RED PRIMULA Installation And User Manual

Hydro model
Hide thumbs Also See for PRIMULA:

Advertisement

INSTALLATION AND USER GUIDE
EN
PELLET STOVE
PRIMULA
ORCHIDEA
GARDENIA
MARGHERITA
HYDRO MODEL
Translation of original instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRIMULA and is the answer not in the manual?

Questions and answers

Summary of Contents for RED PRIMULA

  • Page 1 INSTALLATION AND USER GUIDE PELLET STOVE PRIMULA ORCHIDEA GARDENIA MARGHERITA HYDRO MODEL Translation of original instructions...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS ....................II INTRODUCTION ......................1 1-WARNINGS AND WARRANTY CONDITIONS ..............2 2-INSTALLATION INSTRUCTIONS ..................9 3 - TECHNICAL DRAWINGS AND CHARACTERISTICS ............18 4-INSTALLATION AND ASSEMBLY ................22 5-PLUMBING CONNECTION ..................27 6 - ELECTRICAL CONNECTIONS ...................31 7 - INITIAL START-UP ....................32 8 - MENU ITEMS ......................35 9 - PRELIMINARY NOTIONS ..................41 10-OPERATION ......................49...
  • Page 3: Introduction

    Stove+Chimney+Air inlet). REVISIONS TO THE PUBLICATION The content of this manual is strictly technical and the property of RED. No part of this manual may be translated into other languages, adapted or reproduced, even in part, in other mechanical or electronic forms, photocopies, recordings or other, without the prior written authorisation from RED.
  • Page 4: 1-Warnings And Warranty Conditions

    1-WARNINGS AND WARRANTY CONDITIONS SAFETY PRECAUTIONS • Installation, electrical connection, function test and maintenance must only be carried out by authorised and qualified personnel. • Install the product in accordance with all local and national legisla- tion and regulations in force in the region or state. •...
  • Page 5 1-WARNINGS AND WARRANTY CONDITIONS the Manufacturer from any civil and criminal liability. • Any type of tampering or unauthorised replacement with non-original spare parts could be hazardous for the operator’s safety and relieves the company from any civil and criminal liability. •...
  • Page 6 1-WARNINGS AND WARRANTY CONDITIONS damage the electrical insulation and cause electric shocks. • A carbon monoxide alarm must be fitted in the room where the appliance is sited Refer too ADJ part 2.34 through too 2.36 page 41 (ONLY FOR UK). •...
  • Page 7 1-WARNINGS AND WARRANTY CONDITIONS CE, VENTILATE THE ROOM AND CONTACT THE INSTALLER/ SERVICE ENGI- NEER IMMEDIATELY. INFORMATION • In case of any problems, get in touch with your dealer, or a qualified engineer authorised by MCZ, and if a repair is necessary, insist on the use of original spare parts.
  • Page 8 1-WARNINGS AND WARRANTY CONDITIONS EXCLUSIONS The guarantee does not cover malfunctions and/or damage to the appliance that arise due to the following causes: • Damage caused during transportation or relocation • all parts that develop faults due to negligence or improper use, incorrect maintenance, installation that does not comply with the manufacturer’s instructions (always refer to the installation and use manual provided with the appliance) •...
  • Page 9 1-WARNINGS AND WARRANTY CONDITIONS SPARE PARTS In the event of a malfunction, consult the retailer who will forward the call to the Technical Assistance Service. Use only original spare parts. The retailer or service centre can provide all necessary information regarding spare parts. We do not recommend waiting for the parts to be worn before having them replaced.
  • Page 10 1-WARNINGS AND WARRANTY CONDITIONS RULES FOR INSTALLATION The product in question is a stove that uses wood pellets. Below is a list of European regulations regarding the installation of the product: EN 12828 Heating systems design. IEC 64-8 Electrical systems with rated voltage not exceeding 1000 V AC and 1500 V DC. EN 1443 General chimney regulation EN 1856-1 metal smoke ducts EN 1856-2 metal smoke extraction channels...
  • Page 11: 2-Installation Instructions

