Summary of Contents for Dodge 2013 Dart

  • Page 1 2 0 1 3 2 0 1 3 2 0 1 3 O W N E R ’ S M A N U A L O W N E R ’ S M A N U A L O W N E R ’ S M A N U A L...
  • Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of Chrysler Group LLC shall be deemed to be deleted and the features and equipment that are either standard or optional name Chrysler Canada Inc.
  • Page 3: Introduction 3

    TABLE OF CONTENTS SECTION PAGE ............3 INTRODUCTION .
  • Page 5 INTRODUCTION CONTENTS Introduction ......4 Vehicle Identification Number ....6 How To Use This Manual .
  • Page 6: Introduction

    4 INTRODUCTION INTRODUCTION When it comes to service, remember that your authorized Congratulations on selecting your new Chrysler Group dealer knows your vehicle best, has factory-trained tech- LLC vehicle. Be assured that it represents precision nicians and genuine MOPAR parts, and cares about workmanship, distinctive styling, and high quality - all your satisfaction.
  • Page 7 INTRODUCTION 5...
  • Page 8: Warnings And Cautions

    6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
  • Page 9: Vehicle Modifications/Alterations

    INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Right Front Body VIN Location NOTE: It is illegal to remove or alter the VIN.
  • Page 11: Table Of Contents

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Customer Key Programming ... . . 20 Ignition Node Module (IGNM) —...
  • Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Lock The Doors ....25 Keyless Enter-N-Go™ ....35 To Unlatch The Trunk .
  • Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 Energy Management Feature ... . . 56 Child Restraints ..... . 82 Seat Belt Pretensioner .
  • Page 14: Things To Know Before Starting Your Vehicle 9

    12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Ignition Node Module (IGNM) — If Equipped Your vehicle uses either a key start ignition system or The Ignition Node Module (IGNM) operates similar to an keyless ignition system. The key start ignition system ignition switch.
  • Page 15 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 NOTE: If your vehicle is equipped with Keyless Enter- N-Go, the Electronic Vehicle Information Center (EVIC) will display the ignition switch position (OFF/ACC/ RUN). Refer to “Electronic Vehicle Information Center (EVIC) — If Equipped” in “Understanding Your Instru- ment Panel”...
  • Page 16: Keyless Ignition Node (Kin) - If Equipped

    14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Keyless Ignition Node (KIN) — If Equipped This feature allows the driver to operate the ignition switch with the push of a button, as long as the Remote Keyless Entry (RKE) transmitter is in the passenger compartment.
  • Page 17: Standard Blade Ignition Key - If Equipped

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 Keyless Enter-N-Go Feature If your vehicle is equipped with the Keyless Enter-N-Go feature, refer to “Starting Procedure” in “Starting And Operating” for further information. Standard Blade Ignition Key — If Equipped Your vehicle may use a standard blade key ignition system.
  • Page 18: Key Fob - If Equipped

    16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Key Fob — If Equipped The Key Fob also contains the Remote Keyless Entry (RKE) transmitter and an emergency key, which stores in the rear of the Key Fob. The emergency key allows for entry into the vehicle should the battery in the vehicle or the Key Fob go dead.
  • Page 19: Ignition Or Accessory On Message

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 you to cycle the ignition to OFF. In addition to the chime, the ignition or accessory on message will display in the cluster. NOTE: With the Uconnect Touch™ system, the power window switches, radio, power sunroof (if equipped), and power outlets will remain active for up to 10 minutes after the ignition is cycled to the OFF position.
  • Page 20: Sentry Key

    18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) CAUTION! • Allowing children to be in a vehicle unattended is An unlocked car is an invitation to thieves. Always dangerous for a number of reasons. A child or remove the Key or Key Fob from vehicle, cycle the others could be seriously or fatally injured.
  • Page 21: Replacement Keys

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 After cycling the ignition to the ON/RUN position, the CAUTION! Vehicle Security Light will turn on for three seconds for a bulb check. If the light remains on after the bulb check, it The Sentry Key Immobilizer system is not compat- indicates that there is a problem with the electronics.
  • Page 22: Customer Key Programming

    20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Customer Key Programming CAUTION! Programming Keys or Key Fobs with RKE transmitters may be performed at an authorized dealer. Always remove the keys from the vehicle and lock all doors when leaving the vehicle unattended. General Information The Sentry Key system complies with FCC rules Part 15 At the time of purchase, the original owner is provided...
  • Page 23: Rearming Of The System

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 Security Alarm will provide the following audible and time, the Vehicle Security Light will flash. If it does not visible signals: the horn will pulse, the headlights, park illuminate, the Vehicle Security Alarm is not arming. In lamps and/or turn signals will flash, and the Vehicle addition, if you open a door during the arming period, Security Light in the instrument cluster will flash.
  • Page 24: To Disarm The System

    22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Disarm The System Vehicles Equipped With Keyless Enter-N-Go Either press the UNLOCK button on the RKE transmitter Vehicles Not Equipped With Keyless Enter-N-Go or grasp the Passive Entry Unlock Door Handle (refer to Either press the UNLOCK button on the RKE transmitter “Keyless Enter-N-Go”...
  • Page 25: Illuminated Entry

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 If the Vehicle Security Alarm is armed and the battery The lights will fade to off after approximately 30 seconds becomes disconnected the Vehicle Security Alarm will or they will immediately fade to off once the ignition is remain armed when the battery is reconnected.
  • Page 26: To Unlock The Doors

    24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Driving at speeds 5 mph (8 km/h) and above disables the system from responding to all RKE transmit- ter buttons for all RKE transmitters. Keyless Enter-N-Go Key Fob With RKE Transmitter To Unlock The Doors Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door or twice...
  • Page 27: To Lock The Doors

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 If the vehicle is equipped with Passive Entry, refer to Turn Headlights On With Remote Key Unlock “Keyless Enter-N-Go” under “Things To Know Before This feature activates the headlights for up to 90 seconds Starting Your Vehicle”...
  • Page 28: To Unlatch The Trunk

    26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE turned on or turned off. To change the current setting, The Panic Alarm will stay on for three minutes unless refer to “Uconnect Touch™ Settings” in “Understanding you turn it off by either pressing the PANIC button a Your Instrument Panel”...
  • Page 29: Transmitter Battery Replacement

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 Transmitter Battery Replacement “gap” between the two halves. If equipped, install and The recommended replacement battery is CR2032. tighten the screw until snug. Test RKE transmitter operation. NOTE: Perchlorate Material – special handling may ap- ply.
  • Page 30: Remote Starting System - If Equipped

    28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If your RKE transmitter fails to operate from a normal How To Use Remote Start distance, check for these two conditions: All of the following conditions must be met before the engine will remote start: 1.
  • Page 31 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 • Remote Start Aborted — Hood Open WARNING! • Remote Start Aborted — Trunk Open • Do not start or run an engine in a closed garage or • Remote Start Aborted — Fuel Low confined area.
  • Page 32 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: NOTE: To avoid unintentional shutdowns, the system • If an engine fault is present or fuel level is low, the will disable the one time press of the REMOTE START vehicle will start and then shut down in 10 seconds. button for two seconds after receiving a valid Remote Start request.
  • Page 33: Door Locks

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 with Keyless Enter-N-Go) will display in the EVIC until you push the START button or turn the key to the RUN position. DOOR LOCKS Manual Door Locks To lock each door, rotate the door lock knob on each door trim panel forward.
  • Page 34: Power Door Locks

    32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Door Locks WARNING! A power door lock switch is on each front door trim • For personal security and safety in the event of an panel. Use this switch to lock or unlock the doors. accident, lock the vehicle doors before you drive as well as when you park and leave the vehicle.
  • Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 The doors can also be locked and unlocked with the authorized dealer per written request of the customer. Keyless Enter-N-Go (Passive Entry) system. For further Please see your authorized dealer for service. information, refer to “Keyless Enter-N-Go”...
  • Page 36: Child-Protection Door Lock System - Rear Doors

    34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Unlock Doors On Exit Programming To Engage Or Disengage The Child-Protection To change the current setting, refer to “Uconnect Touch™ Door Lock System Settings” in “Understanding Your Instrument Panel” for 1. Open the rear door. further information.
  • Page 37: Keyless Enter-N-Go

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 KEYLESS ENTER-N-GO™ WARNING! The Passive Entry system is an enhancement to the vehicle’s Remote Keyless Entry (RKE) system and a Avoid trapping anyone in a vehicle in a collision. feature of Keyless Enter-N-Go™. This feature allows you Remember that the rear doors can only be opened to lock and unlock the vehicle’s door(s) without having to from the outside when the Child-Protection locks are...
  • Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Unlock From The Driver’s Side: NOTE: If “Unlock All Doors 1st Press” is programmed With a valid Passive Entry RKE transmitter within 5 ft all doors will unlock when you grab hold of the front (1.5 m) of the driver’s door handle, grab the front driver driver’s door handle.
  • Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 Preventing Inadvertent Locking Of Passive Entry RKE NOTE: The vehicle will only unlock the doors when the Transmitter In Vehicle doors are locked using the door panel switch, a valid To minimize the possibility of unintentionally locking a Passive Entry RKE transmitter is detected inside the Passive Entry RKE transmitter inside your vehicle, the vehicle, and no valid Passive Entry RKE transmitter is...
  • Page 40 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Enter The Trunk NOTE: If you inadvertently leave your vehicle’s Passive With a valid Passive Entry RKE transmitter within 3 ft Entry RKE transmitter in the trunk and try to close the (1.0 m) of the deck lid, press the button on the right side deck lid, the deck lid will automatically unlatch, unless of CHMSL, (Center High Mounted Stop Light) which is...
  • Page 41 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 To Lock The Vehicle’s Doors NOTE: • After pressing the door handle LOCK button, you With one of the vehicle’s Passive Entry RKE transmitters within 5 ft (1.5 m) of the driver or passenger front door must wait two seconds before you can lock or unlock handles, press the door handle LOCK button to lock all the doors, using either Passive Entry door handle.
  • Page 42: Windows

    40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WINDOWS There are single window controls on each passenger door trim panel, which operate the passenger door windows. Power Windows The window controls will operate only when the ignition The window controls on the driver’s door control all the is in the ACC or ON/RUN position.
  • Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 Driver One Touch Down Express Up The driver door power window switch has an auto down Lift the switch for less than a half a second and release. feature. Press the window switch to the second detent The window will go up automatically.
  • Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Window Lockout Switch WARNING! The window lockout switch on the driver’s door trim panel allows you to disable the window controls on the There is no anti-pinch protection when the window rear passenger doors. To disable the window controls, is almost closed.
  • Page 45: Wind Buffeting

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions.
  • Page 46: Trunk Lock And Release

    44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE TRUNK LOCK AND RELEASE With the ignition in the ON/RUN position, the Trunk The trunk lid can be released from inside the vehicle by Open symbol will display in the instrument cluster pressing the TRUNK RELEASE button located on the indicating that the trunk is open.
  • Page 47: Trunk Safety Warning

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 TRUNK SAFETY WARNING Trunk Emergency Release As a security measure, a trunk internal emergency release WARNING! lever is built into the trunk latching mechanism. In the event of an individual being locked inside the trunk, the Do not allow children to have access to the trunk, trunk can be simply opened by pulling on the glow-in-the- either by climbing into the trunk from outside, or...
  • Page 48: Occupant Restraints

    46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Front seat belts incorporate pretensioners that may OCCUPANT RESTRAINTS Some of the most important safety features in your enhance occupant protection by managing occupant vehicle are the restraint systems: energy during an impact event •...
  • Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 Here are some simple steps you can take to minimize the ride properly buckled up in the rear seat. Never allow risk of harm from a deploying air bag: children to slide the shoulder belt behind them or under their arm.
  • Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE (SAB), and when deployment occurs, the SABIC and WARNING! (Continued) SAB air bags will inflate forcefully into the space • Being too close to the steering wheel or instrument between you and the door. panel during Advanced Front Air Bag deployment 5.
  • Page 51: Lap/Shoulder Belts

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 Buckle up even though you are an excellent driver, even normal conditions. However, in a collision, the belt will on short trips. Someone on the road may be a poor driver lock and reduce your risk of striking the inside of the and cause a collision that includes you.
  • Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Operating Instructions WARNING! (Continued) 1. Enter the vehicle and close the door. Sit back and • Wearing your belt in the wrong place could make adjust the front seat. your injuries in a collision much worse. You might suffer internal injuries, or you could even slide out of part of the belt.
  • Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 2. The seat belt latch plate is above the back of your seat. WARNING! Grasp the latch plate and pull out the belt. Slide the latch • A belt that is buckled into the wrong buckle will plate up the webbing as far as necessary to make the belt go around your lap.
  • Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE tight, tilt the latch plate and pull on the lap belt. A snug WARNING! (Continued) belt reduces the risk of sliding under the belt in a • A belt that is worn under your arm is dangerous. collision.
  • Page 55 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 6. To release the belt, push the red button on the buckle. WARNING! The belt will automatically retract to its stowed position. • A lap belt worn too high can increase the risk of If necessary, slide the latch plate down the webbing to allow the belt to retract fully.
  • Page 56: Lap/Shoulder Belt Untwisting Procedure

    54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE above the webbing to release the anchorage, then move it In the rear seat, move toward the center of the seat to up or down to the position that fits you best. position the belt away from your neck.
  • Page 57: Seat Belts In Passenger Seating Positions

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 Seat Belts In Passenger Seating Positions activate the ALR. If the ALR is activated, you will hear a The seat belts in the passenger seating positions are ratcheting sound as the belt retracts. Allow the webbing equipped with Automatic Locking Retractors (ALR) to retract completely in this case and then carefully pull which are used to secure a child restraint system.
  • Page 58: Energy Management Feature

    56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Engage The Automatic Locking Mode WARNING! 1. Buckle the combination lap and shoulder belt. • The belt and retractor assembly must be replaced 2. Grasp the shoulder portion and pull downward until if the seat belt assembly Automatic Locking Re- the entire belt is extracted.
  • Page 59: Seat Belt Pretensioner

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 Seat Belt Pretensioner Enhanced Seat Belt Use Reminder System The seat belts for both front seating positions are (BeltAlert ) equipped with pretensioning devices that are designed to BeltAlert is a feature intended to remind the driver and remove slack from the seat belt in the event of a collision.
  • Page 60: Seat Belts And Pregnant Women

    58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE unbuckled while traveling at speeds greater than 5 mph Seat Belts And Pregnant Women (8 km/h), BeltAlert will provide both audio and visual We recommend that pregnant women use the seat belts notification.
  • Page 61: Supplemental Restraint System (Srs) - Air Bags

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 WARNING! Using a seat belt extender when not needed can in- crease the risk of injury in a collision. Only use when the seat belt is not long enough when it is worn low and snug and in the recommended seating positions.
  • Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Advanced Front Air Bags have a multistage inflator This vehicle is equipped with Supplemental Side Air Bag design. This allows the air bag to have different rates of Inflatable Curtains (SABIC) to protect the driver, front, inflation based on several factors, including the severity and rear passengers sitting next to a window.
  • Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 • Supplemental Side Air Bag Inflatable Curtains Air Bag System Components Your vehicle may be equipped with the following air bag (SABIC) system components: • Front and Side Impact Sensors • Occupant Restraint Controller (ORC) •...
  • Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Do not mount any accessories to the knee bolster • No objects should be placed over or near the air such as alarm lights, stereos, citizen band radios, bag on the instrument panel, because any such etc.
  • Page 65 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 Supplemental Side Air Bag Inflatable Curtain SAB and SABIC air bags are a supplement to the seat belt (SABIC) restraint system. SABIC air bags may offer side-impact protection to front Occupants, including children who are up against or very and rear seat outboard occupants in addition to that close to SABIC or SAB air bags can be seriously injured or provided by the body structure.
  • Page 66: Air Bag Deployment Sensors And Controls

    64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Along with seat belts and pretensioners, Advanced Front WARNING! Air Bags work with the Supplemental Knee Air Bags to • Your vehicle is equipped with left and right provide improved protection for the driver and front passenger.
  • Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 Advanced Front Air Bags and Supplemental Driver and The side air bags will not deploy in all side collisions. Front Passenger Knee Air Bags are designed to provide Side air bag deployment will depend on the severity and additional protection by supplementing the seat belts in type of collision.
  • Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The ORC contains a backup power supply system that WARNING! may deploy the air bags even if the battery loses power or it becomes disconnected prior to deployment. Ignoring the Air Bag Warning Light in your instru- ment panel could mean you won’t have the air bags Also, the ORC turns on the Air Bag Warning to protect you in a collision.
  • Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 • Occupant Classification Module (OCM) located in the Front Passenger Seat Front Passenger Air front passenger seat Occupant Status Bag Classification • OCS Sensor located in the front passenger seat Rearward-facing infant seat* Reduced-power deployment •...
  • Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In order for the OCS to operate as designed, it is WARNING! important for the front passenger to be seated properly • Never place a rear facing infant seat in front of an and properly wearing the seat belt.
  • Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 WARNING! Occupants in the front passenger seat sitting improp- erly may cause the OCS to not classify the passen- ger’s weight accurately. This may result in serious injury or death in a collision. Always wear your seat belt and sit properly, with the seat back in an upright position, your back against the seat back, sitting upright, facing forward, in the center of the seat, with...
  • Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The OCS may not classify the front passenger properly if: • The front passenger’s weight is transferred to another part of the vehicle (like the door, arm rest or instru- ment panel) •...
  • Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 Not Seated Properly Not Seated Properly...
  • Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Not Seated Properly Not Seated Properly...
  • Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 The Features Of Your Vehicle” for additional informa- WARNING! tion). Make sure that objects inside the Flip ’n Stow™ Front Passenger Seat Storage bin do not interfere with the Placing an object on the floor under the front pas- latch before closing the seat.
  • Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Do not use prior or future model year seat covers or WARNING! cushions not designated by Chrysler Group LLC for the specific model being repaired. Always use the Make sure that objects inside the Flip ’n Stow™ correct seat cover and cushion specified for the ve- Front Passenger Seat Storage bin do not interfere hicle.
  • Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 When the ORC detects a collision requiring the Ad- WARNING! vanced Front Air Bags, it signals the inflator units. A large quantity of non-toxic gas is generated to inflate the Unapproved modifications or service procedures to Advanced Front Air Bags.
  • Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Driver And Front Passenger Knee The ORC determines if a side collision requires the side Air Bag Inflator Units air bags to inflate, based on several factors, including the The Supplemental Knee Air Bag units are located in the severity and type of collision.
  • Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 including the severity and type of collision. In these Front And Side Impact Sensors events, the ORC will deploy the SABIC only on the In front and side impacts, impact sensors can aid the impact side of the vehicle.
  • Page 80 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Turn on the interior lights, which remain on as long as • The nylon air bag material may sometimes cause the battery has power, until the ignition key is re- abrasions and/or skin reddening to the driver and moved or the ignition switch is changed to OFF using front passenger as the air bags deploy and unfold.
  • Page 81 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 continues, see your doctor. If these particles settle on Maintaining Your Air Bag System your clothing, follow the garment manufacturer’s in- WARNING! structions for cleaning. • Modifications to any part of the air bag system Do not drive your vehicle after the air bags have de- ployed.
  • Page 82 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag Warning Light WARNING! (Continued) You will want to have the air bags ready to • Do not attempt to modify any part of your air bag inflate for your protection in a collision. The system.
  • Page 83: Event Data Recorder (Edr)

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 • How various systems in your vehicle were operating; NOTE: If the speedometer, tachometer, or any engine related gauges are not working, the Occupant Restraint • Whether or not the driver and passenger safety belts Controller (ORC) may also be disabled.
  • Page 84: Child Restraints

