SARATOGA
wArNINg: If the information in these in-
structions are not followed exactly, a fire or ex-
plosion may result causing property damage,
personal injury or loss of life.
— Do not store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of this or
any other appliance.
— wHAT TO DO If YOu SMeLL gAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from
a neighbor's phone. follow the gas sup-
plier's instructions.
•
If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
INSTALLATION INSTrucTIONS
AND OwNer'S MANuAL
GAS-FIRED
LOg SeT fOr uNVeNTeD
gAS LOg HeATer
VeNTeD DecOrATIVe APPLIANce
MODeLS
ALS-18Sg-1
ALS-24Sg-1
ALS-30Sg-1
Installer: Leave this manual with the appli-
ance.
consumer: retain this manual for future refer-
ence.
Log sets comply with ANSI Z21.11.2 unvented
Heaters and also comply with ANSI Z21.60
Decorative Vented Appliances for Solid fuel
Burning fireplaces. State or local codes may only
allow operation of log sets in a vented configuration.
check your state or local codes.
wArNINg: If not installed, operated and main-
tained in accordance with the manufacturer's
instructions, this product could expose you to sub-
stances in fuel or from fuel combustion which can
cause death or serious illness.
Or
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SARATOGA ALS-24SG-1 and is the answer not in the manual?

Questions and answers

Related Manuals for American Hearth SARATOGA ALS-24SG-1

Summary of Contents for American Hearth SARATOGA ALS-24SG-1

  • Page 1 INSTALLATION INSTrucTIONS AND OwNer'S MANuAL SARATOGA LOg SeT fOr uNVeNTeD gAS LOg HeATer VeNTeD DecOrATIVe APPLIANce MODeLS ALS-18Sg-1 ALS-24Sg-1 ALS-30Sg-1 GAS-FIRED wArNINg: If the information in these in- structions are not followed exactly, a fire or ex- plosion may result causing property damage, Installer: Leave this manual with the appli- personal injury or loss of life.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Section Page Important Installation Guidelines ................. 3 General Information ..................... 3 Requirements for Canada ..................4 Log Placement ....................5-6 ALS-18SG-1 Photos ..................... 7 ALS-24SG-1 Photos ..................... 8 ALS-30SG-1 Photos ..................... 9 Parts List & Parts View ..................10 Master Parts Distributor List ................

  • Page 3: Important Installation Guidelines

    IMPORTANT INSTALLATION GUIDELINES Proper Log Placement wArNINg: Do not allow fans to blow directly into the fireplace. Log placement is critical to proper burner performance. Logs must Avoid any drafts that alter burner flame patterns. be correctly positioned onto the burner. The photos in this manual wArNINg: Do not use a blower insert, heat exchanger insert or show the proper pinned position for logs on this set.

  • Page 4: Requirements For Canada

    reQuIreMeNTS fOr cANADA This unit cannot be installed in a UNVENTED application, this WARNING; DO NOT OPERATE THIS GAS LOG SET unit can only be installed as a VENTED application with these wITH gLASS DOOrS cLOSeD requirements. • Clothing or other flammable material should not be placed on IMPOrTANT SAfeTY INfOrMATION or near the appliance.

  • Page 5: Log Placement

    LOG PLACEMENT Before you begin: Do not, handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs The positioning of the logs is critical to the safe and clean operation of this heater. Sooting and other problems may result if the logs are not properly and firmly positioned in the appliance.
  • Page 6 LOG PLACEMENT Apply loose material (glowing embers) per appropriate Installation Instructions and Owner's Manual. Replacement of loose material (glowing embers) must be purchased from Empire Comfort Systems, Inc. Application of excess loose material (glowing embers) may adversely affect performance of the heater. WARNING: All previously applied loose material must be removed prior to reapplication.
  • Page 7 EMBER PLACEMENT ALS-18SG-1 PHOTOS 24977-2-0210 Page 7...
  • Page 8 EMBER PLACEMENT ALS-24SG-1 PHOTOS Page 8 24977-2-0210...
  • Page 9 EMBER PLACEMENT ALS-30SG-1 PHOTOS 24977-2-0210 Page 9...

  • Page 10: Als-18Sg-1 Photos

    PARTS LIST & PARTS VIEW Attention: When ordering parts, it is very important that part number and description of part coincide. Index No. Part Number Part Number Part Number ALS-18Sg-1 ALS-24Sg-1 ALS-30Sg-1 Description R8353 R10240 R8368 Front Left Log R10233 R10241 R10249 Rear Left Log...

  • Page 11: Master Parts Distributor List

    MASTer PArTS DISTrIBuTOr LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort.com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit.
  • Page 12 A Registered Trademark of Empire Comfort Systems Inc. 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. www.americanhearth.com Page 12 24977-2-0210...
