Page 1 Viper 2 0 1 3 O W N E R ’ S M A N U A L...
Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of Chrysler Group LLC shall be deemed to be deleted and the features and equipment that are either standard or optional name Chrysler Canada Inc.
Page 3: Introduction 3
TABLE OF CONTENTS SECTION PAGE INTRODUCTION ............. . . 3 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE .
Page 5: Table Of Contents
INTRODUCTION CONTENTS INTRODUCTION ......4 VEHICLE IDENTIFICATION NUMBER ..6 HOW TO USE THIS MANUAL ....4 VEHICLE MODIFICATIONS/ALTERATIONS .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION When it comes to service, remember that your authorized dealer knows your vehicle best, has factory-trained tech- Congratulations on selecting your new Chrysler Group nicians and genuine parts, and cares about your satisfac- LLC vehicle. Be assured that it represents precision tion.
Page 7 INTRODUCTION 5...
Page 8: Vehicle Identification Number
6 INTRODUCTION WARNINGS AND CAUTIONS This Owners Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire Owners Manual, you may miss important information.
Page 9: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death.
Page 11 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS ▫ To Arm The System .....18 A WORD ABOUT YOUR KEYS ... . .12 ▫...
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ General Information ....24 ▫ Enhanced Seat Belt Use Reminder System (BeltAlert®) ......40 DOOR LOCKS .
Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 ▫ Safety Checks You Should Make Inside The SAFETY TIPS ......68 Vehicle .
Page 14: A Word About Your Keys
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Keyless Ignition Node (KIN) Your vehicle uses a keyless ignition system. This system This feature allows the driver to operate the ignition with consists of a Key Fob with Remote Keyless Entry (RKE) the push of a button, as long as the Remote Keyless Entry transmitter and a Keyless Ignition Node (KIN).
Page 15: Key Fob
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key Fob The Key Fob also contains the Remote Keyless Entry (RKE) transmitter and an emergency key, which stores in the rear of the Key Fob. The emergency key allows for entry into the vehicle hatch should the battery in the vehicle or the Key Fob go dead.
Page 16: Ignition Or Accessory On Message
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Ignition Or Accessory On Message Opening the driver’s door when the ignition is in ACC or ON (engine not running), a chime will sound to remind you to cycle the ignition to OFF. In addition to the chime, the ignition or accessory on message will display in the cluster.
Page 17: Sentry Key
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 WARNING! WARNING! (Continued) • Do not leave children or animals inside parked • When leaving the vehicle, always remove the Key vehicles in hot weather. Interior heat build-up may Fob from the vehicle and lock your vehicle. cause serious injury or death.
Page 18: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The system uses a Key Fob with Remote Keyless Entry CAUTION! (RKE) transmitter, a Keyless Ignition Node (KIN) and a RF receiver to prevent unauthorized vehicle operation. The Sentry Key® Immobilizer system is not compat- Therefore, only Key Fobs that are programmed to the ible with some after-market remote starting systems.
Page 19: Customer Key Programming
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 NOTE: When having the Sentry Key® Immobilizer Sys- CAUTION! tem serviced, bring all vehicle keys with you to an • Always remove the Key Fobs from the vehicle and authorized dealer. lock all doors when leaving the vehicle unat- Customer Key Programming tended.
Page 20: Vehicle Security Alarm System
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE VEHICLE SECURITY ALARM SYSTEM 2. Perform one of the following methods to lock the vehicle: The Vehicle Security Alarm monitors the doors, liftgate, Press LOCK on the interior power door lock switch with and hood for unauthorized entry and the ignition for the driver and/or passenger door open.
Page 21: To Disarm The System
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 To Disarm The System system will give you a false alarm. If one of the previ- ously described arming sequences has occurred, the The Vehicle Security Alarm can be disarmed using any of Vehicle Security Alarm will arm regardless of whether the following methods: you are in the vehicle or not.
Page 22: Illuminated Entry
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Electronic Immobilization System The interior lights will turn on and remain on for about four seconds and then fade to off if a door is opened The Electronic Immobilization system prevents unau- using the inside door handle.
Page 23: To Unlock The Doors
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 “Uconnect® Access Programmable Settings” in “Under- standing Your Instrument Panel” for further information. Remote Key Unlock, Driver Door/Both Doors First This feature lets you program the system to unlock either the driver’s door or all doors on the first press of the UNLOCK button on the RKE transmitter.
Page 24: To Lock The Doors
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Lock The Doors Using The Panic Alarm Press and release the LOCK button on the RKE transmit- To turn the Panic Alarm feature on or off, press and hold ter to lock the doors. The horn will chirp once and the the PANIC button on the RKE transmitter for at least one park lights and turn signal lights will flash to acknowl- second and release.
Page 25: Programming Additional Transmitters
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 Programming Additional Transmitters 2. Insert the tip of the emergency key or a #2 flat blade screwdriver into the slot and gently pry the two halves Programming Key Fobs or RKE transmitters may be of the RKE transmitter apart.
Page 26: General Information
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Remove the battery by turning the back cover over If your RKE transmitter fails to operate from a normal (battery facing downward) and tapping it lightly on a distance, check for these two conditions: solid surface such as a table or similar, then replace the 1.
Page 27: Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 3. The RKE transmitter battery may be weak or dead. WARNING! (Continued) The expected life of the battery is a minimum of three • Never leave children alone in a vehicle. Leaving years.
Page 28 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Never leave children alone in a vehicle, or with access to an unlocked vehicle. • Allowing children to be in a vehicle unattended is dangerous for a number of reasons. A child or others could be seriously or fatally injured.
Page 29 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 is open, and the ignition is in the ACC or ON/RUN 2. The driver door is opened. position, a chime will sound as a reminder to remove the 3. The doors were not previously unlocked. Key Fob.
Page 30: Windows
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WINDOWS There are single window controls on the passenger door trim panel, which operate the passenger door window. Power Windows The window controls will operate only when the ignition The window controls on the driver’s door control both of is in the ACC or ON/RUN position.
Page 31: Auto-Down Feature
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 AUTO-Up Feature With Anti-Pinch Protection — If WARNING! (Continued) Equipped in the ACC or ON/RUN mode. Occupants, particu- Lift the window switch to the second detent, release, and larly unattended children, can become entrapped by the window will go up automatically.
Page 32: Reset Auto-Up
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Any impact due to rough road conditions may trigger 2. Push the window switch down firmly to the second the auto-reverse function unexpectedly during auto- detent to open the window completely and continue closure.
Page 33 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 Once unlocked, the liftgate can be opened or closed. To open the liftgate, press the LIFTGATE RELEASE switch located under the right side of the tail panel, which is located below the liftgate, then pull the liftgate open with one fluid motion.
Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The liftgate release switch will be ignored under WARNING! the following conditions: • Driving with the liftgate open can allow poisonous • When the ignition is in ON/RUN and the parking exhaust gases into your vehicle.
Page 35: Occupant Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 OCCUPANT RESTRAINTS out and then adjusting the belt to the desired length to restrain a child seat or secure a large item in a seat — Some of the most important safety features in your if equipped vehicle are the restraint systems: If you will be carrying children too small for adult-sized...
Page 36: Lap/Shoulder Belts
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE of ejection and the risk of injury caused by striking the WARNING! inside of the vehicle. Everyone in a motor vehicle should be belted at all times. In a collision, you and your passengers can suffer much greater injuries if you are not properly buckled Lap/Shoulder Belts up.
Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 WARNING! WARNING! (Continued) • Wearing your belt in the wrong place can make • It is extremely dangerous to ride in a cargo area, your injuries in a collision much worse. You might inside or outside of a vehicle.
Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Operating Instructions 3. Slide the latch plate up the webbing as far as necessary to make the belt go around your lap. 1. Enter the vehicle and close the door. Sit back and adjust the seat.
Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 WARNING! WARNING! (Continued) • A belt that is worn under your arm is dangerous. • A belt that is buckled into the wrong buckle will Your body could strike the inside surfaces of the not protect you properly.
Page 40 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A lap belt worn too high can increase the risk of injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdo- men.
Page 41: Lap/Shoulder Belt Untwisting Procedure
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 8. To release the belt, push the red button in the buckle. Lap/Shoulder Belt Untwisting Procedure The belt will retract automatically to its stowed posi- Use the following procedure to untwist a twisted lap/ tion.
Page 42: Enhanced Seat Belt Use Reminder System (Beltalert®)
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Enhanced Seat Belt Use Reminder System unbuckled while traveling at speeds greater than 5 mph (BeltAlert®) (8 km/h), BeltAlert® will provide both audio and visual notification. BeltAlert® is a feature intended to remind the driver and front passenger (if equipped with front passenger The front passenger seat BeltAlert®...
Page 43: Automatic Locking Retractor Mode (Alr) - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 Automatic Locking Retractor Mode (ALR) — If 3. Allow the belt to retract. As the belt retracts, you will Equipped hear a clicking sound. This indicates the safety belt is now in the Automatic Locking Mode. In this mode, the shoulder belt is automatically pre- locked.
Page 44: Seat Belt Pretensioners - If Equipped
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Pretensioners — If Equipped Seat Belts and Pregnant Women The seat belts for both front seating positions may be We recommend that pregnant women use the seat belts equipped with pretensioning devices that are designed to throughout their pregnancy.
Page 45: Driver And Passenger Supplemental Restraint System (Srs) - Air Bags
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use the seat belt extender when the lap belt is not long enough when it is worn low and snug, and in the recommended seating positions.
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: These Air Bags are certified to the new Federal WARNING! (Continued) regulations for Advanced Air Bags. The passenger’s • Do not put anything on or around the air bag Advanced Front Air Bag is certified to the Federal covers or attempt to open them manually.
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 The Air Bags have a multistage inflator design. This WARNING! (Continued) allows the air bag to have different rates of inflation that • Relying on the Air Bags alone could lead to more are based on several factors, including collision severity severe injuries in a collision.
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Here are some simple steps you can take to minimize the risk of harm from a deploying Air Bag: • The passenger Advanced Front Air Bag may not deploy if the Occupant Classification System (refer to 1.
Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 4. An older child who does not use a child safety seat or 8. Read the instructions provided with your child re- booster seat should ride buckled properly in their seat. straint to make sure that you are using it properly. 5.
Page 50: Air Bag Deployment Sensors And Controls
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Occupant Classification Module (OCM) Air Bag System Components • Passenger Air Bag Disable (PAD) Indicator Light Your vehicle may be equipped with the following Air Bag • Flex Mat system components: •...
Page 51 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 • Do not replace the seat cover with an aftermarket seat required, depending on several factors, including the se- cover. verity and type of impact. The Air Bag inflators are designed to provide different rates of inflation. The ORC •...
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE impact, Advanced Front Air Bags may deploy in crashes The ORC contains a backup power supply system that with little vehicle front-end damage but that produce a may deploy the Air Bags even if the battery loses power severe initial deceleration.
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 collision type, severity and occupant size. The steering WARNING! wheel hub trim cover and the upper right side of the instrument panel separate and then fold out of the way, Ignoring the Air Bag Warning Light in your instru- as the Air Bags inflate to their full size.
Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE information to the ORC. The ORC may modify the rate of Passenger Air Bag Disabled (PAD) Indicator Light passenger Air Bag inflation or prevent passenger Ad- The Passenger Air Bag Disabled (PAD) Indicator Light vanced Front Air Bag deployment based on occupant indicates to the driver and passenger when the passenger classification.
