Page 2: Table Of Contents
Contents Features ..............2 Adding Locks to Channels ........ 16 Introduction ............. 2 Setting Favourites ..........16 Accessories ............2 Program Guide ..........16 Preparation ............. 2 Timers ............... 16 Safety Precautions ..........2 Common Interface ........... 16 Power Source ............. 2 TV Setup ............ -
Page 3: Features
Features Accessories • Remote controlled colour LCD TV. • Fully integrated digital TV (DVB-T - MPEG2) (DVB-T- MPEG4). • DTV input supports 1920x1080i. • HDMI connectors for digital video and audio. This connection is also designed to accept high defi nition signals. -
Page 4: Moisture And Water
Servicing power cord by the plug. Do not unplug the appliance by pulling from the power cord and never touch the Please refer all servicing to qualified power cord with wet hands as this could cause a short personnel. Do not remove the cover circuit or electric shock. -
Page 5: Warning
Warning Switching the TV On/Off Do not leave your TV in standby or operating mode To Switch the TV On when you leave your house. • Connect the power cord to the 220-240V AC, 50 Connection to a Television Distribution System (Cable TV etc.) •... -
Page 6: Environmental Information
Environmental Information • This television is designed to consume less energy to save environment. You not only help to save the environment but also you can save money by reducing electricity bills thanks to the energy effi ciency feauture of this TV. To reduce energy consumption, you should take the following steps: •... -
Page 7: Overview Of The Remote Control
Overview of the Remote Control Standby Yellow (Audio language (in DTV mode) (*) / Feature menu) Blue (Install menu) Previous programme / Swap Cursor up Cursor right Cursor down TV / Digital TV Mono/Stereo - Dual I-II Programme up/down Numeric buttons Exit (in DTV mode) Hold (in TXT mode) / PIP position Update (in TXT mode) / PAP mode... -
Page 8: Lcd Tv And Operating Buttons
LCD TV and Operating Buttons FRONT and REAR VIEW SIDE VIEW Control Buttons Standby button TV/AV button Programme Up/Down buttons Volume Up/Down buttons Note: Press “ ” and buttons at the same time to view main menu. Viewing the Connections- Back Connectors 1. - Page 9 Note: If an external device is connected via the SCART sockets, the TV will automatically switch to AV mode. If both sockets are employed at the same time, SCART 1 will override SCART 2 unless manually selected. Note: You should connect the decoder to EXT-1, if you are planning to watch a scrambled channel. The decoder might not function properly if you do not connect the decoder to the Scart 1 (Ext-1) socket.
-
Page 10: Viewing The Connections - Side Connectors
Viewing the Connections - Side Connectors CI Slot is used for inserting a CI card. A CI card allows you to view all the channels that you subscribe to. For more information, see “Common Interface” section. Side USB input . Note: Codec update cannot be performed. -
Page 11: Using Digital Multimedia Connectors
Using Digital Multimedia Connecting the LCD TV to a PC Connectors For displaying your computer’s screen image on your LCD TV, you can connect your computer to the •You can connect USB devices to your TV by using TV set. the USB input of the TV. -
Page 12: Connecting To A Dvd Player
Connecting to a DVD Player Using Side AV Connectors If you want to connect a DVD player to your LCD You can connect a range of optional equipment TV, you can use connectors of the TV set. DVD to your LCD TV. Possible connections are shown players may have different connectors. -
Page 13: Input Selection
functions will be described in accordance with the Input Selection menu system of your TV. Once you have connected external systems to your • Functions of the menu system are described in the TV, you can switch to different input sources. following sections. -
Page 14: General Operation
To search for analogue channels, select “Yes”. TV switches to the analogue TV mode. A menu will be displayed to search for analogue channels . Set Language item by pressing “ ” or “ ” button. Press “ ” or “ ” button to highlight Country item and If an active antenna is connected to your TV, you can then use “... -
Page 15: Programme Options
• Press “ ” or “ ” buttons to navigate through Over Air Download channels. To ensure that your IDTV always has the most up- • Press “ ” or “ ” buttons to navigate through the to-date information, please ensure that, after use, programme list. -
Page 16: Idtv Menu System
IDTV Menu System • Press “M” button and DTV main menu will be displayed. Select “YES” to continue. Select “NO” to cancel (LCN feature is available for only Germany, Austria, Switzerland and Italy country options). Deleting the Channels in the Channel List •... -
Page 17: Adding Locks To Channels
Program Guide highlighted character with the characters printed above the key one by one as the button is pressed. This section is same with the instructions given in Press the “M” button to cancel the editing or OK the General Operations page. Please see Electronic button to save the new name. -
Page 18: Tv Setup
• Insert the CAM, and then the viewing card to the slot. • The CAM should be correctly inserted, it is impossible to insert fully if reversed. The CAM or the TV terminal may be damaged if the CAM is forcefully inserted. •... -
Page 19: Time Settings(**)
When set, this option gets the maturity information Receiver Upgrade from the broadcast and if this maturity level is disabled, Over Air Download (OAD) the TV will not display the related video-audio. To ensure that your TV always has the most up to date Menu Lock information, use this setting. -
Page 20: Language Settings
