CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: ANSI Z21.50 • CSA 2.22 FOR VENTED GAS FIREPLACES.
GD19N

NATURAL GAS

GD19P
PROPANE
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.

SAFETY INFORMATION

WARNING
!
If the information in these instructions are
not followed exactly, a fi re or explosion
may result causing property damage,
personal injury or loss of life.
- Do not store or use gasoline or other fl ammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use
any phone in your building.
•
Immediately call your gas supplier from a
neighbour's phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas supplier, call the
fi re department.
- Installation and service must be performed by a
qualifi ed installer, service agency or the supplier.
Phone (705)721-1212 • Fax (705)722-6031 • www.napoleonfi replaces.com • ask@napoleon.on.ca
$10.00
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
OPERATING INSTRUCTIONS
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 4Y8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
INSTALLATION AND
1.2
W415-0825 / 07.06.09
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vittoria GD19N and is the answer not in the manual?

Questions and answers

Related Manuals for Napoleon Vittoria GD19N

Summary of Contents for Napoleon Vittoria GD19N

  • Page 1: Natural Gas

    - Installation and service must be performed by a qualifi ed installer, service agency or the supplier. Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 4Y8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030 Phone (705)721-1212 • Fax (705)722-6031 • www.napoleonfi replaces.com • ask@napoleon.on.ca W415-0825 / 07.06.09...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION WARRANTY DIMENSIONS INSTALLATION OVERVIEW GENERAL INSTRUCTIONS GENERAL INFORMATION CARE OF GLASS VENTING VENTING LENGTHS AND COMPONENTS TYPICAL VENT INSTALLATION SPECIAL VENT INSTALLATIONS 2.3.1 PERISCOPE TERMINATION 2.3.2 CORNER TERMINATION MINIMUM AIR TERMINAL LOCATION CLEARANCES VENTING APPLICATION FLOW CHART DEFINITIONS ELBOW VENT LENGTH VALUES TOP EXIT HORIZONTAL TERMINATION...

  • Page 3: Introduction

    1.0 INTRODUCTION WARNING • Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to operating instructions could cause fi re or injury. • Risk of fi re or asphyxiation do not operate appliance with fi xed glass removed. •...

  • Page 4: Warranty

    NAPOLEON® warrants its stainless steel burners against defects in workmanship and material for life, subject to the following conditions: During the fi rst 10 years NAPOLEON® will replace or repair the defective parts at our option free of charge. From 10 years to life, NAPOLEON®...

  • Page 5: Dimensions

    DIMENSIONS 7” DIA. 4” DIA. ” ” ” ” ” RATING LINE PLATE ACCESS LOCATION 12” ” ELECTRICAL 13” ” ” ACCESS ” ” 9” ” 7” DIA. 4” DIA. RATING LINE 5” PLATE ACCESS LOCATION ” ” ELECTRICAL ACCESS W415-0825 / 07.06.09...

  • Page 6: Installation Overview

    INSTALLATION OVERVIEW Top vent, see “REAR VENT CONVERSION” section. Door, see “GLASS DOOR Venting, see “VENTING” INSTALLATION AND section. REMOVAL” section. Front face, see “FRONT FACING AND INSET KIT Blower, see “OPTIONAL INSTALLATION” section. BLOWER INSTALLATION” section. W415-0825 / 07.06.09...

  • Page 7: General Instructions

    GENERAL INSTRUCTIONS WARNING ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RAN OUT, WITH THE GLASS DOOR OPENED OR REMOVED. PROVIDE ADEQUATE CLEARANCE FOR SERVICING AND OPERATING THE APPLIANCE. PROVIDE ADEQUATE VENTILATION. NEVER OBSTRUCT THE FRONT OPENING OF THE APPLIANCE. OBJECTS PLACED IN FRONT OF THE APPLIANCE MUST BE KEPT A MINIMUM OF 48”...

  • Page 8: General Information

    If the optional fan or blower is installed, the junction box must be electrically connected and grounded in ac- cordance with local codes. In the absence of local codes, use the current CSA C22.1 Canadian Electrical Code in Canada or the ANSI/NFPA 70 National Electrical Code in the United States. GENERAL INFORMATION FOR YOUR SATISFACTION, THIS APPLIANCE HAS BEEN TEST-FIRED TO ASSURE ITS OPERATION AND QUALITY!

