  • Page 1 PDA Scanner - HT682 - User’s Manual 400974G Version 0.2...

  • Page 3: Preface

    Preface About This Manual This manual explains how to install, operate and maintain the HT682 PDA Scanner. No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means, without permission in writing from the manufacturer. This includes electronic or mechanical means, such as photocopying, recording, or information storage and retrieval systems.

  • Page 4: Regulatory Compliance Statements

    Regulatory Compliance Statements FCC Warning Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 5: Canadian Compliance Statement

    RF Radiation Exposure Statement: For body worn operation, this phone has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the handset a minimum of 1.5 cm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines.

  • Page 6: Laser Information

    When both batteries are discharged, recharge the unit for 16 hours in order to fully charge the main battery and backup battery. Recharge the HT682 through the following: Plug the USB charging cable to the HT682 and plug the 5V/3A AC-DC adapter to the power jack of the USB charging cable.

  • Page 7: Battery Charge Notice

    If the performance decrease is greater than 20% in a Lithium-Ion battery, the battery is at the end of its life cycle. Do not continue to use, and ensure the battery is disposed of properly. The length of time that a battery power lasts depends on the battery type and how the device is used.

  • Page 8: Storage And Safety Notice

    60°C, however they may deplete more rapidly at the higher temperature ranges. It is recommended to store batteries within normal room temperature ranges. Warranty The following items covered under Unitech Limited Warranty are free from defects during normal use: HT682 – 1-year limited warranty.

  • Page 9: Table Of Contents

    Laser Information........................iv Battery Notices ........................iv Battery charge notice ......................v Storage and safety notice....................vi Warranty ..........................vi Chapter 1 Getting Started ........................... 1 Introducing the HT682 ......................1 Notice ............................. 1 Warranty ..........................2 Regulatory........................... 2 HT682 Model Specification ..................... 2...
  • Page 10 Communication and Charging Cable Kits ................3 Universal Adaptor........................ 3 Holster..........................3 Li-ion Battery Pack ......................3 HT682 Product Introduction & Accessory Kit ................4 HT682 Front View ....................... 5 HT682 Rear View........................ 6 First Step with HT682......................7 Install the Battery Pack ....................... 7 Switch On Backup Battery ....................
  • Page 11 Bar Code Scanner ........................ 15 Chapter 3 Power system........................... 17 Charging the Lithium-Ion Battery Pack ................. 17 Charging the Main and Backup Battery for the First Time..........17 Environment Consideration for Charging ................17 Power Status Indication..................... 18 “Backup Battery Low” Icon ....................18 Charging the Lithium-Ion Battery Pack .................
  • Page 12 Installation..........................25 Connecting the Device to Your Computer ................. 26 Changing Communications Settings..................27 WiFi Connection........................ 28 Bluetooth Connection......................31 Chapter 5 Useful Utilities .......................... 39 Introduction ........................... 39 Scanner Setting ........................ 39 Scan2Key.......................... 42 Chapter 6 Device Setting .......................... 43 Introduction ...........................

  • Page 13: Getting Started

    This unit is equipped with a battery pack and backup battery. It is possible that the Unitech HT682 may not be powered ON due to battery discharge as a result of storage. In the above situation and the first-time use, plug the HT682 to the charging cable or charging cradle (with 5V/2A AC-DC adapter), and charge the unused unit for over 16 hours in order to fully charge its backup battery as well.

  • Page 14: Warranty

    Warranty Unitech's Limited Warranty provides for different warranty periods for different parts and accessories: PDA Scanner is covered by 1-year limit warranty. Docking Station is covered by 1-year limit warranty. Cable is covered by 1-year limit warranty. Battery is covered by 6-month warranty.

  • Page 15: Ht682 Accessories

    Communication and Charging Cable Kits An included USB cable or an optional serial cable connects the HT682 PDA Scanner directly to a peripheral device for communication and a power source for charging. Adaptor...

  • Page 16: Ht682 Product Introduction & Accessory Kit

    HT682 Product Introduction & Accessory Kit HT682 PDA Scanner Manual CD Communication Cable Battery Adaptor Plugs Communication Cradle...