Use “ ” or “ ” button to select Standby Search and select “TV Only”, with the “ ” or “ ” buttons, you then press “ ” or “ ” button to set this setting as On or navigate through only TV channels. If you select Off. -
Page 21: Installation
while viewing a media fi le via Media Browser use this Set Language item by pressing “ ” or “ ” button. setting to select a movie subtitle language. Press “ ” or “ ” button to highlight Country item and then use “... -
Page 22: Media Browser (In Dtv Mode)
Note: If the USB stick is not recognized after Power off/on or First Time Installation, fi rst plug the USB device out and power off/on the TV set. Plug the USB device again. After factory settings are loaded, “First Time Installation”... -
Page 23: Video Playback (Optional)
Play / Slideshow (GREEN) : start to slideshow with Analogue TV Menu System all pictures in the folder. Picture Menu Slideshow Options Pause (YELLOW) : Pause the slideshow. Mode Continue (GREEN) : Continue with the slideshow. For your viewing requirements, you can set the related mode option. -
Page 24: Sound Menu
Sound Menu Note : • Setting Cool option gives white colours a slight blue stress. • Setting Warm option gives white colours a slight red stress. • For normal colours, select Normal option. Noise Reduction If the broadcast signal is weak and the picture is noisy, use Noise Reduction setting to reduce the noise amount. -
Page 25: Feature Menu
Volume If you select to Audio Out as “Speaker” by using “ ” or “ ” button, you can get audio through the Press “ ” or “ ” button to select Volume . Press “ TV’s speakers. ” button to increase headphone volume level. Press Dolby Virtual Speaker (optional) “... -
Page 26: Child Lock
Movie Sense (optional) Select PIP Position item by using “ ” or “ ” button. Use “ ” or “ ” button to adjust PIP Press “ ” or “ ” button to select Movie Sense. position. Use “ ” or “ ” to set Movie Sense Low, Med, High or Positions available are: Bottom Right,Bottom Left, Top Off. -
Page 27: Install Menu
Blue Background Ext Out If the signal is weak or absent, the TV will automatically Press “ ” or “ ” button to select Ext Out. Use “ ” or change to a blue screen. To enable this, set Blue “... -
Page 28: Program Table
Store Move Press “ ” or “ ” button to select Store. Press “ ” Select the programme which you want to insert by or OK button to store the settings. “ Stored... ” will be navigation buttons. Press the GREEN button. By displayed on the screen. -
Page 29: Source Menu
Source Menu Select Autoposition item by using “ ” or “ ” buttons. Press OK or “ ”, “ ” button. Press “ ” or “ ” button and select the sixth icon. Warning : Please ensure auto adjustment is performed Then press “... -
Page 30: Displaying Tv Information
Displaying TV Information Zoom Modes Programme Number , Programme Name , Sound You can change the aspect ratio (image size) of the TV Indicator and Zoom Mode information is displayed for viewing the picture in different zoom modes. on the screen when a new programme is entered or Press “... -
Page 31: Cinema
Teletext Teletext system transmits information such as news, sports and weather on your TV. Note that is the signal degrades, for example in poor/adverse weather Cinema conditions, some text errors may occur or the teletext This zooms up the wide picture (16:9 aspect ratio) to mode may be aborted. -
Page 32: Tips
Remote Control Tips Your TV no longer responds to the remote control. Screen Care Perhaps the batteries are exhausted. If so you can still Clean the screen with a slightly damp, soft cloth. Do use the local buttons at the bottom of the TV. not use abrasive solvents as they may damage the Input Sources coating layer of the TV screen. -
Page 33: Appendix A: Pc Input Typical Display Modes
Appendix A: PC Input Typical Display Modes The display has a maximum resolution of 1920 x 1200 . The following table is an illustration of some of the typical video display modes. Your TV may not support different resolutions. Supported resolution modes are listed below. If you switch your PC to an unsupported mode, a warning OSD will appear on the screen. -
Page 34: Appendix B: Av And Hdmi Signal Compatibility (Input Signal Types)
Appendix B: AV and HDMI Signal Compatibility (Input Signal Types) Source Supported Signals Available PAL 50/60 NTSC 60 EXT-1 (SCART 1) RGB 50 RGB 60 PAL 50/60 NTSC 60 EXT-2 (SCART-2) RGB 50 RGB 60 PAL 50/60 NTSC 60 480I 60Hz 480P 60Hz... -
Page 35: Appendix C: Pip/Pap Mode Combinations
Appendix C: PIP/PAP Mode Combinations MAIN DTV/USB Scart1 Scart2 HDMI1 HDMI2 YPbPr (RGB) DTV/USB Scart1 (RGB) (RGB) (RGB) Scart2 (RGB) (RGB) HDMI1 HDMI2 YPbPr PC-VGA ( RGB ): This indicates that, selection is possible only if Scart-1 has a RGB signal. Restrictions : Scart-1 source must have RGB signal to perform PIP\PAP with sources TV, Scart-2, FAV. -
Page 36: Appendix D: Supported File Formats For Usb Mode
Appendix D: Supported File Formats for USB Mode Remarks File Format Media Extension Video Audio (Maximum resolution/Bit rate etc.) Movie Standart defi nition videos (up to 720x576 .avi XviD PCM/MP3 resolution) are supported. (optional) MPEG 1/2 Music .mp3 (CBR and VBR up to 320 Kbps) Layer 1/ 2/ 3 (MP3) Up to 5760x4608 resolution. -
Page 37: Specifi Cations
Specifi cations Digital Reception TV BROADCASTING Transmission Standards: PAL/SECAM B/G D/K K’ I/I’ L/L’ DVB-T, MPEG2,DVB-T, MPEG4 HD RECEIVING CHANNELS i. DEMODULATION VHF (BAND I/III) -Symbol rate: COFDM with 2K/8K FFT mode. -Modulation: 16-QAM - 64-QAM FEC for all DVB UHF (BAND U) modes (automatically found) HYPERBAND... -
Page 38: Important Instruction
Important Instruction For your own safety read following instruction carefully before attempting to connect this unit to the mains supply. MAINS (AC) OPERATION The wires in the mains lead are coloured in accordance with the following code : GREEN FUSE &...