  • Page 9: Venting

    2.0 VENTING WARNING RISK OF FIRE, MAINTAIN SPECIFIED AIR SPACE CLEARANCES TO VENT PIPE AND APPLIANCE. THE VENT SYSTEM MUST BE SUPPORTED EVERY 3 FEET FOR BOTH VERTICAL AND HORIZONTAL RUNS. USE SUPPORTS OR EQUIVALENT NON-COMBUSTIBLE STRAPPING TO MAINTAIN THE REQUIRED CLEARANCE FROM COMBUSTIBLES.

  • Page 10: Typical Vent Installation

    For optimum flame appearance and appliance performance, keep the vent length and number of elbows to a minimum. The air terminal must remain unobstructed at all times. Examine the air terminal at least once a year to verify that it is unobstructed and undamaged. Rigid and fl...
  • Page 11 16" MINIMUM 35 FT MAXIMUM 3 FT MINIMUM 20" MAXIMUM 33 1/8" 26 3/8" 26 3/8" MINIMUM PLUS RISE* * See "VENTING" section W415-0825 / 07.06.09...

  • Page 12: Special Vent Installations

    SPECIAL VENT INSTALLATIONS 2.3.1 PERISCOPE TERMINATION Use the periscope kit to locate the air termination above grade. The periscope must be installed so that when fi nal grading is completed, the bottom air slot is located a minimum 12” above grade. The maximum allowable vent length is 10’.

  • Page 13: Minimum Air Terminal Location Clearances

    MINIMUM AIR TERMINAL LOCATION CLEARANCES INSTALLATIONS CANADA U.S.A. 12” 12” Clearance above grade, veranda porch, deck or balcony. 12” 9” Clearance to windows or doors that open. 12” * 12” * Clearance to permanently closed windows. Vertical clearance to ventilated soffi ts located above the terminal within a horizontal distance of 2’ from 18”...

  • Page 14: Venting Application Flow Chart

    VENTING APPLICATION FLOW CHART TOP EXIT Horizontal Termination Vertical Termination Vertical rise is equal Vertical rise is equal Vertical rise is less Vertical rise is less to or greater than to or greater than than horizontal run than horizontal run the horizontal run the horizontal run Horizontal run +...

  • Page 15: Elbow Vent Length Values

    ELBOW VENT LENGTH VALUES FEET INCHES 1° 0.03 15° 0.45 30° 11.0 45° 1.35 16.0 90°* 32.0 * The fi rst 90° offset has a zero value and is shown in the formula as - 90° 15.1 TOP EXIT HORIZONTAL TERMINATION ) <...
  • Page 16 ) > (V Simple venting configuration (only one 90° elbow) See graph to determine the required vertical rise V for the required horizontal run H 147” REQUIRED VERTICAL RISE IN INCHES V 57” 19 1/2” 2’ 12.5’ 19.5’ HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable values for H and V...

  • Page 17: Rear Exit Horizontal Termination

    REAR EXIT HORIZONTAL TERMINATION ) < (V Simple venting configuration See graph to determine the required vertical rise V for the required (only two 90° elbows) horizontal run H 32.3 REQUIRED VERTICAL RISE IN FEET V 12.5 17.5 HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable values for H and H 90°...
  • Page 18 ) > (V Simple venting configuration See graph to determine the required vertical rise V for the (only two 90° elbows) required horizontal run H REQUIRED VERTICAL RISE IN INCHES V 12.5 17.5 19.25 HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable values for H and H...

  • Page 19: Top Or Rear Exit Vertical Termination

    2.10 TOP OR REAR EXIT VERTICAL TERMINATION ) < (V See graph to determine the required vertical rise V for the Simple venting configurations. required horizontal run H REQUIRED VERTICAL 17.5 RISE IN FEET V 17.5 HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable values for H and H...
  • Page 20 ) > (V See graph to determine the required vertical rise V for the Simple venting configurations. required horizontal run H REQUIRED VERTICAL RISE IN FEET V HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable values for H and H For vent configurations requiring more than one 90°...
  • Page 21 Example 8: = 1.5 FT = 5 FT = 1.5 + 1 + 5 = 6.5 FT = 1 FT = 1 FT = 10.75 FT = 1 + 1 + 10.75 = 12.75 FT = .03 (four 90° elbows + one 45° elbow - 90°) 90°...

