USER'S MANUAL
MaxPower 1000 UPS
Uninterruptible Power System
28-2MAXPO0019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MaxPower 1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Centralion MaxPower 1000

Summary of Contents for Centralion MaxPower 1000

  • Page 1 USER’S MANUAL MaxPower 1000 UPS Uninterruptible Power System 28-2MAXPO0019...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS – This manual contains important instructions for the model MaxPower 1000 that should be followed during installation and maintenance of the UPS and batteries.

  • Page 3: Safety Caution

    Safety – CAUTION! This product is specially designed for PCs and it is not recommended for use in any life-supporting system and other specific important equipment. This equipment can be operated by any individual with no previous training. Do not plug household appliances such as hair dryers to UPS receptacles.
  • Page 4 Servicing of batteries should be performed or supervised by personnel knowledgeable of batteries and the required precautions. Keep unauthorized personnel away from batteries. When replacing batteries, replace with the same type and number of the sealed lead-acid batteries. The maximum ambient temperature rating is 40 . This pluggable type A equipment with battery already installed by the supplier is operator installable and may be operated by laymen.

  • Page 5: System Description

    System Description Front panel: Power Switch 1. UPS status Indicator – AC Mode: Green lighting Battery Mode: Green flashing Fault LED: Red flashing Back Panel 1. Output receptacles 4. AC Input 2. Fuse 5 Modem/Phone Line Surge 3. AC Input with AC fuse Protection (Option)
  • Page 6 Installation and operation 1. Inspection Remove the UPS from its packaging and inspect it for damage that may have occurred during shipping. If any damage is discovered, repack the unit and return it to the place of purchase. 2. Charging This unit is shipped from the factory with its internal battery fully charged, however, some charge may be lost during shipping and the battery should be recharged prior to use.
  • Page 7 4. Computer Connection Plug the UPS into a 2-pole, 3-wire grounded receptacle. Then connect one computer-related device into each of the power receptacles supplied on the back of the UPS. 5. Modem/Phone Line Connection Plug incoming internet line into the “In” socket at the back of the UPS. Use one more Internet line cable and plug one end of the Internet line cable to the “Out”...

  • Page 8: Troubleshooting

    3. Trouble Shooting Symptom Possible Cause Remedy No LED display 1. Battery Weak 1. Re-charge battery up to 8 on the front hours. panel. 2. Battery defect. 2. Replace with the same type of battery. 3. Power switch is not 3.

  • Page 9: Specification

    4. Specification MODEL MaxPower 1000 CAPACITY VA/W 1000VA/600W INPUT Voltage 110/120VAC or 220/230/240VAC Voltage Range 90-145VAC / 170-280VAC OUTPUT Voltage 110/120VAC or 220/230/240VAC Voltage Regulation(Batt. ±10% Mode) Frequency 50Hz or 60Hz Frequency Regulation (Batt. +/-1 Hz Mode) Output Waveform (Batt. Mode)