    82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To read data recorded by an EDR, special equipment is Occupants, especially children, should not lean on or required, and access to the vehicle or the EDR is needed. sleep against the door, side windows, or area where the In addition to the vehicle manufacturer, other parties, SABIC or SAB air bags inflate, even if they are in an such as law enforcement, that have the special equip-...
  • Page 85 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 seat Owner’s Manual to ensure you have the correct seat their infant carrier but are still less than at least two years for your child. Use the restraint that is correct for your old.
  • Page 86 84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE convertible child seats used in the forward-facing direc- Children Too Large For Booster Seats tion are for children who are over two years old or who Children who are large enough to wear the shoulder belt have outgrown the rear-facing weight or height limit of comfortably and whose legs are long enough to bend their rear-facing convertible child seat.
  • Page 87 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 NOTE: For additional information, refer to Here are some tips on getting the most out of your child www.seatcheck.org or call 1–866–SEATCHECK. Cana- restraint: dian residents should refer to Transport Canada’s web- •...
  • Page 88 86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE having attachments for those anchorages will continue to WARNING! have features for installation using the vehicle’s seat belts. Child restraints having tether straps and hooks for When your child restraint is not in use, secure it in connection to the top tether anchorages have been avail- the vehicle with the seat belt or remove it from the able for some time.
  • Page 89 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 87 adjacent rear seating positions, or if your child restraints Installing The LATCH-Compatible Child Restraint are not LATCH-compatible, install the restraints using System the vehicle’s seat belts. We urge you to follow the manufacturer’s directions carefully when installing your child restraint.
  • Page 90 88 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Many, but not all, restraint systems will be equipped with push the child restraint rearward and downward into the separate straps on each side, with each having a hook or seat, removing slack in the straps according to the child connector for attachment to the lower anchorage and a restraint manufacturer’s instructions.
  • Page 91 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 89 installing the child restraint, buckle the seat belt so the Installing Child Restraints Using The Vehicle Seat seat belt is tucked behind the child restraint and out of Belts reach. If the buckled seat belt interferes with the child The seat belts in the passenger seating positions are restraint installation, instead of tucking the seat belt equipped with an Automatic Locking Retractor (ALR) to...
  • Page 92 90 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Finally, pull on any excess webbing to tighten the lap Driver Center Passenger portion around the child restraint. Any seat belt system CRS Lock CRS Lock CRS Lock will loosen with time, so check the belt occasionally, and First Row pull it tight if necessary.
  • Page 93 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 91 route the tether strap under the head restraint and between the two posts. If not possible, lower the head restraint and pass the tether strap around the outboard side of the head restraint. 3.
  • Page 94: Engine Break-In Recommendations

    92 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Transporting Pets The engine oil installed in the engine at the factory is a Air Bags deploying in the front seat could harm your pet. high-quality energy conserving type lubricant. Oil An unrestrained pet will be thrown about and possibly changes should be consistent with anticipated climate injured, or injure a passenger during panic braking or in conditions under which vehicle operations will occur.
  • Page 95: Safety Tips

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 93 SAFETY TIPS WARNING! (Continued) Transporting Passengers • Be sure everyone in your vehicle is in a seat and NEVER TRANSPORT PASSENGERS IN THE CARGO using a seat belt properly. AREA. Exhaust Gas WARNING! WARNING! •...
  • Page 96: Safety Checks You Should Make Inside The Vehicle

    94 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE damaged, deteriorated, or mispositioned parts. Open WARNING! (Continued) seams or loose connections could permit exhaust fumes • If you are required to drive with the trunk/liftgate to seep into the passenger compartment. In addition, open, make sure that all windows are closed and inspect the exhaust system each time the vehicle is raised the climate control BLOWER switch is set at high...
  • Page 97 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 95 Air Bag Warning Light cannot slip out of position and interfere with the pedals The light should come on and remain on for four to eight or impair safe operation of your vehicle in other ways. seconds as a bulb check when the ignition switch is first WARNING! turned ON.
  • Page 98: Periodic Safety Checks You Should Make Outside The Vehicle

    96 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) WARNING! (Continued) • Never put floor mats or other floor coverings on Failure to properly follow floor mat installation or top of already installed floor mats. Additional mounting can cause interference with the brake floor mats and other coverings will reduce the size pedal and accelerator pedal operation causing loss of of the pedal area and interfere with the pedals.
  • Page 99 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 97 Lights Have someone observe the operation of exterior lights while you work the controls. Check turn signal and high beam indicator lights on the instrument panel. Door Latches Check for positive closing, latching, and locking. Fluid Leaks Check area under vehicle after overnight parking for fuel, engine coolant, oil, or other fluid leaks.
  • Page 101: Understanding The Features Of Your Vehicle

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......105 Illuminated Vanity Mirrors — If Equipped . . 109 Inside Day/Night Mirror .
  • Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Things You Should Know About Your Commands ......182 Uconnect™ Phone ....137 Voice Training .
  • Page 103 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 Head Restraints ..... 207 Multifunction Lever ....218 Folding Rear Seat .
  • Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Headlights On With Wipers (Available With Parksense Rear Park Assist — If Equipped . . . 234 Automatic Headlights Only) ... . 225 Parksense Sensors .
  • Page 105 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 Overhead Console ..... 250 Power Sunroof — If Equipped ... . 261 Front Map/Reading Lights .
  • Page 106 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Cupholders ......268 Cargo Area Features ....274 Front Seat Cupholders .
  • Page 107: Mirrors

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical adjustment of the mirror. Adjust the mirror to center on the view through the rear window. The mirror should be adjusted while set in the day position (toward the windshield).
  • Page 108: Automatic Dimming Mirror - If Equipped

    106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. This feature will be defaulted on, and only be disabled when the vehicle is moving in reverse.
  • Page 109: Outside Mirrors

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 Outside Mirrors Outside Mirrors Folding Feature — If Equipped To receive maximum benefit, adjust the outside mirror(s) Some models have outside mirrors that are hinged. The to center on the adjacent lane of traffic and a slight hinge allows the mirror to pivot forward and rearward to overlap of the view obtained from the inside mirror.
  • Page 110: Power Mirrors

    108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Illuminated Entry lighting fades to off after about 30 seconds or it will fade to off immediately once the ignition is placed into the RUN position. NOTE: The approach lighting will not function when the shift lever is moved out of the PARK position.
  • Page 111: Heated Mirrors - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 Using the mirror control switch, press on any of the four arrows for the direction that you want the mirror to move. Heated Mirrors — If Equipped These mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the rear window defroster.
  • Page 112: Blind Spot Monitoring - If Equipped

    110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sun Visor “Slide-On Rod” Feature — If Equipped This feature allows for additional flexibility in position- ing the visor to block out the sun. 1. Fold down the sun visor. 2. Unclip the visor from the center clip. 3.
  • Page 113 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 vehicle when the vehicle speed reaches approximately 6 mph (10 km/h) or higher and will alert the driver of vehicles in these areas. NOTE: • The BSM system does NOT alert the driver about rapidly approaching vehicles that are outside the detection zones.
  • Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE properly. Do not block the area of the rear fascia where the radar sensors are located with foreign objects (bum- per stickers, bicycle racks, etc.). The BSM system notifies the driver of objects in the detection zones by illuminating the BSM warning light located in the outside mirrors in addition to sounding an audible (chime) alert and reducing the radio volume.
  • Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 between the two vehicles is greater than 10 mph (16 km/h), the warning light will not illuminate. Rear Monitoring Overtaking Traffic If you pass another vehicle slowly (with a relative speed Overtaking/Approaching of less than 10 mph (16 km/h) and the vehicle remains in the blind spot for approximately 1.5 seconds, the warning light will be illuminated.
  • Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The BSM system is designed not to issue an alert on stationary objects such as guardrails, posts, walls, foliage, berms, etc. However, occasionally the system may alert on such objects. This is normal operation and your vehicle does not require service.
  • Page 117 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 The BSM system will not alert you of objects that are WARNING! traveling in the opposite direction of the vehicle in adjacent lanes. The Blind Spot Monitoring system is only an aid to help detect objects in the blind spot zones.
  • Page 118: Rear Cross Path

    116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Cross Path The Rear Cross Path (RCP) feature is intended to aid the drivers when backing out of parking spaces where their vision of oncoming vehicles may be blocked. Proceed slowly and cautiously out of the parking space until the rear end of the vehicle is exposed.
  • Page 119: Modes Of Operation

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 NOTE: In a parking lot situation, oncoming vehicles can Modes Of Operation be obscured by vehicles parked on either side. If the Three selectable modes of operation are available in the sensors are blocked by other structures or vehicles, the Uconnect Touch™...
  • Page 120: Uconnect™ Phone (Media Center 200)

    118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE alert present on that side of the vehicle, an audible chime Blind Spot Alert Off will also be sounded. Whenever a turn signal and de- When the BSM system is turned off, there will be no tected object are present on the same side at the same visual or audible alerts from either the BSM or RCP time, both the visual and audio alerts will be issued.
  • Page 121 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 phone using simple voice commands (e.g., “Call” Uconnect™ features Bluetooth technology - the global “Mike” “Work” or “Dial” “248-555-1212”). Your standard that enables different electronic devices to con- mobile phone’s audio is transmitted through your vehi- nect to each other without wires or a docking station, so cle’s audio system;...
  • Page 122: Operation

    120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Uconnect™ Phone Button The Uconnect™ Phone is fully integrated with the vehi- The steering wheel controls will contain the cle’s audio system. The volume of the Uconnect™ Phone two control buttons (Uconnect™ Phone can be adjusted either from the radio volume control button and Voice Command button) that...
  • Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 • For certain operations, compound commands can be Help Command used. For example, instead of saying “Setup”, “Device If you need assistance at any prompt, or if you want to Pairing” and then “Pair a Device”, the following know your options at any prompt, say “Help”...
  • Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • For identification purposes, you will be prompted to To complete the pairing process, you will need to refer- ence your mobile phone Owner’s Manual. The give the Uconnect™ Phone a name for your mobile Uconnect™...
  • Page 125 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 • The system will prompt you to say the name of the Dial By Saying A Number person you want to call. • Press the button to begin. • After the “Ready” prompt and the following beep, say •...
  • Page 126 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the “Ready” prompt and the following beep, say The Uconnect™ Phone will allow you to enter up to 32 “Phonebook New Entry”. names in the phonebook with each name having up to four associated phone numbers and designations.
  • Page 127 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 • You will then be asked for the name of the phonebook Phonebook Download – Automatic Phonebook entry that you wish to edit. Transfer From Mobile Phone If equipped and specifically supported by your phone, •...
  • Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Depending on the maximum number of entries down- Delete Uconnect™ Phonebook Entry loaded, there may be a short delay before the latest NOTE: Editing phonebook entries is recommended downloaded names can be used. Until then, if avail- when the vehicle is not in motion.
  • Page 129 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 • After you enter the name, the Uconnect™ Phone will • Note that only the phonebook in the current language ask you which designation you wish to delete: home, is deleted. work, mobile, other, or all. Say the designation you •...
  • Page 130: Phone Call Features

    128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phone Call Features Answer Or Reject An Incoming Call — Call The following features can be accessed through the Currently In Progress Uconnect™ Phone if the feature(s) are available on your If a call is currently in progress and you have another mobile service plan.
  • Page 131 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 in progress. To go back to the first call, refer to “Toggling Conference Call Between Calls” in this section. To combine two calls, refer When two calls are in progress (one active and one on to “Conference Call”...
  • Page 132: Uconnect™ Phone Features

    130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the ignition key is switched to OFF, a call can on hold may not become active automatically. This is cell phone-dependent. To bring the call back from hold, press continue on the Uconnect™ Phone either until the call and hold the button until you hear a single beep.
  • Page 133 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 • Continue to follow the system prompts to complete • Press the button to begin. the language selection. • After the “Ready” prompt and the following beep, say After selecting one of the languages, all prompts and “Emergency”...
  • Page 134 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Uconnect™ Phone does slightly lower your NOTE: • The roadside assistance number dialed is based on the chances of successfully making a phone call as com- pared to using the mobile phone directly. country where the vehicle is purchased (1-800-528- 2069 for the U.S., 1-877-213-4525 for Canada, 55-14- WARNING!
  • Page 135 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 Voice Mail Calling your PIN followed with a pound, (3 7 4 6 #), you can To learn how to access your voice mail, refer to “Working press the button and say, “3 7 4 6 # Send”. Saying with Automated Systems”.
  • Page 136 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Some paging and voice mail systems have system time • After the “Ready” prompt and the following beep, say out settings that are too short and may not allow the one of the following: use of this feature.
  • Page 137: Advanced Phone Connectivity

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 • Following the beep, say “Mute”. dialing a number with your paired Bluetooth mobile phone, the audio will be played through your vehicle’s In order to un-mute the Uconnect™ Phone: audio system. The Uconnect™ Phone will work the same •...
  • Page 138 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Connect Or Disconnect Link Between The the lowest priority. To “Select” or “Delete” a paired Uconnect™ Phone And Mobile Phone phone being announced, press the button and Your mobile phone can be paired with many different say “Select”...
  • Page 139: Things You Should Know About Your Uconnect™ Phone

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 Uconnect™ Phone will return to using the highest Things You Should Know About Your Uconnect™ priority phone present in or near (approximately Phone within 30 ft (9 m)) the vehicle. Uconnect™ Phone Tutorial Delete Uconnect™...
  • Page 140 138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE You can either press the Uconnect™ Phone button to Voice Command restore the factory setting or repeat the words and Uconnect™ Voice Command Tutorial phrases when prompted by the Uconnect™ Phone. For To hear a brief tutorial of the Voice Command features, best results, the Voice Training session should be com- press the button and say “Voice Command Tuto-...
  • Page 141 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 • low-to-medium vehicle speed, • Phonebook (Downloaded and Uconnect™ Phone Lo- cal) name recognition rate is optimized when the • low road noise, entries are not similar. • smooth road surface, • Numbers must be spoken in single digits. “800” must •...
  • Page 142 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • low road noise, Recent Calls If your phone supports “Automatic Phonebook Down- • smooth road surface, load”, Uconnect™ Phone can list your Outgoing, Incom- • fully closed windows, ing and Missed Calls. •...
  • Page 143 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 • Uconnect™ Phone will play the new text message for List of Preset Messages: you. 1. Yes After reading a message, you can “Reply” or “Forward” 2. No the message using Uconnect™ Phone. 3.
  • Page 144 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the “Ready” prompt and the following beep, say 13. I’ll be late “Setup, SMS Incoming Message Announcement,” you 14. Are you there yet? will then be given a choice to change it. 15.
  • Page 145 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143...
  • Page 146 144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 147 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145...
  • Page 148: General Information

    146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information Uconnect™ Phone supports the following features: This device complies with Part 15 of the FCC rules and Voice Activated Features: RSS 210 of Industry Canada. Operation is subject to the • Hands Free dialing via Voice (“Call John Smiths Mo- following conditions: bile”...
  • Page 149 • Setting Favorite Contact Phone numbers so the are • www.chrysler.com/uconnect easily accessible on the Main Phone screen. • www.dodge.com/uconnect • Viewing and Calling contacts from Recent Call logs. • www.jeep.com/uconnect • Reviewing your recent Incoming SMS. • or call 1–877–855–8400 •...
  • Page 150 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE phone and one audio device can be used with the system WARNING! at a time. The system is available in English, Spanish, or French languages. Any voice commanded system should be used only in safe driving conditions following local laws and Uconnect™...
  • Page 151: Operation

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 if your vehicle is equipped. Please see the Uconnect™ 2. Say the individual commands and allow the system to Voice Command section for direction on how to use the guide you to complete the task. button.
  • Page 152 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE for it. For example, you can use the compound com- The system handles multiple inputs in the same phrase mand form voice command “Search for John Smith”, or sentence such as “make a phone call” and “to Kelly or you can break the compound command form into Smith”.
  • Page 153 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Voice Command Tree NOTE: Pressing the buttons while the Refer to “Voice Tree” in this section. system is playing is known as “Barging In”, refer to “Barge — Overriding Prompts” further Help Command information.
  • Page 154 152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. If there is no phone currently connected with the 3. Select Yes to begin the pairing process. Then, search system, a pop-up will appear. for available devices on your Bluetooth enabled mobile phone.
  • Page 155 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 4. Uconnect™ Phone will display an in process screen 5. When the pairing process has successfully completed, while the system is connecting. the system will prompt you to choose whether or not this is your favorite phone.
  • Page 156 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When the pairing process has successfully completed, NOTE: For phones which are not made a favorite, the the system will prompt you to choose whether or not phone priority is determined by the order in which it was this is your favorite phone.
  • Page 157 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 • Search for available devices on your Bluetooth en- Connecting To A Particular Mobile Phone Or abled audio device. When prompted on the device, Audio Device enter the name and PIN shown on the Uconnect Uconnect™...
  • Page 158 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Touch the + soft-key located to the right of the device Making A Phone Or Audio Device A Favorite name, • Touch the “Settings” soft-key, • The options pop-up will be displayed, •...
  • Page 159 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 phonebook. Specific Bluetooth Phones with Phone Book downloaded names can be used. Until then, if avail- Access Profile may support this feature. See Uconnect™ able, the previously downloaded phonebook is avail- website for supported phones. able for use.
  • Page 160 158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. After loading the mobile phonebook, select phone- 3. From the Phone main screen, select phonebook. From book from the Phone main screen, then select the appro- the phonebook screen, select the “Favorites” soft-key and priate number.
  • Page 161 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 • Touch the + next to the Favorite you would like to remove. To Remove A Favorite • To remove a Favorite, select phonebook from the • The Options pop-up will display, touch “Remove from Phone main screen.
  • Page 162: Phone Call Features

    160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Emergency And Towing Assistance The Emergency and Towing Favorite numbers can only be altered. These cannot be deleted and the names cannot be changed. To change the Emergency or Towing number follow these steps.
  • Page 163 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 For example, if your mobile service plan provides three- NOTE: All of the above operations except Redial can be way calling, this feature can be accessed through the done with 1 call or less active. Uconnect™...
  • Page 164 162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Call Controls Touch-Tone Number Entry The touch-screen allows you to control the following call • Touch the “Phone” soft-key, features: • Touch the “Dial” soft-key, • Answer • The Touch-Tone screen will be displayed, •...
  • Page 165 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 These can be accessed by touching the “recent calls” soft-key on the Phone main screen. You can also press the button and say “Show my incoming calls” from any screen and the Incoming calls will be displayed.
  • Page 166 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Answer Or Ignore An Incoming Call — Call in progress. Or you can place a call on hold by touching Currently In Progress the Hold soft-key on the Phone main screen, then dial a If a call is currently in progress and you have another number from the dialpad, recent calls, SMS Inbox or from incoming call, you will hear the same network tones for...
  • Page 167: Uconnect™ Phone Features

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 • The Uconnect™ Phone will call the last number that Join Calls When two calls are in progress (one active and one on was dialed from your mobile phone. hold), touch the “Join Calls” soft-key on the Phone main Call Continuation screen to combine all calls into a Conference Call.
  • Page 168 166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Uconnect™ Phone does slightly lower your If the phone is not reachable and the Uconnect™ Phone is operational, you may reach the emergency number as chances of successfully making a phone call as to that follows: for the mobile phone directly.
  • Page 169 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 NOTE: You can use your Uconnect™ Phone to access a voice • The roadside assistance call may also be initiated by mail system or an automated service, such as a paging touch. service or automated customer service line. Some ser- vices require immediate response selection.
  • Page 170 168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Pauses, wait or other characters that are supported by You can also send stored mobile phonebook entries as tones for fast and easy access to voice mail and pager some phones are not supported over Bluetooth . entries.
  • Page 171 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 • Touch the “Display” soft-key, then scroll down to audio system. The Uconnect™ Phone will work the same Voice Response Length, as if you dial the number using voice command. • Select either “Brief” or “Detailed” by touching the box NOTE: Certain brands of mobile phones do not send the next to the selection.
  • Page 172: Advanced Phone Connectivity

    170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Advanced Phone Connectivity Things You Should Know About Your Uconnect™ Phone Transfer Call To And From Mobile Phone The Uconnect™ Phone allows ongoing calls to be trans- Voice Command ferred from your mobile phone to the Uconnect™ Phone •...
  • Page 173 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 • Performance is maximized under: • Phonebook (Mobile and Favorites) name recognition rate is optimized when the entries are not similar. • low-to-medium blower setting, • You can say “O” (letter “O”) for “0” (zero). •...
  • Page 174 172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • fully closed windows, Bluetooth the “Messaging” button will be greyed out and the feature will not be available for use. • dry weather conditions, and NOTE: Uconnect™ Phone SMS is only available when •...
  • Page 175 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 Read Messages: Once a message is received and viewed or listened to, you will have the following options: If you receive a new text message while your phone is • Send a Reply connected to Uconnect™...
  • Page 176 174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Send Messages Using Soft-Keys: You can send messages using Uconnect™ Phone. To send a new message: • Touch the “Phone” soft-key, • Touch the “messaging” soft-key then “New Message”, • Touch one of the 18 preset messages and the person you wish to send the message to, •...
  • Page 177 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 Send Messages Using Voice Commands: • Press the button, • After the “Listening” prompt and the following beep, say “Send message to John Smith mobile”, • After the system prompts you for what message you want to send, say the message you wish to send or say “List”.
  • Page 178 176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 6. I’ll call you later. Bluetooth Communication Link Mobile phones have been found to lose connection to the 7. I’m on my way. Uconnect™ Phone. When this happens, the connection 8. Thanks. can generally be reestablished by switching the phone OFF/ON.
  • Page 179 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 Voice Tree...
  • Page 180 178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • You can replace “248 555 1212” with any phone NOTE: • You can replace “John Smith” with any name in your number supported by your Mobile phone. mobile or favorite phone book. You can also say “Send •...
  • Page 181 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179...
  • Page 182: General Information