Page 55 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 the PAD Indicator Light is illuminated the passenger WARNING! Advanced Front Air Bag will not inflate in the event of a • Never place a rear facing infant seat in front of an collision.
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Sitting upright • The front passenger carries or holds an object while seated (e.g., backpack, box, etc.) • Facing forward • Sitting in the center of the seat with their feet comfort- WARNING! ably on or near the floor Occupants in the front passenger seat sitting improp-...
Page 57 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 Furthermore, objects lodged under the seat can prevent any reason, take the vehicle to your authorized dealer. Only Chrysler Group LLC approved seat accessories may the occupant’s weight from being measured properly and be used may result in the occupant being classified improperly.
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE event the ORC will determine whether to have the WARNING! Enhanced Accident Response System perform the follow- ing functions: Unapproved modifications or service procedures to the passenger seat assembly, its related components, •...
Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 If you do have a collision, which deploys the Air Bags, throat irritation, move to fresh air. If the irritation any or all of the following may occur: continues, see your doctor. If these particles settle on your clothing, follow the garment manufacturer’s in- •...
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Maintaining Your Air Bag System WARNING! (Continued) • Do not attempt to modify any part of your air bag WARNING! system. The air bag may inflate accidentally or may • Modifications to any part of the air bag system not function properly if modifications are made.
Page 61: Event Data Recorder (Edr)
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 Air Bag Warning Light NOTE: If the speedometer, tachometer, or any engine related gauges are not working, the Occupant Restraint Controller (ORC) may also be disabled. The Air Bags may You will want to have the Air Bags ready to not be ready to inflate for your protection.
Page 62: Child Restraints
60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Whether or not the driver and passenger safety belts In addition to the vehicle manufacturer, other parties, were buckled/fastened; such as law enforcement, that have the special equip- ment, can read the information if they have access to the •...
Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 • The infant carrier is only used rearward-facing in the WARNING! (Continued) vehicle. It is recommended for children from birth how strong you are. The child and others could be until they reach the weight or height limit of the infant badly injured.
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Older Children and Child Restraints seat. The child and belt-positioning booster seat are held in the vehicle by the seat belt. Children who are two years old or who have outgrown their rear-facing convertible child seat can ride forward- WARNING! facing in the vehicle.
Page 65 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 • Can the child stay seated like this for the whole trip? Children Too Large for Booster Seats Children who are large enough to wear the shoulder belt If the answer to any of these questions was “no,” then the comfortably, and whose legs are long enough to bend child still needs to use a booster seat in this vehicle.
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To attach a child restraint tether strap: WARNING! 1. Move the seat forward. Improper installation of a child restraint to the tether 2. Move the seatback to its full forward position. anchorage can lead to failure of an infant or child restraint.
Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 Child Tether Tether Hook NOTE: While the child tether is in use, keep the access 6. Move the seat to its farthest rearward position. Apply cover in a safe place so that it can be replaced after use of body pressure to the seat to be sure the seat adjusters the child tether.
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 8. Install the child restraint according to the manufactur- To restrain the child seat: er’s directions. 1. Pull enough webbing from the retractor to allow the 9. Remove slack from the tether strap according to the belt to pass through the child restraint and insert the child restraint manufacturer’s directions.
Page 69: Break-In Recommendations
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 NOTE: Once the belt is in Automatic Locking Mode, you For the first 500 miles (800 km): will not be able to pull any more of the webbing out of • Keep your vehicle speed below the legal, posted speed the retractor.
Page 70: Safety Tips
68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: A new engine will consume some oil during the WARNING! (Continued) first few thousand miles (kilometers) of operation. This • It is extremely dangerous to ride in a cargo area, should be considered a normal part of the break-in and inside or outside of a vehicle.
Page 71: Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 Whenever a change is noticed in the sound of the exhaust WARNING! (Continued) system, when exhaust fumes can be detected inside the eventually poison you. To avoid breathing (CO), vehicle, or when the underside or rear of the vehicle is follow these safety tips: damaged, have a competent mechanic inspect the com- •...
Page 72: Periodic Safety Checks You Should Make Outside The Vehicle
70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Front seat belt assemblies must be replaced after a Floor Mat Safety Information collision. Rear seat belt assemblies must be replaced after Always use floor mats designed to fit the foot well of a collision if they have been damaged (i.e., bent retractor, your vehicle.
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 Lights Have someone observe the operation of brake lights and exterior lights while you work the controls. Check turn signal and high beam indicator lights on the instrument panel. Door Latches Check for positive closing, latching, and locking. Fluid Leaks Check area under vehicle after overnight parking for fuel, engine coolant, oil, or other fluid leaks.
Page 75 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS ▫ Headlight Switch ..... .88 MIRRORS ......76 ▫...
Page 76 74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Flash-To-Pass ......92 ▫ To Activate ......102 ▫...
Page 77 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 75 ▫ Canadian/Gate Operator Programming ..111 STORAGE ......118 ▫...
Page 78: Mirrors
76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Automatic Dimming Mirror This mirror automatically adjusts for headlight glare from vehicles behind you. This feature will be defaulted on, and only be disabled when the vehicle is moving in reverse. Automatic Dimming Mirror NOTE: The mirror contains an Assist button and a 9–1–1 button located on the bottom of the mirror.
Page 79: Outside Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77 Assist Call 9-1-1 Call The rear view mirror contains an ASSIST push button Report an accident without taking your eyes off the road. which automatically connects the vehicle occupants to Just press 9-1-1 on your mirror and connect. one of several predefined locations for immediate sup- port: CAUTION!
Page 80: Power Mirrors
78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side mirror could cause you to collide with another vehicle or other object.
Page 81: Vanity Mirror
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79 Using the mirror control switch, press on any of the four arrows for the direction that you want the mirror to move. Vanity Mirror A vanity mirror is on the passenger side sun visor. To use the mirror, rotate the sun visor downward and swing the mirror cover upward.
Page 82: Seats
80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE SEATS Manual Seats Seats are a part of the Occupant Restraint System of the Forward and Rearward Adjustment vehicle. The adjusting bar is at the front of the seat, near the floor. Pull the bar upward to move the seat forward or rear- WARNING! ward.
Page 83 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 81 Seat Height Adjustment The seat height adjustment lever is located on the out- board side of the seat. Pull upward on the lever to raise the seat height or push downward on the lever to lower the seat height.
Page 84 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Recliner Adjustment The recliner lever is located on the outboard side of the seat. To recline the seat, lean forward slightly, pull the recliner lever upward, lean backward until the seat is in the desired position, and release the lever.
Page 85: Power Seats
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83 Power Seats WARNING! On models equipped with power seats, the power seat • Adjusting a seat while driving may be dangerous. switch is located on the outboard side of the seat near the Moving a seat while driving could result in loss of floor.
Page 86 84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adjusting The Seat Forward Or Rearward The seat can be adjusted both forward and rearward. Push the seat switch forward or rearward, the seat will move in the direction of the switch. Release the switch when the desired position has been reached.
Page 87: To Open And Close The Hood
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85 WARNING! CAUTION! • Adjusting a seat while driving may be dangerous. Do not place any article under a power seat or Moving a seat while driving could result in loss of impede its ability to move as it may cause damage to control which could cause a collision and serious the seat controls.
Page 88 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Hood Release Lever Location Hood Release Lever 2. Pull the hood release lever rearward to release the 3. Lift the hood upward to the full forward position. hood latches.
Page 89 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 CAUTION! • Do not leave the hood open in areas where strong gust of wind are likely. Such a place might be by the side of the road where large trucks pass by. Strong gusts of wind may damage the hood.
Page 90: Lights
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) when the vehicle is in motion and block your vision. Failure to follow this warning could result in serious injury or death. LIGHTS Headlight Switch The headlight switch is located on the left side of the instrument panel.
Page 91: Automatic Headlights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 Automatic Headlights NOTE: The Headlights On with Wipers feature can be turned on or off using the Uconnect® System, refer to This system automatically turns the headlights on or off “Uconnect® Settings” in “Understanding Your Instru- according to ambient light levels.
Page 92: Daytime Running Lights (Drl)
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: NOTE: If allowed by law in the country in which the vehicle was purchased the Daytime Running Lights can • The lights must be turned off within 45 seconds of be turned on and off using the Uconnect® System, refer placing the ignition in the OFF position to activate this to “Uconnect®...
Page 93: Turn Signals
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 NOTE: • If either light remains on and does not flash, or there is a very fast flash rate, check for a defective outside light bulb. If an indicator fails to light when the lever is moved, it would suggest that the indicator bulb is defective.
Page 94: Understanding The Features Of Your Vehicle Flash-To-Pass
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Flash-To-Pass Dimmer Controls You can signal another vehicle with your headlights by The dimmer control is part of the headlight switch and is lightly pulling the multifunction lever toward you. This located on the left side of the instrument panel. will turn on the high beams headlights until the lever is released.
Page 95 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 With the parking lights or headlights on, rotating the left The right dimmer control adjusts the ambient light for dimmer control upward will increase the brightness of the the interior door release handles. instrument panel lights and turn on the courtesy lights.
Page 96 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Interior Light Control Interior Light Defeat (OFF) Rotate the left dimmer control completely upward to the Rotate the left dimmer control to the extreme bottom OFF second detent to turn on the interior lights. The interior position.
Page 97: Windshield Wipers And Washers
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 WINDSHIELD WIPERS AND WASHERS Intermittent Wiper System The multifunction lever operates the windshield wipers Use the intermittent wiper when weather conditions and washer when the ignition is placed in the ON/RUN make a single wiping cycle with a variable pause be- or ACC position.
Page 98: Mist Feature
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Mist Feature CAUTION! When a single wipe to clear off road mist or spray from • Turn the windshield wipers off when driving a passing vehicle is needed, push the washer knob, through an automatic car wash. Damage to the located on the end of the multifunction lever, inward to windshield wipers may result if the wiper control the first detent and release.
Page 99: Headlights On With Wipers (Available With Automatic Headlights Only)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 released. It will then resume the intermittent interval Headlights On With Wipers (Available with previously selected. If the washer knob is pushed while Automatic Headlights Only) in the off position, the wiper will turn on and cycle When this feature is active, the headlights will turn on approximately three times after the wash knob is re- approximately 10 seconds after the wipers are turned on...
Page 100: Adjustable Pedals
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE position, push the release lever forward to lock the WARNING! column firmly in place. Do not adjust the steering column while driving. Adjusting the steering column while driving or driv- ing with the steering column unlocked, could cause the driver to lose control of the vehicle.
Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 CAUTION! Do not place any article under the adjustable pedals or impede its ability to move as it may cause damage to the pedal controls. Pedal travel may become lim- ited if movement is stopped by an obstruction in the adjustable pedal’s path.
Page 102: Adjustable Foot Rest
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adjustable Foot Rest To adjust the pedal: This feature allows the driver to adjust the foot rest 1. Adjust the seat and steering column to a comfortable forward or backward and to rotate it upward or down- position.
Page 103: Electronic Speed Control
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 ELECTRONIC SPEED CONTROL When engaged, the Electronic Speed Control takes over accelerator operations at speeds greater than 25 mph (40 km/h). The Electronic Speed Control buttons are located on the right side of the steering wheel. Electronic Speed Control Buttons 1 —...
