Page 1: Operating Instructions
OPERATING INSTRUCTIONS WP3214SMWI COLOUR TELEVISION WITH REMOTE CONTROL BE WALKER WISE...logon to www.walker.ie... -
Page 2: Table Of Contents
Contents Safety Information ..........2 Getting Started ............3 Notifications & Features & Accessories ....3 Remote Control - 1 ..........6 Connections............7 First Time Installation - USB Connections ....8 TV Menu Features and Functions ......12 General TV Operation .......... 15 Software Upgrade.......... -
Page 3: Safety Information
Safety Information In extreme weather (storms, lightning) and long CAUTION inactivity periods (going on holiday) disconnect the TV set from the mains. The mains plug RISK OF ELECTRIC SHOCK is used to disconnect TV set from the mains DO NOT OPEN and therefore it must remain readily operable. -
Page 4: Getting Started
Getting Started Notifications & Features & Accessories • Automatic programming system Environmental Information • Manual tuning This television is designed to consume less energy • Automatic power down after up to six hours to help save the environment. To reduce energy consumption, you should take the following steps: •... - Page 5 Notification TV Control Switch & Operation TRADEMARK ACKNOWLEDGMENT Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. The terms HDMI and High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
-
Page 6: Digital Teletext
Specification TV Broadcasting PAL SECAM BG/I/DK/LL’ Receiving Channels VHF (BAND I/III) - UHF (BAND U) - HYPERBAND Digital Reception Fully integrated digital terrestrial-cable-satellite TV(DVB-T/C/S2) Number of Preset 10000 Channels Channel Indicator On Screen Display RF Aerial Input 75 Ohm (unbalanced) Operating Voltage 220-240V AC, 50Hz. -
Page 7: Remote Control - 1
Getting Started Remote Control - 1 1. Source 2. Launches Netflix Application 3. Internet Portal 4. Play ( in media browser mode ) SOURCE 5. Programme recording 6. Rapid reverse ( in media browser mode ) LANG. 7. Mono/Stereo - Dual I-II / Current language (in DVB channels) .,/@ 8. -
Page 8: Connections
Getting Started Connections Connector Type Cables Device NOTE: When connecting a device via the YPbPr or Scart S i d e AV i n p u t , y o u m u s t Connection u s e c o n n e c t i o n c a b l e s t o (back) enable connection. -
Page 9: First Time Installation - Usb Connections
Getting Started First Time Installation - USB Connections While the search continues a message will appear, Switching On/Off asking whether you want to sort channels according To Switch the TV On to the LCN(*). Select Yes and press OK to confirm. Connect the power cord to the 220-240V AC 50 Hz. - Page 10 Recording a Programme Using SatcoDX Feature IMPORTANT: When using a new USB hard disk drive, You can perform SatcoDX operations using the it is recommended that you first format the disk using Satelite Settings menu. In the SatcoDX menu, there your TV’s “Format Disk”...
-
Page 11: Slow Forward
Instant Recording Media Browser Menu Press Record button to start recording an event You can play photo, music and movie files stored instantly while watching a programme. You can on a USB disk by connecting it to your TV. Connect press Record button on the remote control again to a USB disk to one of the USB inputs located on the record the next event on the EPG. - Page 12 To terminate this operation and control the TV Quick Menu via the remote again, press and hold the “0-Zero” The Quick Settings menu allows you to access some button on the remote control for 3 seconds. Or press options quickly. This menu includes Power Save Mode, Q.Menu button on the remote, highlight the CEC Picture Mode, Equalizer Settings, Favourites, Sleep RC Passthrough and set as Off by pressing Left...
-
Page 13: Tv Menu Features And Functions
TV Menu Features and Functions Picture Menu Contents You can change the picture mode to suit your preference or requirements. Picture mode can Mode be set to one of these options: Cinema, Game, Sports, Dynamic and Natural. Contrast Adjusts the light and dark values on the screen. Brightness Adjusts the brightness values on the screen. - Page 14 Sound Menu Contents Volume Adjusts the volume level. Selects the equalizer mode. Custom settings can be made only when in user Equalizer mode. Balance Adjusts whether the sound comes from the left or right speaker. Headphone Sets headphone volume. Sound Mode You can select a sound mode (If the viewed channel supports).
- Page 15 A norration track will be played for the blind or visually impaired audience. This feature Audio is available only if the broadcaster supports it. Description Note: Audio description sound feature is not available in recording or time shifting mode. Sets the desired time for the TV to automatically go into standby mode when not being Auto TV Off operated.