    180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • If your phone does not support phonebook download NOTE: • You can replace “John Smith” with any name in your or call log download over Bluetooth than these com- mobile or favorite phone book. You can also say “Send mands will return a response that the contact does not a message to John Smith”...
  • Page 183: Voice Command (Media Center 200)

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 VOICE COMMAND (Media Center 200) When you press the Voice Command button, you will hear a beep. The beep is your signal to give a Voice Command System Operation command. This Voice Command system allows you to control your AM, FM radio, satellite radio, disc NOTE: If you do not say a command within a few player, and a memo recorder.
  • Page 184: Commands

    182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE These commands are universal and can be used from any Changing the Volume menu. All other commands can be used depending upon 1. Start a dialogue by pressing the Voice Command the active application. button.
  • Page 185 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 • “Memo” (to switch to the memo recorder) Radio FM To switch to the FM band, say “FM” or “Radio FM”. In • “Setup” (to switch to system setup) this mode, you may say the following commands: Radio AM •...
  • Page 186 184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Satellite Radio Disc To switch to satellite radio mode, say “Sat” or “Satellite To switch to the disc mode, say “Disc”. In this mode, you Radio”. In this mode, you may say the following commands: may say the following commands: •...
  • Page 187 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185 − “Continue” (to continue recording) Setup To switch to system setup, you may say on of the − “Delete” (to delete the recording) following: • “Play Memos” (to play previously recorded memos) • “Change to setup” —...
  • Page 188: Voice Training

    186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • “Language Spanish” session should be completed when the vehicle is parked, engine running, all windows closed, and the blower fan • “Tutorial” switched off. This procedure may be repeated with a new •...
  • Page 189 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 what can be said based on the context you are in. After WARNING! three consecutive failures of a spoken command the VR session with end. Any voice commanded system should be used only in safe driving conditions following local laws.
  • Page 190: Uconnect™ Voice Commands

    188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The system will best recognize your speech if the win- Smith”. For multiple inputs in the same phrase or sen- dows are closed, and the heater/air conditioning fan is tence, the system identifies the topic or context and set to low.
  • Page 191 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189 Changing the Volume Disc To switch to the disc mode, say “Change source to Disc”. 1. Start a dialogue by pressing the Voice Command This command can be given in any mode or screen: button.
  • Page 192: Voice Tree

    190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Tree...
  • Page 193 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191 NOTE: 1. You can replace “950 AM” with any other AM or FM frequency, such as “98.7 FM”. 2. You can replace “80’s on 8” with any other satellite station name received by the radio. 3.
  • Page 194 192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 195 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193 NOTE: 1. You can replace the album, artist, song, genre, playlist, podcast and audio book names with any corresponding names on the current device that is playing. 2. You can replace “8” with any track on the CD that is currently playing.
  • Page 196 194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 197 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 195 NOTE: 1. You can replace “NFL” with any league shown on the sports league screen. For example you can say “Show MLB headlines” or “Show PGA headlines”. 2. You can replace “Headlines” with any menu items shown on a league screen.
  • Page 198 196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 199 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 197 NOTE: 1. Only available with Navigation equipped vehicles. 2. You can replace “Player” with “Radio”, “Navigation”, “Phone”, “Climate”, “More” or “Settings”. 3. Navigation commands only work if equipped with Navigation. 4. Available Voice Commands are shown in bold face and shaded grey.
  • Page 200 198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 201: Seats

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199 NOTE: WARNING! 1. You can also say “Find City”, “Find Favorite”, “Find • It is dangerous to ride in a cargo area, inside or Play by Category”, “Find Play by Name”, “Find Recently Found”, “Where to?”...
  • Page 202: Power Seats - If Equipped

    200 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Seats — If Equipped Adjusting The Seat Forward Or Rearward Some models may be equipped with a power driver’s The seat can be adjusted both forward and rearward. seat. The power seat switch is located on the outboard Push the seat switch forward or rearward, the seat will side of the seat near the floor.
  • Page 203 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 201 WARNING! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death. • Seats should be adjusted before fastening the seat belts and while the vehicle is parked.
  • Page 204 202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Lumbar — If Equipped Vehicles equipped with power driver or passenger seats may be also be equipped with power lumbar. The power lumbar switch is located on the outboard side of the power seat.
  • Page 205: Manual Front Seat Forward/Rearward Adjustment

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 203 Manual Front Seat Forward/Rearward Adjustment While sitting in the seat, lift up on the bar and move the On models equipped with manual seats, the adjusting seat forward or rearward. Release the bar once you have bar is located at the front of the seats, near the floor.
  • Page 206: Manual Front Seat Recline Adjustment

    204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Front Seat Recline Adjustment WARNING! To adjust the seatback, lift the lever located on the outboard side of the seat, lean back to the desired Do not ride with the seatback reclined so that the position and release the lever.
  • Page 207: Heated Seats - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 205 WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, ex- haustion or other physical condition must exercise care when using the seat heater.
  • Page 208 206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Heated Seat Operations — Uconnect Touch™ Touch the “Driver” or “Passenger” seat soft-key once to 8.4 and 8.4 Nav: select HI-level heating. Touch the soft-key a second time Touch the “Controls” soft-key located on the bottom of to select LO-level heating.
  • Page 209: Head Restraints

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207 When the HI-level setting is selected, the heater will Head Restraints provide a boosted heat level during the first four minutes Head restraints are designed to reduce the risk of injury of operation. Then, the heat output will drop to the by restricting head movement in the event of a rear normal HI-level.
  • Page 210 208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Active Head Restraints — Front Seats The front driver and passenger seats are equipped with Active Head Restraints (AHR). In the event of a rear impact the AHRs will automatically extend forward minimizing the gap between the back of the occupants head and the AHR.
  • Page 211 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 209 To raise the head restraint, pull upward on the head WARNING! restraint. To lower the head restraint, press the push button, located at the base of the head restraint, and push Do not place items over the top of the Active Head downward on the head restraint.
  • Page 212: Folding Rear Seat

    210 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Folding Rear Seat After releasing the seatback, it can be folded forward. The rear seatbacks can be folded forward to provide an additional storage area. To fold the rear seatback, pull on the loops located on the upper seatback. NOTE: These loops can be tucked away when not in use.
  • Page 213: To Open And Close The Hood

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211 TO OPEN AND CLOSE THE HOOD WARNING! Two latches must be released to open the hood. • Be certain that the seatback is securely locked into 1. Pull the hood release lever located under the left side position.
  • Page 214 212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Move to the outside of the vehicle and push the safety catch to the left. The safety catch is located under the center front edge of the hood. Hood Prop Rod 4. Place the hood prop rod in hood slot to secure the hood in the open position.
  • Page 215 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 213 CAUTION! To prevent possible damage, do not slam the hood to close it. Lower the hood, until it is open approxi- mately 6 in (15 cm), and then drop it. This should secure both latches. Never drive your vehicle unless the hood is fully closed, with both latches engaged.
  • Page 216: Lights

    214 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS Headlight Switch The headlight switch is located on the left side of the instrument panel. This switch controls the operation of the headlights, parking lights, instru- ment panel lights, instrument panel light dimming, inte- rior lights and fog lights.
  • Page 217: Automatic Headlights - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 215 Automatic Headlights — If Equipped Headlights On With Wipers (Available With This system automatically turns the headlights on or off Automatic Headlights Only) according to ambient light levels. To turn the system on, When this feature is active, the headlights will turn on rotate the headlight switch counterclockwise to the approximately 10 seconds after the wipers are turned on...
  • Page 218: Smartbeam™ - If Equipped

    216 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the headlights within 45 seconds. The delay interval SmartBeam™ — If Equipped begins when the headlight switch is turned off. The SmartBeam™ system provides increased forward lighting at night by automating high beam control If you turn the headlights or parking lights on, or place through the use of a digital camera mounted on the the ignition in ACC or RUN, the system will cancel the...
  • Page 219: Daytime Running Lights (Drl)

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 217 To Deactivate Daytime Running Lights (DRL) The Daytime Running Lights will come on whenever the 1. Pull the multifunction lever toward you (or rearward ignition is placed in the RUN position, the headlights are in car) to manually deactivate the system (normal opera- off and the parking brake is off.
  • Page 220: Fog Lights - If Equipped

    218 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fog Lights — If Equipped To activate the front fog lights, turn on the parking The front fog light switch is built into the headlight lights or the low beam headlights and press the switch.
  • Page 221: Turn Signals

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 219 NOTE: • If either light remains on and does not flash, or there is a very fast flash rate, check for a defective outside light bulb. If an indicator fails to light when the lever is moved, it would suggest that the indicator bulb is defective.
  • Page 222: High/Low Beam Switch

    220 UNDERSTANDING THE FEATURES OF YOUR VEHICLE High/Low Beam Switch Push the multifunction lever away from you to switch the headlights to high beam. Pull the multifunction lever toward you to switch the headlights back to low beam. Flash-To-Pass You can signal another vehicle with your headlights by lightly pulling the multifunction lever toward you.
  • Page 223: Interior Lights

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 221 Interior Lights Dimmer Controls The interior lights come on when a door is opened. The dimmer control is part of the headlight switch and is located on the left side of the instrument panel. To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition switch is moved to the LOCK position.
  • Page 224 222 UNDERSTANDING THE FEATURES OF YOUR VEHICLE With the parking lights or headlights on, rotating the left Ambient Light Control dimmer control upward will increase the brightness of Rotate the right dimmer control upward or downward to the instrument panel lights and lighted cupholders (if increase or decrease the brightness of the door handle equipped).
  • Page 225: Windshield Wipers And Washers

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 223 Dome Light Position WINDSHIELD WIPERS AND WASHERS Rotate the dimmer control completely upward to the The multifunction lever operates the windshield wipers second detent to turn on the interior lights. The interior and washer when the ignition is placed in the ON/RUN lights will remain on when the dimmer control is in this or ACC position.
  • Page 226: Intermittent Wiper System

    224 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Intermittent Wiper System CAUTION! Use the intermittent wiper when weather conditions • Turn the windshield wipers off when driving make a single wiping cycle with a variable pause be- tween cycles desirable. Rotate the end of the multifunc- through an automatic car wash.
  • Page 227: Mist Feature

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 225 Mist Feature If you activate the washer while the windshield wiper is Rotate the end of the lever downward to the Mist turned off, the wipers will operate for three wipe cycles position to activate a single wipe cycle to clear off road and then turn off.
  • Page 228: Rain Sensing Wipers - If Equipped

    226 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Headlights On with Wipers feature can be turned on automatically change between an intermittent wipe, slow and off using the Uconnect Touch™ System, refer to wipe and a fast wipe depending on the amount of “Uconnect Touch™...
  • Page 229: Tilt/Telescoping Steering Column

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 227 The Rain Sensing system has protective features for the TILT/TELESCOPING STEERING COLUMN wiper blades and arms. It will not operate under the This feature allows you to tilt the steering column following conditions: upward or downward.
  • Page 230: Heated Steering Wheel - If Equipped

    228 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To unlock the steering column, pull the control handle HEATED STEERING WHEEL — IF EQUIPPED down. To tilt the steering column, move the steering The steering wheel contains a heating element that helps wheel upward or downward as desired.
  • Page 231 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 229 Controls Soft-Key Heated Steering Wheel Soft-Key NOTE: The engine must be running for the heated steering wheel to operate.
  • Page 232: Electronic Speed Control - If Equipped

    230 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Vehicles Equipped With Remote Start WARNING! (Continued) On models that are equipped with remote start, the • Do not place anything on the steering wheel that heated steering wheel can be programmed to come on insulates against heat, such as a blanket or steering during a remote start.
  • Page 233: To Activate

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 231 System can be reactivated by pushing the Electronic Speed Control ON/OFF button and resetting the desired vehicle set speed. To Activate Push the ON/OFF button. The Cruise Indicator Light in the Electronic Vehicle Information Center (EVIC) will illuminate.
  • Page 234: To Set A Desired Speed

    232 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Set A Desired Speed To Deactivate Turn the Electronic Speed Control ON. A soft tap on the brake pedal, pushing the CANCEL button, or normal brake pressure while slowing the NOTE: The vehicle should be traveling at a steady vehicle will deactivate Electronic Speed Control without speed and on level ground before pressing the SET erasing the set speed memory.
  • Page 235: To Resume Speed

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 233 To Resume Speed decrease until the button is released. Release the button To resume a previously set speed, push the RES (+) when the desired speed is reached, and the new set speed button and release.
  • Page 236: Parksense Rear Park Assist - If Equipped

    234 UNDERSTANDING THE FEATURES OF YOUR VEHICLE On steep hills, a greater speed loss or gain may occur so Usage Precautions” for limitations of this system and it may be preferable to drive without Electronic Speed recommendations. Control. ParkSense will retain the last system state (enabled or disabled) from the last ignition cycle when the ignition is WARNING! changed to the ON/RUN position.
  • Page 237: Parksense Warning Display

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 235 (200 cm) from the rear fascia/bumper in the horizontal ParkSense Display direction, depending on the location, type and orienta- When the vehicle is in REVERSE, the warning display tion of the obstacle. will turn ON indicating the system status. ParkSense Warning Display The ParkSense Warning screen will only be displayed if Sound and Display is selected from the Uconnect...
  • Page 238 236 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If an object is detected in the center rear region, the display will show a single solid arc in the center rear region and will produce a one-half second tone. As the vehicle moves closer to the object, the display will show the single arc moving closer to the vehicle and the sound tone will change from slow, to fast, to continuous.
  • Page 239 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 237 One-Half Second Tone Slow Tone...
  • Page 240 238 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Slow Tone Fast Tone...
  • Page 241 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 239 Fast Tone Fast Tone...
  • Page 242 240 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Continuous Tone Continuous Tone The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert opera- tion when the system is detecting an obstacle:...
  • Page 243 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 241 WARNING ALERTS Rear Greater than 79-59 in 59-47 in 47-39 in 39-25 in 25-12 in Less than Distance 79 in (200-150 cm) (150-120 cm) (120-100 cm) (100-65 cm) (65-30 cm) 12 in (in/cm) (200 cm) (30 cm) Audible...
  • Page 244: Enabling And Disabling Parksense

    242 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Enabling And Disabling ParkSense (EVIC) will actuate a single chime, once per ignition ParkSense can be enabled and disabled using the cycle, and it will display the “WIPE OFF REAR PARK Uconnect Touch™ System. The available choices are: Off, ASSIST SENSORS”, “SERVICE PARK ASSIST SENSORS”...
  • Page 245 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 243 Wipe Off Rear Park Assist Sensors Service Park Assist Sensors If “SERVICE PARK ASSIST SENSORS” or “SERVICE PARK ASSIST SYSTEM” appears in the EVIC, see an authorized dealer.
  • Page 246 244 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ASSIST SYSTEM DISABLED message. If “PARK ASSIST SYSTEM DISABLED” appears in the EVIC, cycle the ignition. If the message appears again, see an authorized dealer. Service Park Assist System The ParkSense Rear Park Assist system will be automati- cally disabled when there are faulted conditions outside of the ParkSense Rear Park Assist system that inhibit the feature from functioning properly.
  • Page 247: Cleaning The Parksense System

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 245 • When you move the shift lever to the REVERSE Cleaning The ParkSense System Clean the ParkSense sensors with water, car wash soap position and ParkSense is turned off, the EVIC will and a soft cloth. Do not use rough or hard cloths. Do not display “PARK ASSIST SYSTEM OFF”...
  • Page 248 246 UNDERSTANDING THE FEATURES OF YOUR VEHICLE object as a sensor problem, causing the “SERVICE WARNING! PARK ASSIST SENSORS” message to be displayed in • Drivers must be careful when backing up even the EVIC. when using the ParkSense Rear Park Assist sys- CAUTION! tem.
  • Page 249: Parkview Rear Back Up Camera - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 247 PARKVIEW REAR BACK UP CAMERA — IF WARNING! (Continued) EQUIPPED • Before using the ParkSense Rear Park Assist Your vehicle may be equipped with the ParkView Rear system, it is strongly recommended that the ball Back Up Camera that allows you to see an on-screen mount and hitch ball assembly is disconnected image of the rear surroundings of your vehicle whenever...
  • Page 250 248 UNDERSTANDING THE FEATURES OF YOUR VEHICLE zones that will help indicate the distance to the rear of the vehicle. The following table shows the approximate distances for each zone: Zone Distance to the rear of the vehicle 0 - 1 ft (0 - 30 cm) Yellow 1 ft - 3 ft (30 cm - 1 m) Green...
  • Page 251: Turning Parkview On Or Off - With Touch Screen Radio

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 249 Turning ParkView On Or Off — With Touch CAUTION! (Continued) Screen Radio • To avoid vehicle damage, the vehicle must be 1. Turn the Radio on. driven slowly when using ParkView to be able to stop in time when an obstacle is seen.
  • Page 252: Overhead Console

    250 UNDERSTANDING THE FEATURES OF YOUR VEHICLE OVERHEAD CONSOLE Front Map/Reading Lights The overhead console contains courtesy/reading lights Lights are mounted in the overhead console. Each light and storage for sunglasses. Universal Garage Door can be turned on by pressing the lens. Opener (HomeLink ) and power sunroof switches may To turn the lights off, press the lens a second time.
  • Page 253: Sunglass Bin Door

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 251 The lights also turn on when a door is opened. The lights will also turn on when the UNLOCK button on the RKE is pressed. Sunglass Bin Door At the front of the console a compartment is provided for the storage of a pair of sunglasses.
  • Page 254: Garage Door Opener - If Equipped

    252 UNDERSTANDING THE FEATURES OF YOUR VEHICLE GARAGE DOOR OPENER — IF EQUIPPED HomeLink replaces up to three hand-held transmitters that operate devices such as garage door openers, motor- ized gates, lighting or home security systems. The HomeLink unit is powered by your vehicles 12 Volt battery.
  • Page 255: Before You Begin Programming Homelink

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 253 Before You Begin Programming HomeLink Be sure that your vehicle is parked outside of the garage before you begin programming. For more efficient programming and accurate transmis- sion of the radio-frequency signal it is recommended that a new battery be placed in the hand-held transmitter of the device that is being programmed to the HomeLink system.
  • Page 256: Programming A Rolling Code

    254 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • If you have any problems, or require assistance, please call toll-free 1–800–355–3515 or, on the Internet at www.HomeLink.com for information or assistance. Programming A Rolling Code For programming garage door openers that were manu- factured after 1995.
  • Page 257 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 255 3. Simultaneously press and hold both the Homelink light that blinks when the garage door opener/device is button you want to program and the hand-held transmit- in the LEARN/TRAIN mode. ter button. NOTE: You have 30 seconds in which to initiate the next 4.
  • Page 258: Programming A Non-Rolling Code

    256 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Reprogramming A Single HomeLink Button Programming A Non-Rolling Code To reprogram a channel that has been previously trained, For programming Garage Door Openers manufactured follow these steps: before 1995. 1. Turn the ignition switch to the ON/RUN position. 1.
  • Page 259: Canadian/Gate Operator Programming

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 257 5. Press and hold the programmed HomeLink button 3. Without releasing the button proceed with “Program- and observe the indicator light. ming A Non-Rolling Code” Step 2 and follow all remain- ing steps. •...
  • Page 260 258 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • To program the two remaining HomeLink buttons, 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) away from the HomeLink button you wish to program repeat each step for each remaining button. DO while keeping the HomeLink indicator light in view.
  • Page 261: Using Homelink

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 259 Using HomeLink Troubleshooting Tips To operate, press and release the programmed If you are having trouble programming HomeLink , here HomeLink button. Activation will now occur for the are some of the most common solutions: programmed device (i.e., garage door opener, gate opera- •...
  • Page 262: General Information

    260 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information WARNING! This device complies with FCC rules Part 15 and Industry • Your motorized door or gate will open and close Canada RSS-210. Operation is subject to the following two conditions: while you are programming the universal trans- ceiver.
  • Page 263: Power Sunroof - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 261 POWER SUNROOF — IF EQUIPPED WARNING! The power sunroof switch is located between the sun • Never leave children in a vehicle with the key in visors on the overhead console. the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch.
  • Page 264: Opening Sunroof - Express