    2-INSTALLATION INSTRUCTIONS The instructions in this chapter refer explicitly to the Italian installation regulation UNI 10683. In any case, always observe the domestic regulations in force. PELLETS Wood pellets are manufactured by hot-extruding compressed sawdust which is produced during the working of natural dried wood. The compactness of the material is guaranteed by the lignin contained in the wood itself and allows pellets to be produced without glue or binders.
  • Page 12 If the floor is made of wood, it is recommended to fit a floor protection sheet in compliance with the Standards in force in the country of installation. Non-flammable walls Flammable walls PRIMULA/ORCHIDEA GARDENIA/MARGHERITA A = 5 cm A = 10 cm...
  • Page 13 2-INSTALLATION INSTRUCTIONS FOREWORD This chapter on the Smoke Flue has been produced in reference to the prescriptions of European regulations (EN13384 - EN1443 - EN1856 - EN1457). The chapter provides indications for installing an efficient and correct smoke flue but is under no circumstances to substitute the regulations in force, which the qualified technician must be in possession of.
  • Page 14 2-INSTALLATION INSTRUCTIONS TECHNICAL CHARACTERISTICS Have the efficiency of the flue checked by an authorised technician. The flue must be sealed against flue gasses, in a vertical direction without narrowing, be made with materials impermeable to smoke, condensation, thermally insulated and suitable to resist normal mechanical stress over time (we recommend fireplaces made of A/316 or refractory material with insulated round section double chamber).
  • Page 15 2-INSTALLATION INSTRUCTIONS ROOF AT 60° ROOF AT 45° 45° 60° A = MIN. 2.60 metres A = MIN. 2.00 metres FIGURE 5 FIGURE 6 B = DISTANCE > 1.20 metres B = DISTANCE > 1.30 metres C = DISTANCE < 1.20 metres C = DISTANCE <...
  • Page 16 2-INSTALLATION INSTRUCTIONS MAINTENANCE The flue must be kept clean, since the deposit of soot or unburned oils reduces the cross-section reducing the draft and thus compromising the efficient functioning of the heater and, if large build-ups accumulate, can catch fire. The flue and chimney must be cleaned and checked by a skilled chimney sweep at least once a year.
  • Page 17 2-INSTALLATION INSTRUCTIONS EXTERNAL AIR INLET It is mandatory to provide an adequate external air intake that supplies the combustion air required for the product to work properly. The flow of air between the outside and the installation room may be direct, through an inlet in an external wall of the room; or indirect, via air intake from adjoining rooms and connecting permanently with the installation room (see Figure 9 b).
  • Page 18 2-INSTALLATION INSTRUCTIONS DISTANCE (metres) The air inlet must be at a distance of: 1.5 m UNDER Windows, doors, smoke outlets, cavities, ..1.5 m HORIZONTALLY Windows, doors, smoke outlets, cavities, ..0.3 m ABOVE Windows, doors, smoke outlets, cavities, ..1.5 m AWAY from smoke outlet...
  • Page 19 2-INSTALLATION INSTRUCTIONS EXAMPLES OF CORRECT INSTALLATION 1. Installation of Ø150mm flue with hole for the passage of the tube increased by: minimum 100 mm around the tube if next to non flammable parts such as cement, brick, etc.; or minimum 300 mm around the tube (or as prescribed by data tags) if next to flammable parts such as wood etc.
  • Page 20: Technical Drawings And Characteristics

