Summary of Contents for STOLZENBERG KSE 910
- Page 1 Operating Manual Battery-operated suction sweeper KSE 910 KSE 910 Date 0507...
-
Page 3: Table Of Contents
Maintenance chart ....................13 Malfunctions / error messages and troubleshooting..........14 Accessories and spare parts ................15 Transport....................... 15 Disposal ........................ 15 Technical Data ...................... 15 Product marking....................16 Service ........................16 Declaration of conformity ..................17 KSE 910 Date 0507... -
Page 4: Introduction
Introduction This operating manual contains instructions for using the hand- operated sweeper KSE 910. Our products are subject to continuous improvement. Therefore, design changes that were made after this manual went to print could not be incorporated. If you have any questions, please contact our Service department. -
Page 5: Safety Device
Never short-circuit battery poles. The batteries must always be kept clean and dry to avoid leakage currents. For avoiding damage to health, smoking, eating and drinking in the vicinity of the battery charging station must be avoided. KSE 910 Date 0507... -
Page 6: Sweeper Description
Sweeper description The suction sweeper is driven by an electric motor. Sweeping is done with two side brushes which convey the refuse to the two sweeping rollers that are mounted at 90 degrees to the direction of motion. The rollers throw the refuse overhead in the rear dirt collector. The dust that is collected by the sweeping rollers is kept in a lamellar filter in the machine by the dust extraction. -
Page 7: Initial Start-Up
Never leave the running machine unattended. Securely switch off the machine (see page 7."Switching off the sweeper“). In this manner, prevent unauthorised use by third parties. KSE 910 Date 0507... -
Page 8: Movement Operation
Movement operation Insert the key in the key switch and rotate it in the clockwise • direction: The electric motor starts. Pull the movement lever. • The sweeper moves forward. If the lever is released, the sweeper remains at standstill. Parking the sweeper Move the machine to an area provided (assigned) for the purpose. -
Page 9: Sweeping Wet Refuse
Lift the dustbin securing device –1-and pull the dustbin on the • handle –2-from the frame of the machine. Empty the dustbin into a suitable container. • Push the dustbin back into the machine. • Do not park the sweeper with a full dustbin. KSE 910 Date 0507... -
Page 10: Cleaning
Cleaning The suction sweeper may only be cleaned in the off state, when it is dry (for example: sweeping away). The suction sweeper is a machine with electrical components. Caution! Moisture damages the electronics of the device. Moisture can result in leakage currents and short-circuits. Do not use any high-pressure cleaners Maintenance Safety information... -
Page 11: Filter Cleaning
Press the side brush upwards till it tangibly clicks into place. • Removing the side brushes Press the clips –1- below the side sweeper brushes inwards and • at the same time, pull down the side sweeper brushes downwards. KSE 910 Date 0507... -
Page 12: Changing The Sweeping Rollers
Changing the sweeping rollers The sweeping roller consists of two split shells with brushes. Screws join the split shells. Dismantling the sweeping roller To dismantle the sweeping roller, follow the procedure below: Remove the dustbin (see the page 8."Emptying the dustbin"). •... -
Page 13: Battery Charging
- Check all seals as to damage and tightness. - Check cable joints for firmness, replace faulty cables. - Check the dust filter and replace if necessary. - Check dust suction for foreign objects, and clean. KSE 910 Date 0507... -
Page 14: Malfunctions / Error Messages And Troubleshooting
Malfunctions / error messages and troubleshooting Error Possible causes Possible remedies Electrical actuators After charging, the battery charging Reinsert the battery charging plug are not working plug was not connected with the on-board charger plug Battery discharged Charge the battery and connect it correctly connected The hood is still open Close the hood... -
Page 15: Accessories And Spare Parts
790 mm Height 740 mm Weight 97 kg Sweeping Width Main sweeping roller 500 mm With Side brushes 900 mm Dust Container Volume 58 L Battery Voltage 12 V Capacity 50 / 66 / 70 / 80 KSE 910 Date 0507... -
Page 16: Product Marking
Product marking Suctionsweeper Tandem KSE 910 Weight: 97 kg Stolzenberg GmbH & Co. KG Hamburger Straße 15-17 D-49124 Georgsmarienhütte Build in: 2007 Serialnumber: 0607058 Power: 0,3 KW Service Stolzenberg GmbH & Co. KG Hamburger Straße 15-17 D-49114 Georgmarienhütte Telefon: 0049 / (0)5401 83 53-0 Fax: 0049 / (0)5401 83 53-11 www.Stolzenberg.de... -
Page 17: Declaration Of Conformity
EC Machine Directive. In case of a change being made that has not previously been agreed with us, this declaration will lose its validity. Manufacturer: Stolzenberg GmbH & Co. KG Designation of the machine: KSE 910 Machine type: Suction sweeper with tandem-roller-system relevant EC Directives:...