    262 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Opening Sunroof — Express position. The sunroof will close fully and stop automati- Press the switch rearward and release it within one-half cally. This is called “Express Close”. During Express second and the sunroof will open automatically from any Close operation, any movement of the switch will stop position.
  • Page 265: Venting Sunroof - Express

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 263 NOTE: If three consecutive sunroof close attempts re- Wind Buffeting sult in Pinch Protect reversals, the fourth close attempt Wind buffeting can be described as the perception of will be a Manual Close movement with Pinch Protect pressure on the ears or a helicopter-type sound in the disabled.
  • Page 266: Ignition Off Operation

    264 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Ignition OFF Operation ELECTRICAL POWER OUTLETS — IF EQUIPPED The 12 Volt (13 Amp) instrument panel power outlet is For vehicles not equipped with the Electronic Vehicle located on the lower instrument panel, below the climate Information Center (EVIC), the power sunroof switch controls.
  • Page 267 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 265 CAUTION! • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded the fuse protecting the system will need to be replaced. •...
  • Page 268 266 UNDERSTANDING THE FEATURES OF YOUR VEHICLE There is also a 12 volt power outlet located in the center console. This power outlet has power available only when the ignition is placed in the ACC or RUN position. Underhood Fuses (Power Outlet Fuses) 1—...
  • Page 269 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 267 WARNING! CAUTION! • Many accessories that can be plugged in draw To avoid serious injury or death: • Only devices designed for use in this type of power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.).
  • Page 270: Cupholders

    268 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) • Power outlets are designed for accessory plugs only. Do not hang any type of accessory or acces- sory bracket from the plug. Improper use of the power outlet can cause damage. CUPHOLDERS Front Seat Cupholders The cupholders are located in the center console forward...
  • Page 271: Rear Seat Cupholders

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 269 convenient access to beverage cans or bottles while maintaining a resting place for the rear occupant’s el- bows. Light Ring In Front Cupholder Rear Seat Cupholders The rear seat cupholders are located in the center armrest between the rear seats.
  • Page 272: Storage

    270 UNDERSTANDING THE FEATURES OF YOUR VEHICLE STORAGE Glovebox Storage The glovebox storage compartment is located on the passenger side of the instrument panel. Pull on the release handle to open the glovebox storage compart- ment. Opened Glovebox Storage Compartment Glovebox Storage Compartment...
  • Page 273: Console Features

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 271 Console Features Pull upward on the release handle, located on the front of An open storage area, or cubby bin, is located in the the armrest, to open the storage compartment. center console forward of the shift lever. WARNING! There is a storage compartment located under the center console armrest.
  • Page 274: Door Storage

    272 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Door Storage The door panels contain storage areas. Rear Door Trim Storage Front Door Trim Storage...
  • Page 275: Passenger Seat Storage - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 273 Passenger Seat Storage — If Equipped Some models may be equipped with storage under the front passenger seat cushion. Pull upward on the seat tether to open the storage compartment. Passenger Seat Cushion Storage Compartment Passenger Seat Cushion Tether...
  • Page 276: Rear Seat Armrest Storage - If Equipped

    274 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Seat Armrest Storage — If Equipped CARGO AREA FEATURES For rear passengers there is a storage bin located in the Cargo Area — Vehicles Equipped with 60/40 armrest. Lift upward on the latch to open the storage Split-Folding Rear Seat compartment.
  • Page 277 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 275 Rear Seatback Loops Folded Rear Seatback After releasing the seatback, it can be folded forward. When the seatback is folded to the upright position, make sure it is latched by strongly pulling on the top of the seatback above the seat strap.
  • Page 278 276 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! WARNING! (Continued) • To help protect against personal injury, passengers • Be certain that the seatback is securely locked into should not be seated in the rear cargo area. The position. If the seatback is not securely locked into rear cargo space is intended for load carrying position, the seat will not provide the proper purposes only, not for passengers, who should sit...
  • Page 279: Trunk Mat - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 277 Cargo Tie-Downs WARNING! (Continued) The rear cargo area is equipped with cargo tie-downs, • Place as much cargo as possible in front of the rear located on either side of the rear cargo area. axle.
  • Page 280: Ski Pass-Through

    278 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Ski Pass-Through REAR WINDOW FEATURES There is a ski pass-through door located behind the rear Rear Window Defroster seat armrest that allows longer items, such as snow skis, The rear window defroster button is located on the to be stored in the rear cargo area.
  • Page 281 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 279 CAUTION! Failure to follow these cautions can cause damage to the heating elements: • Use care when washing the inside of the rear window. Do not use abrasive window cleaners on the interior surface of the window. Use a soft cloth and a mild washing solution, wiping parallel to the heating elements.
  • Page 283: Understanding Your Instrument Panel

    UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....284 Uconnect Touch™ Settings ....332 Instrument Cluster —...
  • Page 284 282 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions — CD Mode For CD Connecting The iPod Or External USB And MP3 Audio Play ....350 Device .
  • Page 285 UNDERSTANDING YOUR INSTRUMENT PANEL 283 Climate Controls ..... . 367 Climate Control Functions ....378 Manual Heating And Air Conditioning —...
  • Page 286: Instrument Panel Features

    284 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Demister 5 — Glove Compartment 9 — Trunk Release 2 — Outlet 6 — Climate Control Hard Controls/ 10 — Hood Release Uconnect Touch™ System Hard Controls 3 — Instrument Cluster 7 —...
  • Page 287: Instrument Cluster - Base

    UNDERSTANDING YOUR INSTRUMENT PANEL 285 INSTRUMENT CLUSTER — BASE...
  • Page 288: Instrument Cluster - Premium Analog

    286 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER — PREMIUM ANALOG...
  • Page 289: Instrument Cluster - Premium Digital

    UNDERSTANDING YOUR INSTRUMENT PANEL 287 INSTRUMENT CLUSTER — PREMIUM DIGITAL...
  • Page 290: Instrument Cluster Descriptions

    288 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS one or more of your tires is significantly under-inflated. Accordingly, when the low tire pressure telltale illumi- 1. Tachometer nates, you should stop and check your tires as soon as This gauge measures engine revolutions-per-minute possible, and inflate them to the proper pressure.
  • Page 291 UNDERSTANDING YOUR INSTRUMENT PANEL 289 approximately one minute and then remain continuously CAUTION! illuminated. This sequence will continue upon subse- quent vehicle start-ups as long as the malfunction exists. The TPMS has been optimized for the original When the malfunction indicator is illuminated, the sys- equipment tires and wheels.
  • Page 292 290 UNDERSTANDING YOUR INSTRUMENT PANEL continuous chime will sound to alert you to turn the CAUTION! signals off. If either indicator flashes at a rapid rate, check for a defective outside light bulb. Driving with a hot engine cooling system could damage your vehicle.
  • Page 293 UNDERSTANDING YOUR INSTRUMENT PANEL 291 system. If this light remains on after several ignition WARNING! cycles, and the vehicle has been driven several miles (kilometers) at speeds greater than 30 mph (48 km/h), see A hot engine cooling system is dangerous. You or your authorized dealer as soon as possible to have the others could be badly burned by steam or boiling problem diagnosed and corrected.
  • Page 294 292 UNDERSTANDING YOUR INSTRUMENT PANEL 6. Front Fog Light Indicator — If Equipped Center (EVIC). Refer to ”Electronic Vehicle Information This indicator will illuminate when the front fog Center (EVIC) — If Equipped” for further information. lights are on. 8. High Beam Indicator This indicator shows that the high beam head- 7.
  • Page 295 UNDERSTANDING YOUR INSTRUMENT PANEL 293 10. Brake Warning Light The dual brake system provides a reserve braking capac- This light monitors various brake functions, ity in the event of a failure to a portion of the hydraulic including brake fluid level and parking brake system.
  • Page 296 294 UNDERSTANDING YOUR INSTRUMENT PANEL The light also will turn on when the parking brake is WARNING! applied with the ignition switch in the ON/RUN posi- tion. Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. NOTE: This light shows only that the parking brake is It will take longer to stop the vehicle.
  • Page 297 UNDERSTANDING YOUR INSTRUMENT PANEL 295 14. Power Steering System Warning when the ignition is first turned to ON/RUN and remain This light is used to manage the electrical on briefly as a bulb check. If the light does not come on warning of the EPS (Power Steering System).
  • Page 298 296 UNDERSTANDING YOUR INSTRUMENT PANEL 18. Fuel Door Reminder 22. Odometer Display / Electronic Vehicle Information The arrow in this symbol is a reminder that the Center (EVIC) Display Fuel Filler Door is located on the left side of the Odometer Display vehicle.
  • Page 299 UNDERSTANDING YOUR INSTRUMENT PANEL 297 The Shift Lever Indicator is self-contained within the charging system is experiencing a problem. See your EVIC display. It displays the gear position of the auto- local authorized dealer to obtain service immediately. matic transmission. If jump starting is required, refer to “Jump Starting NOTE: You must apply the brakes before shifting from Procedures”...
  • Page 300 298 UNDERSTANDING YOUR INSTRUMENT PANEL 25. Anti-Lock Brake (ABS) Light 26. Malfunction Indicator Light (MIL) This light monitors the Anti-Lock Brake System The Malfunction Indicator Light (MIL) is part of (ABS). The light will turn on when the ignition an onboard diagnostic system, called OBD, that switch is turned to the ON/RUN position and monitors engine and automatic transmission con- may stay on for as long as four seconds.
  • Page 301 UNDERSTANDING YOUR INSTRUMENT PANEL 299 27. Transmission Temperature Warning Light — If CAUTION! Equipped This light indicates that the transmission fluid Prolonged driving with the MIL on could cause temperature is running hot. This may occur damage to the engine control system. It also could with severe usage, such as trailer towing.
  • Page 302 300 UNDERSTANDING YOUR INSTRUMENT PANEL This telltale will illuminate green when the elec- WARNING! tronic speed control is SET. For further informa- tion, refer to “Electronic Speed Control” in “Un- If the Transmission Temperature Warning Light is derstanding The Features Of Your Vehicle.” illuminated and you continue operating the vehicle, in some circumstances you could cause the fluid to 30.
  • Page 303: Electronic Vehicle Information Center (Evic)

    UNDERSTANDING YOUR INSTRUMENT PANEL 301 Malfunction). For further information, refer to “Elec- tronic Vehicle Information Center (EVIC)”. 32. ECO (Fuel Saver Indicator) — If Equipped The ECO indicator will illuminate when you are driving in a fuel efficient manner and can be used to modify driving habits in order to increase fuel economy.
  • Page 304 302 UNDERSTANDING YOUR INSTRUMENT PANEL messages that consist of approximately 60 possible warn- of this message type are Turn Signal On (if a turn signal ing or information messages. These pop up messages fall is left on) and Lights On (if driver leaves the vehicle). into several categories: •...
  • Page 305: Engine Oil Change Indicator System

    UNDERSTANDING YOUR INSTRUMENT PANEL 303 Engine Oil Change Indicator System Vehicles Equipped With Keyless Enter-N-Go™ Oil Change Required 1. Without pressing the brake pedal, press the ENGINE Your vehicle is equipped with an engine oil change START/STOP button and cycle the ignition to the ON/ indicator system.
  • Page 306: Two Button Evic - If Equipped

    304 UNDERSTANDING YOUR INSTRUMENT PANEL • Fuel Economy Info NOTE: If the indicator message illuminates when you start the vehicle, the oil change indicator system did not • Cruise Control Info reset. If necessary, repeat this procedure. • Stored Messages Two Button EVIC —...
  • Page 307 UNDERSTANDING YOUR INSTRUMENT PANEL 305 UP Arrow Button Press and release the UP arrow button to scroll upward through the main menus (Odometer, Digital Vehicle Speed, Trip Info, Range To Empty, Average Fuel Economy, Current Fuel Economy, Stored Messages, Settings). RIGHT Arrow Button Press and release the RIGHT arrow button to access the sub-menu screens of a main menu...
  • Page 308 306 UNDERSTANDING YOUR INSTRUMENT PANEL • Key In Ignition • Washer Fluid Low • Left Turn Signal Out • Parking Brake Engaged • Right Turn Signal Out • Brake Fluid Low • Turn Signal On • Service Electronic Braking System •...
  • Page 309 UNDERSTANDING YOUR INSTRUMENT PANEL 307 • Check Fuel Cap • Cruise Set To XXX km/h • Oil Change Due • Cruise Not Set Below Min. Speed • Service Tire Pressure System • Driver Seatbelt Unbuckled • Inflate Tire to XX •...
  • Page 310 308 UNDERSTANDING YOUR INSTRUMENT PANEL • Remote Start Aborted Hood Open • Cruise Control Info • Remote Start Aborted Time Expired • Stored Messages • Remote Start Aborted Too Cold • Tire Pressure • Remote Start Active Push Start Button •...
  • Page 311 UNDERSTANDING YOUR INSTRUMENT PANEL 309 • Trip A Elapsed Time Shows the total elapsed time of travel since the last reset. • Trip B Elapsed time will increment when the ignition is in the • Elapsed Time ON or START position. Press the UP buttons to cycle through all the Trip Resetting A Trip Info Function Computer functions.
  • Page 312 310 UNDERSTANDING YOUR INSTRUMENT PANEL When the RTE value is less than 30 miles (48 km) Current Miles Per Gallon (MPG) or Liters Per 100 estimated driving distance, the RTE display will change Kilometers (L/100km) to a text display of LOW FUEL”. This display will This display shows the instantaneous MPG in bar graph continue until the vehicle runs out of fuel.
  • Page 313: Four Button Evic - If Equipped

    UNDERSTANDING YOUR INSTRUMENT PANEL 311 • If the Tire Pressure System requires service, Service Four Button EVIC — If Equipped TPM System is displayed. Tire Pressure is an infor- This system allows the driver to select a variety of useful mation only function and cannot be reset.
  • Page 314 312 UNDERSTANDING YOUR INSTRUMENT PANEL The system allows the driver to select information by UP Arrow Button pressing the following buttons mounted on the steering Press and release the UP arrow button to scroll wheel: upward through the main menu and sub- menus (Fuel Economy, Trip A, Trip B, Audio, Stored Messages, Screen Set Up).
  • Page 315 UNDERSTANDING YOUR INSTRUMENT PANEL 313 RIGHT Arrow Button Electronic Vehicle Information Center (EVIC) Press and release the RIGHT arrow button to Displays access the information screens or sub-menu The EVIC displays are located in the center portion of the screens of a main menu item. Press and hold cluster and consists of eight sections: the RIGHT arrow button for two seconds to reset displayed/selected features that can be reset.
  • Page 316 314 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Selectable Information (Compass, Temp, Range to Empty, Trip A, Trip B, Average MPG) 4. Menu Titles / Odometer 5. Menu Set (Selectable Icons) 6. Shift Lever Status (PRNDL) 7. Reconfigurable Telltales 8. Audio / Phone Information 9.
  • Page 317 UNDERSTANDING YOUR INSTRUMENT PANEL 315 • Passenger Seatbelt Unbuckled • Tire Pressure Screen With Low Tire(s) “Inflate Tire to XX” • Service Airbag System • Service Tire Pressure System • Traction Control Off • Parking Brake Engaged • Washer Fluid Low •...
  • Page 318 316 UNDERSTANDING YOUR INSTRUMENT PANEL • Vehicle Not in Park • Service Airbag Warning Light • Key in Ignition • Driver Seatbelt Unbuckled • Key in Ignition Lights On • Passenger Seatbelt Unbuckled • Remote Start Active Key to Run •...
  • Page 319 UNDERSTANDING YOUR INSTRUMENT PANEL 317 • Trans. Hot Stop Safely Shift to Park Wait to Cool • Low Fuel Telltale When the fuel level reaches approximately 3.0 gal • Transmission Cool Ready to Drive (11.0 L) this light will turn on, and remain on until •...
  • Page 320 318 UNDERSTANDING YOUR INSTRUMENT PANEL • Door Ajar CAUTION! This telltale turns on when one or more doors are ajar. The telltale will show which doors are Continuous driving with the Transmission Tempera- ajar. ture Warning Telltale illuminated will eventually cause severe transmission damage or transmission •...
  • Page 321 UNDERSTANDING YOUR INSTRUMENT PANEL 319 idle). If the charging system telltale remains on, it means If the telltale remains lit with the engine running, your that the vehicle is experiencing a problem with the vehicle will usually be drivable. However, see an autho- charging system.
  • Page 322 320 UNDERSTANDING YOUR INSTRUMENT PANEL shift the transmission into NEUTRAL and idle the ve- EVIC Green Telltales hicle. If the temperature reading does not return to • Electronic Speed Control SET normal, turn the engine off immediately and call for This telltale will illuminate green when the service.
  • Page 323 UNDERSTANDING YOUR INSTRUMENT PANEL 321 EVIC. Press and release the RIGHT arrow button to Vehicle Info (Customer Information Features) change the display between analog and digital. Press and release the UP or DOWN arrow button until the Vehicle Info icon is highlighted Vehicle Speed MPH / Km/h in the EVIC.
  • Page 324 322 UNDERSTANDING YOUR INSTRUMENT PANEL pressure values in each corner of the ICON with the pressure value of the low tire displayed in a different color than the other tire pressure value. • If the Tire Pressure system requires service, Service Tire Pressure System is displayed.
  • Page 325 UNDERSTANDING YOUR INSTRUMENT PANEL 323 Coolant Temperature Press and release the UP or DOWN arrow button until Coolant Temperature is highlighted in the EVIC. Press and release the RIGHT arrow button and the coolant temperature will be displayed. Fuel Economy Press and release the UP or DOWN arrow button until the Fuel Economy icon is high- lighted.
  • Page 326 324 UNDERSTANDING YOUR INSTRUMENT PANEL Fuel Economy Digital Display Fuel Economy MPG Flower Analog Display The EVIC has the capability of displaying an interactive flower through the Fuel Economy sub-menu which will add one flower pedal for every 2.5 Miles Per Gallon (MPG) increment.
  • Page 327 UNDERSTANDING YOUR INSTRUMENT PANEL 325 Then, the history information will be erased, and the averaging will continue from the last fuel average read- ing before the reset. Range To Empty (RTE) Shows the estimated distance that can be traveled with the fuel remaining in the tank.
  • Page 328 326 UNDERSTANDING YOUR INSTRUMENT PANEL FUEL” message and a new RTE value will display. Press the LEFT arrow button to return to the main menu. Miles Per Gallon (MPG) The Miles Per Gallon (MPG) feature displays instanta- neous fuel economy in a bar graph below the DTE, this function cannot be reset.
  • Page 329 UNDERSTANDING YOUR INSTRUMENT PANEL 327 The Trip Functions mode displays the following information: Trip A Shows the total distance traveled for Trip A since the last reset. Trip B Shows the total distance traveled for Trip B since the last reset.
  • Page 330 328 UNDERSTANDING YOUR INSTRUMENT PANEL Resetting A Trip Info Function To Reset any of the three Trip Info functions, select the function you want to reset using the UP or DOWN buttons. Press the RIGHT arrow button until the feature displays zero.
  • Page 331 UNDERSTANDING YOUR INSTRUMENT PANEL 329 Stored Messages Press and release the UP or DOWN arrow button until the Messages display icon is high- lighted in the EVIC. This feature shows the number of stored warning messages. Pressing the RIGHT arrow button will allow you to see what the stored messages are.
  • Page 332 330 UNDERSTANDING YOUR INSTRUMENT PANEL Press and release the RIGHT arrow button to enter the save the display setting. You can press the LEFT arrow Screen Setup sub-menu. The Screen Setup feature allows button at any time to back out of a sub-menu selection. you to change what information is displayed in the NOTE: The Screen Setup items are only available at instrument cluster as well as the location that information...
  • Page 333 UNDERSTANDING YOUR INSTRUMENT PANEL 331 Gear Display Upper Right • Standard (PRND –/+) (default setting) • None • Single Character (D) • Compass (default setting) • Word (Drive) • Outside Temp Upper Left • Time • None • Range To Empty (RTE) •...
  • Page 334: Uconnect Touch™ Settings

