This series is a compact and fully pure sinewave line interactive UPS, and it
designs for critical application and environment, such as desktops, servers,
workstations, and other networking equipments. This model is available in the
output ratings of 750, 1000, 1500, 2000, and 3000VA. This series protects
your sensitive electronic equipments against power problems including power
sags, spike, brownouts, line noise, and blackouts.
This series designs from two-in-one form factor; it can be placed either in
Rack 2U or Tower. The front panel of the UPS includes LED indicators and
four push buttons (Power Switch, UPS Test/Silence, Configure, and Enter)
that allow to monitor easily, configuration and control, AC line-in, notification
of site wiring fault and output load status of the UPS. It also includes four
LED bar graphic (Load/Battery Level Indication); two status indications (On
AC, On Battery); five alarm indications (Overload, Over Temperature, Site
Wiring Fault, Battery Fault, Self Test Failure). A push button from the front
panel allows silencing of the AC fail alarm and the initiation of the UPS self
test sequence as well. The UPS case for 750 ~ 2000VA is made of plastic as
well as 3000VA is made of metal.
This series is powered from the AC mains and supply AC outputs via
receptacles on the rear panel. Communication and control to the unit is
available through serial or USB ports located on the rear panel. The serial
port will support communications directly with a server. The communications
protocol for the serial ports shall conform to true RS232 interface.
Features:
Microprocessor control guarantees high reliability
High frequency design
Built-in boost and buck AVR
User replaceable design for 1500VA or above
Selectable output range and line sensitive
Cold startup capability
Built-in Dry contact/RS-232/USB communication port
SNMP allows for web-based remote or monitoring management
Enable to extend runtime with scalable external battery pack for
1500VA or above
Overload, Short-circuit, and overheat protection
Rack/Tower 2 in 1 Design
19" rack mount available for all models