Page 104: To Activate
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: In order to ensure proper operation, the Elec- WARNING! tronic Speed Control System has been designed to shut down if multiple Speed Control functions are operated at Leaving the Electronic Speed Control system on the same time.
Page 105: To Deactivate
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 To Deactivate Pressing the RES (+) button once will result in a 1 mph (1.6 km/h) increase in set speed. Each subsequent tap of A soft tap on the brake pedal, pushing the CANCEL the button results in an increase of 1 mph (1.6 km/h).
Page 106: Parkview® Rear Back Up Camera - If Equipped
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Using Electronic Speed Control On Hills PARKVIEW® REAR BACK UP CAMERA — IF EQUIPPED The transmission may downshift on hills to maintain the vehicle set speed. Your vehicle may be equipped with the ParkView® Rear Back Up Camera that allows you to see an on-screen NOTE: The Electronic Speed Control system maintains image of the rear surroundings of your vehicle whenever...
Page 107 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 indicate the distance to the rear of the vehicle.The follow- ing table shows the approximate distances for each zone: Zone Distance to the rear of the vehicle 0 - 1 ft (0 - 30 cm) Yellow 1 ft - 3 ft (30 cm - 1 m) Green...
Page 108: Turning Parkview® On Or Off - With Touch-Screen Radio
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Press the “Safety & Driving Assistance” soft-key. CAUTION! (Continued) 5. Press the check box soft key next to “Parkview® • To avoid vehicle damage, the vehicle must be Backup Camera” to enable/disable. driven slowly when using ParkView®...
Page 109: Before You Begin Programming Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 For more efficient programming and accurate transmis- sion of the radio-frequency signal it is recommended that a new battery be placed in the hand-held transmitter of the device that is being programmed to the HomeLink® system.
Page 110: Programming A Rolling Code
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming A Rolling Code For programming garage door openers that were manu- factured after 1995. These garage door openers can be identified by the “LEARN” or “TRAIN” button located where the hanging antenna is attached to the garage door opener.
Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) Firmly press and release the “LEARN” or “TRAIN- away from the HomeLink® button you wish to pro- ING” button. On some garage door openers/devices gram while keeping the HomeLink®...
Page 112: Programming A Non-Rolling Code
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Reprogramming A Single HomeLink® Button 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) away from the HomeLink® button you wish to pro- To reprogram a channel that has been previously trained, gram while keeping the HomeLink®...
Page 113: Canadian/Gate Operator Programming
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 • To program the remaining two HomeLink® buttons, Canadian/Gate Operator Programming repeat each step for each remaining button. DO NOT For programming transmitters in Canada/United States erase the channels. that require the transmitter signals to “time-out” after several seconds of transmission.
Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • To program the two remaining HomeLink® buttons, 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) away from the HomeLink® button you wish to program repeat each step for each remaining button. DO NOT while keeping the HomeLink®...
Page 115: Using Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Using HomeLink® Troubleshooting Tips To operate, press and release the programmed If you are having trouble programming HomeLink®, HomeLink® button. Activation will now occur for the here are some of the most common solutions: programmed device (i.e., garage door opener, gate opera- •...
Page 116: General Information
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information WARNING! This device complies with FCC rules Part 15 and Industry • Your motorized door or gate will open and close Canada RSS-210. Operation is subject to the following while you are programming the universal trans- two conditions: ceiver.
Page 117: Electrical Power Outlets
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 ELECTRICAL POWER OUTLETS Your vehicle is equipped with two 12 Volt (13 Amp) power outlet that can be used to power cellular phones, small electronics and other low powered electrical acces- sories. One power outlet is located on the center console to the right of the shifter.
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! To avoid serious injury or death: • Only devices designed for use in this type of outlet should be inserted into any 12 Volt outlet. • Do not touch with wet hands. •...
Page 119: Cupholders - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 CUPHOLDERS — If Equipped CAUTION! There are two cupholders located in the rear of the center • Many accessories that can be plugged in draw console. power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.).
Page 120: Storage
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE STORAGE Glovebox Storage An electronic glovebox storage compartment is located on the passenger side of the instrument panel. Push in the button to open the glovebox. Opened Glove Box Storage Compartment NOTE: The glovebox storage compartment will lock with the door locks.
Page 121: Console Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 Console Features Cargo Net Storage— If Equipped Console Cubby Bin — If Equipped There is a cargo net storage area located between the driver and passengers seat. An open storage area, or cubby bin, is located in the center console rearward of the shift lever.
Page 122 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Storage Bin — If Equipped WARNING! There is a storage bin located between the driver and Do not operate this vehicle with a console compart- passengers seat. Pull up on the release lever to open the ment lid in the open position.
Page 123: Door Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Door Storage REAR WINDOW FEATURES The door panels contain storage areas located in the Rear Window Defroster lower center area of the door panel. The rear window defroster button is located on the climate control panel. Press this button to turn on the rear window defroster.
Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Failure to follow these cautions can cause damage to the heating elements: • Use care when washing the inside of the rear window. Do not use abrasive window cleaners on the interior surface of the window. Use a soft cloth and a mild washing solution, wiping parallel to the heating elements.
Page 125: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS ▫ EVIC Green Telltales ....146 INSTRUMENT PANEL FEATURES ..125 ▫...
Page 126 124 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Summer Operation ....170 iPod®/USB/MP3 CONTROL — IF EQUIPPED......163 ▫...
Page 127: Instrument Panel Features
UNDERSTANDING YOUR INSTRUMENT PANEL 125 INSTRUMENT PANEL FEATURES 1 — Air Outlet 6 — Passenger Air Bag 11 — Climate Controls 2 — Sound System Speaker 7 — Glove Compartment 12 — Dimmer Controls 3 — Instrument Cluster 8 — Uconnect® System 13 —...
Page 128: Instrument Cluster
126 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER...
Page 129: Instrument Cluster Descriptions
UNDERSTANDING YOUR INSTRUMENT PANEL 127 INSTRUMENT CLUSTER DESCRIPTIONS check or when driving, if the driver’s seat belt remains unbuckled, the Seat Belt Reminder Light will illuminate 1. Speedometer and the chime will sound. Refer to “Occupant Restraints” Indicates vehicle speed. in “Things To Know Before Starting Your Vehicle”...
Page 130 128 UNDERSTANDING YOUR INSTRUMENT PANEL • Selectable Information (Compass, Temp, Range, to NOTE: Leaving the hazard flashers on for extended periods will wear down the battery. Empty, Trip A, Trip B, Average MPG) • Menu Titles / Odometer 5. High Beam Indicator •...
Page 131 UNDERSTANDING YOUR INSTRUMENT PANEL 129 indicate that the parking brake is applied, that the brake The light will remain on until the cause is corrected. fluid level is low, or that there is a problem with the anti-lock brake system reservoir. WARNING! If the light remains on when the parking brake has been Driving a vehicle with the red brake light on is...
Page 132 130 UNDERSTANDING YOUR INSTRUMENT PANEL the parking brake is applied or a brake fault is detected. Do not operate the vehicle until the cause is corrected. If the light does not illuminate, have the light inspected This light does not indicate how much oil is in the engine. by an authorized dealer.
Page 133 UNDERSTANDING YOUR INSTRUMENT PANEL 131 placard or tire inflation pressure label. (If your vehicle maintain correct tire pressure, even if under-inflation has has tires of a different size than the size indicated on the not reached the level to trigger illumination of the TPMS vehicle placard or tire inflation pressure label, you should low tire pressure telltale.
Page 134 132 UNDERSTANDING YOUR INSTRUMENT PANEL replacement or alternate tires and wheels allow the TPMS monitors engine control systems. The light will illumi- to continue to function properly. nate when the ignition is in the ON/RUN position, before engine start. If the bulb does not come on when CAUTION! cycling the ignition from OFF to ON/RUN, have the condition checked promptly.
Page 135 UNDERSTANDING YOUR INSTRUMENT PANEL 133 • Electronic Speed Control SET Indicator WARNING! This light will turn on when the electronic speed control is SET. For further information, A malfunctioning catalytic converter, as referenced refer to “Electronic Speed Control” in “Under- above, can reach higher temperatures than in normal standing The Features Of Your Vehicle.”...
Page 136 134 UNDERSTANDING YOUR INSTRUMENT PANEL • Low Fuel Light shift the transmission into NEUTRAL and idle the ve- When the fuel level reaches approximately 3.0 gal hicle. If the temperature reading does not return to (11.0 L) this light will turn on, and remain on until normal, turn the engine off immediately and call for fuel is added.
Page 137 UNDERSTANDING YOUR INSTRUMENT PANEL 135 • Oil Pressure Warning If the telltale remains lit with the engine running, your This telltale indicates low engine oil pressure. If vehicle will usually be drivable. However, see an autho- the light turns on while driving, stop the vehicle rized dealer for service as soon as possible.
Page 138 136 UNDERSTANDING YOUR INSTRUMENT PANEL 18. Electronic Stability Control (ESC) OFF Indicator speeds greater than 30 mph (48 km/h), see your autho- Light — If Equipped rized dealer as soon as possible to have the problem diagnosed and corrected. This light indicates the Electronic Stability Con- trol (ESC) is off.
Page 139 UNDERSTANDING YOUR INSTRUMENT PANEL 137 20. Anti-Lock Brake (ABS) Light If the ABS light is on, the brake system should be serviced as soon as possible to restore the benefits of Anti-Lock brakes. If the ABS light does not turn on when the This light monitors the Anti-Lock Brake System ignition is cycled to the ON/RUN position, have the light (ABS).
Page 140: Electronic Vehicle Information
138 UNDERSTANDING YOUR INSTRUMENT PANEL ELECTRONIC VEHICLE INFORMATION CENTER This system allows the driver to select a variety of useful (EVIC) information by pressing the switches mounted on the steering wheel. The EVIC consists of the following: • Digital Speedometer •...
Page 141 UNDERSTANDING YOUR INSTRUMENT PANEL 139 • Vehicle Settings • UP Arrow Button The system allows the driver to select information by Press and release the UP arrow button to scroll pressing the following buttons mounted on the steering upward through the main menu and sub- wheel: menus (Fuel Economy, Trip A, Trip B, Audio, Stored Messages, Screen Set Up).
Page 142: Electronic Vehicle Information Center (Evic) Displays
140 UNDERSTANDING YOUR INSTRUMENT PANEL • LEFT Arrow Button Electronic Vehicle Information Center (EVIC) Displays Press the LEFT arrow button to return to the main menu from an info screen or sub-menu item. The EVIC displays are located in the center portion of the cluster and consists of the following sections:...
Page 143 UNDERSTANDING YOUR INSTRUMENT PANEL 141 1. Main Screen — The inner ring of the display will The main display area will normally display the main illuminate in grey under normal conditions, yellow for menu or the screens of a selected feature of the main non critical warnings, red for critical warnings and menu.
Page 144: Electronic Vehicle Information Center (Evic) Messages
142 UNDERSTANDING YOUR INSTRUMENT PANEL • Unstored Messages • Key Fob Battery Low • Service Airbag System This message type is displayed indefinitely or until the condition that activated the message is cleared. Examples • ESC Status of this message type are “Turn Signal On” (if a turn signal •...
Page 145: Evic Amber Telltales
UNDERSTANDING YOUR INSTRUMENT PANEL 143 • Brake Fluid Low • Passenger Seatbelt Unbuckled • Service Electronic Braking System • Front Seatbelts Unbuckled • Engine Temperature Hot • Door Open • Battery Voltage Low • Doors Open • Service Electronic Throttle Control •...