-
Page 16: General Tv Operation
General TV Operation Using the Channel List SUBTTL: Press “ ” button to view Select Genre menu. Using this feature, you can search the The TV sorts all stored stations in the Channel List. programme guide database in accordance with the You can edit this channel list, set favourites or set genre. -
Page 17: Software Upgrade
Input sources - can not be selected Software Upgrade • If you cannot select an input source, it is possible Your TV is capable of finding and updating automatically that no device is connected. If not; via the broadcast signal. •... -
Page 18: Pc Input Typical Display Modes
PC Input Typical Display Modes AV and HDMI Signal Compatibility The following table is an illustration of some of the Source Supported Signals Available typical video display modes. Your TV may not support all resolutions. NTSC 60 Index Resolution Frequency (SCART) RGB 50/60 640x350... - Page 19 Supported File Formats for USB Mode Media Extension Format Notes Video .dat, .mpg, Mpeg1-2 1080P@30fps, 50Mbit/sec .mpeg .ts, .trp, MPEG2 , H.264, H.264:1080Px2@25fps, 1080P@50fps MVC:1080P@ 24fps Other: 1080P@30fps - .tp, .m2ts VC1, AVS, MVC 50Mbit/sec .vob MPEG2 1080P@30fps 50Mbit/sec .mkv MPEG1-2-4, H.264:1080Px2@25fps, 1080P@ 50fps, 1080P@30fps, 50Mbit/sec H.264...
-
Page 20: Supported Dvi Resolutions
Supported DVI Resolutions When connecting devices to your TV’s connectors by using DVI converter cable(DVI to HDMI cable - not supplied), you can refer to the following resolution information. 56Hz 60Hz 66Hz 70Hz 72Hz 75Hz 640x400 þ 640x480 þ þ þ... - Page 21 Configuring Wired Device Settings Connectivity Network Type The Network type can be selected as Wired or Wireless Wired Connectivity Device, in accordance with the active connection to the To Connect to a Wired Network TV set. Select this as Wired Device if you are connecting •...
-
Page 22: Connection Is Slow
Delete Saved Wi-Fi Profiles • The frequency and channel differ depending on the area. • The transmission speed differs depending on the Saved profiles will be deleted if you press the Red button distance and number of obstructions between the while the wireless device selection OSD is on the screen. transmission products, the configuration of these Connecting to your mobile device via WiFi products, the radio wave conditions, the line traffic... - Page 23 You can connect only one television with DLNA to Using DLNA Network Service the same network. If a problem occurs with the DLNA DLNA (Digital Living Network Alliance) is a standard network, please switch your television off at the wall that eases the viewing process of digital electronics and socket and back on again.
- Page 24 Internet Portal(OEM) HINT: A Broadband internet connection is required for high quality viewing. You must set the Country and Language data correctly in the First Time Installation for proper operation of the internet portal. Ensure the TV is connected to a Wired/Wireless(if available) network.
-
Page 25: Internet Browser
Internet Browser To use the internet browser, please select the internet browser logo from the portal section. • To navigate the web browser, use the arrow buttons pages and these will take you to the appropriate on the remote control. Press OK to continue. pages. -
Page 26: Getting Started With Skype
Getting Started with Skype Make voice calls and video calls with Skype on your TV. Select the Skype app from the portal section to start a conversation. Follow the on screen instructions to see how to operate related features. NOTE •... - Page 27 Sign In & Sign Up Now To use the Skype application, you need a Skype account. You can create a Skype account, using this app, in the ‘Sign In & Sign Up Now’ menu if you don’t already have one. If you already have a Skype account, enter your name and password correctly.
- Page 28 Adding a contact By pressing the button select Search Contacts option. Enter full name, skype name or email address to find and add. Use remote control or virtual keyboard to enter keyword. Recent history Incoming call Outgoing call Missed call Icon meaning Skype history can be seen in this section.
- Page 29 Actions A c c o u n t N a m e , O n l i n e Select a Menu by pressing the button. mood message and status profile picture. Your contact list (Press Ok to use video&voice call) Help bar Select a person from contact list screen and press OK.
- Page 30 Incoming call Incoming call dialog is shown when you are logged into Skype and other user initiates Skype call. A small dialog box will appear in lower right corner of TV screen whether user watches TV or is browsing through Skype. Use the remote control button and choose your action.
-
Page 31: Important Instruction
Important Instruction For your own safety read following instruction carefully before attempting to connect this unit to the mains supply. MAINS (AC) OPERATION The wires in the mains lead are coloured in accordance with the following code : GREEN & FUSE YELLOW (Earth) - Page 32 Product Fiche Commercial Brand: Walker Product No. 10092348 Model No. WP3214SMWI Energy efficiency class Visible screen size 32 inches 81 cm (diagonal, approx.) (inch/cm) On mode average power consumption (Watt) Annual energy consumption (kWh/annum) Standby power consumption (Watt) Off mode power consumption...
- Page 33 WALKER Executive House, Red Cow, Naas Road, Dublin 22 Rebuplic of Ireland 50284210...