    332 UNDERSTANDING YOUR INSTRUMENT PANEL • Outside Temp panel that allows you to access and change the customer programmable features. • Time Hard-Keys Lower Right Hard-Keys are located below the Uconnect Touch™ • None (default setting) system in the center of the instrument panel. In addition, there is a Scroll/Enter control knob located on the right •...
  • Page 335 UNDERSTANDING YOUR INSTRUMENT PANEL 333 Uconnect Touch™ system allows you to access program- Up or Down Arrow soft-keys on the right side of the mable features that may be equipped such as Display, screen will allow you to toggle up or down through the Clock, Safety/Assistance, Lights, Doors &...
  • Page 336 334 UNDERSTANDING YOUR INSTRUMENT PANEL • Display Brightness With Headlights OFF Metric until a check-mark appears next to the setting, When in this display, you may select the brightness with showing that setting has been selected. Touch the back the headlights off. Adjust the brightness with the + and – arrow soft-key to return to the previous menu.
  • Page 337 UNDERSTANDING YOUR INSTRUMENT PANEL 335 • Navigation Turn-By-Turn In Cluster • Set Time Hours When this feature is selected, the turn-by-turn directions When in this display, you may adjust the hours. The Sync will appear in the display as the vehicle approaches a with GPS Time soft-key must be unchecked.
  • Page 338 336 UNDERSTANDING YOUR INSTRUMENT PANEL showing that setting has been selected. Touch the back Assist status, touch and release the OFF, Sound Only or arrow soft-key to return to the previous menu. Sounds and Display button. Then touch the arrow back soft-key.
  • Page 339 UNDERSTANDING YOUR INSTRUMENT PANEL 337 NOTE: If your vehicle has experienced any damage in until a check-mark appears next to setting, showing that the area where the sensor is located, even if the fascia is setting has been selected. Touch the back arrow soft-key not damaged, the sensor may have become misaligned.
  • Page 340 338 UNDERSTANDING YOUR INSTRUMENT PANEL touch the + or - soft-key to select your desired time that setting has been selected. Touch the back arrow interval. Touch the back arrow soft-key to return to the soft-key to return to the previous menu. Refer to “Lights/ previous menu.
  • Page 341 UNDERSTANDING YOUR INSTRUMENT PANEL 339 next to setting, showing that setting has been selected. selection, touch the Flash Lights With Lock soft-key, until Touch the back arrow soft-key to return to the previous a check-mark appears next to setting, showing that menu.
  • Page 342 340 UNDERSTANDING YOUR INSTRUMENT PANEL • 1st Press Of Key Fob Unlocks opened, the interior door lock/unlock switch can be used When 1st Press Of Key Fob Unlocks is selected, only the to unlock all doors (or use RKE transmitter). driver’s door will unlock on the first press of the Remote •...
  • Page 343 UNDERSTANDING YOUR INSTRUMENT PANEL 341 check-mark appears next to setting, showing that setting DVD video system (if equipped), power sunroof (if has been selected. Touch the back arrow soft-key to equipped), and power outlets will remain active for up to return to the previous menu.
  • Page 344 342 UNDERSTANDING YOUR INSTRUMENT PANEL Compass Settings After pressing the Compass Settings soft-key the follow- ing settings will be available. • Variance Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differences the variance should be set for the zone where the vehicle is driven, per the zone map.
  • Page 345 UNDERSTANDING YOUR INSTRUMENT PANEL 343 calibrate the compass by pressing the ON soft-key and NOTE: Bass/Mid/Treble allow you to simply slide your completing one or more 360-degree turns (in an area free finger up or down to change the setting as well as touch from large metal or metallic objects) until the CAL directly on the desired setting.
  • Page 346 344 UNDERSTANDING YOUR INSTRUMENT PANEL • Subscription Information Phone/Bluetooth After pressing the Phone/Bluetooth soft-key the follow- New vehicle purchasers or lessees will receive a free ing settings will be available. limited time subscription to SiriusXM™ Satellite Radio with your radio. Following the expiration of the free •...
  • Page 347: Media Center 200 (Sales Code Rae) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack) And Siriusxm™ Radio

    UNDERSTANDING YOUR INSTRUMENT PANEL 345 MEDIA CENTER 200 (SALES CODE RAE) — Power Switch/Volume Control (Rotary) AM/FM STEREO RADIO WITH CD PLAYER (MP3 Push the ON/VOLUME control knob to turn on the AUX JACK) AND SiriusXM™ RADIO radio. Push the ON/VOLUME control knob a second time to turn off the radio.
  • Page 348 346 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button The clock can also be set by pressing the MENU button. Press the TIME button to alternate display of the time For vehicles equipped with satellite radio, press the and radio frequency. MENU button until CLOCK appears in the display. Using the ENTER/BROWSE button select SET TIME, Clock Setting Procedure and then follow the above procedure, starting at Step 2.
  • Page 349 UNDERSTANDING YOUR INSTRUMENT PANEL 347 TUNE Control Press the ENTER/BROWSE button and BASS will dis- Turn the rotary TUNE/SCROLL control knob clockwise play. Turn the TUNE/SCROLL control knob clockwise to to increase or counterclockwise to decrease the frequency. increase or counterclockwise to decrease the bass tones. Setting The Bass, Mid Range, Treble, Balance Or Press the ENTER/BROWSE button a second time and Fade...
  • Page 350 348 UNDERSTANDING YOUR INSTRUMENT PANEL • Clock — Selecting Clock will allow you to set the Press the ENTER/BROWSE button a fifth time and FADE will display. Turn the TUNE/SCROLL control knob clock. Adjust the hours by turning the TUNE/ clockwise or counterclockwise to adjust the sound level SCROLL control knob.
  • Page 351 UNDERSTANDING YOUR INSTRUMENT PANEL 349 • Repeat (RPT) — When Repeat is activated, the cur- SCROLL control knob. After adjusting the hours, press rently playing song will begin again when it ends. It the ENTER/BROWSE button to set the minutes. The will continue to cycle through the same song until minutes will highlight.
  • Page 352: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play

    350 UNDERSTANDING YOUR INSTRUMENT PANEL To Set The Pushbutton Memory Operation Instructions — CD MODE For CD And When you are receiving a station that you wish to MP3 Audio Play commit to pushbutton memory, press and hold the NOTE: button (1–5) you wish to lock onto this station for •...
  • Page 353 UNDERSTANDING YOUR INSTRUMENT PANEL 351 If you insert a disc with the ignition ON/RUN and the EJECT Button — Ejecting A CD radio ON, the unit will switch from radio to CD mode Press the EJECT button to eject the CD. and begin to play when you insert the disc.
  • Page 354: Notes On Playing Mp3/Wma Files

    352 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button Shuffle and Repeat cannot be active at the same time. If Press this button to change the display from a large CD one is selected while the other is currently active the playing time display to a small CD playing time display. currently active one will be changed to OFF.
  • Page 355 UNDERSTANDING YOUR INSTRUMENT PANEL 353 Supported Medium Formats (File Systems) exceeding 20 folders will result in this display. With The medium formats supported by the radio are ISO 9660 200 files, exceeding 50 folders will result in this Level 1 and Level 2 and includes the Joliet extension. display.) When reading discs recorded using formats other than •...
  • Page 356 354 UNDERSTANDING YOUR INSTRUMENT PANEL Supported MP3 File Formats MPEG Specifi- Sampling Bit Rate (kbps) The radio will recognize only files with the *.MP3 exten- cation Frequency (kHz) sion as MP3 files. Non-MP3 files named with the *.MP3 160, 128, 144, extension may cause playback problems.
  • Page 357: Enter/Browse Button (Cd Mode For Mp3/Wma Play)

    UNDERSTANDING YOUR INSTRUMENT PANEL 355 Loading times for playback of MP3 files may be affected done by turning the TUNE/SCROLL control knob. Se- by the following: lecting a folder by pressing the ENTER/BROWSE button will begin playing the files contained in that folder (or the •...
  • Page 358: Operation Instructions - Auxiliary Mode

    356 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions — Auxiliary Mode Operation Instructions — Universal Serial Bus The auxiliary (AUX) jack is an audio input jack which (USB) allows the user to plug in a portable device such as an The USB audio input which allows the user to plug in a MP3 player and utilize the vehicle’s audio system to flash drive and utilize the vehicle’s audio system to amplify the source and play through the vehicle speak-...
  • Page 359: Security

    UNDERSTANDING YOUR INSTRUMENT PANEL 357 will display, “No audio files on device” this messaged is to be displayed for all devices that do not have audio files when connected and selected. Security If this radio is installed in a vehicle that does not have a matching Vehicle Identification Number (VIN) an Secu- rity code will need to be entered by the dealer.
  • Page 360: Cd Player Operating Instructions

    358 UNDERSTANDING YOUR INSTRUMENT PANEL CD Player Operating Instructions iPod /USB/MP3 CONTROL WITH Uconnect™ VOICE COMMAND — IF EQUIPPED Loading This feature allows an iPod or external USB device to be To insert disc into the player, follow the instructions plugged into the USB port.
  • Page 361 UNDERSTANDING YOUR INSTRUMENT PANEL 359 Center Console USB/AUX Connector Port Center Console USB/AUX Connector Port Cable Routing NOTE: The center console will have a position where the iPod or consumer electronic audio device cable can be routed through without damaging the cable when closing the lid.
  • Page 362: Using This Feature

    360 UNDERSTANDING YOUR INSTRUMENT PANEL • The audio device can be played on the vehicle’s sound without damaging it while closing the lid. If a cut out is not available in the center console base, route the cable system, providing metadata (artist, track title, album, away from the lid latch and in a place that will allow the etc.) information on the radio display.
  • Page 363: Play Mode

    UNDERSTANDING YOUR INSTRUMENT PANEL 361 • Jump backward in the current track by pressing and Play Mode When switched to iPod /USB/MP3 control mode, the holding the << RW button. Holding the << RW iPod or external USB device automatically starts Play button long enough will jump to the beginning of mode.
  • Page 364: List Or Browse Mode

    362 UNDERSTANDING YOUR INSTRUMENT PANEL • In Browse mode, the radio PRESET buttons are used to the next screen of data for that track. Once all screens have been viewed, the last INFO button press as shortcuts to the following lists on the iPod or will go back to the play mode screen on the radio.
  • Page 365: Bluetooth Streaming Audio (Btsa)

    UNDERSTANDING YOUR INSTRUMENT PANEL 363 • Browse button: The Browse button will display the CAUTION! (Continued) top level menu of the iPod or external USB device. • Placing items on the iPod or external USB device, Press and then turn the TUNE/SCROLL control knob or connections to the iPod or external USB device to list the top-menu item to be selected and press the in the vehicle, can cause damage to the device...
  • Page 366 364 UNDERSTANDING YOUR INSTRUMENT PANEL Controlling BTSA Using Radio Buttons 3. Say the name of the audio device or ask the To get into the BTSA mode, press either “AUX” button on Uconnect™ phone system to list audio devices. the radio or press the VR button and say “Bluetooth Next Track Streaming Audio”.
  • Page 367: Steering Wheel Audio Controls

    UNDERSTANDING YOUR INSTRUMENT PANEL 365 STEERING WHEEL AUDIO CONTROLS The right-hand control is a rocker-type switch with a The remote sound system controls are located on the rear pushbutton in the center and controls the volume and surface of the steering wheel. Reach behind the wheel to mode of the sound system.
  • Page 368: Cd Player

    366 UNDERSTANDING YOUR INSTRUMENT PANEL The button located in the center of the left-hand control CD/DVD DISC MAINTENANCE will tune to the next preset station that you have pro- To keep a CD/DVD in good condition, take the following grammed in the radio preset pushbutton. precautions: CD Player 1.
  • Page 369: Radio Operation And Mobile Phones

    UNDERSTANDING YOUR INSTRUMENT PANEL 367 NOTE: If you experience difficulty in playing a particu- CLIMATE CONTROLS lar disc, it may be damaged (i.e., scratched, reflective The air conditioning and heating system is designed to coating removed, a hair, moisture or dew on the disc) make you comfortable in all types of weather.
  • Page 370: Equipped

    368 UNDERSTANDING YOUR INSTRUMENT PANEL Manual Heating And Air Conditioning — If Equipped The Manual Temperature Controls consist of a series of outer rotary dials and inner push knobs. Uconnect Touch™ 8.4 Manual Temperature Control 1. Blower Control Rotate this control to regulate the amount of air forced through the ventilation system in any mode.
  • Page 371 UNDERSTANDING YOUR INSTRUMENT PANEL 369 • The A/C will engage automatically to prevent fogging NOTE: For vehicles equipped with Remote Start, the climate controls will not function during Remote Start when the recirculation button is pressed and the mode operation if the blower control is left in the “O” (Off) control is set to panel or Bi-Level.
  • Page 372 370 UNDERSTANDING YOUR INSTRUMENT PANEL into the blue area of the scale indicates cooler tempera- NOTE: The air conditioning compressor will not engage tures, while rotating right into the red area indicates until the engine has been running for about 10 seconds. warmer temperatures.
  • Page 373 UNDERSTANDING YOUR INSTRUMENT PANEL 371 • Panel • Floor Air is directed through the outlets in the instrument Air is directed through the floor outlets with a panel. These outlets can be adjusted to direct airflow. small amount flowing through the defrost and side window demist outlets.
  • Page 374 372 UNDERSTANDING YOUR INSTRUMENT PANEL Conditioning (A/C) button is not pressed. This dehu- CAUTION! midifies the air to help dry the windshield. To improve fuel economy, use these modes only when necessary. Failure to follow these cautions can cause damage to the heating elements: 6.
  • Page 375: Uconnect Touch™ 8.4 Climate Controls - If Equipped

    UNDERSTANDING YOUR INSTRUMENT PANEL 373 Uconnect Touch™ 8.4 Climate Controls — If Soft-Keys Equipped Soft-keys are accessible on the Uconnect Touch™ system screen. Hard-Keys The hard-keys are located below the Uconnect Touch™ screen, in the center of the instrument panel. Uconnect Touch™...
  • Page 376 374 UNDERSTANDING YOUR INSTRUMENT PANEL Button Descriptions (Applies To Both Hard-keys And NOTE: For vehicles equipped with Remote Start, the Soft-keys) climate controls will not function during Remote Start operation if the blower control is left in the “O” (Off) 1.
  • Page 377 UNDERSTANDING YOUR INSTRUMENT PANEL 375 4. Front Defrost Button CAUTION! Press and release to change the current airflow setting to Defrost mode. The indicator illuminates when this fea- Failure to follow these cautions can cause damage to ture is ON. Performing this function will cause the ATC the heating elements: to switch into manual mode.
  • Page 378 376 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Pressing this button while in Sync mode will 10. Driver Temperature Control Down Button automatically exit Sync. Provides the driver with independent temperature con- trol. Push the button for cooler temperature settings. 7. Passenger Temperature Control Down Button Provides the passenger with independent temperature NOTE: In Sync mode, this button will also automati- control.
  • Page 379 UNDERSTANDING YOUR INSTRUMENT PANEL 377 • Panel Mode • Floor Mode Air comes from the outlets in the instrument panel. Air comes from the floor outlets. A slight amount of Each of these outlets can be individually adjusted to air is directed through the defrost and side window direct the flow of air.
  • Page 380: Climate Control Functions

    378 UNDERSTANDING YOUR INSTRUMENT PANEL • If your air conditioning performance seems lower than temperature setting with the driver temperature setting. Changing the passenger temperature setting while in expected, check the front of the A/C condenser (lo- Sync will automatically exit this feature. cated in front of the radiator), for an accumulation of dirt or insects.
  • Page 381: Automatic Temperature Control (Atc)

    UNDERSTANDING YOUR INSTRUMENT PANEL 379 allowed in Defrost mode to improve window clearing Once the desired temperature is displayed, the system operation. Recirculation will be disabled automatically if will achieve and automatically maintain that comfort this mode is selected. Attempting to use Recirculation level.
  • Page 382: Operating Tips

    380 UNDERSTANDING YOUR INSTRUMENT PANEL To provide you with maximum comfort in the Automatic Operating Tips mode, during cold start-ups the blower fan will remain NOTE: Refer to the chart at the end of this section for on low until the engine warms up. The blower will suggested control settings for various weather condi- increase in speed and transition into Auto mode.
  • Page 383 UNDERSTANDING YOUR INSTRUMENT PANEL 381 • Automatic Temperature Controls (ATC) will automati- Vacation Storage Any time you store your vehicle or keep it out of service cally adjust the climate control settings to reduce or (i.e., vacation) for two weeks or more, run the air eliminate window fogging on the front windshield.
  • Page 385 STARTING AND OPERATING CONTENTS Starting Procedures ....387 After Starting ..... . . 392 Manual Transmission –...
  • Page 386 384 STARTING AND OPERATING Six-Speed Automatic Transmission (1.4L Parking Brake ......420 Turbo Engine Only — Ddct) ... . . 398 Power Steering .
  • Page 387 STARTING AND OPERATING 385 Tire Terminology And Definitions ..438 Tread Wear Indicators ....450 Tire Loading And Tire Pressure ..439 Life Of Tire .
  • Page 388 386 STARTING AND OPERATING Reformulated Gasoline ....465 Trailer Towing ......474 Gasoline/Oxygenate Blends .
  • Page 389: Starting Procedures

    STARTING AND OPERATING 387 STARTING PROCEDURES WARNING! (Continued) Before starting your vehicle, adjust your seat, adjust both • Do not leave the key fob in or near the vehicle, and inside and outside mirrors, and fasten your seat belts. do not leave a vehicle equipped with Keyless Enter-N-Go in the ACC or ON/RUN mode.
  • Page 390: Automatic Transmission - If Equipped

    388 STARTING AND OPERATING Automatic Transmission – If Equipped Installing And Removing The ENGINE The shift lever must be in the PARK or NEUTRAL START/STOP Button – If Equipped position before you can start the engine. Apply the brakes NOTE: The START/STOP button is not removable on before shifting to any driving gear.
  • Page 391: Normal Starting

    STARTING AND OPERATING 389 Removing The Button To start the engine, the transmission must be in PARK or NEUTRAL. Press and hold the brake pedal while press- 1. The ENGINE START/STOP button can be removed ing the ENGINE START/STOP button once. The system from the ignition switch for key fob use.
  • Page 392 390 STARTING AND OPERATING button is pressed twice to the OFF position. If the shift and START. To change the ignition switch positions lever is not in PARK and the ENGINE START/STOP without starting the vehicle and use the accessories button is pressed once, the EVIC (if equipped) will follow these steps.
  • Page 393: Extreme Cold Weather

    STARTING AND OPERATING 391 Extreme Cold Weather (Below –20°F or 29°C) If Engine Fails To Start To ensure reliable starting at these temperatures, use of If the engine fails to start after you have followed the an externally powered electric engine block heater (avail- “Normal Starting”...
  • Page 394: After Starting

    392 STARTING AND OPERATING ENGINE BLOCK HEATER — IF EQUIPPED CAUTION! The engine block heater warms the engine, and permits quicker starts in cold weather. Connect the cord to a To prevent damage to the starter, do not continuously standard 110-115 Volt AC electrical outlet with a crank the engine for more than 25 seconds at a time.
  • Page 395: Manual Transmission - If Equipped

    STARTING AND OPERATING 393 MANUAL TRANSMISSION — IF EQUIPPED NOTE: During cold weather, you may experience in- creased effort in shifting until the transmission fluid WARNING! warms up. This is normal. Shifting You or others could be injured if you leave the Fully press the clutch pedal before shifting gears.
  • Page 396: Downshifting

    394 STARTING AND OPERATING Manual Transmission Shift Speeds in MPH (KM/H) WARNING! Engine Speeds 1 to 2 2 to 3 3 to 4 4 to 5 5 to 6 Do not downshift for additional engine braking on a Accel. slippery surface. The drive wheels could lose their (24) (39) (55)
  • Page 397: Automatic Transmission - If Equipped

    STARTING AND OPERATING 395 Maximum Recommended Downshift Speeds AUTOMATIC TRANSMISSION — IF EQUIPPED CAUTION! CAUTION! Failure to follow the maximum recommended down- Damage to the transmission may occur if the follow- shifting speeds may cause the engine to overspeed ing precautions are not observed: •...
  • Page 398 396 STARTING AND OPERATING WARNING! WARNING! (Continued) • Unintended movement of a vehicle could injure • It is dangerous to move the shift lever out of PARK those in and near the vehicle. As with all vehicles, or NEUTRAL if the engine speed is higher than you should never exit a vehicle while the engine is idle speed.
  • Page 399: Key Ignition Park Interlock

