Liberty
WARNING: If the information in these in-
plosion may result causing property damage,
personal injury or loss of life.
ble vapors and liquids in the vicinity of this or
any other appliance.
— WHAT TO DO IF YOU SMELL GAS
use any phone in your building.
a neighbor's phone. Follow the gas sup-
plier's instructions.
— Installation and service must be performed
gas supplier.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
-
-
LOG SET FOR UNVENTED
GAS LOG HEATER
VENTED DECORATIVE APPLIANCE
MODELS
ALX-24LF-1
ALX-30LF-1
Installer: Leave this manual with the appli-
ance.
Consumer: Retain this manual for future refer-
ence.
Log sets comply with ANSI Z21.11.2 Unvented
Heaters and also comply with ANSI Z21.60
Decorative Vented Appliances for Solid Fuel
Burning Fireplaces. State or local codes may only
Check your state or local codes.
WARNING: If not installed, operated and main-
tained in accordance with the manufacturer's
instructions, this product could expose you to sub-
stances in fuel or from fuel combustion which can
cause death or serious illness.
OR
Page 1
Advertisement
Table of Contents
Related Manuals for American Hearth ALX-24LF-1
Summary of Contents for American Hearth ALX-24LF-1
- Page 1 AND OWNER'S MANUAL LOG SET FOR UNVENTED Liberty GAS LOG HEATER VENTED DECORATIVE APPLIANCE MODELS ALX-24LF-1 ALX-30LF-1 WARNING: If the information in these in- Installer: Leave this manual with the appli- ance. plosion may result causing property damage, Consumer: Retain this manual for future refer- personal injury or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Section Page Important Installation Guidelines ................ 3 General Information .................... 3 Requirements for Canada ..................4 Parts List & Parts View ..................5 Log Placement ....................6 - 13 Placement of Glowing Embers ALX-(24,30)CF-1 ........14 - 16 Placement of Glowing Embers ................16 Master Parts Distributor List ................ -
Page 3: Important Installation Guidelines
IMPORTANT INSTALLATION GUIDELINES Proper Log Placement Log placement is critical to proper burner performance. Logs must log and create a sooting situation. be correctly positioned onto the burner. The photos in this manual WARNING: show the proper pinned position for logs on this set. Owners need to be shown proper log placement and instructed not to move the logs. -
Page 4: Requirements For Canada
REQUIREMENTS FOR CANADA This unit cannot be installed in an UNVENTED application, this unit can only be installed as a VENTED application with these WITH GLASS DOORS CLOSED requirements. IMPORTANT SAFETY INFORMATION or near the appliance. This unit complies with ANSI Z21.60and CGA 2.26 Decorative eration. -
Page 5: Parts List & Parts View
Attention: When ordering parts, it is very important that part number and description of part coincide. ALX-(24,30)LF INDEX INDEX TOP VIEW FRONT VIEW Part No. Index No. Description ALX-24LF-1 ALX30LF-1 R10453 R10468 Front Center Chunk R10451 R10466 Left Crossover Log R10448... -
Page 6: Log Placement
LOG PLACEMENT Before you begin: Do not, handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs The positioning of the logs is critical to the safe and clean operation of this heater. Sooting and other problems may result if the logs are Refer to Figure 1 for the following warning. - Page 7 LOG PLACEMENT Place Front Center Chunk (A) on Front Center Pin on burner base. FRONT VIEW TOP VIEW R10574-2-0510 Page 7...
- Page 8 LOG PLACEMENT Place Left Crossover Log (B) on Left Pin on Rear Log Shelf and Center Pin and Front Right Pin on burner base. FRONT VIEW TOP VIEW Page 8 R10574-2-0510...
- Page 9 LOG PLACEMENT Place Right Log (C) on Right Pin on Rear Log Shelf and Right Pin on burner base. FRONT VIEW TOP VIEW R10574-2-0510 Page 9...
- Page 10 LOG PLACEMENT Place Left Bottom Log (D) onto top pin on Left Crossover Log (B). FRONT VIEW TOP VIEW Page 10 R10574-2-0510...
- Page 11 LOG PLACEMENT Place Front Log (E) on Left Front Pin on burner base and Lower Pin on Left Crossover Log (B). Front Log will rest on Front Center Chunk (A). FRONT VIEW TOP VIEW R10574-2-0510 Page 11...
- Page 12 LOG PLACEMENT Place Right Top Log on the Pin on the Right Log (C). Right Top Log will rest on Rear Log Shelf Ledge. FRONT VIEW TOP VIEW Page 12 R10574-2-0510...
-
Page 13: Log Placement
LOG PLACEMENT Place Left Top Log (G) onto Pin on Front Log (E) and rest on Bottom Left Log (D). The curve on the bottom of the Left Top Log FRONT VIEW TOP VIEW R10574-2-0510 Page 13... -
Page 14: Placement Of Glowing Embers Alx-(24,30)Cf-1
PLACEMENT OF GLOWING EMBERS ALX-(24,30)LF-1 Page 14 R10574-2-0510... - Page 15 PLACEMENT OF GLOWING EMBERS ALX-(24,30)LF-1 R10574-2-0510 Page 15...
-
Page 16: Placement Of Glowing Embers
Place just enough embers on the burner to obtain the glow and a removed prior to reapplication. Replacement glowing embers Part Number Do not place glowing embers over large ports in rear portion of burner. ALX-24LF-1 15970 Glowing embers should not be placed in the area of the pilot ALX-30LF-1 15970 assembly. -
Page 17: Master Parts Distributor List
MASTER PARTS DISTRIBUTOR LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort.com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit. -
Page 18: Service Notes
SERVICE NOTES Page 18 R10574-2-0510... - Page 19 SERVICE NOTES R10574-2-0510 Page 19...
- Page 20 A Registered Trademark of Empire Comfort Systems Inc. 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. www.americanhearth.com Page 20 R10574-2-0510...