Page 146: Evic Red Telltales
144 UNDERSTANDING YOUR INSTRUMENT PANEL • Electronic Speed Control Ready • Oil Pressure Warning Light This light will turn on when the electronic This telltale indicates low engine oil pressure. If speed control is ON. For further information, the light turns on while driving, stop the vehicle and shut refer to “Electronic Speed Control”...
Page 147 UNDERSTANDING YOUR INSTRUMENT PANEL 145 If jump starting is required, refer to “Jump Starting required. You may experience reduced performance, an Procedures” in “What To Do In Emergencies”. elevated/rough idle or engine stall and your vehicle may require towing. • Electronic Throttle Control (ETC) Light •...
Page 148: Evic Green Telltales
146 UNDERSTANDING YOUR INSTRUMENT PANEL EVIC Green Telltales Tachometer • Electronic Speed Control SET Press and release the UP or DOWN arrow This telltale will illuminate green when the elec- button until the Tachometer icon is highlighted tronic speed control is SET. For further informa- in the EVIC.
Page 149 UNDERSTANDING YOUR INSTRUMENT PANEL 147 • If one or more tires have low pressure, The tire Vehicle Info (Customer Information Features) pressure values in each corner of the ICON with the pressure value of the low tire displayed in a different Press and release the UP or DOWN arrow color than the other tire pressure value.
Page 150 148 UNDERSTANDING YOUR INSTRUMENT PANEL Oil Temperature Current Torque Press and release the UP or DOWN arrow button until Press and release the UP or DOWN arrow button until “Oil Temperature” is highlighted in the EVIC. Press and “Current Torque” is highlighted in the EVIC. Press and release the RIGHT arrow button and the oil temperature release the RIGHT arrow button and the current torque will be displayed.
Page 151 UNDERSTANDING YOUR INSTRUMENT PANEL 149 SRT Performance Info Current G-Forces Press and release the UP or DOWN arrow button until Press and release the UP or DOWN arrow the Current G-Forces are displayed. button until the SRT icon is highlighted in the Peak G-Forces EVIC.
Page 152 150 UNDERSTANDING YOUR INSTRUMENT PANEL Range To Empty (RTE) Trip B Current Miles Per Gallon (MPG) Press and release the Left or Right arrow but- Trip A ton until the Trip B icon is highlighted in the EVIC (Toggle left or right to select Trip A or Press and release the UP or DOWN arrow Trip B).
Page 153 UNDERSTANDING YOUR INSTRUMENT PANEL 151 Audio Diagnostic Codes Press and release the UP or DOWN arrow Press and release the UP or DOWN arrow button until the Audio display icon is high- button until the Diagnostic Code icon is high- lighted in the EVIC.
Page 154: Screen Setup Driver Selectable Items
152 UNDERSTANDING YOUR INSTRUMENT PANEL Screen Setup Driver Selectable Items Upper Right • None Upper Left • None • Compass (default setting) • Compass • Outside Temp • Outside Temp (default setting) • Time • ime • Range To Empty (RTE) •...
Page 155: Uconnect® Access Settings
UNDERSTANDING YOUR INSTRUMENT PANEL 153 Restore To Defaults (Restores All Settings To Default menus and change settings (i.e., 30, 60, 90), press the Settings) center of the control knob one or more times to select or change a setting (i.e., ON, OFF). •...
Page 156 154 UNDERSTANDING YOUR INSTRUMENT PANEL • Display Brightness With Headlights ON When making a selection, press the soft-key to enter the desired mode. Once in the desired mode press and release When in this display, you may select the brightness with the preferred setting until a check-mark appears next to the the headlights on.
Page 157 UNDERSTANDING YOUR INSTRUMENT PANEL 155 • Touchscreen Beep language soft-key until a check-mark appears next to the language, showing that setting has been selected. Touch When in this display, you may turn on or shut off the the back arrow soft-key to return to the previous menu. sound heard when a touch screen button (soft-key) is •...
Page 158 156 UNDERSTANDING YOUR INSTRUMENT PANEL • Set Time Minutes Clock After pressing the Clock soft-key the following settings When in this display, you may adjust the minutes. The will be available. Sync with GPS Time soft-key must be unchecked. To make your selection touch the + or - soft-keys to adjust •...
Page 159 UNDERSTANDING YOUR INSTRUMENT PANEL 157 Safety / Assistance Lights After pressing the Safety / Assistance soft-key the fol- After pressing the Lights soft-key the following settings lowing settings will be available. will be available. • ParkView® Backup Camera • Headlight Illumination On Approach Your vehicle may be equipped with the ParkView®...
Page 160 158 UNDERSTANDING YOUR INSTRUMENT PANEL your selection, touch the Headlights With Wipers softkey, next to setting, showing that setting has been selected. until a check-mark appears next to setting, showing that Touch the back arrow soft-key to return to the previous setting has been selected.
Page 161 UNDERSTANDING YOUR INSTRUMENT PANEL 159 Remote Keyless Entry (RKE) transmitter. To make your 1st Press Of Key Fob Unlocks is selected, you must press selection, touch the Flash Lights With Lock soft-key, until the RKE transmitter UNLOCK button twice to unlock the a check-mark appears next to setting, showing that passenger’s doors.
Page 162 160 UNDERSTANDING YOUR INSTRUMENT PANEL Engine Off Options Delay status touch the + or - soft-key to select your desired time interval. Touch the back arrow soft-key to After pressing the Engine Off Options soft-key the fol- return to the previous menu. lowing settings will be available.
Page 163 UNDERSTANDING YOUR INSTRUMENT PANEL 161 • Perform Compass Calibration NOTE: Keep magnetic materials away from the top of the instrument panel, such as iPod’s, Mobile Phones, Touch the Calibration soft-key to change this setting. This Laptops and Radar Detectors. This is where the compass compass is self-calibrating, which eliminates the need to module is located, and it can cause interference with the manually reset the compass.
Page 164 162 UNDERSTANDING YOUR INSTRUMENT PANEL • Equalizer Phone/Bluetooth When in this display you may adjust the Bass, Mid and After pressing the Phone/Bluetooth soft-key the follow- Treble settings. Adjust the settings with the + and – setting ing settings will be available. soft-keys or by selecting any point on the scale between the •...
Page 165: Uconnect® Radios - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 163 • Subscription Information Uconnect® RADIOS — IF EQUIPPED For detailed information about your Uconnect® radio New vehicle purchasers or lessees will receive a free refer to your Uconnect® Supplement Manual. limited time subscription to SiriusXM Satellite Radio with your radio.
Page 166: Steering Wheel Audio Controls
164 UNDERSTANDING YOUR INSTRUMENT PANEL iPod® control supports Mini, 4G, Photo, Nano, 5G iPod® The left hand control is a rocker type switch with a and iPhone® devices. Some iPod® software versions pushbutton in the center. The function of the left hand may not fully support the iPod®...
Page 167: Radio Operation And Mobile Phones
UNDERSTANDING YOUR INSTRUMENT PANEL 165 RADIO OPERATION AND MOBILE PHONES Automatic Temperature Control (ATC) Under certain conditions, the mobile phone being on in Hard-Keys your vehicle can cause erratic or noisy performance from The hard-keys located below the Uconnect® Access screen. your radio.
Page 168 166 UNDERSTANDING YOUR INSTRUMENT PANEL Soft-Keys Button Descriptions (Applies To Both Hard-keys And Soft-keys) Soft-keys are accessible on the Uconnect® Access system 1. A/C Button screen. Press and release to change the current setting, the indicator illuminates when A/C is ON. Performing this function again will cause the A/C operation to switch into manual mode and the A/C indicator will turn off.
Page 169 UNDERSTANDING YOUR INSTRUMENT PANEL 167 4. Front Defrost Button CAUTION! Press and release to change the current airflow setting to Failure to follow these cautions can cause damage to Defrost mode. The indicator illuminates when this fea- the heating elements: ture is ON.
Page 170 168 UNDERSTANDING YOUR INSTRUMENT PANEL • Bi-Level Mode 6. Modes Air comes from the instrument panel outlets and The airflow distribution mode can be adjusted so air floor outlets. A slight amount of air is directed comes from the instrument panel outlets, floor outlets, through the defrost and side window demister demist outlets and defrost outlets.
Page 171 UNDERSTANDING YOUR INSTRUMENT PANEL 169 7. Blower Control 8. Climate Control OFF Button Blower control is used to regulate the amount of air Press and release this button to turn the Climate Control forced through the climate system. There are seven ON/OFF.
Page 172: Summer Operation
170 UNDERSTANDING YOUR INSTRUMENT PANEL 3. When the system is set up for your comfort level, it is Recirculation Control not necessary to change the settings. You will experi- When outside air contains smoke, odors, or high humid- ence the greatest efficiency by simply allowing the ity, or if rapid cooling is desired, you may wish to system to function automatically.
Page 173: Winter Operation
UNDERSTANDING YOUR INSTRUMENT PANEL 171 against engine overheating. A solution of 50% ethylene adequate system lubrication to minimize the possibility glycol antifreeze coolant and 50% water is recommended. of compressor damage when the system is started again. Refer to “Maintenance Procedures” in “Maintaining Your Window Fogging and Frosting Vehicle”...
Page 174: Control Setting Suggestions For Various Weather Conditions
172 UNDERSTANDING YOUR INSTRUMENT PANEL Control Setting Suggestions for Various Weather Conditions...
Page 175 STARTING AND OPERATING CONTENTS STARTING PROCEDURES ....176 DRIVING ON SLIPPERY SURFACES ..186 ▫ Normal Starting..... . .176 ▫...
Page 176 174 STARTING AND OPERATING ▫ Brake Pad Break-In ....193 ▫ Tire Pressure ......214 ▫...
Page 177 STARTING AND OPERATING 175 ▫ Carbon Monoxide Warnings ... . .228 TIRE PRESSURE MONITOR SYSTEM (TPMS) . .223 ▫ Tire Pressure Monitoring Low Pressure ADDING FUEL ......229 Warnings .
Page 178: Starting Procedures
176 STARTING AND OPERATING STARTING PROCEDURES CAUTION! Before starting your vehicle, adjust your seat, adjust the Long periods of engine idling, especially at high inside and outside mirrors, fasten your seat belt, and if engine speeds, can cause excessive exhaust tempera- present, instruct any other occupant to buckle their seat tures, which can damage your vehicle.
Page 179 STARTING AND OPERATING 177 NOTE: 3. Place the shift lever in NEUTRAL. • You must disarm the security system in order to start 4. Press the red ENGINE START/STOP button located the engine. Refer to “Security Alarm System” in on the instrument panel. Release the button when the “Things To Know Before Starting Your Vehicle”...
Page 180: If Engine Fails To Start
178 STARTING AND OPERATING If Engine Fails To Start WARNING! (Continued) • Do not attempt to push or tow your vehicle to get it CAUTION! started. Unburned fuel could enter the catalytic con- To prevent damage to the starter, do not crank the verter and once the engine has started, ignite and engine for more than 15 seconds at a time.
Page 181: After Starting
STARTING AND OPERATING 179 If the engine shows no sign of starting after two 15 CAUTION! second periods of cranking with the accelerator pedal • Never drive with your foot resting on the clutch held to the floor, the “Normal Starting” procedure should be repeated.