  • Page 22: Rear Vent Conversion

    2.11 REAR VENT CONVERSION In order to convert the venting confi guration from a top exit to a rear exit, remove components as illustrated: When reinstalling in the alternate position: Check gaskets for tears, replace if necessary to ensure a proper seal.

  • Page 23: Installation

    3.0 INSTALLATION WARNING FOLLOW THE VENTING INSTRUCTIONS EXACTLY. ALL INNER EXHAUST AND OUTER INTAKE VENT PIPE JOINTS MAY BE SEALED USING EITHER RED RTV HIGH TEMP SILICONE SEALANT W573-0002 (NOT SUPPLIED) OR BLACK HIGH TEMP MILL PAC W573-0007 (NOT SUPPLIED) WITH THE EXCEPTION OF THE APPLIANCE EXHAUST FLUE COLLAR WHICH MUST BE SEALED USING MILL PAC.

  • Page 24: Horizontal Installation

    3.1.1 HORIZONTAL INSTALLATION WARNING THE FIRESTOP ASSEMBLY MUST BE INSTALLED WITH THE VENT SHIELD TO THE TOP. TERMINALS MUST NOT BE RECESSED INTO A WALL OR SIDING MORE THAN THE DEPTH OF THE RETURN FLANGE OF THE MOUNTING PLATE. This application occurs when venting through an exterior wall. Having determined the correct height for the air terminal VENT location, cut and frame a hole in the exterior wall as...

  • Page 25: Using Flexible Vent Components

    USING FLEXIBLE VENT COMPONENTS WARNING DO NOT ALLOW THE INNER FLEX PIPE TO BUNCH UP ON HORIZONTAL OR VERTICAL RUNS AND ELBOWS. KEEP IT PULLED TIGHT. SPACERS ARE ATTACHED TO THE INNER FLEX PIPE AT PREDETERMINED INTERVALS TO MAINTAIN AN EVEN AIR GAP TO THE OUTER FLEX PIPE.

  • Page 26: Vertical Air Terminal Installation

    3.2.2 VERTICAL AIR TERMINAL INSTALLATION WARNING MAINTAIN A MINIMUM 2” SPACE BETWEEN THE AIR INLET BASE AND THE STORM COLLAR. Fasten the roof support to the roof using the screws provided. The roof support is optional. In this case the venting is to be adequately supported using either an alternate method suitable to the authority having jurisdiction or the optional roof support.

  • Page 27: Using Rigid Vent Components

    USING RIGID VENT COMPONENTS The vent system must be supported approximately every 3 feet for both vertical and horizontal runs. Use Wolf Steel Ltd. support ring assembly or equivalent noncombustible strapping to maintain the minimum clearance to combustibles for both vertical and horizontal runs. All inner exhaust and outer intake vent pipe joints may be sealed using either red high temperature silicone sealant W573-0002 (not supplied) or black high temperature sealant W573-0007 Mill Pac (not supplied) with the exception of the appliance exhaust fl...

  • Page 28: Vertical Air Terminal Installation

    3.3.3 VERTICAL AIR TERMINAL INSTALLATION NOTE: Before attaching elbows to the collars on the back of the appliance, 1 1/2” will need to be trimmed off the 4” collar. REAR VENT APPLICATION: Attach 4” and 7” elbows to the appliance. Secure with 3 screws and seal the joints and screw heads using high temperature sealant.

  • Page 29: Restricting Vertical Vents

    3.3.4 RESTRICTING VERTICAL VENTS Vertical terminations running longer than 15 feet may display a very active fl ame. If this appearance is not desirable, the vent exit must be restricted to reduce the velocity of the exhaust gases, thus slowing down the fl...

  • Page 30: Gas Installation

    GAS INSTALLATION WARNING RISK OF FIRE, EXPLOSION OR ASPHYXIATION. ENSURE THERE ARE NO IGNITION SOURCES SUCH AS SPARKS OR OPEN FLAMES. SUPPORT GAS CONTROL WHEN ATTACHING GAS SUPPLY PIPE TO PREVENT DAMAGING GAS LINE. ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT WITH THE GLASS DOOR OPENED OR REMOVED.