    STARTING AND OPERATING 397 position. The key fob can only be removed from the WARNING! (Continued) ignition when the ignition is in the OFF position and the • Never leave children alone in a vehicle, or with shift lever is locked in PARK. access to an unlocked vehicle.
  • Page 400: Starting And Operating

    398 STARTING AND OPERATING Six-Speed Automatic Transmission (1.4L Turbo Only shift from DRIVE to PARK or REVERSE should be Engine Only — DDCT) done only when the accelerator pedal is released and the The shift lever position display (located in the instrument vehicle is stopped.
  • Page 401: Gear Ranges

    STARTING AND OPERATING 399 PARK This range supplements the parking brake by locking the transmission. The engine can be started in this range. Never attempt to use PARK while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range.
  • Page 402 400 STARTING AND OPERATING WARNING! WARNING! (Continued) • It is dangerous to move the shift lever out of PARK • Never use the PARK position as a substitute for or NEUTRAL if the engine speed is higher than the parking brake. Always apply the parking idle speed.
  • Page 403 STARTING AND OPERATING 401 WARNING! (Continued) WARNING! (Continued) • Unintended movement of a vehicle could injure • Never leave children alone in a vehicle, or with those in or near the vehicle. As with all vehicles, access to an unlocked vehicle. Allowing children you should never exit a vehicle while the engine is to be in a vehicle unattended is dangerous for a running.
  • Page 404 402 STARTING AND OPERATING • With brake pedal released, verify that the shift lever CAUTION! will not move out of PARK. • Before moving the shift lever out of PARK, you REVERSE must turn the ignition switch from the OFF posi- This range is for moving the vehicle backward.
  • Page 405 STARTING AND OPERATING 403 DRIVE WARNING! This range should be used for most city and highway driving. It provides the smoothest upshifts and down- Do not coast in NEUTRAL and never turn off the shifts, and the best fuel economy. The transmission ignition to coast down a hill.
  • Page 406 404 STARTING AND OPERATING • At low speeds you may hear mechanical noises similar When frequent transmission shifting occurs (such as to a manual transmission as the transmission changes when operating the vehicle under heavy loading condi- gears. These noises are normal and will not damage tions, in hilly terrain, or traveling into strong head winds, the transmission.
  • Page 407 STARTING AND OPERATING 405 MESSAGE DESCRIPTION MESSAGE DESCRIPTION GEAR NOT In AutoStick mode, the gear SHIFT TO The transmission has shifted AVAILABLE selected by the driver is not NEUTRAL – THEN itself into NEUTRAL (due to a available due to a fault condi- D or R fault condition, or overheat tion.
  • Page 408 406 STARTING AND OPERATING MESSAGE DESCRIPTION MESSAGE DESCRIPTION AUTOMATIC The transmission is unable to TRANS. GETTING The transmission driving clutch MODE NOT shift itself automatically, due to HOT PRESS BRAKE is overheating, usually due to AVAILABLE a fault condition. Use the repeated launches in stop- AutoStick mode to shift the and-go traffic.
  • Page 409 STARTING AND OPERATING 407 to be available. The “Malfunction Indicator Light (MIL)” MESSAGE DESCRIPTION may be illuminated. Limp Home Mode allows the vehicle SERVICE SHIFTER A shift lever fault has been de- to be driven to an authorized dealer for service without tected.
  • Page 410: Six-Speed Automatic Transmission (2.0L And 2.4L Engine Only - 6F24)

    408 STARTING AND OPERATING NOTE: Even if the transmission can be reset, we recom- self-calibrating; therefore, the first few shifts on a new mend that you visit your authorized dealer at your vehicle may be somewhat abrupt. This is a normal earliest possible convenience.
  • Page 411: Gear Ranges

    STARTING AND OPERATING 409 Gear Ranges move the shift lever out of PARK. As an added precau- DO NOT race the engine when shifting from PARK or tion, turn the front wheels toward the curb on a downhill NEUTRAL into another gear range. grade and away from the curb on an uphill grade.
  • Page 412 410 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • It is dangerous to move the shift lever out of PARK • Unintended movement of a vehicle could injure or NEUTRAL if the engine speed is higher than those in or near the vehicle. As with all vehicles, idle speed.
  • Page 413 STARTING AND OPERATING 411 WARNING! (Continued) CAUTION! • Never leave children alone in a vehicle, or with • Before moving the shift lever out of PARK, you access to an unlocked vehicle. Allowing children must turn the ignition switch from the OFF position to be in a vehicle unattended is dangerous for a to the ON/RUN position, press the brake pedal, and number of reasons.
  • Page 414 412 STARTING AND OPERATING REVERSE CAUTION! This range is for moving the vehicle backward. Shift into REVERSE only after the vehicle has come to a complete Towing the vehicle, coasting, or driving for any other stop. reason with the transmission in NEUTRAL can cause severe transmission damage.
  • Page 415 STARTING AND OPERATING 413 When frequent transmission shifting occurs (such as During very cold temperatures (-4°F [-20°C] or below), when operating the vehicle under heavy loading condi- transmission operation may be modified depending on tions, in hilly terrain, traveling into strong head winds, or engine and transmission temperature as well as vehicle while towing heavy trailers), use the AutoStick shift speed.
  • Page 416 414 STARTING AND OPERATING In the event of a momentary problem, the transmission If the transmission cannot be reset, authorized dealer can be reset to regain all forward gears by performing the service is required. following steps: Overdrive Operation 1. Stop the vehicle. The automatic transmission includes an electronically controlled Overdrive (sixth gear).
  • Page 417: Autostick

    STARTING AND OPERATING 415 Torque Converter Clutch of the vehicle. AutoStick allows you to maximize engine A feature designed to improve fuel economy has been braking, eliminate undesirable upshifts and downshifts, included in the automatic transmission on your vehicle. and improve overall vehicle performance. A clutch within the torque converter engages automati- This system can also provide you with more control cally at calibrated speeds.
  • Page 418 416 STARTING AND OPERATING • If the system detects powertrain overheating, the overspeed condition would result. It will remain in the selected gear until another upshift or downshift is cho- transmission will revert to automatic shift mode and sen, except as described below. remain in that mode until the powertrain cools off.
  • Page 419: Driving On Slippery Surfaces

    STARTING AND OPERATING 417 DRIVING ON SLIPPERY SURFACES Traction When driving on wet or slushy roads, it is possible for a Acceleration wedge of water to build up between the tire and road Rapid acceleration on snow covered, wet, or other slip- surface.
  • Page 420: Driving Through Water

    418 STARTING AND OPERATING DRIVING THROUGH WATER Shallow Standing Water Driving through water more than a few inches/ Although your vehicle is capable of driving through centimeters deep will require extra caution to ensure shallow standing water, consider the following Caution safety and prevent damage to your vehicle.
  • Page 421 STARTING AND OPERATING 419 CAUTION! (Continued) WARNING! • Driving through standing water may cause dam- • Driving through standing water limits your vehi- age to your vehicle’s drivetrain components. Al- cle’s traction capabilities. Do not exceed 5 mph ways inspect your vehicle’s fluids (i.e., engine oil, (8 km/h) when driving through standing water.
  • Page 422: Parking Brake

    420 STARTING AND OPERATING PARKING BRAKE The parking brake lever is located in the center console. Before leaving the vehicle, make sure that the parking To apply the parking brake, pull the lever up as firmly as brake is fully applied. Also, be certain to leave an possible.
  • Page 423 STARTING AND OPERATING 421 When parking on a hill, it is important to turn the front WARNING! (Continued) wheels toward the curb on a downhill grade and away • Allowing children to be in a vehicle unattended is from the curb on an uphill grade. For vehicles equipped dangerous for a number of reasons.
  • Page 424: Power Steering

    422 STARTING AND OPERATING CAUTION! WARNING! If the “Brake Warning Light” remains on with the Continued operation with reduced assist could pose parking brake released, a brake system malfunction a safety risk to yourself and others. Service should be is indicated. Have the brake system serviced by an obtained as soon as possible.
  • Page 425: Electronic Brake Control System

    STARTING AND OPERATING 423 If the Steering icon is displayed and the “SERVICE Assist System (BAS), Traction Control System (TCS), POWER STEERING – ASSIST OFF” message is displayed Electronic Roll Mitigation (ERM), Trailer Sway Control the EVIC screen, they indicate the vehicle needs to be (TCS), Hill Start Assist (HSA), and Electronic Stability taken to the dealer for service.
  • Page 426 424 STARTING AND OPERATING ABS is activated during braking under certain road or WARNING! stopping conditions. ABS-inducing conditions can in- • The ABS contains sophisticated electronic equip- clude ice, snow, gravel, bumps, railroad tracks, loose debris, or panic stops. ment that may be susceptible to interference caused by improperly installed or high output You also may experience the following when the brake radio transmitting equipment.
  • Page 427 STARTING AND OPERATING 425 Anti-Lock Brake Warning Light WARNING! (Continued) The “Anti-Lock Brake Warning Light” moni- • The ABS cannot prevent the natural laws of phys- tors the ABS. The light will turn on when the ics from acting on the vehicle, nor can it increase ignition switch is turned to the ON position braking or steering efficiency beyond that af- and may stay on for as long as four seconds.
  • Page 428: Brake Assist System (Bas)

    426 STARTING AND OPERATING If both the “Brake System Warning Light” and the “ABS WARNING! Warning Light” remain on, the ABS and Electronic Brake Force Distribution (EBD) systems are not functioning. The BAS cannot prevent the natural laws of physics Immediate repair to the ABS system is required.
  • Page 429: Electronic Roll Mitigation (Erm)

    STARTING AND OPERATING 427 across a driven axle. If one wheel on a driven axle is driving maneuvers. It cannot prevent wheel lift due to spinning faster than the other, the system will apply the other factors, such as road conditions, leaving the road- brake of the spinning wheel.
  • Page 430: Hill Start Assist (Hsa)

    428 STARTING AND OPERATING is functioning, the “ESC Off Indicator Light” will flash, WARNING! (Continued) the engine power will be reduced, and you will feel the • Failure to follow these warnings can result in a brake being applied to individual wheels in an attempt to collision or serious personal injury.
  • Page 431 STARTING AND OPERATING 429 HSA Activation Criteria WARNING! The following criteria must be met in order for HSA to activate: There may be situations on minor hills (i.e., less than 7%), with a loaded vehicle, or while pulling a trailer, •...
  • Page 432: Electronic Stability Control (Esc)

    430 STARTING AND OPERATING WARNING! WARNING! (Continued) • Failure to follow these warnings may cause the • If you use a trailer brake controller with your vehicle to roll down the incline and could collide trailer, your trailer brakes may be activated and with another vehicle, object or person, and cause deactivated with the brake switch.
  • Page 433 STARTING AND OPERATING 431 does not match the intended path, the ESC applies the WARNING! brake of the appropriate wheel to assist in counteracting • The Electronic Stability Control (ESC) cannot pre- the condition of over-steer or under-steer. vent the natural laws of physics from acting on the •...
  • Page 434 432 STARTING AND OPERATING should go out with the engine running. If the “ESC ESC Operating Modes Malfunction Indicator Light” comes on continuously The ESC system has two available operating modes. with the engine running, a malfunction has been detected Full On in the ESC system.
  • Page 435: Tire Safety Information

    STARTING AND OPERATING 433 TIRE SAFETY INFORMATION WARNING! Tire Markings When in “Partial Off” mode, the TCS portion of ESC, except for the limited wheel spin feature described in the TCS section, has been disabled and the “ESC Off Indicator Light” will be illuminated. All other stabil- ity features of ESC function normally.
  • Page 436 434 STARTING AND OPERATING NOTE: tires is the same as for P-Metric tires except for the • P (Passenger) - Metric tire sizing is based on U.S. letters “LT” that are molded into the sidewall preced- design standards. P-Metric tires have the letter “P” ing the size designation.
  • Page 437 STARTING AND OPERATING 435 Tire Sizing Chart EXAMPLE: Size Designation: P = Passenger car tire size based on U.S. design standards ..blank..= Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T or S = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
  • Page 438 436 STARTING AND OPERATING EXAMPLE: Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
  • Page 439: Tire Identification Number (Tin)

    STARTING AND OPERATING 437 Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on however, the date code may only be on one side.
  • Page 440: Tire Terminology And Definitions

    438 STARTING AND OPERATING Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold tire inflation pressure is defined as the tire pressure Cold Tire Inflation Pressure after the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
  • Page 441: Tire Loading And Tire Pressure

    STARTING AND OPERATING 439 Tire Loading And Tire Pressure Tire And Loading Information Placard Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door.
  • Page 442 440 STARTING AND OPERATING Loading The combined weight of occupants, cargo/luggage and The vehicle maximum load on the tire must not exceed trailer tongue weight (if applicable) should never exceed the load carrying capacity of the tire on your vehicle. You the weight referenced here.
  • Page 443 STARTING AND OPERATING 441 available cargo and luggage load capacity is 650 lbs NOTE: • The following table shows examples on how to calcu- (295 kg) (since 5 x 150 = 750, and 1400 – 750 = 650 lbs [295 kg]). late total load, cargo/luggage, and towing capacities of your vehicle with varying seating configurations 5.
  • Page 444 442 STARTING AND OPERATING...
  • Page 445: Tires - General Information

    STARTING AND OPERATING 443 Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
  • Page 446: Tire Inflation Pressures

    444 STARTING AND OPERATING Tire Inflation Pressures WARNING! (Continued) The proper cold tire inflation pressure is listed on the left • Unequal tire pressures from one side of the ve- side “B” Pillar or rear edge of the driver’s side door. hicle to the other can cause the vehicle to drift to Some vehicles may have Supplemental Tire Pressure the right or left.
  • Page 447: Tire Pressures For High Speed Operation

    STARTING AND OPERATING 445 Tire pressures change by approximately 1 psi (7 kPa) per CAUTION! 12°F (7°C) of air temperature change. Keep this in mind when checking tire pressure inside a garage, especially in After inspecting or adjusting the tire pressure, al- the Winter.
  • Page 448: Radial Ply Tires

    446 STARTING AND OPERATING loading may be required for high-speed vehicle opera- Radial Ply Tires tion. Refer to original equipment or an authorized tire WARNING! dealer for recommended safe operating speeds, loading and cold tire inflation pressures. Combining radial ply tires with other types of tires on your vehicle will cause your vehicle to handle WARNING! poorly.
  • Page 449: Compact Spare Tire - If Equipped

    STARTING AND OPERATING 447 vehicle. If your vehicle has this option refer to an Compact Spare Tire – If Equipped authorized tire dealer for the recommended tire rotation The compact spare is for temporary emergency use only. pattern. You can identify if your vehicle is equipped with a compact spare by looking at the spare tire description on If your vehicle is not equipped with an original equip- the Tire and Loading Information Placard located on the...
  • Page 450: Full Size Spare - If Equipped

    448 STARTING AND OPERATING your original equipment tire, replace (or repair) the WARNING! original equipment tire and reinstall on the vehicle at the first opportunity. Compact spares are for temporary emergency use only. With these spares, do not drive more than Limited-Use Spare –...
  • Page 451: Tire Spinning

    STARTING AND OPERATING 449 Tire Spinning WARNING! When stuck in mud, sand, snow, or ice conditions, do not spin your vehicle’s wheels faster than 30 mph (48 km/h) Limited-use spares are for emergency use only. In- or for longer than 30 seconds continuously without stallation of this limited-use spare tire affects vehicle stopping when you are stuck.
  • Page 452: Starting And Operating

    450 STARTING AND OPERATING Tread Wear Indicators These indicators are molded into the bottom of the tread Tread wear indicators are in the original equipment tires grooves. They will appear as bands when the tread depth to help you in determining when your tires should be becomes 1/16 in (2 mm).
  • Page 453: Replacement Tires

    STARTING AND OPERATING 451 Information” placard for the size designation of your tire. WARNING! The Load Index and Speed Symbol for your tire will be found on the original equipment tire sidewall. See the Tires and the spare tire should be replaced after six Tire Sizing Chart example found in the Tire Safety years, regardless of the remaining tread.
  • Page 454 452 STARTING AND OPERATING WARNING! WARNING! (Continued) • Never use a tire with a smaller load index or • Do not use a tire, wheel size or rating other than capacity other than what was originally equipped that specified for your vehicle. Some combinations on your vehicle.
  • Page 455: Tire Chains (Traction Devices)

    STARTING AND OPERATING 453 TIRE CHAINS (TRACTION DEVICES) CAUTION! Use of traction devices require sufficient tire-to-body clearance. Follow these recommendations to guard To avoid damage to your vehicle or tires, observe the against damage. following precautions: • Because of restricted traction device clearance be- •...
  • Page 456: Snow Tires

    454 STARTING AND OPERATING Snow tires generally have lower speed ratings than what CAUTION! (Continued) was originally equipped with your vehicle and should • Do not drive for prolonged period on dry pave- not be operated at sustained speeds over 75 mph ment.
  • Page 457 STARTING AND OPERATING 455 These effects can be reduced by timely rotation of tires. The benefits of rotation are especially worthwhile with aggressive tread designs such as those on all season type tires. Rotation will increase tread life, help to maintain mud, snow and wet traction levels, and contribute to a smooth, quiet ride.
  • Page 458: Tire Pressure Monitoring System (Tpms)

    456 STARTING AND OPERATING TIRE PRESSURE MONITORING SYSTEM (TPMS) The TPMS will warn the driver of a low tire pressure if The Tire Pressure Monitor System (TPMS) will warn the the tire pressure falls below the low-pressure warning driver of a low tire pressure based on the vehicle recom- limit for any reason, including low temperature effects, or mended cold placard pressure.
  • Page 459 STARTING AND OPERATING 457 For example, your vehicle may have a recommended CAUTION! cold (parked for more than three hours) placard pressure • The TPMS has been optimized for the original of 30 psi (207 kPa). If the ambient temperature is 68°F (20°C) and the measured tire pressure is 27 psi (186 kPa), equipment tires and wheels.
  • Page 460: Base System

    458 STARTING AND OPERATING • Seasonal temperature changes will affect tire pressure, NOTE: • The TPMS is not intended to replace normal tire care and the TPMS will monitor the actual tire pressure in and maintenance or to provide warning of a tire failure the tire.
  • Page 461 STARTING AND OPERATING 459 • Four Tire Pressure Monitoring Sensors received. The vehicle may need to be driven for up to 20 minutes above 15 mph (24 km/h) to receive this • Tire Pressure Monitoring Telltale Light information. Tire Pressure Monitoring Low Pressure Warnings Service TPMS Warnings The Tire Pressure Monitoring Telltale Light will illumi- The Tire Pressure Monitoring Telltale Light will flash on...
  • Page 462 460 STARTING AND OPERATING 2. Installing some form of aftermarket window tinting 3. However, after driving the vehicle for up to 20 min- that affects radio wave signals. utes above 15 mph (24 km/h), the Tire Pressure Moni- toring Telltale Light will flash on and off for 75 seconds 3.
  • Page 463: Premium System - If Equipped

    STARTING AND OPERATING 461 • Various Tire Pressure Monitoring System Messages, need to be driven for up to 20 minutes above 15 mph (24 km/h) in order for the TPMS to receive this which display in the Electronic Vehicle Information information.
  • Page 464 462 STARTING AND OPERATING Should a low tire condition occur on any of the four in place of the pressure value(s) indicating which Tire active road tire(s), you should stop as soon as possible Pressure Monitoring Sensor(s) is not being received. and inflate all tires that are flashing on the graphic If the ignition key is cycled, this sequence will repeat, display to the vehicle’s recommended cold placard pres-...
  • Page 465 STARTING AND OPERATING 463 5. Using wheels/tires not equipped with TPM sensors. 2. If you install the compact spare tire in place of a road tire that has a pressure below the low-pressure warning The EVIC will also display a “SERVICE TPM SYSTEM” limit, upon the next ignition key cycle, a chime will message for a minimum of five seconds and the Tire sound and the Tire Pressure Monitoring Telltale Light...
  • Page 466: General Information

    464 STARTING AND OPERATING SYSTEM” message for a minimum of five seconds and FUEL REQUIREMENTS then display dashes (- -) in place of the pressure values. 1.4L Turbo Engine 5. Once you repair or replace the original road tire and This engine is designed to meet all emis- reinstall it on the vehicle in place of the compact spare tire, sion regulations and provide satisfactory...
  • Page 467: Reformulated Gasoline

    STARTING AND OPERATING 465 Light spark knock at low engine speeds is not harmful to Reformulated Gasoline your engine. However, continued heavy spark knock at Many areas of the country require the use of cleaner high speeds can cause damage and immediate service is burning gasoline referred to as “Reformulated Gasoline.”...
  • Page 468: E-85 Usage In Non-Flex Fuel Vehicles

