American Hearth VLS-16MV-CR1-2 Installation Instructions And Owner's Manual

Unvented gas log heater or vented decorative appliance

Advertisement

VLS-18, 24, 30 Shown
This appliance may be installed in an aftermarket,
f i r e - p a r t s . c o m
permanently located, manufactured (mobile)
home, where not prohibited by local codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This appliance
is not convertible for use with other gases.
WARNINGS
If the information in this manual is not followed
exactly, a fire or explosion may result causing prop-
erty damage, personal injury or loss of life.
– Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use
any phone in your building.
Immediately call your gas supplier from
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the
fire department.
– Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
12406-2-0703
INSTALLATION INSTRUCTIONS
OWNER'S MANUAL
AND
UNVENTED GAS LOG HEATER OR
VENTED DECORATIVE APPLIANCE
MODELS
VLS-16MV-CR1-2
VLS-24MV-CR1-2
VLS-16MM-CR1-2
VLS-24MM-CR1-2
EFFECTIVE DATE
JULY, 2003
This is an unvented gas-fired heater. It uses air (oxy-
gen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be
provided. Refer to page 7.
WARNING: If not installed, operated and maintained
in accordance with the manufacturer's instructions,
this product could expose you to substances in fuel
or from fuel combustion which can cause death or
serious illness.
WATER VAPOR: A BY-PRODUCT OF UNVENT-
ED ROOM HEATERS
Water vapor is a by-product of gas combustion. An
unvented room heater produces approximately one
(1) ounce (30ml) of water for every 1,000 BTU's
(.3KW's) of gas input per hour. Refer to page 6.
VLS-18MV-CR1-2
VLS-30MV-CR1-2
VLS-18MM-CR1-2
VLS-30MM-CR1-2
Page 1

Advertisement