  • Page 31: Framing

    4.0 FRAMING WARNING IN ORDER TO AVOID THE POSSIBILITY OF EXPOSED INSULATION OR VAPOUR BARRIER COMING IN CONTACT WITH THE APPLIANCE BODY, IT IS RECOMMENDED THAT THE WALLS OF THE APPLI- ANCE ENCLOSURE BE “FINISHED” (IE: DRYWALL / SHEETROCK), AS YOU WOULD FINISH ANY OTHER OUTSIDE WALL OF A HOME.
  • Page 32 Minimum clearance to combustible construction from appliance and vent surfaces: Combustible Framing: 0" to stand-offs 1" to bottom and sides of the vent pipe* 2" to top of the vent pipe* Combustible Finishing: 0" to rear 0" to front face top and sides 13"...

  • Page 33: Rear Vent

    4.1.1 REAR VENT OUTSIDE MINIMUM CHASE ” ” ENCLOSURE HEIGHT ” ” ” INSIDE ” CHASE ” ” 2" ” 4" SIDE 2" PROTRUSION WALL 4" 6" 4.1.2 TOP VENT MINIMUM 23” ” MINIMUM ENCLOSURE HEIGHT ” ” OUTSIDE ” CHASE ”...

  • Page 34: Minimum Clearance To Combustible Enclosures

    MINIMUM CLEARANCE TO COMBUSTIBLE ENCLOSURES COMBUSTIBLE NON-COMBUSTIBLE BRICK 6” 0” IF NON-COMBUSTIBLE 2” FINISHING IS USED SUCH AS BRICK AND STONE. 39 1 /8” 1” 33 1 /8” 26 3 /8” MINIMUM PLUS RISE * 1” * See "VENTING" section COMBUSTIBLE NON-COMBUSTIBLE BRICK...

  • Page 35: Minimum Mantel Clearances

    MINIMUM MANTEL CLEARANCES WARNING RISK OF FIRE, MAINTAIN ALL SPECIFIED AIR SPACE CLEARANCES TO COMBUSTIBLES. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY CAUSE A FIRE OR CAUSE THE APPLIANCE TO OVERHEAT. ENSURE ALL CLEARANCES (I.E. BACK, SIDE, TOP, VENT, MANTEL, FRONT, ETC.) ARE CLEARLY MAINTAINED.

  • Page 36: Electrical Connection

    5.0 ELECTRICAL CONNECTION WARNING DO NOT USE THIS APPLIANCE IF ANY PART HAS BEEN UNDER WATER. CALL A QUALIFIED SERVICE TECHNICIAN IMMEDIATELY TO HAVE THE APPLIANCE INSPECTED FOR DAMAGE TO THE ELECTRICAL CIRCUIT. RISK OF ELECTRICAL SHOCK OR EXPLOSION. DO NOT WIRE 110V TO THE VALVE OR TO THE APPLIANCE WALL SWITCH.

  • Page 37: Wiring Diagram

    6.0 WIRING DIAGRAM GNITION ODULE ILOT SSEMBLY IRE TAGS [through Yellow ARE BRACKETED Gas line conduit] [through Orange independent conduit] ATTERY Black ILOT OLDER URNER WITCH ALVE ATTERY ELAY Red (3 Volt) ARNESS AC A DAPTOR Black (12 Volt) To Accent Light & Night Light Switch Orange...

  • Page 38: Finishing

    7.0 FINISHING GLASS DOOR REMOVAL: • Before the glass door can be removed, the decorative front must be removed. • The glass door is secured to the top and front DOOR bottom edges of the fi rebox with four spring LATCH latches.

  • Page 39: Log Placement

    LOG PLACEMENT WARNING LOGS MUST BE PLACED IN THEIR EXACT LOCATION IN THE APPLIANCE. DO NOT MODIFY THE PROPER LOG POSITIONS, SINCE APPLIANCE MAY NOT FUNCTION PROPERLY AND DELAYED IGNITION MAY OCCUR. THE LOGS ARE FRAGILE AND SHOULD BE HANDLED WITH CARE. In order to assemble the log set, the glass door must be removed, see "GLASS DOOR INSTALLATION AND REMOVAL"section.