    3 - TECHNICAL DRAWINGS AND CHARACTERISTICS DRAWINGS AND CHARACTERISTICS DIMENSIONS OF PRIMULA AND ORCHIDEA HYDRO VERSION WITHOUT HOT WATER PRODUCTION KIT DIMENSIONS OF PRIMULA AND ORCHIDEA HYDRO VERSION WITH HOT WATER PRODUCTION KIT...
  • Page 21 3 - TECHNICAL DRAWINGS AND CHARACTERISTICS DIMENSIONS OF MARGHERITA ANDGARDENIA HYDRO VERSION Technical Dept. - All rights reserved - Reproduction is prohibited...
  • Page 22 3 - TECHNICAL DRAWINGS AND CHARACTERISTICS TECHNICAL CHARACTERISTICS Primula Hydro / Orchidea Hydro Nominal output power 21 kW (18060 kcal/h) Nominal output power (H 17,0 kW (14620 kcal/h) Minimum output power 4,4 kW (3784 kcal/h) Minimum output power (H 3,0 kW (2580 kcal/h)
  • Page 23 3 - TECHNICAL DRAWINGS AND CHARACTERISTICS TECHNICAL CHARACTERISTICS Margherita Hydro / Gardenia Hydro Nominal output power 11,6 kW (9976 kcal/h) Nominal output power (H 10,0 kW (8600 kcal/h) Minimum output power 3,6 kW (3096 kcal/h) Minimum output power (H 2,5 kW (2150 kcal/h) Efficiency at Max 91,5% Efficiency at Min...
  • Page 24: 4-Installation And Assembly

    4-INSTALLATION AND ASSEMBLY PREPARATION AND UNPACKING The Primula/Gardenia and Orchidea/Margherita stoves are delivered with two different types of packing: GARDENIA and PRIMULA stoves come in 1 pack • It contains the stove and also the steel sides with the profiles (fig.1) The ORCHIDEA and MARGHERITA stoves come in 2 packs •...
  • Page 25 4-INSTALLATION AND ASSEMBLY The stove body or unit must always be kept in a vertical position when handled and moved by using carts only. Pay particular attention to the door and its glass, protecting them from mechanical knocks that would compromise their integrity. Always handle the product with care.
  • Page 26 ASSEMBLING THE SIDE CLADDING ASSEMBLY OF PROFILES FOR INSERTION OF STEEL SIDES (PRIMULA) Remove, on the upper part, the cast iron top (A). Take the side (B) (make sure it goes into the part under the plugs (F) and secure it to the upper sheet metal of the stove with the bracket (C) and four screws (D).
  • Page 27 4-INSTALLATION AND ASSEMBLY ASSEMBLY OF PROFILES FOR INSERTION OF STEEL SIDES (GARDENIA) Remove, on the upper part, the cast iron top (A). Take the two profiles (B) to be assembled on the front part of the stove (one to the right and one to the left). Make sure that the profile (B) at the bottom enters the hole predisposed for fixing on the base, and that along the side it enters the blade (B1) predisposed in the stove along its entire height.
  • Page 28 4-INSTALLATION AND ASSEMBLY CERAMIC SIDES INSERTION (ORCHIDEA AND MARGHERITA) Remove, on the upper part, the cast iron top (A). Take the six ceramic sides (B) from the box and insert them onto the profile (C) in correspondence of the guide, from the top downwards. Repeat the same operation for both sides.
  • Page 29: 5-Plumbing Connection

    3/4”M heating water return 3/4”M 3 bar 1/2” M safety valve 3/4”M system draining and emptying CONNECTION DIAGRAM FOR THE PRIMULA-ORCHIDEA HYDRO STOVE EQUIPPED WITH KIT FOR DOMESTIC HOT WATER PRODUCTION 3/4”M heating water delivery 3/4”M heating water return 3/4”M 3 bar 1/2”...
  • Page 30 5-PLUMBING CONNECTION CONNECTION DIAGRAM FOR GARDENIA-MARGHERITA HYDRO STOVE 3/4”M heating water delivery 3/4”M heating water return 3/4”M 3 bar 1/2” M safety valve 3/4”M system draining and emptying SYSTEM CONNECTIONS Make the connections to the corresponding fittings shown in the diagram on the previous page. Make sure the pipes are not placed under tension or undersized.
  • Page 31 To allow the valve to vent, it is recommended to loosen the grey cap by one turn and leave the red cap locked (see figure). The filling pressure of the system WHEN COLD must be 1 bar. If during operation the system pressure drops (due to evaporation of gases dissolved in the water) to values lower than the minimum ones indicated above, the user must use the filling tap to bring the pressure back up to its initial pressure.
  • Page 32 5-PLUMBING CONNECTION WATER CHARACTERISTICS The characteristics of the water used to fill the system are very important to prevent the build-up of mineral salts and the formation of incrustations along the pipes, in the boiler and in the heat exchangers. Therefore, please ASK YOUR PLUMBER FOR HIS ADVICE CONCERNING: •...
  • Page 33: Electrical Connections