    466 STARTING AND OPERATING If a Non-FFV vehicle is inadvertently fueled with E-85 CAUTION! fuel, the engine will have some or all of these symptoms: DO NOT use gasoline containing Methanol or gaso- • operate in a lean mode line containing more than 10% Ethanol. Use of these •...
  • Page 469: Mmt In Gasoline

    STARTING AND OPERATING 467 MMT In Gasoline Materials Added To Fuel MMT is a manganese-containing metallic additive that is All gasoline sold in the United States is required to blended into some gasoline to increase octane. Gasoline contain effective detergent additives. Use of additional blended with MMT provides no performance advantage detergents or other additives is not needed under normal beyond gasoline of the same octane number without...
  • Page 470: Carbon Monoxide Warnings

    468 STARTING AND OPERATING Carbon Monoxide Warnings CAUTION! (Continued) • An out-of-tune engine or certain fuel or ignition WARNING! malfunctions can cause the catalytic converter to Carbon monoxide (CO) in exhaust gases is deadly. overheat. If you notice a pungent burning odor or Follow the precautions below to prevent carbon some light smoke, your engine may be out of tune monoxide poisoning:...
  • Page 471: Adding Fuel

    STARTING AND OPERATING 469 1. Press the fuel filler door release switch (located on the WARNING! (Continued) driver’s side door trim). • Guard against carbon monoxide with proper 2. Open the fuel filler door, and remove the fuel filler maintenance. Have the exhaust system inspected cap.
  • Page 472 470 STARTING AND OPERATING CAUTION! WARNING! • Damage to the fuel system or emission control • Never have any smoking materials lit in or near system could result from using an improper fuel the vehicle when the gas cap is removed or the cap (gas cap).
  • Page 473: Vehicle Loading

    STARTING AND OPERATING 471 • Tighten the gas cap about one-quarter turn until you hear one click. This is an indication that the cap is properly tightened. • If the gas cap is not tighten properly, the MIL will come on. Be sure the gas cap is tightened every time the vehicle is refueled.
  • Page 474: Vehicle Certification Label

    472 STARTING AND OPERATING Vehicle Certification Label Gross Vehicle Weight Rating (GVWR) Your vehicle has a Vehicle Certification Label attached to The GVWR is the total allowable weight of your vehicle. the driver’s door B-Pillar. This includes driver, passengers, and cargo. The total load must be limited so that you do not exceed the The label contains the following information: GVWR.
  • Page 475 STARTING AND OPERATING 473 Curb Weight Overloading can cause potential safety hazards and The curb weight of a vehicle is defined as the total weight shorten useful service life. Heavier suspension compo- of the vehicle with all fluids, including vehicle fuel, at full nents do not necessarily increase the vehicle’s GVWR.
  • Page 476: Trailer Towing

    474 STARTING AND OPERATING TRAILER TOWING exceed the GVWR. Refer to “Vehicle Loading/Vehicle In this section, you will find safety tips and information Certification Label” in “Starting and Operating” for on limits to the type of towing you can reasonably do further information.
  • Page 477 STARTING AND OPERATING 475 Gross Axle Weight Rating (GAWR) Frontal Area The GAWR is the maximum capacity of the front and rear The frontal area is the maximum height multiplied by the axles. Distribute the load over the front and rear axles maximum width of the front of a trailer.
  • Page 478: Trailer Hitch Classification

    476 STARTING AND OPERATING Weight-Distributing Hitch tow and should be used to assist you in selecting the A weight-distributing hitch system works by applying correct trailer hitch for your intended towing condition. leverage through spring (load) bars. They are typically Refer to the Trailer Towing Weights (Maximum Trailer used for heavier loads, to distribute trailer tongue weight Weight Ratings) chart for the Maximum GTW towable...
  • Page 479: Trailer Towing Weights (Maximum Trailer Weight Ratings)

    STARTING AND OPERATING 477 Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. 1.4L Turbo Engine Trailer towing is not recommended. Engine/Transmission Frontal Area Max. GTW (Gross Trailer Wt.) Max.
  • Page 480: Trailer And Tongue Weight

    478 STARTING AND OPERATING Trailer And Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the GTW on the tow hitch of your vehicle. Loads balanced over the wheels or heavier in the rear can cause the trailer to sway severely from side-to-side which will cause loss of con- trol of vehicle and trailer.
  • Page 481: Towing Requirements

    STARTING AND OPERATING 479 Consider the following items when computing the Towing Requirements weight on the rear axle of the vehicle: To promote proper break-in of your new vehicle drive- train components, the following guidelines are recom- • The tongue weight of the trailer. mended: •...
  • Page 482 480 STARTING AND OPERATING WARNING! WARNING! (Continued) • Safety chains must always be used between your Improper towing can lead to a collision. Follow these vehicle and trailer. Always connect the chains to guidelines to make your trailer towing as safe as the frame or hook retainers of the vehicle hitch.
  • Page 483 STARTING AND OPERATING 481 − Check for signs of tire wear or visible tire damage WARNING! (Continued) before towing a trailer. Refer to “Tires – General 2. GTW Information” in “Starting and Operating” for the 3. GAWR proper inspection procedure. 4.
  • Page 484 482 STARTING AND OPERATING actuated brakes. When towing a trailer equipped with WARNING! a hydraulic surge actuated brake system, an electronic • Do not connect trailer brakes to your vehicle’s brake controller is not required. hydraulic brake lines. It can overload your brake −...
  • Page 485 STARTING AND OPERATING 483 Towing Requirements – Trailer Lights And Wiring Whenever you pull a trailer, regardless of the trailer size, stop lights and turn signals on the trailer are required for motoring safety. The Trailer Tow Package may include a four-pin and seven-pin wiring harness.
  • Page 486: Towing Tips

    484 STARTING AND OPERATING Towing Tips Before setting out on a trip, practice turning, stopping and backing the trailer in an area away from heavy traffic. Manual Transmission – If Equipped If using a manual transmission vehicle for trailer towing, all starts must be in first gear to avoid excessive clutch slippage.
  • Page 487 STARTING AND OPERATING 485 then change the transmission fluid and filter as specified − When using the speed control, if you experience speed for police, taxi, fleet, or frequent trailer towing. Refer to drops greater than 10 mph (16 km/h), disengage it the Maintenance Schedule for the proper maintenance until you can get back to cruising speed.
  • Page 488: Recreational Towing (Behind Motorhome, Etc.)

    486 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Ground Manual Transmission Automatic Transmission Flat Tow None NOT ALLOWED • Transmission in NEUTRAL • Ignition switch in ACC Front Dolly Tow Rear NOT ALLOWED...
  • Page 489 STARTING AND OPERATING 487 4. Properly secure the front wheels to the dolly, following CAUTION! the dolly manufacturer’s instructions. DO NOT flat tow any vehicle equipped with an 5. Release the parking brake. automatic transmission. Damage to the drivetrain will result. If these vehicles require towing, make CAUTION! sure all drive wheels are off the ground.
  • Page 491: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flashers ....491 TIREFIT Kit Components And Operation . . . 503 If Your Engine Overheats ....491 TIREFIT Usage Precautions .
  • Page 492 490 WHAT TO DO IN EMERGENCIES Towing A Disabled Vehicle ....521 Manual Transmission ....522 Automatic Transmission .
  • Page 493: Hazard Warning Flashers

    WHAT TO DO IN EMERGENCIES 491 HAZARD WARNING FLASHERS IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located in the In any of the following situations, you can reduce the center of the instrument panel. potential for overheating by taking the appropriate action. •...
  • Page 494: Jacking And Tire Changing

    492 WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING CAUTION! WARNING! Driving with a hot cooling system could damage your vehicle. If the temperature gauge reads “H,” • Do not attempt to change a tire on the side of the pull over and stop the vehicle.
  • Page 495: Jack Location/Spare Tire Stowage

    WHAT TO DO IN EMERGENCIES 493 WARNING! (Continued) • The jack is designed to be used as a tool for changing tires only. The jack should not be used to lift the vehicle for service purposes. The vehicle should be jacked on a firm level surface only. Avoid ice or slippery areas.
  • Page 496: Preparations For Jacking

    494 WHAT TO DO IN EMERGENCIES 3. Remove the fastener securing the jack and spare tire. WARNING! • A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the vehicle. Always stow the jack parts and the spare tire in the places provided.
  • Page 497: Jacking And Changing A Tire

    WHAT TO DO IN EMERGENCIES 495 NOTE: Passengers should not remain in the vehicle WARNING! when the vehicle is being jacked. Do not attempt to change a tire on the side of the Jacking And Changing A Tire vehicle close to moving traffic, pull far enough off the road to avoid being hit when operating the jack WARNING! or changing the wheel.
  • Page 498 496 WHAT TO DO IN EMERGENCIES WARNING! (Continued) CAUTION! • Never start or run the engine with the vehicle on a Do not attempt to raise the vehicle by jacking on jack. locations other than those indicated in the Jacking •...
  • Page 499 WHAT TO DO IN EMERGENCIES 497 1. Remove the spare tire, jack, and wheel bolt wrench. 2. If equipped with aluminum wheels where the center cap covers the wheel bolts, use the wheel bolt wrench to pry the center cap off carefully before raising the vehicle. 3.
  • Page 500 498 WHAT TO DO IN EMERGENCIES WARNING! Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. 6. Remove the wheel bolts and tire. 7.
  • Page 501 WHAT TO DO IN EMERGENCIES 499 • Refer to “Compact Spare Tire” and to “Limited-Use Spare” under “Tires—General Information” in “Start- ing and Operating” for additional warnings, cautions, and information about the spare tire, its use, and operation. 8. Install the wheel bolts with the threaded end of the wheel bolt toward the wheel.
  • Page 502: Road Tire Installation

    500 WHAT TO DO IN EMERGENCIES 10. Finish tightening the wheel bolts. Push down on the WARNING! wrench while at the end of the handle for increased • A loose tire or jack thrown forward in a collision leverage. Tighten the wheel bolts in a star pattern until each wheel bolt has been tightened twice.
  • Page 503 WHAT TO DO IN EMERGENCIES 501 3. Align the valve notch in the wheel cover with the valve stem on the wheel. Install the cover by hand, snapping the cover over the two wheel bolts. Do not use a hammer or excessive force to install the cover. 4.
  • Page 504 502 WHAT TO DO IN EMERGENCIES leverage. Tighten the wheel bolts in a star pattern until WARNING! each wheel bolt has been tightened twice. The correct tightness of each wheel bolt is 110 ft/lbs (150 N·m). If in To avoid the risk of forcing the vehicle off the jack, doubt about the correct tightness, have them checked do not tighten the wheel bolts fully until the vehicle with a torque wrench by your authorized dealer or...
  • Page 505: Tirefit Kit - If Equipped

    WHAT TO DO IN EMERGENCIES 503 5. After 25 miles (40 km) check the wheel bolt torque TIREFIT Kit Components And Operation with a torque wrench to ensure that all wheel bolts are properly seated against the wheel. TIREFIT KIT — IF EQUIPPED Small punctures up to 1/4 in (6 mm) in the tire tread can be sealed with TIREFIT.
  • Page 506 504 WHAT TO DO IN EMERGENCIES 5. Mode Select Knob Selecting Sealant Mode Turn the Mode Select Knob (5) to this 6. Sealant Hose (Clear) position to inject the TIREFIT Sealant 7. Air Pump Hose (Black) and to inflate the tire. Use the Sealant Hose (clear hose) (6) when selecting 8.
  • Page 507: Tirefit Usage Precautions

    WHAT TO DO IN EMERGENCIES 505 • For optimum performance, make sure the valve stem TIREFIT Usage Precautions on the wheel is free of debris before connecting the • Replace the TIREFIT Sealant Bottle (1) and Sealant TIREFIT kit. Hose (6) prior to the expiration date (printed on the •...
  • Page 508 506 WHAT TO DO IN EMERGENCIES WARNING! WARNING! (Continued) − If you are unsure of the condition of the tire or the • Do not attempt to seal a tire on the side of the wheel. vehicle closest to traffic. Pull far enough off the •...
  • Page 509: Sealing A Tire With Tirefit

    WHAT TO DO IN EMERGENCIES 507 Sealing A Tire With TIREFIT WARNING! (Continued) (A) Whenever You Stop To Use TIREFIT: • Take care not to allow the contents of TIREFIT to come in contact with hair, eyes, or clothing. TIRE- 1.
  • Page 510 508 WHAT TO DO IN EMERGENCIES (B) Setting Up To Use TIREFIT: (C) Injecting TIREFIT Sealant Into The Deflated Tire: • Always start the engine before turning ON the TIRE- 1. Turn the Mode Select Knob (5) to the Sealant Mode position.
  • Page 511 WHAT TO DO IN EMERGENCIES 509 Select Knob (5) is in the Sealant Mode position and not the Pressure Gauge (3) can read as high as 70 psi (5 Bar). Air Mode. Press the Power Button (4) to turn On the The Pressure Gauge (3) will decrease quickly from ap- TIREFIT kit.
  • Page 512 510 WHAT TO DO IN EMERGENCIES If the tire inflates to the recommended pressure or is at CAUTION! (Continued) least 26 psi (1.8 Bar) pressure within 15 minutes: • Failure to reinstall the cap on the fitting at the end 1.
  • Page 513 WHAT TO DO IN EMERGENCIES 511 3. Uncoil the Air Pump Hose (7) (black in color) and WARNING! screw the fitting at the end of hose (7) onto the valve stem. TIREFIT is not a permanent flat tire repair. Have the tire inspected and repaired or replaced after using 4.
  • Page 514 512 WHAT TO DO IN EMERGENCIES 2. Disconnect the TIREFIT kit from the valve stem, (F) Sealant Bottle And Hose Replacement: reinstall the cap on the valve stem and unplug from 12 1. Uncoil the Sealant Hose (6) (clear in color). Volt outlet.
  • Page 515: Jump-Starting Procedures

    WHAT TO DO IN EMERGENCIES 513 6. Verify that the cap is installed on the fitting at the end CAUTION! of the Sealant Hose (6) and return the hose to its storage area (located on the bottom of the air pump). Do not use a portable battery booster pack or any other booster source with a system voltage greater 7.
  • Page 516: Preparations For Jump-Start

    514 WHAT TO DO IN EMERGENCIES Preparations For Jump-Start WARNING! The battery in your vehicle is located in the front of the • Take care to avoid the radiator cooling fan when- engine compartment, behind the left headlight assembly. ever the hood is raised. It can start anytime the NOTE: The positive battery post is covered with a ignition switch is on.
  • Page 517: Jump-Starting Procedure

    WHAT TO DO IN EMERGENCIES 515 3. If using another vehicle to jump-start the battery, park CAUTION! the vehicle within the jumper cables reach, set the parking brake and make sure the ignition is OFF. Failure to follow these procedures could result in damage to the charging system of the booster vehicle WARNING! or the discharged vehicle.
  • Page 518 516 WHAT TO DO IN EMERGENCIES 8. Disconnect the opposite end of the positive (+) jumper WARNING! cable from the positive (+) post of the booster battery. Do not connect the cable to the negative post (-) of the 9. Disconnect the positive (+) end of the jumper cable discharged battery.
  • Page 519: Freeing A Stuck Vehicle

    WHAT TO DO IN EMERGENCIES 517 FREEING A STUCK VEHICLE CAUTION! If your manual transmission vehicle becomes stuck in mud, sand, or snow, it can often be moved by a rocking Racing the engine or spinning the wheels may lead to motion.
  • Page 520 518 WHAT TO DO IN EMERGENCIES CAUTION! WARNING! • When “rocking” a stuck vehicle by moving be- Fast spinning tires can be dangerous. Forces gener- tween DRIVE (automatic transmission) or 1st Gear ated by excessive wheel speeds may cause damage, or (manual transmission) and REVERSE, do not spin even failure, of the axle and tires.
  • Page 521: Shift Lever Override

    WHAT TO DO IN EMERGENCIES 519 SHIFT LEVER OVERRIDE If a malfunction occurs and the shift lever cannot be moved out of the PARK position, you can use the following procedure to temporarily move the shift lever: 1. Turn the engine OFF. 2.
  • Page 522 520 WHAT TO DO IN EMERGENCIES 5. Insert a small screwdriver or similar tool down into the access slot at the front of the shift lever assembly, and push and hold the white override release lever down. Shift Lever 7. The vehicle may then be started in NEUTRAL. 8.
  • Page 523: Towing A Disabled Vehicle

    WHAT TO DO IN EMERGENCIES 521 TOWING A DISABLED VEHICLE NOTE: This section describes procedures for towing a disabled vehicle using a commercial wrecker service. AUTOMATIC MANUAL Towing Condition Wheels OFF The Ground TRANSMISSION TRANSMISSION Flat Tow NONE NOT ALLOWED Trans in NEUTRAL Rear NOT ALLOWED...
  • Page 524: Manual Transmission

    522 WHAT TO DO IN EMERGENCIES All Transmissions CAUTION! If you must use the accessories (wipers, defroster, etc.) DO NOT flat tow any vehicle equipped with an while being towed, the key must be in the ON/RUN automatic transmission. Damage to the drivetrain position, not the ACC position.
  • Page 525 MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 1.4L Turbo ..525 Maintenance Procedures ....531 Engine Compartment — 2.0L ... . . 526 Engine Oil .
  • Page 526 524 MAINTAINING YOUR VEHICLE Exhaust System ..... 543 Replacement Bulbs ....565 Cooling System .
  • Page 527: Engine Compartment - 1.4L Turbo

    MAINTAINING YOUR VEHICLE 525 ENGINE COMPARTMENT — 1.4L TURBO 1 — Engine Coolant Reservoir 5 — Power Distribution Center 2 — Engine Oil Level Indicator 6 — Washer Fluid Reservoir 3 — Engine Oil Fill 7 — Battery 4 — Brake Fluid Reservoir 8 —...
  • Page 528: Engine Compartment - 2.0L

    526 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 2.0L 1 — Engine Coolant Reservoir 5 — Washer Fluid Reservoir 2 — Engine Oil Fill 6 — Battery 3 — Brake Fluid Reservoir 7 — Engine Oil Level Indicator 4 — Integrated Power Module (Fuses) 8 —...
  • Page 529: Engine Compartment - 2.4L

    MAINTAINING YOUR VEHICLE 527 ENGINE COMPARTMENT — 2.4L 1 — Engine Coolant Reservoir 5 — Washer Fluid Reservoir 2 — Engine Oil Fill 6 — Battery 3 — Brake Fluid Reservoir 7 — Engine Oil Level Indicator 4 — Integrated Power Module (Fuses) 8 —...
  • Page 530: Onboard Diagnostic System - Obd Ii

    528 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic further damage to the emission control system.
  • Page 531: Emissions Inspection And Maintenance Programs

    MAINTAINING YOUR VEHICLE 529 persists, the message will appear the next time the Normally, the OBD II system will be ready. The OBD II vehicle is started. This might indicate a damaged cap. If system may not be ready if your vehicle was recently the problem is detected twice in a row, the system will serviced, recently had a dead battery or a battery replace- turn on the MIL.
  • Page 532: Replacement Parts

    530 MAINTAINING YOUR VEHICLE 4. Approximately 15 seconds later, one of two things will system to update. A recheck with the above test routine happen: may then indicate that the system is now ready. a. The MIL will flash for about 10 seconds and then Regardless of whether your vehicle’s OBD II system is return to being fully illuminated until you turn OFF ready or not, if the MIL is illuminated during normal...
  • Page 533: Dealer Service

    MAINTAINING YOUR VEHICLE 531 DEALER SERVICE MAINTENANCE PROCEDURES Your authorized dealer has the qualified service person- The pages that follow contain the required maintenance nel, special tools, and equipment to perform all service services determined by the engineers who designed your operations in an expert manner.
  • Page 534: Engine Oil

    532 MAINTAINING YOUR VEHICLE fully warmed engine is shut off. Do not check oil level CAUTION! (Continued) before starting the engine after it has sat overnight. • Your vehicle has been built with improved fluids Checking engine oil level when the engine is cold will that protect the performance and durability of give you an incorrect reading.
  • Page 535 MAINTAINING YOUR VEHICLE 533 Engine Oil Selection – 1.4L Turbo Engine CAUTION! For best performance and maximum protection for all engines under all types of operating conditions, the Do not overfill the engine. Overfilling the engine manufacturer recommends engine oils that are API Cer- will cause oil aeration, which can lead to loss of oil tified and meet the requirements of Chrysler Material pressure and an increase in oil temperature.
  • Page 536 534 MAINTAINING YOUR VEHICLE American Petroleum Institute (API) Engine Oil Engine Oil Viscosity (SAE Grade) – 1.4L Turbo Identification Symbol Engine This symbol means that the oil has SAE 5W-40 synthetic engine oil is recommended for all been certified by the American operating temperatures.
  • Page 537: Engine Oil Filter

