RTI CX7 Quick Reference Manual

Table top controller

Download this manual

CX7

Table Top Controller

Quick Reference Guide

CX7 Inverted

CX7 Rear View

CX7 Display Tilted 10°

From the kitchen table top to the conference room, the hard wired CX7 is perfect wherever "always on", intuitive control

is required. The 7" LCD touchpanel has adjustable tilt, allowing the display to be angled straight up to nearly flat. The

CX7 can even be mounted inverted under a cabinet. Additional features include wired and wireless Ethernet for two-way

control, digital video (motion JPEG) and web browsing, while analog audio/video inputs and stereo speakers provide video

viewing from sources such as satellite TV or security cameras.

The CX7 provides superior quality and reliability as well as these features:

• 800x480 WVGA LCD with integrated multi-touch capacitive touchscreen.

• Composite, S-video and component input for viewing video at 480i, 576i, 480p or 576p.

• Analog audio input and stereo speakers.

• Integrated 10/100 Base-T and 802.11 Wireless Ethernet.

• Built-in high output IR for direct control of devices through an IR connecting block.

• Powered using power supply or PoE (Power over Ethernet).

• Proximity and ambient light sensors automatically wake the unit up and adjust the brightness upon being approached.

• Optional modules/processors provide advanced two-way control of electronics such as media servers, lighting and more.

• USB and Ethernet (hard-wired or wireless) software program updates.

• Adjustable tilt display (from 10°-90°) or CX7 can be mounted inverted under a cabinet.

Need help?

Do you have a question about the CX7 and is the answer not in the manual?

Page 1 CX7 Display Tilted 10° From the kitchen table top to the conference room, the hard wired CX7 is perfect wherever “always on”, intuitive control is required. The 7” LCD touchpanel has adjustable tilt, allowing the display to be angled straight up to nearly flat. The CX7 can even be mounted inverted under a cabinet.
Page 2: Connection Options
Silkscreen Graphics May 27, 2010 Tilting the CX7 Display Scale 1:1 The CX7 display tilts between 10° and 90° by simply pushing or pulling it into to the desired position. NOTE: Forcing the display past these angles may result Camera in damage to the unit.
Page 3 UPDATING SOFTWARE RTI’s Integration Designer data files can be downloaded to the CX7 using a USB cable (USB A to Mini B), or via hard-wired or wireless Ethernet. If the CX7 is hard-wired to a LAN and the router has DHCP enabled, the initial data file can be made over Ethernet.
Page 4 Limited Warranty RTI warrants its products for a period of one (1) year (90 days only for included battery packs); or for a period of time compliant with local laws when applicable from the date of purchase from RTI or an authorized RTI distributor.