    6 - ELECTRICAL CONNECTIONS GENERAL PRECAUTIONS Electrical safety of the system is ensured only when it is properly connected to an efficient earthing system made in compliance with the safety standards in force: gas, water or heating systems pipes are not suitable as earth connections. One must check this essential safety requirement;...
  • Page 34: Initial Start-Up

    7 - INITIAL START-UP GENERAL PRECAUTIONS Remove all components that could burn from the brazier and glass (manual, various adhesive labels and any polystyrene). Check that the brazier is positioned correctly and rests properly on the base. After a long period of inactivity, remove any pellets left in the hopper (using a vacuum cleaner with a long pipe ), as they could have absorbed moisture, thereby altering their original characteristics and no longer being suitable for combustion.
  • Page 35 7 - INITIAL START-UP Do not stand close to the product and air the room. The smoke and smell of paint will disappear after about an hour of operation, however, remember they are not harmful in any case. The boiler will be subject to expansion and contraction during the start-up and cooling phases, therefore slight creaking noises may be heard.
  • Page 36 7 - INITIAL START-UP LOADING THE PELLETS Fuel is loaded from the upper part of the stove by opening the door. Pour the pellets into the hopper. To ease the procedure carry out the operation in two steps: Pour half of the contents into the hopper and wait for the fuel to settle on the bottom. Then complete the operation by pouring in the rest.
  • Page 37: Menu Items

    8 - MENU ITEMS CONTROL PANEL DISPLAY Menu items 1. Boiler lighting/shutdown 5. Decrease set temperature/programming functions. 2. Scrolling of programming menu to decrease. 6. Increase set temperature/programming functions. 3. Menu 7. Display. 4. Scrolling of programming menu to increase. MAIN MENU It is accessed by pressing key 3 (menu).
  • Page 38 8 - MENU ITEMS Timer setting (see relative chapter) Sleep setting (see relative chapter) SETTINGS MENU The SETTINGS menu allows to act on the boiler operating mode: a. Language. b. Cleaning (displayed only when the boiler is switched off). Feed screw loading (displayed only when the boiler is switched off). d.
  • Page 39 8 - MENU ITEMS c - Feed screw loading To select “Feed screw loading” (only when the boiler is switched off) act as follows: • Press the “menu” button. • Scroll to “Settings” using the arrows • Press “menu” to confirm. •...
  • Page 40 8 - MENU ITEMS h - Pump On T To select the Pump On T function act as follows: • Press the “menu” button. • Scroll to “Settings” using the arrows • Press “menu” to confirm. • Scroll to “Pump On T” using the arrows. •...
  • Page 41 8 - MENU ITEMS o - Components test To activate the “Components test” function (only when the boiler is switched off) act as follows: • Press the “menu” button. • Scroll to “Settings” using the arrows • Press “menu” to confirm. •...
  • Page 42 Press “menu” to confirm and “esc” to exit. Important! The RED HYDRO stoves come in different types, some have a fan and some have domestic hot water (DHW). Therefore within the stove functions one must bear in mind the features of the purchased product.
  • Page 43: Preliminary Notions