Page 182: Shifting
180 STARTING AND OPERATING The spring will try to pull the shift lever toward third and CAUTION! fourth gear. Make sure you move the shift lever into second or fifth gear. If you let the shift lever move in the Failure to start out in first gear when moving forward direction of the pulling, you may end shifting from first from a starting position may result in damage to the...
Page 183 STARTING AND OPERATING 181 • Due to the high performance nature of your drivetrain, NOTE: a certain amount of noise from the transmission is • Your vehicle is equipped with a transmission reverse normal. This noise can be most noticeable when the inhibitor system.
Page 184: Recommended Shift Speeds
182 STARTING AND OPERATING Recommended Shift Speeds Skip Shift Indicator Light To use your manual transmission for fuel economy it should be upshifted as listed below. Shift at the vehicle There are times when you must shift the trans- speeds listed for acceleration. Earlier upshifts during mission directly from first gear into fourth gear cruise conditions (relatively steady speeds) will result in instead of from first gear into second gear.
Page 185: Street/Race Mode - If Equipped
STARTING AND OPERATING 183 Downshifting - Proper downshifting will improve fuel STREET/RACE MODE – IF EQUIPPED economy and prolong engine life. This vehicle is equipped with an electronic controlled To maintain a safe speed and prolong brake life, down- damping system. This system allows for a street suspen- shift to maintain a safe speed when descending a steep sion damping setting or a firmer race suspension damp- grade.
Page 186: Launch Mode - If Equipped
184 STARTING AND OPERATING speed, braking and acceleration. This mode is driver LAUNCH MODE – IF EQUIPPED selectable when the vehicle is placed in STREET mode This system maximizes acceleration traction for straight (press the “STREET” button on the Instrument Panel). line racing.
Page 187 STARTING AND OPERATING 185 6. Release the clutch. Pressing the launch control button when launch control is active will deactivate launch control also shifting the vehicle into second gear will disable the system.. NOTE: • Launch Mode brings the engine to optimum launch RPM and waits for the driver to release the clutch.
Page 188: Driving On Slippery Surfaces
186 STARTING AND OPERATING DRIVING ON SLIPPERY SURFACES 1. Slow down during rainstorms or when roads are slushy. Acceleration 2. Slow down if road has standing water or puddles. WARNING! CAUTION! Rapid acceleration on slippery surfaces is dangerous. Driving your vehicle through deep puddles at speeds You could lose control of the vehicle and possibly over 5 mph (8 km/h), may cause water to be ingested have a collision.
Page 189: Driving Through Water
STARTING AND OPERATING 187 DRIVING THROUGH WATER Shallow Standing Water Driving through water more than a few inches/ Although your vehicle is capable of driving through centimeters deep will require extra caution to ensure shallow standing water, consider the following Caution safety and prevent damage to your vehicle.
Page 190 188 STARTING AND OPERATING CAUTION! (Continued) WARNING! • Driving through standing water may cause damage • Driving through standing water limits your vehi- to your vehicle’s drivetrain components. Always cle’s traction capabilities. Do not exceed 5 mph inspect your vehicle’s fluids (i.e., engine oil, trans- (8 km/h) when driving through standing water.
Page 191: Power Steering
STARTING AND OPERATING 189 • Upon initial start-up in cold weather, the power steer- POWER STEERING ing pump may make noise for a short amount of time. The standard power steering system will give you good This is due to the cold, thick fluid in the steering vehicle response and increased ease of maneuverability system.
Page 192: Power Steering Fluid Check
190 STARTING AND OPERATING Power Steering Fluid Check WARNING! Checking the power steering fluid level at a defined Fluid level should be checked on a level surface and service interval is not required. The fluid should only be with the engine off to prevent injury from moving checked if a leak is suspected, abnormal noises are parts and to ensure accurate fluid level reading.
Page 193: Parking Brake
STARTING AND OPERATING 191 PARKING BRAKE WARNING! Before leaving the vehicle, make sure you fully apply the parking brake and shift the transmission into REVERSE. Failure to do so may cause the vehicle to roll and cause damage or injury. As an added precaution when parking the vehicle, turn the front wheels toward the curb on a downhill grade and away from the curb on an uphill grade.
Page 194 192 STARTING AND OPERATING The “Brake System Warning Light” in the instrument WARNING! cluster will turn on when the ignition is in the ON/RUN • Never leave children alone in a vehicle. Leaving position and the parking brake is applied. children in a vehicle unattended is dangerous for a NOTE: This light only shows that the parking brake is number of reasons.
Page 195: Brake System
STARTING AND OPERATING 193 BRAKE SYSTEM Brake Pad Break-In NOTE: Your vehicle is equipped with a high perfor- Your vehicle is equipped with dual hydraulic mance braking system. The brake pads are a semi- brake systems. If either of the two hydraulic metallic compound, which offer superior fade resistance systems loses normal capability, the remaining for consistent operation.
Page 196 194 STARTING AND OPERATING Safe Operating Tips WARNING! (Continued) • Do not drive too fast for road conditions, especially WARNING! when roads are wet or slushy. A wedge of water can To use your brakes and accelerator more safely, build up between the tire tread and the road. This follow these tips: hydroplaning action can cause loss of traction, •...
Page 197: Anti-Lock Brake System
STARTING AND OPERATING 195 Anti-Lock Brake System The ABS pump motor runs during the self-test at 12 mph (20 km/h) and during an ABS stop. The pump motor The Anti-Lock Brake System (ABS) is designed to aid the makes a low humming noise during operation, which is driver in maintaining vehicle control under adverse normal.
Page 198 196 STARTING AND OPERATING WARNING! WARNING! (Continued) • The Anti-Lock Brake System (ABS) cannot prevent • The Anti-Lock Brake System (ABS) contains so- the natural laws of physics from acting on the phisticated electronic equipment that may be sus- vehicle, nor can it increase braking or steering ceptible to interference caused by improperly in- efficiency beyond that afforded by the condition of stalled...
Page 199: Electronic Brake Control System
STARTING AND OPERATING 197 the vehicle to a complete stop as soon as possible and WARNING! cycle the ignition to attempt to reset the ABS. If the light remains on, see your authorized dealer immediately to Significant over or under-inflation of tires, or mixing have the system serviced.
Page 200: Anti-Lock Brake System (Abs)
198 STARTING AND OPERATING Anti-Lock Brake System (ABS) Traction Control System (TCS) This system aids the driver in maintaining vehicle control This system monitors the amount of wheel spin of each under adverse braking conditions. The system controls driven wheel. If wheel spin is detected, brake pressure is hydraulic brake pressure to prevent wheel lock-up and applied to the slipping wheel(s) and engine power is help avoid skidding on slippery surfaces during braking.
Page 201 STARTING AND OPERATING 199 In full on mode ESC uses sensors in the vehicle to WARNING! (Continued) determine the path that the driver intends to steer the prevailing road conditions. ESC cannot prevent all vehicle and compares it to the actual path of the vehicle. accidents, including those resulting from excessive When the actual path does not match the intended path, speed in turns, driving on very slippery surfaces, or...
Page 202 200 STARTING AND OPERATING ESC Operating Modes The ESC system has four available operating modes: ESC On This is the normal operating mode for the ESC. When- ever the vehicle is started, the ESC system will be in this mode. This mode should be used for most driving situations.
Page 203 STARTING AND OPERATING 201 message may appear in the Electronic Vehicle Informa- The “ESC Sport Light” will illuminate, and the ESC tion Center (EVIC). Refer to “Electronic Vehicle Informa- SPORT message will display in the vehicle odometer. tion Center (EVIC)” in “Understanding Your Instrument Refer to “Electronic Vehicle Information Center (EVIC)”...
Page 204: Tire Safety Information
202 STARTING AND OPERATING TIRE SAFETY INFORMATION WARNING! Tire Markings In the ESC “Full Off” mode, the engine torque reduction and stability features are disabled. There- fore, the enhanced vehicle stability offered by ESC is unavailable. In an emergency evasive maneuver, the ESC system will not engage to assist in maintaining stability.
Page 205 STARTING AND OPERATING 203 • Temporary spare tires are spares designed for tempo- NOTE: rary emergency use only. Temporary high pressure • P (Passenger) - Metric tire sizing is based on U.S. compact spare tires have the letter “T” or “S” molded design standards.
Page 206 204 STARTING AND OPERATING Tire Sizing Chart EXAMPLE: Size Designation: P = Passenger car tire size based on U.S. design standards ..blank..= Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T or S = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 207 STARTING AND OPERATING 205 EXAMPLE: Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 208: Tire Identification Number (Tin)
206 STARTING AND OPERATING Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall tires as mounted on the vehicle. If the TIN is not found on The TIN may be found on one or both sides of the tire, the outboard side, then you will find it on the inboard however, the date code may only be on one side.
Page 209: Tire Terminology And Definitions
STARTING AND OPERATING 207 EXAMPLE: DOT MA L9 ABCD 0301 01 = Number representing the year in which the tire was manufactured (two digits) — 01 means the year 2001 — Prior to July 2000, tire manufacturers were only required to have one number to represent the year in which the tire was manufactured.
Page 210 208 STARTING AND OPERATING Term Definition Maximum Inflation Pressure The maximum inflation pressure is the maximum permissible cold tire inflation pressure for this tire. The maximum inflation pressure is molded into the sidewall. Recommended Cold Tire Inflation Vehicle manufacturer’s recommended cold tire inflation pressure Pressure as shown on the tire placard.
Page 211: Tire Loading And Tire Pressure
STARTING AND OPERATING 209 Tire Loading And Tire Pressure Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door. Tire Placard Location...
Page 212 210 STARTING AND OPERATING Tire And Loading Information Placard 3) tire size designed for your vehicle 4) cold tire inflation pressures for the front, rear, and spare tires. Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading...
Page 213 STARTING AND OPERATING 211 To determine the maximum loading conditions of your 4. The resulting figure equals the available amount of vehicle, locate the statement “The combined weight of cargo and luggage load capacity. For example, if occupants and cargo should never exceed XXX lbs or “XXX”...
Page 214 212 STARTING AND OPERATING NOTE: • The following table shows examples on how to calcu- late total load, cargo/luggage, and towing capacities of your vehicle with varying seating configurations and number and size of occupants. This table is for illustration purposes only and may not be accurate for the seating and load carry capacity of your vehicle.
Page 215 STARTING AND OPERATING 213...
Page 216: Tires - General Information
214 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 217: Tire Inflation Pressures
STARTING AND OPERATING 215 stability of the vehicle and can produce a feeling of WARNING! (Continued) sluggish response or over responsiveness in the steering. • Unequal tire pressures from one side of the vehicle Unequal tire pressures can cause erratic and unpredict- to the other can cause the vehicle to drift to the able steering response.
Page 218 216 STARTING AND OPERATING Tire pressures change by approximately 1 psi (7 kPa) per CAUTION! 12°F (7°C) of air temperature change. Keep this in mind when checking tire pressure inside a garage, especially in After inspecting or adjusting the tire pressure, al- the winter.
Page 219: Tire Pressures For High Speed Operation
STARTING AND OPERATING 217 Tire Pressures For High Speed Operation Radial Ply Tires The manufacturer advocates driving at safe speeds WARNING! within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high Combining radial ply tires with other types of tires speeds, maintaining correct tire inflation pressure is very on your vehicle will cause your vehicle to handle...
