Silicon Solar AquaJet-Pro-PUMP69 User Manual

1. OVERVIEW

1） The brushless water pump is designed for outdoor or indoor fountain use, and is powered by DC power supply
such as solar module, rechargeable battery or AC/DC adapter etc.
2） While using solar power, the solar module needs to be placed in the sunlight facing
the sun, and the performance of the pump depends on the sunlight intensity and the
angle of incident light.
3） The pump introduces the latest DC brushless motor technology, it has long service
life.
4） The pump has built-in function of dry-run protection. Two sensor points are provided
on the side of the housing for this. The pump works if these points are under water.
If a point projects out of the water, the pump does not work.

2. COMPONENTS

1） Pump

3. ASSEMBLING

1） Connect the pump to the related DC
power supply.
2） For the application of producing
waterfall feature in small garden water
decorations, fit the pump outlet to the
water inlet of the decoration.
3） For the application of creating a small
spraying up fountain, just fix the pump
at the base of a basin or small shallow
pond etc.
4） Connect the fountain nozzles to the
pump outlet tube according to the above photo; the attached nozzles can
produce 4 different jet shapes.
5） To produce excellent fountain effect, please leave the fountain head above the
water surface using the extension tubes. If these 4pcs of extension tubes are
all used and the pump head is still immerged in the water, please uplift the
pump body somehow.
6） It can easily create a floating fountain by the optional floating disk according to the above photo.
7） Make sure to place the pump fully underwater when the pump operates.
SOLAR PUMP USER'S MANUAL
AquaJet Solar Pump
SKU: AquaJet-Pro-PUMP69
2）Nozzle (Optional)
Innovative Solar Solutions | 2917 State Hwy 7, Bainbridge, N.Y. 13733 | Ph: 800.786.0329 | www.SiliconSolar.com
3）Floating disk (Optional)
