- Page 1 Installation Guide 10/100 Dual-speed Fast Ethernet PCI Adapters KF223TX, KF230TX DOC.971115-KF223/230TX-K P/N:750-0099-001...
- Page 2 Ó 1997, KTI Networks Inc. All rights reserved. No part of this docu- mentation may be reproduced in any form or by any means or used to make any directive work (such as translation or transformation) without permission from KTI Networks Inc.
- Page 3 TRADEMARKS Ethernet is a registered trademark of Xerox Corp. NetWare is a registered trademark of Novell Inc. WARNING: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 4: Installation Guide
10/100BASE-TX FAST ETHERNET PCI ADAPTERS INSTALLATION GUIDE DOC.971114 DF223TX-KF230TX-NK P/N:750-0099-002... -
Page 5: Table Of Contents
1. Introduction 1.1 Adapter Features ... 1 1.2 Connector and LEDs ... 2 2. Installing the Adapter 2.1 Installing the Adapter ... 3 2.2 Connecting to the Network ... 4 3. Network Driver Installation 3.1 Driver Information ... 7 3.2 PCI BIOS Setup ... 8 4. -
Page 6: Introduction
1. Introduction The 10/100BASE-TX Fast Ethernet PCI Adapter is a 32-bit LAN adapter for use in personal computers with PCI computer bus slots. This adapter is a dual-speed adapter and features one RJ-45 connec- tor for either a 10 Mbps or a 100 Mbps IEEE 802.3 Ethernet network connection over unshielded twisted-pair (UTP) cable. -
Page 7: Connector And Leds
1.2 Connector and LEDs Figure 1-1 shows the connector and LEDs on the adapter. The fol- lowing table describes these components. No. Components 10/100 Mbps network connector cable for 10Mbps or 100 Mbps 100Mb Link LED 10Mb Link LED Activity status LED This LED indicates a receive or a Figure 1-1 Network Connector and LEDs Description This RJ-45 connector requires UTP... -
Page 8: Installing The Adapter
2. Installing the Adapter This chapter describes how to install the Fast Ethernet PCI adapter in a PCI computer and how to connect the adapter to the network. Before installing the adapter, you need the following: • A computer system that is compliant with the PCI specifications version 2.0 or later. -
Page 9: Connecting To The Network
Figure 2-1 Inserting the Adapter into the PCI Slot 2.2 Connecting to the Network This section describes how to connect 10 Mbps or 100 Mbps net- work cables to the adapter. The rear bracket of the Fast Ethernet adapter contains one RJ-45 connector. The connector is used for either 100Mbps 100BASE-TX connection or 10Mbps 10BASE-T con- nection. -
Page 10: Figure 2-3 Connecting 10Base-T Cable
10 Mbps Connection For 10BASE-T Ethernet networks, the Fast Ethernet adapter uses Category 3, 4, or 5 UTP cable. To establish a valid 10 Mbps connec- tion, the cable must be connected to a 10BASE-T hub. Connect the network cable as follows: 1. -
Page 11: Figure 2-4 Connecting 100Base-Tx Cable
100 Mbps Connection For 100BASE-TX Fast Ethernet networks, the adapter supports Cat- egory 5 UTP cabling. To establish a valid 100 Mbps connection, the cable must be connected to a 100BASE-TX hub. 1. Make sure that the plug on the cable is wired appropriately for a standard 100BASE-TX adapter. -
Page 12: Network Driver Installation
3. Network Driver Installation After making the connection to the network, you must install the adapter network driver in order to connect the Fast Ethernet adapter to your network operating system. 3.1 Driver Information The adapter driver diskette contains the latest versions of the net- work drivers available when the adapter is shipped from the factory. -
Page 13: Pci Bios Setup
may be included in the driver diskette after this guide is published. Please refer to the \README.DOC file first for the latest informa- tion before you install any drivers. 3.2 PCI BIOS Setup Before installing the driver, it is recommended to run the system PCI BIOS setup utility to check each PCI slot that contains a Fast Ethernet PCI adapter for the following PCI settings: 1. -
Page 14: Running Setup Program
4. Setup Program 4.1 Running Setup Program One setup program, SETUP.EXE, is contained in the adapter driver diskette. The Setup program is a DOS program for you to perform the following functions from its main menu as illustrated in Figure 4-1: Install menu: supports a quick method to install NetWare DOS ODI client driver on your computer. - Page 15 You can run the program and perform the tests at any time after installing the adapter to verify the installation or you can run it when a fault is suspected. Before running the program Before running the setup program, make sure that the adapter is cor- rectly installed in a computer with the PCI bus.