  • Page 17: Ht682 Front View

    HT682 Front View LED Indicator Touch Screen Display Trigger Function Alpha I/O Port Power Note: The LED indicators are defined as follows according to the colors of LED: Green:...

  • Page 18: Ht682 Rear View

    HT682 Rear View Bar Code Scanner Stylus Speaker Battery Cover...

  • Page 19: First Step With Ht682

    First Step with HT682 Before first using the HT682, please ensure the battery is fully charged. There are three ways to charge your HT682: Docking Station USB/Charging cable Rechargeable Lithium-Ion battery pack NOTE: Data loss may occur if the HT682's backup battery is not adequately charged. Before charging the main battery, make sure the backup battery switch is ON.

  • Page 20: Switch On Backup Battery

    Please ensure that it is in the “ON” position before charging the main battery. Supply Power to the HT682 Before using the power adapter, please follow the instruction made below to remove the O-ring from the socket of the adapter.

  • Page 21: First Time To Charge The Main Battery & Backup Battery

    Face the side of the connector with the smaller pillar up, as shown below; and Connect. Or place the HT682 into the Docking Station (first connect the power supply to the Docking Station). First Time to Charge the Main Battery & Backup Battery We would like to propose to charge the battery at least up to 16 hours for the first time to use.

  • Page 22: Setting The Time Zone First

    To adjust the original default setting of the screen brightness, the backlight setting will be required. Please refer to page 20 for the new setting procedure. Setting Time Zone/ Date Before using the HT682 please take a few minutes to set the time and date so that data can be properly time-stamped.

  • Page 23: Setting Date/Time

    If you would like the PDA Scanner automatically adjust clock for daylight saving, please tick on Setting Date/Time Tap the Left or Right arrows to scroll the year and month you desire. Or, directly tap location of year or month to change the year or month setting. To set up time, tap on the Hr/Min/Sec AM/PM to input the Hr/Min/Sec...

  • Page 25: Using The Keypad And Scanner

    Chapter 2 Using the Keypad and Scanner Keypad Data can be entered into the HT682 via its keypads, which includes: 0~9, alpha, function, escape, enter, scanner trigger, cursor, and on/off keys. Scan Key Enter Key Escape Key Cursor Key Power ON/OFF Key...

  • Page 26: Ht682 Hotkey

    HT682 HotKey The HT682 provides hotkeys for frequently used functions. Press the Function key and the appropriate numeric key for the following functions listed below: Func 6 = Task Manager Func 7 = Scanner Setting Func 8 = Power Properties Func 9 = System Info Hotkeys can be modified to suit the user's preferences.

  • Page 27: Other Character Support From Wince Keyboard

    [áü] key on the touch screen keyboard to display the available characters. Bar Code Scanner The HT682 has an integrated 1D laser and 2D imager bar code scanner (depending on model number) capable of reading all major bar code labels.

  • Page 29: Power System

    Charging the Main and Backup Battery for the First Time When first charging the HT682, please allow at least 16 hours to fully charge both the main and backup batteries. When the HT682 arrives from the factory the backup battery switch is in the OFF position in order to protect the backup battery.

  • Page 30: Power Status Indication

    Automatic shutdown of the HT682 The HT682 will enter idle mode when there is no task, or all tasks are waiting for input. In default setting, the HT682 will automatically turn itself off if it remains idle for 3 minutes and when there is no external charging power applied.

  • Page 31: Storage And Safety Precautions

    Tap Setting → Control Panel → Device Setting to enter the Device Setting zone. Alternatively, Press Func key and “9” button to bring the Device Setting screen. Move to the IO tab and select Disable to disable the wireless mode. Storage and Safety Precautions Batteries should be stored in an open environment and placed where there is no risk of accidental shorting or other damage.

  • Page 32: Backlight Setting

    Warm Boot / Cold Boot Warm Boot Warm Boot is a reset to re-boot the HT682 without losing saved data. Perform a warm boot when: The PDA Scanner fails to respond.