Page 220: Tread Wear Indicators
218 STARTING AND OPERATING Refer to “Freeing A Stuck Vehicle” in “What To Do In Emergencies” for further information. WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one.
Page 221: Life Of Tire
STARTING AND OPERATING 219 Life Of Tire WARNING! (Continued) The service life of a tire is dependent upon varying You could lose control and have a collision resulting factors including, but not limited to: in serious injury or death. • Driving style Keep dismounted tires in a cool, dry place with as little •...
Page 222 220 STARTING AND OPERATING Tire Sizing Chart example found in the Tire Safety WARNING! Information section of this manual for more information • Do not use a tire, wheel size or rating other than relating to the Load Index and Speed Symbol of a tire. that specified for your vehicle.
Page 223: Tire Storage
STARTING AND OPERATING 221 TIRE CHAINS (TRACTION DEVICES) WARNING! (Continued) Due to limited clearance, tire chains or traction devices • Failure to equip your vehicle with tires having are not recommended. adequate speed capability can result in sudden tire failure and loss of vehicle control. CAUTION! CAUTION! Damage to the vehicle may result if tire chains are...
Page 224 222 STARTING AND OPERATING These effects can be reduced by timely rotation of tires. The front and rear tires are different sizes and cannot be The benefits of rotation are especially worthwhile with used in place of each other. Rotate the tires “side-to-side” aggressive tread designs such as those on all season type as shown in the diagram.
Page 225: Tire Pressure Monitor System (Tpms)
STARTING AND OPERATING 223 TIRE PRESSURE MONITOR SYSTEM (TPMS) Tire Pressure Monitoring Low Pressure Warnings The Tire Pressure Monitor System (TPMS) uses wireless technology with wheel rim mounted electronic sensors to The TPM Telltale Light will illuminate in the instru- monitor tire pressure levels.
Page 226 224 STARTING AND OPERATING Service TPMS Warning 2. Installing aftermarket window tinting that contains materials that may block radio wave signals. If a system fault is detected, the TPM Telltale Light will flash on and off for 75 seconds and then remain on solid. 3.
Page 227: Fuel Requirements
STARTING AND OPERATING 225 FUEL REQUIREMENTS Over 40 automobile manufacturers around the world have issued and endorsed consistent gasoline specifica- 8.4L Engine tions (the World Wide Fuel Charter, WWFC) which define fuel properties necessary to deliver enhanced The 8.4L engine is designed to meet all emissions, engine performance, and durability for your emissions regulations and provide excellent vehicle.
Page 228: Gasoline/Oxygenate Blends
226 STARTING AND OPERATING Gasoline/Oxygenate Blends E-85 Usage In Non-Flex Fuel Vehicles Some fuel suppliers blend unleaded gasoline with oxy- Non-FFV vehicles are compatible with gasoline contain- genates such as Ethanol. Fuels blended with oxygenates ing 10% ethanol (E10). Gasoline with higher ethanol may be used in your vehicle.
Page 229: Mmt In Gasoline
STARTING AND OPERATING 227 • disconnect and reconnect the battery to reset the Materials Added To Fuel engine controller memory All gasoline sold in the United States is required to More extensive repairs will be required for prolonged contain effective detergent additives. Use of additional exposure to E-85 fuel.
Page 230: Carbon Monoxide Warnings
228 STARTING AND OPERATING Carbon Monoxide Warnings CAUTION! (Continued) • An out-of-tune engine or certain fuel or ignition WARNING! malfunctions can cause the catalytic converter to Carbon monoxide (CO) in exhaust gases is deadly. overheat. If you notice a pungent burning odor or Follow the precautions below to prevent carbon some light smoke, your engine may be out of tune monoxide poisoning:...
Page 231: Adding Fuel
STARTING AND OPERATING 229 4. Insert the fuel nozzle fully into the filler pipe – the WARNING! (Continued) nozzle opens and holds the flapper door while refuel- • Guard against carbon monoxide with proper main- ing. tenance. Have the exhaust system inspected every NOTE: Only the correct size nozzle opens the latches time the vehicle is raised.
Page 232: Emergency Fuel Filler Door Release
230 STARTING AND OPERATING Emergency Fuel Filler Door Release WARNING! If you are unable to open the fuel filler door, use the fuel • Never have any smoking materials lit in or near the filler door emergency release. vehicle when the fuel door is open or the tank is 1.
Page 233: Recreational Towing (Behind Motorhome, Etc.)
STARTING AND OPERATING 231 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle (Flat Towing With All Four Wheels On The Ground) Towing Condition Wheels OFF The Ground Manual Transmission Flat Tow None NOT ALLOWED Dolly Tow Front NOT ALLOWED Rear NOT RECOMMENDED...
Page 234: Ground Clearance
232 STARTING AND OPERATING GROUND CLEARANCE The front and rear fascias and side sills ride low and ground clearance is limited. CAUTION! Damage to the front and rear fascias and side sills can occur if you disregard the low ground clearance in these areas of your vehicle.
Page 235: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS ▫ TIREFIT Usage Precautions....238 HAZARD WARNING FLASHER ...234 ▫ Sealing A Tire With TIREFIT ....240 IF YOUR ENGINE OVERHEATS .
Page 236: Hazard Warning Flasher
234 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER NOTE: With extended use the Hazard Warning flasher may wear down your battery. The Hazard Warning flasher switch is located in the center of the instrument panel above the climate controls. IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the Press the switch to turn on the Hazard Warning...
Page 237: Tirefit Kit
WHAT TO DO IN EMERGENCIES 235 NOTE: There are steps that you can take to slow down TIREFIT KIT an impending overheat condition: Small punctures up to ¼” (6 mm) in the tire tread can be • If your air conditioner (A/C) is on, turn it off. The A/C sealed with TIREFIT.
Page 238: Tirefit Storage
236 WHAT TO DO IN EMERGENCIES TIREFIT Storage TIREFIT Kit Components And Operation The TIREFIT kit is located in left side of the trunk. TIREFIT Components TIREFIT Location 1. Sealant Bottle 2. Deflation Button 3. Pressure Gauge...
Page 239 WHAT TO DO IN EMERGENCIES 237 4. Power Button Selecting Sealant Mode 5. Mode Select Knob Turn the Mode Select Knob (5) to this position to inject the TIREFIT Sealant 6. Sealant Hose (Clear) and to inflate the tire. Use the Sealant 7.
Page 240: Tirefit Usage Precautions
238 WHAT TO DO IN EMERGENCIES • For optimum performance, make sure the valve stem TIREFIT Usage Precautions on the wheel is free of debris before connecting the • Replace the TIREFIT Sealant Bottle (1) and Sealant TIREFIT kit. Hose (6) prior to the expiration date (printed on the •...
Page 241 WHAT TO DO IN EMERGENCIES 239 WARNING! WARNING! (Continued) • Keep TIREFIT away from open flames or heat • Do not attempt to seal a tire on the side of the source. vehicle closest to traffic. Pull far enough off the •...
Page 242: Sealing A Tire With Tirefit
240 WHAT TO DO IN EMERGENCIES when injecting the sealant into the deflated tire and WARNING! (Continued) running the air pump. Move the vehicle as necessary to • TIREFIT Sealant solution contains latex. In case of place the valve stem in this position before proceeding. an allergic reaction or rash, consult a physician 3.
Page 243 WHAT TO DO IN EMERGENCIES 241 5. Uncoil the Power Plug (8) and insert the plug into the If the sealant (white fluid) does not flow within 0 – 10 vehicle’s 12 Volt power outlet. seconds through the Sealant Hose (6): NOTE: Do not remove foreign objects (e.g., screws or 1.
Page 244 242 WHAT TO DO IN EMERGENCIES NOTE: If the Mode Select Knob (5) is on Air Mode and If the tire does not inflate to at least 26 psi (1.8 Bar) the pump is operating, air will dispense from the Air pressure within 15 minutes: Pump Hose (7) only, not the Sealant Hose (6).
Page 245 WHAT TO DO IN EMERGENCIES 243 CAUTION! WARNING! • The metal end fitting from Power Plug (8) may get TIREFIT is not a permanent flat tire repair. Have the hot after use, so it should be handled carefully. tire inspected and repaired or replaced after using •...
Page 246 244 WHAT TO DO IN EMERGENCIES 3. Uncoil the Air Pump Hose (7) (black in color) and 2. Disconnect the TIREFIT kit from the valve stem, screw the fitting at the end of hose (7) onto the valve reinstall the cap on the valve stem and unplug from 12 stem.
Page 247: Jump-Starting Procedures
WHAT TO DO IN EMERGENCIES 245 (F) Sealant Bottle And Hose Replacement: 6. Verify that the cap is installed on the fitting at the end of the Sealant Hose (6) and return the hose to its 1. Uncoil the Sealant Hose (6) (clear in color). storage area (located on the bottom of the air pump).
Page 248 246 WHAT TO DO IN EMERGENCIES NOTE: The battery is located underneath an access WARNING! (Continued) panel inside the rear compartment on the left side of the • Do not attempt to push or tow your vehicle to get it vehicle.
Page 249 WHAT TO DO IN EMERGENCIES 247 1. Wear eye protection and remove any metal jewelry such as watchbands or bracelets that might make an inadvertent electrical contact. 2. When boost is provided by a battery in another vehicle, park that vehicle within booster cable reach, but without allowing the vehicles touch one another.
Page 250 248 WHAT TO DO IN EMERGENCIES CAUTION! WARNING! Failure to follow these procedures could result in Do not connect the cable to the negative post (-) of the damage to the charging system of the booster vehicle discharged battery. The resulting electrical spark or the discharged vehicle.
Page 251: Freeing A Stuck Vehicle
WHAT TO DO IN EMERGENCIES 249 13. Disconnect the positive (+) jumper cable from the FREEING A STUCK VEHICLE positive (+) post of the booster battery. If your vehicle becomes stuck in mud, sand, or snow, it can often be moved using a rocking motion. Turn your 14.
Page 252: Towing A Disabled Vehicle
250 WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE CAUTION! (Continued) Do not tow with sling-type equipment. Only use flatbed • Revving the engine or spinning the wheels too fast equipment. Always comply with applicable state or local may lead to transmission or clutch overheating and towing ordinances.
Page 253 MAINTAINING YOUR VEHICLE CONTENTS ▫ Maintenance-Free Battery ....260 ENGINE COMPARTMENT — 8.4L ..253 ▫ Hibernation Mode ....262 ONBOARD DIAGNOSTIC SYSTEM (OBD II) .
Page 254 252 MAINTAINING YOUR VEHICLE ▫ Hydraulic Clutch .....278 ▫ Front/Rear Side Marker Lamp ... .293 ▫...
Page 255: Engine Compartment - 8.4L
MAINTAINING YOUR VEHICLE 253 ENGINE COMPARTMENT — 8.4L 1 — Washer Fluid Reservoir 6 — Brake/Clutch Fluid Reservoir 2 — Coolant Pressure Cap 7 — Engine Oil Fill 3 — Engine Oil Dipstick 8 — Power Steering Fluid Reservoir 4 — Power Distribution Center 9 —...
Page 256: Onboard Diagnostic System (Obd Ii)
254 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM (OBD II) CAUTION! To meet new government regulations and promote Prolonged driving with the light on could cause cleaner air, your vehicle is equipped with a sophisticated further damage to the emission control system. It onboard diagnostic system called OBD II.