-
Page 16: Figure 4-2 Adapter Information
Starting the Setup Program To start the Setup program, follow these steps: 1. Insert the adapter driver diskette labeled "1 of 2" into floppy disk drive A:. 2. Execute the following command from DOS prompt: A>SETUP <enter> A screen appears showing a menu bar on top of the screen and an information window for the first adapter found in the computer on the bottom portion of the screen as illustrated in the following figure: Figure 4-2 Adapter Information... -
Page 17: Functions On The Main Menu
4.2 Functions on the Main Menu This section describes the functions of "Install", "Setup", and "Diag- nostics" menu on the main menu as follows: Running "Install" Menu The "Install" menu provides two functions as follows: • Install NetWare DOS ODI driver This function provides a convenient and quick method to install the Novell's NetWare DOS ODI driver for your computer without the need for Novell's installation diskettes. -
Page 18: Figure 4-4 Setup Menu
Running "Setup" Menu This menu allows you to configure full-duplex mode for the adapter before running Connectivity test. Figure 4-4 Setup Menu "Auto Detection" selection allows adapter to configure du- plex mode automatically. "Full Duplex Enabled" selection will force the adapter to use full duplex mode. This setting will not be effective after any network driver is loaded or the computer is reboot. -
Page 19: Figure 4-5 Diagnostics Menu
Running "Diagnostics" Menu This menu provides two useful functions: Diagnostics and Connectiv- ity test. Figure 4-5 Diagnostics Menu Diagnostics test function allows you to test the major components and verify the basic operations of the selected adapter. It performs many tests for the selected adapter and indicates the result of each test on a report window. - Page 20 To set up an echo station, follow these steps: 1. Install another adapter which is known to have no problem into a second computer as instructed in Chapter 2. 2. Run SETUP.EXE on that computer. 3. Press [F10] and press [® ] to select "Diagnostics" from the main menu.
- Page 21 4. Select "Connectivity Test" and press [Enter]. 5. Make sure an echo station is ready. Select "Start Network Link Test" from "Connectivity Test" pop-up window and press [OK] to start the test. A status window will report several packet counters as shown below: The "Transmit"...
-
Page 22: Led Indicators
5. LED Indicators Each Fast Ethernet adapter has three LEDs, as shown in Figure 1-1. 5.1 Interpretations The interpretations of the LEDs are: 100Mb LED indicates an active 100Mbps connection is established. On : Good connection between adapter and 100BASE-TX hub Off : No connection between adapter and hub Blink: Not applicable... -
Page 23: Appendix A.1 Specifications
100 Mbps IEEE 802.3u 100BASE-TX Fast Ethernet Dimensions: MX98713 NIC 80mm x 125mm (3.15" x 4.92") KF223TX NIC 80mm x 125mm (3.15" x 4.92") RTL8139 NIC 50mm x 120mm (1.97" x 4.72") KF230TX NIC 50mm x 120mm (1.97" x 4.72") RTL8139 NIC 50mm x 120mm (1.97"... -
Page 24: Connectors & Cable
A2. RJ-45 Connector & Cables Figure A-1 shows the pin assignments of the RJ-45 connector for 10BASE-T and 100BASE-TX network. The pin assignments are iden- tical for 10BASE-T and 100BASE-TX, using Category 5 UTP cable. Pin Signal Name Transmit + Transmit - Receive + NC (no connection) -
Page 25: Auto-Negotiation Function
A.3 Auto-negotiation Function The adapter is equipped with an auto-negotiation function. Auto-ne- gotiation is a negotiation procedure between two connected devices. Both devices must be auto-negotiation capable. The procedure de- cides the best operation modes that can be used for the data transfer operation between two connected devices. -
Page 26: Diagnostics Report
A.4 Diagnostics Report When running "Diagnostics" from the SETUP program, the program indicates the result of each test on the Diagnostics Report window. Depending on the adapter model, the report window is shown as fol- lows: MX98713 NIC RTL8139 NIC... -
Page 27: Installing Remote Boot Rom
A.5 Installing Remote Boot ROM Before you can use the remote boot function, you have to setup the remote boot service on the file server and install the remote boot ROM onto the adapter. To install the boot ROM, make sure the notch of the boot ROM is in the same direction as the notch of the socket on the adapter.