  • Page 33: Warm Boot Via Software

    PDA Scanner after a bootloader, keyboard, or kernel upgrade. You are also allowed to stab the cold-boot pinhole to cold boot the HT682. WARNING - Performing a Cold Boot will return the HT682 to its original factory settings!

  • Page 34: Cold Boot Via Software

    Cold Boot via Software Tap Start → Programs → Utilities → BootMode. Tap “Cold Boot”. The system is reset and you will lose all data including all files in the RAM memory. You will need to recalibrate the screen and reset the date and time.

  • Page 35: Data Communication

    Chapter 4 Data Communication Introduction The Unitech HT682 allows users to link to a host computer via RS-232 / USB, Bluetooth, or Wireless connection for data communication. This chapter provides an overview of the communication of the HT682. The following subchapters cover these topics: “Series or USB or Modem”...

  • Page 36: Docking Station

    HT682's USB communication cable into your PC's USB Port and the other end into the HT682 Docking Station's USB port. To simultaneously charge the HT682, plug the AC power adaptor into the power receptacle on the Docking Station. RF Communication...

  • Page 37: Installation

    Because you will be restarting your computer during installation, save your work and quit all programs before you begin. To set up your communication settings, the HT682 serial cable is required to connect the HT682 to your host computer. If you run the Windows NT® operating system with a service pack, you will be informed during setup that you may need to reinstall the service pack.

  • Page 38: Connecting The Device To Your Computer

    Synchronization will be initialized and will take place if you’ve chosen to synchronize periodically or upon connection. NOTE: Your computer can create a partnership with multiple HT682s. Also, a HT682 can create a partnership with up to two computers.

  • Page 39: Changing Communications Settings

    Microsoft ActiveSync uses the specified communication ports to connect to the HT682. Make sure these resources are available for Microsoft ActiveSync to connect to the HT682. Other programs cannot use them while the HT682 and your desktop computer are connected.

  • Page 40: Wifi Connection

    WiFi Connection Unitech PDA Scanners come with built-in RF facility, Summit or Marvel. A wireless network can be added either when the network access point is detected or by manually entering setting data. Before following these instructions, make sure if authentication information is needed.
  • Page 41 Enter Admin Password. (Default pass-word: SUMMIT Scan Available AP Under Profile tab, tap Scan for available You may select a desired AP to create a new profile. Tap Configure.
  • Page 42 Tap Yes to create the new profile. Enter the WEP key or network key. Tap Commit and Activate Tap Commit to activate the setting.

  • Page 43: Bluetooth Connection

    Under Main tab, select the profile you want to activate. A pop-up window appears “A Power Cycle is required to make settings activate properly.” Tap OK, and then tap OK to exit the Summit Client Utility. Tap Start → Programs → Utilities → Boot-Mode. Tap Warm Boot to warm start the PDA Scanner and load the previous settings.
  • Page 44 Using BTMAN to connect and pair a Bluetooth device After enabling the built-in Bluetooth module, you may use BTMAN to connect and pair a Bluetooth device around. BTMAN is a Bluetooth manager gathering and managing all Bluetooth profiles you add. Tap Start →...
  • Page 45 Tap Yes to turn ON the Bluetooth module. Tap the Scan Device tab to scan Bluetooth devices around. Tap Scan Device. Scanned Bluetooth devices around are listed. Later, you may double tap a desired device and check Trusted and then Active.
  • Page 46 ActiveSync Between HT682 and a PC or PDA Scanner On the Scan Device tab, for example, select and double tap a desired PC. Tap Trusted. Tap Yes. Enter a PIN code on the PDA Scanner and tap OK. Then, an Enter PIN dialog box pops up and enter the PIN code same as that you inputted on the PDA Scanner.
  • Page 47 Double tab the paired PC. When the pairing is successful, Trust and Active are checked. Move to the Service tab and tap ActiveSync. Tap Yes to launch ActiveSync. Then, HT682 will synchronize with the desired PC by means of Bluetooth.
  • Page 48 The PDA Scanner is searching for PCs and PDA Scanners that are provided with the FTP function. Select a device and tap OK. An Authentication Request box pops up. Then, input a PIN code and tap OK. Choose a desired PC or PDA Scanner to or from which you want to transfer or receive data.
  • Page 49 Move to subdirectory Modem You may surf on Internet by connecting HT682 to a mobile phone that serves as a modem. Follow the instruction below to connect and pair a mobile phone with GPRS function. Tap the Scan Device tab to scan Bluetooth devices around.
  • Page 50 Scanned Bluetooth mobile phones around are listed. Later, you may double tap a desired phone and check Trusted and then Active. Then, HT682 is successfully connect to and paired with the phone as the modem.