Page 257 MAINTAINING YOUR VEHICLE 255 Indicator Light (MIL)” is functioning and is not on when 3. As soon as you turn the ignition switch to the ON the engine is running, and that the OBD II system is position, you will see the MIL symbol come on as part ready for testing.
Page 258: Replacement Parts
256 MAINTAINING YOUR VEHICLE you may need to do nothing more than drive your DEALER SERVICE vehicle as you normally would in order for your OBD II Your authorized dealer has the qualified service person- system to update. A recheck with the above test routine nel, special tools, and equipment to perform all service may then indicate that the system is now ready.
Page 259: Maintenance Procedures
MAINTAINING YOUR VEHICLE 257 MAINTENANCE PROCEDURES CAUTION! (Continued) The pages that follow contain the required maintenance • Your vehicle has been built with improved fluids services determined by the engineers who designed your that protect the performance and durability of your vehicle.
Page 260 258 MAINTAINING YOUR VEHICLE check the oil level is approximately five minutes after a Engine Oil Selection fully warmed engine is turned off or before starting the For best performance and maximum protection under all engine after it has sat overnight. types of operating conditions, the manufacturer only recommends full synthetic engine oils that meet the Checking the oil while the vehicle is on level ground also...
Page 261: Engine Oil Filter
MAINTAINING YOUR VEHICLE 259 The engine oil filler cap also shows the recommended engine Engine Oil Filter oil viscosity for your engine. For information on engine oil The engine oil filter should be replaced with a new filter filler cap location, refer to “Engine Compartment” in “Main- at every engine oil change.
Page 262: Maintenance-Free Battery
260 MAINTAINING YOUR VEHICLE WARNING! CAUTION! The air induction system (air cleaner, hoses, etc.) can Some aftermarket air cleaners and filters can cause provide a measure of protection in the case of engine mass air flow sensor issues which can lead to a backfire.
Page 263 MAINTAINING YOUR VEHICLE 261 WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Do not allow battery fluid to contact your eyes, skin, or clothing. Do not lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.
Page 264: Hibernation Mode
262 MAINTAINING YOUR VEHICLE Hibernation Mode CAUTION! The Hibernation mode feature conserves battery power • It is essential when replacing the cables on the when storing the vehicle. It allows for up to three months battery that the positive cable is attached to the of storage time without losing radio and engine control- positive post and the negative cable is attached to ler memory.
Page 265: Air Conditioner Maintenance
MAINTAINING YOUR VEHICLE 263 To Activate Hibernation Mode Air Conditioner Maintenance For best possible performance, your air conditioner 1. Cycle the ignition switch to (ACCY). should be checked and serviced by an authorized dealer 2. Select Hibernation mode within the Electronic Vehicle at the start of each warm season.
Page 266: Body Lubrication
264 MAINTAINING YOUR VEHICLE Refrigerant Recovery And Recycling WARNING! R-134a Air Conditioning Refrigerant is a hydrofluoro- • Use only refrigerants and compressor lubricants carbon (HFC) that is endorsed by the Environmental approved by the manufacturer for your air condi- Protection Agency and is an ozone-saving product. How- tioning system.
Page 267: Wiper Blades
MAINTAINING YOUR VEHICLE 265 be wiped clean to remove dust and grit; after lubricating Operation of the wipers on dry glass for long periods excess oil and grease should be removed. Particular may cause deterioration of the wiper blades. Always use attention should also be given to hood latching compo- washer fluid when using the wipers to remove salt or dirt nents to ensure proper function.
Page 268: Adding Washer Fluid
266 MAINTAINING YOUR VEHICLE Adding Washer Fluid Exhaust System The windshield washer fluid reservoir is located in the The best protection against carbon monoxide entry into front of the engine compartment on the passenger side of the vehicle body is a properly maintained engine exhaust the vehicle.
Page 269 MAINTAINING YOUR VEHICLE 267 WARNING! CAUTION! • Exhaust gases can injure or kill. They contain • The catalytic converter requires the use of un- carbon monoxide (CO), which is colorless and leaded fuel only. Leaded gasoline will destroy the odorless. Breathing it can make you unconscious effectiveness of the catalyst as an emissions control and can eventually poison you.
Page 270 268 MAINTAINING YOUR VEHICLE Under normal operating conditions, the catalytic con- To minimize the possibility of catalytic converter dam- verter will not require maintenance. However, it is im- age: portant to keep the engine properly tuned to assure • Do not shut off the engine or interrupt the ignition, proper catalyst operation and prevent possible catalyst when the transmission is in gear and the vehicle is in damage.
Page 271: Cooling System
MAINTAINING YOUR VEHICLE 269 Cooling System Coolant Checks Check engine coolant (antifreeze) protection every 12 WARNING! months (before the onset of freezing weather, where applicable). If the engine coolant (antifreeze) is dirty or • When working near the radiator cooling fan, rusty in appearance, the system should be drained, disconnect the fan motor lead or turn the ignition flushed, and refilled with fresh engine coolant (anti-...
Page 272 270 MAINTAINING YOUR VEHICLE If the cap is sealing properly, the engine coolant (anti- CAUTION! freeze) will begin to drain from the coolant recovery • Mixing of engine coolant (antifreeze) other than bottle. DO NOT REMOVE THE COOLANT PRESSURE CAP WHEN THE COOLING SYSTEM IS HOT. specified Organic Additive Technology (OAT) en- gine coolant (antifreeze), may result in engine Cooling System –...
Page 273 MAINTAINING YOUR VEHICLE 271 you use the same engine coolant (OAT coolant conform- CAUTION! (Continued) ing to MS-12106) throughout the life of your vehicle. • Do not use water alone or alcohol-based engine Please review these recommendations for using Organic coolant (antifreeze) products.
Page 274 272 MAINTAINING YOUR VEHICLE • Use only high purity water such as distilled or deion- The cap should be inspected and cleaned if there is any ized water when mixing the water/engine coolant accumulation of foreign material on the sealing surfaces. (antifreeze) solution.
Page 275 MAINTAINING YOUR VEHICLE 273 Disposal Of Used Engine Coolant engine coolant (antifreeze) freeze point or replacing cool- ant. Advise your service attendant of this. As long as the Used ethylene glycol-based engine coolant (antifreeze) is engine operating temperature is satisfactory, the coolant a regulated substance requiring proper disposal.
Page 276: Brake System
274 MAINTAINING YOUR VEHICLE • Make sure that the coolant expansion bottle overflow If an examination of your engine compartment shows no evidence of radiator or hose leaks, the vehicle may be hoses are not kinked or obstructed. safely driven. The vapor will soon dissipate. •...
Page 277 MAINTAINING YOUR VEHICLE 275 Overfilling of fluid is not recommended because it may WARNING! cause leaking in the system. Riding the brakes can lead to brake failure and With disc brakes, fluid level can be expected to fall as the possibly an accident.
Page 278 276 MAINTAINING YOUR VEHICLE WARNING! WARNING! (Continued) • To avoid contamination from foreign matter or • Use only manufacturer’s recommended brake moisture, use only new brake fluid or fluid that has fluid. Refer to “Fluids, Lubricants, and Genuine been in a tightly closed container. Keep the master Parts”...
Page 279: Manual Transmission
MAINTAINING YOUR VEHICLE 277 Manual Transmission WARNING! (Continued) Transmission Fluid Level Check • Do not allow petroleum based fluid to contaminate the brake fluid. Brake seal components could be Check the fluid in the transmission when performing damaged, causing partial or complete brake failure. other underbody services.
Page 280: Hydraulic Clutch
278 MAINTAINING YOUR VEHICLE manufacturer’s recommended brake fluid. Refer to “Flu- CAUTION! (Continued) ids, Lubricants, and Genuine Parts” in “Maintaining Your in transmission shift quality and/or damage to the Vehicle” for further information. transmission. Refer to “Fluids, Lubricants, and Rear Axle Genuine Parts”...
Page 281: Appearance Care And Protection From Corrosion
MAINTAINING YOUR VEHICLE 279 highly corrosive to the metal in your vehicle. Outside CAUTION! parking, which exposes your vehicle to airborne contami- nants, road surfaces on which the vehicle is operated, Using axle fluid other than the manufactured recom- extreme hot or cold weather and other extreme condi- mended fluid may cause a shudder/noise issue.
Page 282 280 MAINTAINING YOUR VEHICLE • Use a high quality cleaner wax, such as MOPAR® Wheel And Wheel Trim Care Cleaner Wax to remove road film, stains and to protect • All wheels and wheel trim, especially aluminum and your paint finish. Take care never to scratch the paint. chrome plated wheels, should be cleaned regularly •...
Page 283 MAINTAINING YOUR VEHICLE 281 Interior Care WARNING! Use MOPAR® Total Clean to clean fabric upholstery and Do not use volatile solvents for cleaning purposes. carpeting. Many are potentially flammable, and if used in Use MOPAR® Total Clean to clean vinyl upholstery. closed areas they may cause respiratory harm.
Page 284 282 MAINTAINING YOUR VEHICLE Glass Surfaces 1. Clean with a wet soft rag. A mild soap solution may be used, but do not use high alcohol content or abrasive All glass surfaces should be cleaned on a regular basis cleaners. If soap is used, wipe clean with a clean damp with MOPAR®...
Page 285 MAINTAINING YOUR VEHICLE 283 Aero Group — If Equipped Please review all of the precautionary notes regarding the Aero Group option. Front Splitter The front splitter will not flex or compress against impacts from the front. If an impact does occur, have the splitter inspected.
Page 286: Fuses
284 MAINTAINING YOUR VEHICLE FUSES CAUTION! Power Distribution Center Use care when approaching parking blocks, tall The Power Distribution Center is located in the engine speed bumps and garage curbs. These surfaces can compartment on the driver’s side of the vehicle. This damage your splitter.
Page 287 MAINTAINING YOUR VEHICLE 285 Cavity Relay Cartridge Fuse Mini-Fuse Description — 40 Amp Green — Rad Fan — 40 Amp Green — Rad Fan Rly High — 40 Amp Green — ABS/ESP Pump Feed — 40 Amp Green — Starter —...
Page 288 286 MAINTAINING YOUR VEHICLE Cavity Relay Cartridge Fuse Mini-Fuse Description — — 25 Amp circuit Power Seats breaker — 30 Amp Pink — Driver Door Mod — 30 Amp Pink — Passenger Door Mod — 30 Amp Pink — — 20 Amp Blue —...
Page 289 MAINTAINING YOUR VEHICLE 287 Cavity Relay Cartridge Fuse Mini-Fuse Description — 20 Amp Yellow — RR Power Outlet, Adj. Pedals, UCI — — — B+ Jumper — Jumper Black — B+ Jumper — 20 Amp Yellow — Spare — — —...
Page 290 288 MAINTAINING YOUR VEHICLE Cavity Relay Cartridge Fuse Mini-Fuse Description 43AC — — 10 Amp Red SCCM (Forward Fuse) 43BE — — 10 Amp Red Corax (Rearward Fuse) 44BE — — 10 Amp Red (Rearward Fuse) — — 10 Amp Red PCM- Powertrain Control Module —...
