installed the TV on the wall, correctly wired and connected a
compatible pillow speaker, and have the programming remote control in hand. See the User's
Manual for details.

Channel Setup

The TV offers three different programmable channel banks or Service Levels. Programming is
only accomplished using the handheld remote control.

Signal

Four different tuning types are available depending upon the healthcare facilities signal style.
Selection of the correct signal type is required for the TV to recognize all possible channels and
before any channel programming can begin.
1. Press the SETUP button to display the SETUP MODE menu.
2. Press the CH▲ / CH▼ button to select Signal.
3. Press VOL◄ / VOL► to select Air, Cable STD, Cable IRC or Cable HRC. NOTE: Most
hospitals use the Cable STD signal style.
4. Press the CH▲ / CH▼ button to select Mode.
5. Press VOL◄ / VOL► to set the scope of channel scanning.
Analog Only: TV searches for analog channels only.
Digital Only: TV searched for digital channels only.
Analog and Digital: TV searches for both analog and digital channels.
PDI-P23LCDC Quick Programming
Instructions
Page 1 of 3
Document Number PD196-121 Rev 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PDI-P23LCDC and is the answer not in the manual?

Questions and answers

Summary of Contents for PDi PDI-P23LCDC

  • Page 1: Channel Setup

    Document Number PD196-121 Rev 1 Better Solutions Are Within Reach™ These instructions are provided as a quick start for programming the PDI-P23LCDC television. The instructions assume you have installed the TV on the wall, correctly wired and connected a compatible pillow speaker, and have the programming remote control in hand. See the User’s Manual for details.
  • Page 2 Page 2 of 3 Communication PDI-P23LCDC Quick Programming Systems Inc. Instructions Document Number PD196-121 Rev 1 Better Solutions Are Within Reach™ 6. Press the CH▲ / CH▼ button to select the Channel Sequence menu item. 7. Press VOL◄ / VOL► to set the Channel Sequence in which the channels are displayed after searching.
  • Page 3: Minimum Volume

    Page 3 of 3 Communication PDI-P23LCDC Quick Programming Systems Inc. Instructions Document Number PD196-121 Rev 1 Better Solutions Are Within Reach™ Minimum Volume Sets the minimum volume level the TV can reach. Setting this to any value other than 0 guarantees that some level of sound will always be heard in the pillow speaker when the TV is operating.
