KTI Networks KCD-400 Specification Sheet

KCD-400
DIN Rail Mounting Bracket
Panel Mounting Bracket
Industrial 1000Base-T to 1000Base-X
Gigabit Media Converters
The industrial KCD-400 media converter series provides industrial strength Gigabit Ethernet copper
-to-fiber media conversion,allowing for 1000Base-T-to-1000Base-Xover multi-mode or optional
single-mode fiber optical media. With the SFP (Mini-GBIC) connector design,the media converter
not only supports existing variety of multimode and single mode fibers,but also preserves the
flexibility to adapt to any change of your fiber network in the future.
Benefits :
Plug and play design with no configuration setting

Wide operating temperature range for temperature critical environment

Support DIN-rail mounting and panel mounting

Provide two power input types to meet more application needs

Accept wide power input voltage range for application flexibility

Industrial-rated Emission and Immunity performance

Key Features :
Comply with IEEE 802.3ab 1000Base-T,802.3z 1000Base-SX/LX standard

Provide direct media conversion for Gigabit copper and Gigabit fiber

Support full wire speed conversion

Support transparent conversion of any packet types with no packet length limitation

Support auto-negotiation with link partners

Provide link pass through between copper and fiber link

Provide SFP on fiber port for mounting variety of fiber options

Low power consumption

Two power interface types:screw terminal block and DC Jack

Supports DIN-rail mounting and optional screwed plane mounting

Specifications :
Standard IEEE 802.3au, 802.3z
Conversion Direct 1000BASE-T to 1000BASE-X with minimum latency
Packet Types Transparent conversion with no modification to :
- Standard IEEE 802.3 Ethernet packet frames
- IEEE 802.1Q tagged packet frames
Copper Port Shielded RJ-45,1000Mbps
Auto-negotiation capable
Auto-MDI/MDI-X crossover function
Fiber Port SFP connector with pre-configured SFP fiber transceiver
Far End Fault support
Network Cables Copper port : Cat.5e recommended or higher up to 100m
Fiber port :
LEDs Power status, SFP ON status
Link status, Optical link status
MMF 50/125µm, 62.5/125µm, SMF 9/125µm
080110