    9 - PRELIMINARY NOTIONS SYSTEM CONFIGURATIONS DEPENDING ON THE MODEL Upon installation, the product must be set according to the type of system, selecting the appropriate parameter in the “SETTINGS” menu. The possible configurations are 5, as described below: Configuration Description Room temperature management via the boiler probe or by enabling the external room thermostat.
  • Page 44 9 - PRELIMINARY NOTIONS CONFIGURATION 2.1 (FACTORY SETTING FOR VERSION WITH DOMESTIC HOT WATER - DHW) CONFIGURATION 2.2...
  • Page 45 9 - PRELIMINARY NOTIONS CONFIGURATION 3 CONFIGURATION 4 Technical Dept. - All rights reserved - Reproduction is prohibited...
  • Page 46 9 - PRELIMINARY NOTIONS CONFIGURATION 5 RED HYDRO STOVE HEATING DELIVERY HEATING RETURN ZONE VALVES HEATING BODIES DOMESTIC HOT WATER COLD DOMESTIC WATER DOMESTIC WATER BOILER DIVERTER VALVE BOILER THERMOSTAT THERMOSTATIC MIXING VALVE DOMESTIC WATER 10 kΩ β3434 NTC PROBE...
  • Page 47 9 - PRELIMINARY NOTIONS ONLY FOR UK GARDENIA/MARGHERITA/PRIMULA/ORCHIDEA HYDRO Technical Dept. - All rights reserved - Reproduction is prohibited...
  • Page 48 9 - PRELIMINARY NOTIONS ONLY FOR UK GARDENIA/MARGHERITA/PRIMULA/ORCHIDEA HYDRO...
  • Page 49 9 - PRELIMINARY NOTIONS ONLY FOR UK GARDENIA/MARGHERITA/PRIMULA/ORCHIDEA HYDRO Technical Dept. - All rights reserved - Reproduction is prohibited...
  • Page 50 9 - PRELIMINARY NOTIONS ONLY FOR UK GARDENIA/MARGHERITA/PRIMULA/ORCHIDEA HYDRO...
  • Page 51: 10-Operation

    10-OPERATION OPERATING MODE The operating mode for hydro boilers is AUTOMATIC only (manual mode is not envisioned). Flame modulation is managed according to the “System configuration” of the room probe placed on the rear of the appliance (see drawing), by the external thermostat, by the boiler water temperature or by the NTC probes.
  • Page 52 10-OPERATION EXTERNAL THERMOSTAT CONNECTION (e) EXTERNAL THERMOSTAT (not included with the boiler, to be provided by the user) The temperature of the boiler can also be controlled by an external room thermostat. It is located in a central position of the room where the boiler is installed.
  • Page 53 10-OPERATION START-UP Press key 1 (esc) to begin start-up, the control panel displays ON with a flashing flame. When the flame stops flashing the boiler has reached the “power output” operating mode. The room temperature set by default is 20°C, if one wishes to change it act as instructed in the adjustments menu; act likewise to set the heating water temperature and the room fan speed (if envisaged).
  • Page 54 10-OPERATION PROGRAMMED MODE (TIMER) - Main menu Setting the current day and time is essential for the proper operation of the timer. There are six TIMER programmes, for each one the user can decide the start-up and shutdown time as well as the day of the week in which it is active.
  • Page 55 10-OPERATION NOTES FOR TIMER OPERATION • Start-up with the timer always takes place with the last temperature and ventilation settings (or with default 20°C and V3 settings in the event they have never been changed). • Start-up time ranges from 00:00 a 23:50 •...
  • Page 56 10-OPERATION AUXILIARY BOILER (see section 8i) One must install an additional module (optional) to enable start-up of an auxiliary boiler in the event the stove is switched off or in alarm conditions. By default this function is deactivated, if needed activate it to access the settings menu. PELLETS RECIPE (see section 8j) This function is for adapting the stove to the pellets that are being used.
  • Page 57 10-OPERATION SEASON FUNCTION (see section 8p) In configurations 2 and 3, by enabling the “summer” function, the deviation of the 3-way valve to the heating system is inhibited in order to prevent the radiators from heating up, therefore the flow is always directed towards the domestic hot water (DHW) - if envisaged. By activating the “summer”...
  • Page 58: 11-Safety Devices And Alarms

