RTI KX7 Quick Reference Manual

In-wall controller
Hide thumbs
1
2
3
4

Advertisement

Quick Links

Download this manual
The KX7 is designed for sophisticated installations that require a touchpanel with the size and power to
take command of a room's environmental and media technology. With advanced features like a multi-touch
capacitive touchscreen, direct IR/RS-232 control and analog video inputs, the KX7 possesses the style and user-
friendliness required to fit any type of setting.
The KX7 provides superior quality and reliability as well as these features:
• Stylish low-profile faceplate with a gloss finish (standard is white, however other faceplate options are available).
• 800x480 WVGA LCD with integrated multi-touch capacitive touch screen.
• Composite, S-Video or component video inputs allow viewing at 480i, 576i, 480p, or 576p.
• RS-232 port for direct control of devices via RS-232 communication.
• High output IR port for direct control.
• Network connectivity via an integrated 10/100 Base-T Ethernet port and 802.11b/g wireless LAN module.
• Completely customizable and programmable.
• Powered using RTI Control Port or PoE (Power over Ethernet).
• Integrated microphone and camera.
• Built-in ambient light and proximity sensors.
• Field upgradable firmware.
• USB and Ethernet programming.
KX7
In-Wall Controller
Quick Reference Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the KX7 and is the answer not in the manual?

Questions and answers

Related Manuals for RTI KX7

Summary of Contents for RTI KX7

  • Page 1 In-Wall Controller Quick Reference Guide The KX7 is designed for sophisticated installations that require a touchpanel with the size and power to take command of a room’s environmental and media technology. With advanced features like a multi-touch capacitive touchscreen, direct IR/RS-232 control and analog video inputs, the KX7 possesses the style and user- friendliness required to fit any type of setting.

  • Page 2: Connection Options

    Touchscreen Control Panel Connection Options The following diagram shows a “control system operation” of the KX7, which utilizes an RTI control processor (RTI XP-6 shown) and an RTI connecting block (RTI CB-8 shown). Mounting Wings (2) - One located on bottom of KX7 also.
  • Page 3 MOunTing WingS Two mounting wings are located on the top and bottom of the KX7, which can be used to secure the KX7 to drywall in retrofit installations. Place KX7 in the opening in the wall and tighten the mounting wing screws located on the front of the KX7 (bezel removed).

  • Page 4: Limited Warranty

    Warranty RTI warrants its products for a period of one (1) year (90 days only for included battery packs); or for a period of time compliant with local laws when applicable from the date of purchase from RTI or an authorized RTI distributor.