Page 291 MAINTAINING YOUR VEHICLE 289 Cavity Relay Cartridge Fuse Mini-Fuse Description HC Micro — — Starter Relay HC Micro — — EBL Relay HC Relay — — Rad Fan Relay High HC Micro — — Wiper ON/OFF HC Micro — — Wiper LO/HI G8VA —...
Page 292: Vehicle Storage
290 MAINTAINING YOUR VEHICLE VEHICLE STORAGE CAUTION! We recommend that you follow these guidelines for • When installing the power distribution center storing your vehicle for extended periods. cover, it is important to ensure the cover is properly • Fill the fuel tank. This will prevent water condensation positioned and fully latched.
Page 293 MAINTAINING YOUR VEHICLE 291 • Block the wheels. Do not apply the parking brake. Then, either disconnect the battery at the negative terminal or use the “Battery Save Feature” to conserve • Cut blocks of plywood about the same size of the tires. battery power.
Page 294: Replacement Bulbs
292 MAINTAINING YOUR VEHICLE • Check the battery every four to six weeks to ensure flashes, the system is operating properly. If not, there that the voltage is above 12.40 Volts. The voltage will is a problem with a switch or the system. See your authorized dealer for service.
Page 295: Bulb Replacement
MAINTAINING YOUR VEHICLE 293 Bulb Number Bulb Number Courtesy Foot Well Rear Marker Lamp Lights Backup Lamp 3157 Cargo Lamp (Coupe Lift- License Lamp LED (Serviced at gate) Authorized Dealer) BULB REPLACEMENT Exterior Bulbs Bulb Number Front Headlamp, Front Park/Turn Signal Lamp Low/High Beam Head- LED (Serviced at For bulb replacement, see your authorized dealer.
Page 296: Taillamp, Tail/Stop Lamp
294 MAINTAINING YOUR VEHICLE NOTE: Backup Lamps • If a screwdriver is used, make sure a soft material is 1. Reach behind the rear bumper and press the release placed between the vehicle body and tool so not to tabs on the backup lamp housing. scratch the paint.
Page 297: Fluid Capacities
MAINTAINING YOUR VEHICLE 295 FLUID CAPACITIES U.S. Metric Fuel (Approximate) 16 Gallons 60.6 Liters Engine Oil With Filter 8.4 Liter Engine – We recommend you use SAE 0W-40, 11 Quarts 10.4 Liters API Certified. Transmission 8.4 Liter Engine – We recommend you use MOPAR® 3.4 Quarts 3.2 Liters ATF+4®...
Page 298: Fluids, Lubricants And Genuine Parts
296 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant We recommend you use MOPAR® Antifreeze/Coolant 10 Year/150,000 Mile Formula OAT (Organic Additive Technology). Engine Oil We recommend you use a full synthetic 0W-40 or equivalent engine oil.
Page 299: Chassis
MAINTAINING YOUR VEHICLE 297 Chassis Component Fluid, Lubricant, or Genuine Part Transmission We recommend you use MOPAR® ATF+4® Automatic Transmission Fluid. Rear Axle We recommend you use Castrol SAF-XJ/SAE 75W-140 Synthetic Gear and Axle Lubricant. Brake/Clutch Master Cylinder We recommend you use MOPAR® Brake and Clutch Fluid DOT 4 Motor Vehicle.
Page 301: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS ▫ Required Maintenance Intervals ...301 MAINTENANCE SCHEDULES ... . .300...
Page 302 300 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULES At Each Stop For Fuel • Check the engine oil level about five minutes after a The Scheduled Maintenance services listed in this manual must be done at the times or mileages specified fully warmed engine is shut off. Checking the oil level to protect your vehicle warranty and ensure the best while the vehicle is on level ground will improve the vehicle performance and reliability.
Page 303 MAINTENANCE SCHEDULES 301 • Check the fluid levels of the coolant reservoir, brake • Lubricate door hinges and check springs. master cylinder, power steering, and transmission, and • Check the engine coolant level, hoses, and clamps. add as needed. • Check power steering fluid level. •...
Page 304 302 MAINTENANCE SCHEDULES 6,000 Miles (10,000 km) or 12,000 Miles (20,000 km) or 12 Months Maintenance Service 6 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 305 MAINTENANCE SCHEDULES 303 18,000 Miles (30,000 km) or 24,000 Miles (40,000 km) or 24 Months Maintenance Service 18 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 306 304 MAINTENANCE SCHEDULES 30,000 Miles (50,000 km) or 36,000 Miles (60,000 km) or 36 Months Maintenance Service 30 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 307 MAINTENANCE SCHEDULES 305 42,000 Miles (70,000 km) or 48,000 Miles (80,000 km) or 48 Months Maintenance Service 42 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 308 306 MAINTENANCE SCHEDULES 54,000 Miles (90,000 km) or 60,000 Miles (100,000 km) or 60 Months Maintenance Service 54 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 309 MAINTENANCE SCHEDULES 307 66,000 Miles (110,000 km) or 72,000 Miles (120,000 km) or 72 Months Maintenance Service 66 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 310 308 MAINTENANCE SCHEDULES 78,000 Miles (130,000 km) or 84,000 Miles (140,000 km) or 84 Months Maintenance Service 78 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 311 MAINTENANCE SCHEDULES 309 90,000 Miles (150,000 km) or 96,000 Miles (160,000 km) or 96 Months Maintenance Service 90 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 312 310 MAINTENANCE SCHEDULES 102,000 Miles (170,000 km) or 108,000 Miles (180,000 km) or 108 Months Maintenance Service 102 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 313 MAINTENANCE SCHEDULES 311 114,000 Miles (190,000 km) or 114 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature, Authorized Service Center...
Page 314 312 MAINTENANCE SCHEDULES 120,000 Miles (200,000 km) or 120 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Replace the air conditioning filter (if equipped). ❏...
Page 315 MAINTENANCE SCHEDULES 313 126,000 Miles (210,000 km) or 132,000 Miles (220,000 km) or 132 Months Maintenance Service 126 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 316 314 MAINTENANCE SCHEDULES 138,000 Miles (230,000 km) or 144,000 Miles (240,000 km) or 144 Months Maintenance Service 138 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 317 MAINTENANCE SCHEDULES 315 150,000 Miles (250,000 km) or 150 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Flush and replace the engine coolant at 150,000 miles (250 000 km) or 120 months whichever comes first.
Page 318 316 MAINTENANCE SCHEDULES * This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment.
Page 319: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS ▫ Customer Assistance For The Hearing Or Speech SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE ....319 Impaired (TDD/TTY).
Page 320 318 IF YOU NEED CONSUMER ASSISTANCE ▫ Traction Grades ..... . .325 DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES ....325 ▫...
Page 321: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 319 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealer, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you are having warranty work done, be sure to have the...
Page 322: Chrysler Group Llc Customer Center
320 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized Chrysler Group LLC Customer Center dealer service manager first. Most matters can be re- P.O. Box 21–8004 solved with this process. Auburn Hills, MI 48321–8004 •...
Page 323: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
IF YOU NEED CONSUMER ASSISTANCE 321 Customer Assistance For The Hearing Or Speech Warranty expires. The manufacturer stands behind only Impaired (TDD/TTY) the manufacturer’s service contracts. If you purchased a manufacturer’s service contract, you will receive Plan To assist customers who have hearing difficulties, the Provisions and an Owner Identification Card in the mail manufacturer has installed special TDD (Telecommuni- within three weeks of the vehicle delivery date.
Page 324: Warranty Information
322 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment WARRANTY INFORMATION when you purchased the vehicle. An authorized dealer See the Warranty Information Booklet, located on the has also made a major investment in facilities, tools, and DVD, for the terms and provisions of Chrysler Group training to assure that you are absolutely delighted with LLC warranties applicable to this vehicle and market.
Page 325: In Canada
IF YOU NEED CONSUMER ASSISTANCE 323 If NHTSA receives similar complaints, it may open an defect to the Canadian government should contact Trans- investigation, and if it finds that a safety defect exists in port Canada, Motor Vehicle Defect Investigations and a group of vehicles, it may order a recall and remedy Recalls at 1-800-333-0510 or go to http://www.tc.gc.ca/ campaign.
Page 326 324 IF YOU NEED CONSUMER ASSISTANCE diagnosing/troubleshooting, problem solving, maintain- Owner’s Manuals ing, servicing, and repairing Chrysler Group LLC ve- These Owner’s Manuals have been prepared with the hicles. A complete working knowledge of the vehicle, assistance of service and engineering specialists to ac- system, and/or components is written in straightforward quaint you with specific Chrysler Group LLC vehicles.
Page 327 IF YOU NEED CONSUMER ASSISTANCE 325 DEPARTMENT OF TRANSPORTATION UNIFORM significantly from the norm due to variations in driving TIRE QUALITY GRADES habits, service practices, and differences in road charac- teristics and climate. The following tire grading categories were established by the National Highway Traffic Safety Administration.
Page 328 326 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, The temperature grade for this tire is established for representing the tire’s resistance to the generation of heat a tire that is properly inflated and not overloaded. and its ability to dissipate heat, when tested under Excessive speed, under-inflation, or excessive load- controlled conditions on a specified indoor laboratory...
Page 329 INDEX...
Page 330 328 INDEX About Your Brakes ......193 Alterations/Modifications, Vehicle ....7 ABS (Anti-Lock Brake System) .
Page 331 INDEX 329 Jump Starting ......245 Camera, Rear ......104 Keyless Transmitter Replacement (RKE) .
Page 332 330 INDEX Cleaning Cruise Light ......133 Wheels .......280 Cupholders.
Page 333 INDEX 331 Door Opener, Garage..... . .106 Towing ......250 Doors .
Page 334 332 INDEX Enhanced Accident Response Feature ... .56 Fluid Level Checks Ethanol ....... .226 Brake .
Page 335 INDEX 333 Octane Rating ......225 Hazard Requirements ......225 Driving Through Flowing, Rising, or Shallow Tank Capacity .
Page 336 334 INDEX Illuminated Entry ......20 Key, Replacement ......16 Immobilizer (Sentry Key) .
Page 337 INDEX 335 Brake Warning ......128 Malfunction Indicator (Check Engine) ..132 Bulb Replacement .
Page 338 336 INDEX Power Door ......25 Vanity ....... .79 Low Tire Indicator .
Page 339 INDEX 337 Materials Added to ..... .259 Placard, Tire and Loading Information ..210 Recommendation .
Page 340 338 INDEX Rear Window Defroster .....121 Rotation, Tires ......221 Rear Window Features .
Page 341 INDEX 339 Seats ........80 Speed Control (Cruise Control)....101 Adjustment .
Page 342 340 INDEX Tachometer......130 Quality Grading ......325 Theft Alarm (Security Alarm).
Page 343 INDEX 341 Shifting ......179 Vehicle Theft Alarm (Security Alarm) ... .18 Transmitter Battery Service (Remote Keyless Entry) .
Page 344 342 INDEX Windshield Defroster ..... . .70 Windshield Washers ......95 Windshield Wiper Blades .
Page 345 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 346 Chrysler Group LLC 13ZD-126-AA First Edition Rev 1 Printed in U.S.A.

Dodge 2013 SRT Viper Owner's Manual

Introduction

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Maintaining Your Vehicle

If You Need Consumer Assistance

Quick Links

Chapters

Related Manuals for Dodge 2013 SRT Viper

Summary of Contents for Dodge 2013 SRT Viper