    11-SAFETY DEVICES AND ALARMS SAFETY DEVICES The product is supplied with the following safety devices PRESSURE SWITCH Monitors pressure in the smoke duct. It is designed to shut down the pellets feed screw in the event of an obstructed flue or significant back-pressure.
  • Page 59 11-SAFETY DEVICES AND ALARMS TAMPERING WITH THE SAFETY DEVICES IS PROHIBITED If the product is NOT used as described in this instruction manual, the manufacturer declines all liability for any damage caused to persons and property. The manufacturer furthermore refuses to accept responsibility for damage to persons and property arising from the failure to observe all the rules contained in the manual and in particular: •...
  • Page 60 11-SAFETY DEVICES AND ALARMS ALARM ALERTS Whenever an operating condition other than that designed for the regular operation of the boiler occurs, there is an alarm condition. The control panel gives information on the reason of the alarm in progress. A sound signal is not envisioned for alarms A01-A02 only so to not disturb the user in the event of pellets running out in the hopper during the night.
  • Page 61 11-SAFETY DEVICES AND ALARMS NORMAL SHUTDOWN (on the panel: OFF with flashing flame) If the shutdown key is pressed or if there is an alarm signal, the boiler goes into the thermal shutdown phase which entails the automatic execution of the following stages: •...
  • Page 62: 12-Recommendations For A Safe Use

    12-RECOMMENDATIONS FOR A SAFE USE RECOMMENDATIONS FOR A SAFE USE ONLY A SUITABLE INSTALLATION ACCORDING TO THE UK BUILDING REGULATIONS (ADJ) AND A PROPER MAINTAINANCE AND CLEANING OF THE PRODUCT CAN ASSURE YOU THE CORRECT FUNCTIONALITY AND A SAFE USE OF YOUR STOVE(ONLY FOR UK).
  • Page 63: 13-Maintenance And Cleaning

    13-MAINTENANCE AND CLEANING EXAMPLE OF A DIRTY BRAZIER EXAMPLE OF A CLEAN BRAZIER Only a proper maintainance and cleaning of the product can assure you the correct functionality and a safe use of your stove. ATTENTION! All the cleaning operations of all parts must be performed with the product completely cold and the plug disconnected.
  • Page 64 • PRIMULA/ORCHIDEA stoves (Figure 10) – Primula/Orchidea stoves are fitted with a removable ash pan “C” designed to collect any soot and ash build-up. GARDENIA/MARGHERITA stoves (Figure 10a) – Open the door, insert the hook onto the rod of the scraper B (B in figure 10a), shake it vigorously 5-6 times along the entire length.
  • Page 65 ATTENTION: For your safety, the frequency with which the exhaust smoke system is cleaned depends on the intensity of use of the stove. CLEANING THE EXCHANGER AND PIPE UNIT (PRIMULA/ORCHIDEA) CLEANING THE UPPER COMPARTMENT When the stove is cold, remove the top, remove the ceramics/sides, by loosening the relative fastening screws before removing the drivers “B”...
  • Page 66 13-MAINTENANCE AND CLEANING CLEANING THE EXCHANGER AND PIPE UNIT (GARDENIA/MARGHERITA) CLEANING THE UPPER COMPARTMENT When the stove is cold, remove the top, remove the ceramics/sides, by loosening the relative fastening screws before removing the drivers “B” and then remove the boiler cover “C” At this point, remove the four turbulators “D” and using a rigid rod or a bottle brush, clean the internal pipe unit and the turbulators, removing all of the accumulated ash.
  • Page 67 13-MAINTENANCE AND CLEANING ATTENTION: The frequency with which the smoke exhaust must be cleaned depends on the use of the stove and the type of installation. We recommend contacting an authorised service centre for end-of-season maintenance and cleaning as the above- mentioned operations will be performed together with a general inspection of the components.
  • Page 68 13-MAINTENANCE AND CLEANING REPLACEMENT OF OVERPRESSURE SILICON DAMPER FOR COMBUSTION CHAMBER The overpressures sillicon damper “G” for combustion chamber (fig. A) shall be replaced with a new one yearly (during the periodical maintainance) in order to keep the overpressure safety system efficient. For replacement use the following instructions •...
  • Page 69: 14-Problems/Causes/Solutions