    MAINTAINING YOUR VEHICLE 535 If 0W-20 engine oil is not available, SAE 5W-20 API station, or governmental agency for advice on how and Certified may be used as a temporary suitable alterna- where used oil and oil filters can be safely discarded in tive.
  • Page 538: Maintenance-Free Battery

    536 MAINTAINING YOUR VEHICLE Maintenance-Free Battery WARNING! Your vehicle is equipped with a maintenance-free battery. You will never have to add water, nor is periodic main- The air cleaner can provide a measure of protection tenance required. in the case of engine backfire. Do not remove the air cleaner unless such removal is necessary for repair or WARNING! maintenance.
  • Page 539 MAINTAINING YOUR VEHICLE 537 WARNING! (Continued) CAUTION! • Battery gas is flammable and explosive. Keep • It is essential when replacing the cables on the flame or sparks away from the battery. Do not use battery that the positive cable is attached to the a booster battery or any other booster source with positive post and the negative cable is attached to an output greater than 12 Volts.
  • Page 540: Air Conditioner Maintenance

    538 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance WARNING! For best possible performance, your air conditioner • Use only refrigerants and compressor lubricants should be checked and serviced by an authorized dealer at the start of each warm season. This service should approved by the manufacturer for your air condi- include cleaning of the condenser fins and a performance tioning system.
  • Page 541 MAINTAINING YOUR VEHICLE 539 Refrigerant Recovery And Recycling The A/C air filter is located in the fresh air inlet on the R-134a air conditioning refrigerant is a hydrofluoro- lower right of center console. Perform the following carbon (HFC) that is endorsed by the Environmental procedure to replace the filter: Protection Agency and is an ozone-saving product.
  • Page 542 540 MAINTAINING YOUR VEHICLE 2. Disengage the retaining tab that secures the filter cover to the HVAC housing, and remove the cover. 4. Install the A/C air filter with the air filter position indicators pointing in the same direction as removal. When installing the filter cover, make sure the retaining 3.
  • Page 543: Body Lubrication

    MAINTAINING YOUR VEHICLE 541 MOPAR Spray White Lube or equivalent to assure CAUTION! quiet, easy operation and to protect against rust and wear. Prior to the application of any lubricant, the parts The A/C air filter is identified with an arrow to concerned should be wiped clean to remove dust and indicate airflow direction through the filter.
  • Page 544: Windshield Wiper Blades

    542 MAINTAINING YOUR VEHICLE Windshield Wiper Blades marks, water lines or wet spots. If any of these conditions Clean the rubber edges of the wiper blades and the are present, clean the wiper blades or replace as windshield periodically with a sponge or soft cloth and a necessary.
  • Page 545: Exhaust System

    MAINTAINING YOUR VEHICLE 543 into the passenger compartment. In addition, inspect the WARNING! exhaust system each time the vehicle is raised for lubri- cation or oil change. Replace as required. Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care WARNING! must be exercised when filling or working around the washer solution.
  • Page 546 544 MAINTAINING YOUR VEHICLE Under normal operating conditions, the catalytic con- CAUTION! verter will not require maintenance. However, it is im- • The catalytic converter requires the use of un- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst leaded fuel only.
  • Page 547: Cooling System

    MAINTAINING YOUR VEHICLE 545 To minimize the possibility of catalytic converter dam- Cooling System age: WARNING! • Do not shut off the engine or interrupt the ignition, • When working near the radiator cooling fan, dis- when the transmission is in gear and the vehicle is in motion.
  • Page 548 546 MAINTAINING YOUR VEHICLE Coolant Checks Selection Of Coolant Check engine coolant (antifreeze) protection every Refer to “Fluids, Lubricants, and Genuine Parts” in 12 months (before the onset of freezing weather, where “Maintaining Your Vehicle” for further information. applicable). If the engine coolant (antifreeze) is dirty or CAUTION! rusty in appearance, the system should be drained, flushed and refilled with fresh engine coolant (anti-...
  • Page 549 MAINTAINING YOUR VEHICLE 547 Please review these recommendations for using Organic CAUTION! (Continued) Additive Technology (OAT) engine coolant (antifreeze). • Do not use water alone or alcohol-based engine When adding engine coolant (antifreeze): coolant (antifreeze) products. Do not use addi- •...
  • Page 550 548 MAINTAINING YOUR VEHICLE Please note that it is the owner’s responsibility to main- WARNING! tain the proper level of protection against freezing ac- • The warning words “DO NOT OPEN HOT” on cording to the temperatures occurring in the area where the vehicle is operated.
  • Page 551 MAINTAINING YOUR VEHICLE 549 rules for your community. To prevent ingestion by ani- Points To Remember mals or children do not store ethylene glycol-based NOTE: When the vehicle is stopped after a few miles/ engine coolant (antifreeze) in open containers or allow it kilometers of operation, you may observe vapor coming to remain in puddles on the ground.
  • Page 552: Brake System

    550 MAINTAINING YOUR VEHICLE • If frequent engine coolant (antifreeze) additions are result in unsatisfactory engine coolant (antifreeze) required, the cooling system should be pressure tested performance, poor gas mileage, and increased for leaks. emissions. • Maintain engine coolant (antifreeze) concentration at Brake System 50% OAT engine coolant (antifreeze) (minimum) and In order to assure brake system performance, all brake...
  • Page 553 MAINTAINING YOUR VEHICLE 551 Brake Master Cylinder brake fluid reservoir is low and the brake system does The fluid level in the master cylinder should be checked not indicate any leaks or other problems, it may be a when performing under hood services, or immediately if result of a leak in the hydraulic clutch release system.
  • Page 554 552 MAINTAINING YOUR VEHICLE WARNING! (Continued) WARNING! (Continued) • To avoid contamination from foreign matter or • Do not allow petroleum based fluid to contami- moisture, use only new brake fluid or fluid that nate the brake fluid. Brake seal components could has been in a tightly closed container.
  • Page 555: Automatic Transmission - If Equipped

    MAINTAINING YOUR VEHICLE 553 Automatic Transmission – If Equipped CAUTION! The automatic transmission and differential assembly are contained within a single housing. Using a transmission fluid other than the manufac- turer’s recommended fluid may cause deterioration The fluid level in the automatic transmission should be in transmission shift quality.
  • Page 556: Manual Transmission - If Equipped

    554 MAINTAINING YOUR VEHICLE “Maintenance Schedule” for the proper maintenance CAUTION! intervals. Also, if the fluid becomes contaminated (with water, etc.) or the transmission is repaired, the fluid Do not use chemical flushes in your transmission as should be changed. the chemicals can damage your transmission compo- nents.
  • Page 557: Appearance Care And Protection From Corrosion

    MAINTAINING YOUR VEHICLE 555 Frequency Of Fluid Change hot or cold weather and other extreme conditions will Under normal operating conditions, the fluid installed at have an adverse effect on paint, metal trim, and under- the factory will give satisfactory lubrication for the life of body protection.
  • Page 558 556 MAINTAINING YOUR VEHICLE Washing CAUTION! • Wash your vehicle regularly. Always wash your ve- • Do not use abrasive or strong cleaning materials hicle in the shade using MOPAR Car Wash or a mild such as steel wool or scouring powder, which will car wash soap, and rinse the panels completely with scratch metal and painted surfaces.
  • Page 559 MAINTAINING YOUR VEHICLE 557 • If you detect any stone chips or scratches in the paint, Wheel And Wheel Trim Care touch them up immediately. The cost of such repairs is • All wheels and wheel trim, especially aluminum and considered the responsibility of the owner.
  • Page 560 558 MAINTAINING YOUR VEHICLE Stain Repel Fabric Cleaning Procedure – If Interior Care Equipped Use MOPAR Total Clean or equivalent to clean fabric Stain Repel seats may be cleaned in the following man- upholstery and carpeting. ner: Use MOPAR Total Clean or equivalent to clean vinyl •...
  • Page 561 MAINTAINING YOUR VEHICLE 559 Glass Surfaces WARNING! All glass surfaces should be cleaned on a regular basis with MOPAR Glass Cleaner or any commercial Do not use volatile solvents for cleaning purposes. household-type glass cleaner. Never use an abrasive type Many are potentially flammable, and if used in cleaner.
  • Page 562: Fuses

    560 MAINTAINING YOUR VEHICLE Instrument Panel Bezels Seat Belt Maintenance Do not bleach, dye or clean the seat belts with chemical CAUTION! solvents or abrasive cleaners. This will weaken the fabric. Sun damage can also weaken the fabric. When installing hanging air fresheners in your ve- If the seat belts need cleaning, use a mild soap solution or hicle, read the installation instructions carefully.
  • Page 563 MAINTAINING YOUR VEHICLE 561 Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse — 10 Amp PAM, Rear Camera, — 10 Amp UGDO, EOM LBSS, RBSS, Compass — 15 Amp — 20 Amp Sunroof Blue Yellow — 10 Amp HVAC, Humidity Sen- —...
  • Page 564: Underhood Fuses

    562 MAINTAINING YOUR VEHICLE Underhood Fuses Cavity Maxi Mini Description The Integrated Power Module is located on the right side Fuse Fuse of the engine compartment, behind the battery. 70 Amp — Direct Battery Feed #1 To BCM 60 Amp —...
  • Page 565 MAINTAINING YOUR VEHICLE 563 Cavity Maxi Mini Description Cavity Maxi Mini Description Fuse Fuse Fuse Fuse — 10 Amp — 30 Amp Green — 20 Amp ECM, EPS, Backup — 20 Amp Fuel Pump Yellow Lamp Switch Yellow — 15 Amp DDCT Feed #2 —...
  • Page 566: Vehicle Storage

    564 MAINTAINING YOUR VEHICLE VEHICLE STORAGE Cavity Maxi Mini Description If you will not be using your vehicle for more than Fuse Fuse 21 days, you may want to take steps to preserve your 40 Amp — HVAC Blower Motor battery.
  • Page 567: Replacement Bulbs

    MAINTAINING YOUR VEHICLE 565 REPLACEMENT BULBS BULB REPLACEMENT Headlamps Interior Lights Bulb Type High Intensity Discharge Headlamps (HID) Dome Lamp......W5W The headlamps are a type of high voltage discharge tube.
  • Page 568: Backup Lamps

    566 MAINTAINING YOUR VEHICLE NOTE: On vehicles equipped with HID headlamps, when the headlamps are turned on, there is a blue hue to the lights. This diminishes and becomes more white after approximately 10 seconds, as the system charges. Backup Lamps 1.
  • Page 569 MAINTAINING YOUR VEHICLE 567 3. Twist the bulb socket one quarter turn counter clock- 4. Replace bulb. wise to remove. 5. Twist the bulb socket one quarter turn clockwise to install. 6. Install trim cover.
  • Page 570: License Lamp

    568 MAINTAINING YOUR VEHICLE License Lamp 1. Remove the screws securing the lamp to the rear fascia. 2. Remove the bulb and socket assembly. 3. Disconnect the bulb from the socket assembly and install the replacement bulb. 1 — License Lamp Bulb 2 —...
  • Page 571: Fluid Capacities

    MAINTAINING YOUR VEHICLE 569 FLUID CAPACITIES U.S. Metric Fuel (1.4L Aero Model Only) 13.2 Gallons 50 Liters Fuel (All Others) 15.8 Gallons 59.8 Liters Engine Oil With Filter 1.4L Turbo Engine (SAE 5W-40 Synthetic, API Certified) 4 Quarts 3.8 Liters 2.0L and 2.4L Engine (SAE 0W-20, API Certified) 5 Quarts 4.7 Liters...
  • Page 572: Fluids, Lubricants, And Genuine Parts

    570 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant MOPAR Antifreeze/Coolant 10 Year/150,000 Mile Formula OAT (Or- ganic Additive Technology) or equivalent meeting the requirements of Chrysler Material Standard MS-12106. Engine Oil – 1.4L Turbo Engine Use SAE 5W-40 API Certified Synthetic Engine Oil, meeting the require- ments of Chrysler Material Standard MS-10896.
  • Page 573: Chassis

    MAINTAINING YOUR VEHICLE 571 Component Fluid, Lubricant, or Genuine Part Fuel Selection – 1.4L Turbo Engine 87 Octane Acceptable – 91 Octane Recommended Fuel Selection – 2.0L and 2.4L Engine 87 Octane Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission (1.4L Turbo MOPAR C635 DDCT/MTX Transmission Fluid Engine) –...
  • Page 575 MAINTENANCE SCHEDULES CONTENTS Maintenance Schedule ....574 Required Maintenance ....574 Maintenance Chart .
  • Page 576 574 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE Once A Month Or Before A Long Trip: Your vehicle is equipped with an automatic oil change • Check engine oil level. indicator system. The oil change indicator system will • Check windshield washer fluid level. remind you that it is time to take your vehicle in for scheduled maintenance.
  • Page 577 MAINTENANCE SCHEDULES 575 At Every Oil Change Interval As Indicated By Oil Change Indicator System: • Change engine oil and filter. • Rotate the tires. Rotate at the first sign of irregular wear, even if it occurs before the oil indicator system turns on.
  • Page 578: Maintenance Chart

    576 MAINTENANCE SCHEDULES Maintenance Chart Mileage Or Time Passed (Which- ever Comes First) Or Years: Or Kilometers: Additional Inspections Inspect CV joint boots. Inspect front suspension, tie rod ends and replace as necessary. Inspect brake linings, parking brake function. Additional Maintenance Replace the cabin/air conditioning filter.
  • Page 579 MAINTENANCE SCHEDULES 577 Mileage Or Time Passed (Which- ever Comes First) Or Years: Or Kilometers: Flush and replace the engine cool- ant at 10 years or 150,000 miles (240,000 km) whichever comes first. Change the transmission fluid (manual or automatic 1.4L turbo en- gine only) if using your vehicle for any of the following: trailer towing, heavy loading, taxi, police, delivery...
  • Page 580 578 MAINTENANCE SCHEDULES Mileage Or Time Passed (Which- ever Comes First) Or Years: Or Kilometers: Change the automatic transmission fluid and filter (2.0L, 2.4L engines only) if you frequently drive: on rough or unpaved roads, on moun- tain roads, on short trips, in heavy city traffic during hot weather, or while towing a trailer, or if you use the vehicle for police, taxi, or in a...
  • Page 581 MAINTENANCE SCHEDULES 579 WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
  • Page 583: If You Need Consumer Assistance

    IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Customer Assistance For The Hearing Or Vehicle......583 Speech Impaired (TDD/TTY) .
  • Page 584 582 IF YOU NEED CONSUMER ASSISTANCE Department Of Transportation Uniform Tire Traction Grades ..... 589 Quality Grades ......588 Temperature Grades .
  • Page 585: Suggestions For Obtaining Service For Your

    IF YOU NEED CONSUMER ASSISTANCE 583 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...
  • Page 586: Chrysler Group Llc Customer Center

    584 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized Chrysler Group LLC Customer Center dealer’s service manager first. Most matters can be re- P.O. Box 21–8004 solved with this process. Auburn Hills, MI 48321–8004 Phone: (800) 423–6343 •...
  • Page 587: Customer Assistance For The Hearing Or

    IF YOU NEED CONSUMER ASSISTANCE 585 Customer Assistance For The Hearing Or Speech the manufacturer’s service contracts. If you purchased a Impaired (TDD/TTY) manufacturer’s service contract, you will receive Plan To assist customers who have hearing difficulties, the Provisions and an Owner Identification Card in the mail manufacturer has installed special TDD (Telecommuni- within three weeks of the vehicle delivery date.
  • Page 588: Warranty Information

    586 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment WARRANTY INFORMATION when you purchased the vehicle. An authorized dealer See the Warranty Information Booklet, located on the has also made a major investment in facilities, tools, and DVD, for the terms and provisions of Chrysler Group training to assure that you are absolutely delighted with LLC warranties applicable to this vehicle and market.
  • Page 589: In Canada

    IF YOU NEED CONSUMER ASSISTANCE 587 If NHTSA receives similar complaints, it may open an Canada, Motor Vehicle Defect Investigations and Recalls at investigation, and if it finds that a safety defect exists in 1-800-333-0510 or go to http://www.tc.gc.ca/roadsafety/ a group of vehicles, it may order a recall and remedy PUBLICATION ORDER FORMS campaign.
  • Page 590 588 IF YOU NEED CONSUMER ASSISTANCE • Diagnostic Procedure Manuals Call toll free at: • 1–800–890–4038 (U.S.) Diagnostic Procedure Manuals are filled with dia- grams, charts and detailed illustrations. These practi- • 1–800–387–1143 (Canada) cal manuals make it easy for students and technicians to find and fix problems on computer-controlled ve- hicle systems and features.
  • Page 591 IF YOU NEED CONSUMER ASSISTANCE 589 Treadwear WARNING! The Treadwear grade is a comparative rating, based on the wear rate of the tire when tested under controlled The traction grade assigned to this tire is based on conditions on a specified government test course. For straight-ahead braking traction tests, and does not example, a tire graded 150 would wear one and one-half include acceleration, cornering, hydroplaning, or...
  • Page 592 590 IF YOU NEED CONSUMER ASSISTANCE Vehicle Safety Standard No. 109. Grades B and A repre- sent higher levels of performance on the laboratory test wheel, than the minimum required by law. WARNING! The temperature grade for this tire is established for a tire that is properly inflated and not overloaded.
  • Page 593 INDEX...
  • Page 594 592 INDEX ABS (Anti-Lock Brake System) ....423 Alarm (Security Alarm) ....20 Adding Engine Coolant (Antifreeze) .
  • Page 595 INDEX 593 Automatic Door Locks ..... 33 Brake Control System, Electronic ... . . 423 Automatic Headlights .
  • Page 596 594 INDEX Caps, Filler Cleaning Fuel ......469 Wheels ......557 Oil (Engine) .
  • Page 597 INDEX 595 Cooling System ......545 Defroster, Rear Window ....278 Adding Coolant (Antifreeze) .
  • Page 598 596 INDEX Electric Rear Window Defrost ....278 Overheating ......491 Electric Remote Mirrors .
  • Page 599 INDEX 597 Enhanced Accident Response Feature ..77 Turn Signal ....97,219,289 Entry System, Illuminated .
  • Page 600 598 INDEX Ethanol ......465 Gasoline (Fuel) ......569 Filler Cap (Gas Cap) .
  • Page 601 INDEX 599 Hazard Heater, Engine Block ..... 392 Driving Through Flowing, Rising, or Shallow High Beam/Low Beam Select (Dimmer) Switch . . 220 Standing Water .
  • Page 602 600 INDEX Instrument Panel Lens Cleaning ... . . 560 Knee Bolster ......59 Interior Appearance Care .
  • Page 603 INDEX 601 Bulb Replacement ....565 Lights On Reminder ....217 Daytime Running .
  • Page 604 602 INDEX Loading Vehicle ..... . 471,473 Manual Transmission ....393,554 Capacities .
  • Page 605 INDEX 603 Mode Change Interval ..... 533 Fuel Saver ......325 Checking .
  • Page 606 604 INDEX Parking Brake ......420 Radial Ply Tires ......446 Passing Light .
  • Page 607 INDEX 605 Remote Sound System (Radio) Controls ..365 Safety Tips ......93 Remote Starting System .
  • Page 608 606 INDEX Heated ......205 Shoulder Belt Upper Anchorage ....53 Rear Folding .
  • Page 609 INDEX 607 Starting Procedures ..... . 387 Tachometer ......288 Steering Telescoping Steering Column .
  • Page 610 608 INDEX Changing ..... . . 492,495 Spinning ......449 Compact Spare .
  • Page 611 INDEX 609 Trailer Towing Guide ..... 477 Trunk Lid (Deck Lid) ....44,45 Trailer Weight .
  • Page 612 610 INDEX Vehicle Theft Alarm (Security Alarm) ..20 Wheel and Wheel Trim ....557 Voice Recognition System (VR) .
  • Page 613 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
  • Page 614 Chrysler Group LLC 13PFD41-126-AC Printed in U.S.A. 3rd Edition...

Table of Contents

Save PDF