  • Page 51: Useful Utilities

    Chapter 5 Useful Utilities Introduction Unitech has been developing some of useful utilities for user’s application. The followings are Unitech Utilities introduction. Scanner Setting When it is necessary for the user to change the default barcode symbology for a different...
  • Page 52 Transmit Leading Barcode Enable/ Char Check / Check Digit Others Symbology Disable Digit verification Char/digit Transmit Transmit Start/Stop bits, Function Code, Double label decoding,*data length, *double labels separator Code 93 *data length Deta Code EAN 128 Transmit Code ID, * Field separator EAN 13 EAN 8 * Not suppress...
  • Page 53 Transmit Leading Barcode Enable/ Char Check / Check Digit Others Symbology Disable Digit verification Char/digit Transmit before supplement, most have supplement, *Add-on code try level Group GS1 YES Note: *Value Adjustable Scanner Control Pannel V3.0 Barcode Symbologies 2D Transmit Leading Barcode Enable/ Char Check /...

  • Page 54: Scan2Key

    Scan2Key The Scan2Key application can route input from the scanner port to the keyboard buffer, with the result that all scanned data will be treated as if they were input from the keypad. With this router, scanned data can be directly input into generic applications like MS Pocket Word.

  • Page 55: Device Setting

    Chapter 6 Device Setting Introduction The Device Setting is a short cut for you to view device information and do settings, such as Function Key, I/O, Server and so on. The following description will guide you through completion of all device-setting items. 1.

  • Page 56: Funckey

    Funckey Tap “FuncKey” tab. Four hot keys can be changed by the users. 2. Tap “Func6”. Tap “Browse” to select a file. Tap “Set”. 3. Press “Func” key and “6” key. Func6 will call the application that the users specified. 4.

  • Page 57: Server

    When enable, SD/ Wireless card is always accessible; when disabled, SD/Wireless card is not accessible. Server Server Manager is a tool for the user to manager the NTLM (Windows NT LAN Manager) users, FTP users and telnet users. Account Manager NTLM 1.
  • Page 58 1. Under “FTP” tab, tap “Add” to add FTP user. 2. Select the user and tap “Add”. 3. To delete ftp user, select the user and tap “Delete”. You will see the dialog box – “Do you want to delete the user X?” Tap “Yes”. Telnet Under “Telnet”...

  • Page 59: Virtual Key

    2. For FTP server setting, enable/disable server and define anonymous login. Save Tap “Save” to save the server settings. Load Tap “Load” to load the saved server settings. Virtual Key This tool allows you to enable/disable the alpha keys on the PDA Scanner’s keypad, set auto enter and inter character delay.

  • Page 60: Screen

    Screen 1. Tap Rotate Right. Screen rotates to the right. 2. Tap Rotate Left. Screen rotates to the left. 3. Tap Upside Down. Screen rotates upside down. Ping This tool allows you to ping to other devices in LAN network while your PDA Scanner is connected to the network.

  • Page 61: Backup

    Backup This tool allows you to save the current registry or reset to factory default. 1. Tap “Backup” tab. 2. Tap “Save” to save current registry settings. 3. Or tap “Restore” to reset registry to factory default. The PDA Scanner will be warm started. (Note that “Restore”...

  • Page 63: Appendix

    Worldwide Support Unitech’s professional support team is available to quickly answer questions or technical-related issues. Should an equipment problem occur, please contact the nearest Unitech regional service representative. For complete contact information please visit the Web sites listed below: Region...
