Paper
A B C
Size
A3 9920 7014 9684
B4 8597 6070 8361
A4 7014 4960 6778
B5 6070 4298 5830
A5 4960 3508 4720
Ledger 8400 5100 8160
Legal 8400 5100 8160
Letter 6600 5100 6360
Invoice 5100 3300 2860
Foolscap 7800 5100 7560
Folio 7800 4980 7560
Executive 6300 4350 6060
COM-10 5700 2474 3460
C5 5408 3826 5172
DL 5196 2598 4960
2. IMC2 board functions
*Sort function (Electronic sort) 100 sheets (max. 765 sheets) <copy mode> with A4 standard documents at 600dpi. Offset paper exit by the shifter
*Group function
Rotation copy
2 in 1, 4 in 1
Edge erase
Center erase
Margin shift
Memory for electronic sort
*Memory read capacity
Memory expansion
USB2.0
SPLC (JBIG-GDI)
ROPM
Caution: The number of sheets for the columns marked with "*" is calculated supposing that the same quantity is assigned to the ROPM memory and
the copy expansion memory.
Actual page
size
Print area
Logic paper
size
HP/GL
frame
D E F G
118 100 300 9720
118 100 300 8397
118 100 300 6814
118 100 300 5870
118 100 300 4760
120 100 300 8200
120 100 300 8200
120 100 300 6400
120 100 300 4900
120 100 300 7600
120 100 300 7600
120 100 300 6100
120 100 300 5500
118 100 300 5208
118 100 300 4996
function
100 sheets (max. 765 sheets) <copy mode> with A4 standard documents at 600dpi. Offset paper exit by the shifter
function
If there is paper of the same size as the document, the image is rotated to copy even though the paper is set in the
different direction from the document direction.
Copies of 2 pages or 4 pages are integrated into one surface. Divided by solid lines, (Selectable by the user pro-
gram.)
Images surrounding the document are erased when copying. (Adjustable in 5 ~ 20mm by the user program.)
The image at the center is erased when copying. (Adjustable in 5 ~ 20mm by the user program.)
Binding margin is made at the left edge of the set documents. (Adjustable in 5 ~ 20mm by the user program.)
16MB
600dpi: 100 sheets (Max. 765 sheets) <copy mode> of A4 standard documents (Sharp A4 standard document)
DIMM memory slot x 1, max. 256MB x 1 slot + 16MB (Max. 272MB in total)
Standard provision of E-sort (It can be used according to conditions.)
Supported when E-sort is installed.
Supported when E-sort is installed.
AR-EB7 SPECIFICATIONS
*Top margin
The set value is received from the digital copier, and data are made
according to the set value.
*Left margin
Since the paper size sensor is not set, the digital copier cannot recog-
nize the size and direction of paper which is actually inserted.
Therefore, the left margin is set according to the paper size specified
in the print data sent from the computer, and print process is per-
formed.
If the computer does not specify the paper size, or in the case of the
custom size, the left margin is set according to the default paper size.
(7) Print reference
This machine employs the center reference system.
Since the digital copier is not provided with the tray size detection fea-
H ture, formatting and center distribution are performed not by the actual
paper size but by the paper size specified by the computer.
0
0
Origin
0
0
0
0
0
0
0
0
0
0
D. Interface
0
Interface
0
0
– 3 –
Actual paper size
Size specified by the HOST
Center reference line
USB 1.1 (Standard)
USB 2.0 High speed
(With the AR-EB7 installed))