  • Page 40: Glowing Embers

    fl ame. Use only certifi ed "glowing embers" and Phazer logs available from your Napoleon® dealer. LOGO PLACEMENT Remove the backing of the logo supplied and place on the glass viewing door, as indicated.
  • Page 41 7.8.3 Hook the bottom of the front facing on the bottom lip of the fi rebox. Pivot the front facing against the fi rebox and insert the head of the turn button through the slot in the front facing. Secure by turning the head of the turn button 1/4 turn.

  • Page 42: Optional Blower Installation

    8.0 OPTIONAL BLOWER INSTALLATION WARNING RISK OF FIRE AND ELECTRICAL SHOCK. TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THIS APPLIANCE. USE ONLY WOLF STEEL APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH THIS APPLIANCE. USING NON-LISTED ACCESSORIES (BLOWERS, DOORS, LOUVRES, TRIMS, GAS COMPONENTS, VENTING COMPONENTS, ETC.) COULD RESULT IN A SAFETY HAZARD AND WILL VOID THE WARRANTY AND CERTIFICATION.

  • Page 43: Operation

    9.0 OPERATION WARNING IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT WITH THE GLASS DOOR OPENED OR REMOVED.

  • Page 44: Control Functions

    CONTROL FUNCTIONS MAIN BURNER SWITCH This switch turns the Main Burner on and off. FLAME ADJUSTMENT Turn this knob clockwise or counter-clockwise to adjust the main burner fl ame height. NIGHT LIGHT SWITCH This switch turns the Night Light on and off. FAN CONTROL OPTION If installed this switch will turn on and off the power to the blower and control the fan speed.

  • Page 45: Pressure Check

    10.2 PRESSURE CHECK Check Pressure Readings: Inlet pressure can be checked by turning screw (A) counter-clockwise 2 or 3 turns and then placing pressure gauge tubing over the test point. Gauge should read 7” (minimum 4.5”) water column for natural gas or 13” (11” minimum) water column for propane.

  • Page 46: Maintenance

    11.0 MAINTENANCE MAINTENANCE MAINTENANCE WARNING MAINTENANCE TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE. CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. This fi replace and its venting system should be inspected before use and at least annually by a qualifi...

  • Page 47: Replacements

    PILOT INJECTOR - LP W455-0071 PILOT INJECTOR - NG W720-0092 PILOT TUBE W100-0069 PILOT ASSEMBLY - NG W100-0093 PILOT ASSEMBLY - LP W385-0334 NAPOLEON® LOGO W660-0009 ON/OFF SWITCH W387-0009 HALOGEN BULB 5W W387-0010 HIGH TEMPERATURE LIGHT ASSEMBLY W010-2180 GLASS AND GASKET W225-0250...
  • Page 48 ROOF TERMINAL KITS REF NO. APPLIANCE DESCRIPTION GD-110 - 1/12 TO 7/12 PITCH W670-0006 AIR TERMINAL W490-0073 4/7 INNER / OUTER SLEEVE W010-0567 ROOF SUPPORT W170-0063 STORM COLLAR W263-0054 ROOF FLASHING GD-111 - 8/12 TO 12/12 PITCH W670-0006 AIR TERMINAL W490-0073 4/7 INNER / OUTER SLEEVE W010-0567...
  • Page 49 24 25 W415-0825 / 07.06.09...

  • Page 50: Trouble Shooting

    13.0 TROUBLE SHOOTING WARNING ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RAN OUT, WITH THE GLASS DOOR OPEN OR REMOVED. SYMPTOM PROBLEM TEST SOLUTION Pilot will not light. Wiring. Verify the “S” wire for the sensor and the “I” wire for the ignitor are connected to the correct terminals (not reverse) on the module and pilot assembly.
  • Page 51 SYMPTOM PROBLEM TEST SOLUTION Continues to sparks Short or loose Verify all connections. Verify the connections from the and pilot lights, but connection in sensor rod. pilot assembly are tight; also verify these connections main burner will not are not grounding out to any metal. light.

  • Page 52: Service History

    14.0 SERVICE HISTORY 43.1 W415-0825 / 07.06.09...