    14-PROBLEMS/CAUSES/SOLUTIONS CHECKING THE INTERNAL COMPONENTS ATTENTION! The internal electromechanical components must only be checked by qualified personnel whose technical expertise includes combustion and electricity. It is recommended to perform this routine maintenance annually (with a scheduled service contract), which focuses on a visual and functional verification of the internal components.
  • Page 70: 15-Problems/Causes/Solutions

    15-PROBLEMS/CAUSES/SOLUTIONS ATTENTION: All repairs must only be carried out by a specialised technician, with the product switched off and the plug disconnected. If the product is NOT used as described in this instruction manual, the manufacturer declines all liability for any damage caused to persons and property.
  • Page 71 15-PROBLEMS/CAUSES/SOLUTIONS ANOMALY POSSIBLE CAUSES SOLUTIONS Pellets accumulate in the brazier, the Insufficient combustion air. Clean the brazier and check that all the glass of the door gets dirty and the holes are clear. Perform a general cleaning flame is weak. of the combustion chamber and the smoke duct.
  • Page 72 15-PROBLEMS/CAUSES/SOLUTIONS ANOMALIES RELATED TO THE PLUMBING SYSTEM ANOMALY POSSIBLE CAUSES SOLUTIONS Incorrect combustion adjustment. Check recipe. No increase in temperature with stove in operation. Boiler/system dirty. Check and clean the boiler. Insufficient stove power. Check that the stove is properly sized for the requirements of the system.
  • Page 73: 16-Wiring Diagram

    16-WIRING DIAGRAM ELECTRICAL DIAGRAM OF PRIMULA/ORCHIDEA – MARGHERITA/GARDENIA Hydro WITHOUT DOMESTIC HOT WATER LIVE ELECTRIC CABLES DISCONNECT THE 230 V POWER CABLE BEFORE CARRYING OUT ANY OPERATION ON THE CIRCUIT BOARDS MOTHERBOARD WIRING KEY FUSE 14. EXTERNAL THERMOSTAT CONNECTION (TERMINAL BLOCK) BOARD PHASE 15.
  • Page 74 16-WIRING DIAGRAM ELECTRICAL DIAGRAM OF PRIMULA/ORCHIDEA Hydro WITH DOMESTIC HOT WATER KIT LIVE ELECTRIC CABLES DISCONNECT THE 230 V POWER CABLE BEFORE CARRYING OUT ANY OPERATION ON THE CIRCUIT BOARDS MOTHERBOARD WIRING KEY FUSE 14. EXTERNAL THERMOSTAT CONNECTION (TERMINAL BLOCK) BOARD PHASE 15.
  • Page 75 16-WIRING DIAGRAM ELECTRICAL DIAGRAM OF PRIMULA/ORCHIDEA - MARGHERITA/GARDENIA Hydro WITH HIGH EFFICIENCY PUMP LIVE ELECTRIC CABLES DISCONNECT THE 230 V POWER CABLE BEFORE CARRYING OUT ANY OPERATION ON THE CIRCUIT BOARDS MOTHERBOARD WIRING KEY FUSE 15. INTERNAL ROOM PROBE BOARD PHASE 16.
  • Page 76 Via La Croce n°8 33074 Vigonovo di Fontanafredda (PN) – ITALY Telephone: 0434/599599 r.a. Fax: 0434/599598 Internet: www.mcz.it e-mail: info.red@mcz.it 8901231300 REV 2 12/01/2015...
