RALEIGH
wArNING: If the information in these in-
structions are not followed exactly, a fire or ex-
plosion may result causing property damage,
personal injury or loss of life.
— Do not store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of this or
any other appliance.
— wHAT TO DO IF YOu SMeLL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
•
If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
INSTALLATION INSTrucTIONS
AND OwNer'S MANuAL
ALSU18CR1-2 SHOWN
LOG SeT FOr
VeNTeD AND uNVeNTeD
MuLTI-SIDeD GAS LOG HeATer
MODeLS
ALSu18cr1-2
ALSu24cr1-2
ALSu30cr1-2
Installer: Leave this manual with the appli-
ance.
consumer: retain this manual for future refer-
ence.
Log sets comply with ANSI Z21.11.2 unvented
Heaters and also comply with ANSI Z21.60
Decorative Vented Appliances for Solid Fuel
Burning Fireplaces. State or local codes may only
allow operation of log sets in a vented configuration.
check your state or local codes.
wArNING: If not installed, operated and main-
tained in accordance with the manufacturer's
instructions, this product could expose you to
substances in fuel or from fuel combustion which
can cause death or serious illness.
Page 1
Advertisement
Table of Contents
Related Manuals for American Hearth Raleigh ALSU18CR1-2
Summary of Contents for American Hearth Raleigh ALSU18CR1-2
- Page 1 MuLTI-SIDeD GAS LOG HeATer MODeLS ALSu18cr1-2 ALSu24cr1-2 ALSu30cr1-2 ALSU18CR1-2 SHOWN wArNING: If the information in these in- structions are not followed exactly, a fire or ex- plosion may result causing property damage, Installer: Leave this manual with the appli- personal injury or loss of life.
-
Page 2: Table Of Contents
Important Installation Guidelines ................. 3 General Information ..................... 3 Log Placement ....................4-5 Ember Placement....................6 Ember Placement ALSU18CR1-2 Photos ............7 Ember Placement ALSU24CR1-2 Photos ............8 Ember Placement ALSU30CR1-2 Photos ............9 Parts List & Parts View ..................10 Master Parts Distributor List ................ -
Page 3: Important Installation Guidelines
IMPORTANT INSTALLATION GUIDELINES Proper Log Placement Avoid any drafts that alter burner flame patterns. Log placement is critical to proper burner performance. Logs must wArNING: Do not use a blower insert, heat exchanger insert or be correctly positioned onto the burner. The photos in this manual other accessory not approved for use with this heater. -
Page 4: Log Placement
LOG PLACEMENT Before you begin: Do not, handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs The positioning of the logs is critical to the safe and clean operation of this heater. Sooting and other problems may result if the logs are not properly and firmly positioned in the appliance. -
Page 5: Log Placement
Attention: Do not use Figures 1 to 3 to order replacement logs. Refer to Page 10, Parts List and Parts View to order logs for your appropriate model number. Log Placement ALSu18cr1-2 Logs and Burner Shown Figure 4 24243-3-0309 Page 5... -
Page 6: Ember Placement
EMBER PLACEMENT Apply loose material (glowing embers) with the appropriate ember placement photos on pages 7 through 9. Replacement of loose material (glowing embers) must be purchased from Empire Comfort Systems, Inc. Application of excess loose material (glowing embers) may adversely affect performance of the heater. -
Page 7: Ember Placement Alsu18Cr1-2 Photos
EMBER PLACEMENT ALSU18CR1-2 PHOTOS FRONT (VALVE SIDE) REAR Some logs have been removed for clarity Do not cover any large ports with loose material (glowing embers) REAR FRONT (VALVE SIDE) 24243-3-0309 Page 7... -
Page 8: Ember Placement Alsu24Cr1-2 Photos
EMBER PLACEMENT ALSU24CR1-2 PHOTOS FRONT (VALVE SIDE) REAR Some logs have been removed for clarity Do not cover any large ports with loose material (glowing embers) REAR FRONT (VALVE SIDE) Page 8 24243-3-0309... -
Page 9: Ember Placement Alsu30Cr1-2 Photos
EMBER PLACEMENT ALSU30CR1-2 PHOTOS FRONT (VALVE SIDE) REAR Some logs have been removed for clarity Do not cover any large ports with loose material (glowing embers) REAR FRONT (VALVE SIDE) 24243-3-0309 Page 9... -
Page 10: Parts List & Parts View
PARTS LIST & PARTS VIEW Attention: When ordering parts, it is very important that part number and description of part coincide. Index No. Part Number Part Number Part Number ALSu18cr1-2 ALSu24cr1-2 ALSu30cr1-2 Description R9312 R9323 R9329 BACK RIGHT LOG R9313... -
Page 11: Master Parts Distributor List
MASTer PArTS DISTrIBuTOr LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort.com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit. - Page 12 A Registered Trademark of Empire Comfort Systems Inc. 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. www.americanhearth.com Page 12 24243-3-0309...
