- Page 1 STOLZENBERG Kehrmaschinen Operating instructions Matrix, the battery-operated manual sweeper MATRIX MTX-900- V TRS MATRIX MTX-900- B TRS MATRIX MTX-900-VB TRS STOLZENBERG Kehrmaschinen...
-
Page 2: Safety Information
Any risk is to be assumed by the operator. The manual sweeper is not suitable for taking up cords, strings, wires or similar materials. Correct application includes the observation of Operating Instructions as well as inspection and maintenance intervals. STOLZENBERG Kehrmaschinen... -
Page 3: Technical Data
Push the side brushes into the side brush retainers until you feel the side brushes lock into place. Set the side brush arms in their bottom position. • • Connect the battery. See technical data - switching diagram. The sweeper is ready for operation. STOLZENBERG Kehrmaschinen... -
Page 4: Operation
Hold on to the handle and lift the dustbin out of the sweeper's frame. Empty the dustbin in a suitable container. • Insert the dustbin back into the sweeper. • Do not park the sweeper with a full dustbin. Always empty the dustbin once you've finished sweeping. STOLZENBERG Kehrmaschinen... -
Page 5: Service And Maintenance
The machine contains a deep-discharge protection and automatically switches of if such level is reached to protect battery from damage. STOLZENBERG Kehrmaschinen... - Page 6 Position the second split shell on top of the square shaft of the brush roller. • To tighten use three screws for each set of brushes. Tighten until you can no longer see a • gap between the split shells. STOLZENBERG Kehrmaschinen...
-
Page 7: Side Brush Replacement
Please observe! Humidity will damage the electronics and the mechanics of the machine. Moisture may lead to leak current and short-circuits. Do not use high-pressure cleaning devices. The Sweeping & Suction Machine may only be dry-cleaned. STOLZENBERG Kehrmaschinen... -
Page 8: Filter Cleaning
Screw tight the two wing nuts on the threads of the cup square neck bolts of the filter frame. Disposal Disposal of defective parts, specifically electric component parts, batteries and plastic elements in compliance with legislator's waste disposal regulations. STOLZENBERG Kehrmaschinen... -
Page 9: Maintenance Chart
Clean filter Leakage and subsequent aspiration of check for tight fit false air in the filter chamber check if false air is sucked in Ator does not move freely Check ventilator wheel and remove any obstruction STOLZENBERG Kehrmaschinen... - Page 10 D-49124 Georgsmarienhütte declares as solely responsible party, that he product battery-operated manual sweeper MATRIX MTX-900-V TRS, MATRIX MTX-900-B TRS, MATRIX MTX-900-VB this declaration refers to, observes the EG-Guidelinie 89/392/EWG and correspondes to it regarding all relevant safety and health requirements.
