Commando Combo Installation Manual

Commando-combo remote auto alarm & start
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

Enlarged version

LIMITED LIFETIME WARRANTY

This vehicle security systems is warranted to the original consumer pur-
chaser, to be free from defects in material and workmanship. The manufac-
turer will repair or replace, at it's option, and free of charge during the first 12
months of the warranty period, any part which prove defective in material or
workmanship under normal installation, use and service, provided the product
is returned to our factory, transportation charges prepaid. Products returned to
our factory must be accompanied by copy of purchase receipt. Warranty is
limited to defective parts and/or replacement parts only and excludes any
incidental and consequential damages connected therewith. The manufac-
turer, of this theft deterrent systems makes no warranty against the theft of
vehicle or its content. This warranty is not to be construed as an insurance
policy against loss.
After the first 12 months of the warranty period there will be a charge of $25.00
maximum per calendar year (if required) for repairing and/or replacing any
defective parts.
WARRANTY ON INSTALLATION LABOR, REINSTALLATION AND REMOVAL CHARGES
ARE NOT THE RESPONSIBILITY OF THE MANUFACTURER.

OPTIONAL ACCESSORIES

Remote Pager
Glass Break Sensor
Interior Radar Sensor
Window Roll-Up Module
Trunk Release Solenoid
Rechargeable Back-Up Battery Siren
Thank You For Choosing
COMMANDO VEHICLE SECURITY
GNU Industries INC.
Technical Support (954)741-5191
SUPPORT@auto-starter.com
info@auto-starter.com
c 04-2001
COMMANDO
VEHICLE SECURITY
COMMANDO-COMBO
REMOTE AUTO
ALARM & START
INSTALLATION MANUAL
Two 3 Channel (4 Button) Transmitter
2nd Channel Output for Trunk release
Door Entry Protection
Personal Panic Feature
Shock Sensor / Dual Zone Dual Adjust
Remote Trigger Disable
Dome Light Supervision
Five Function LED Plug-In
120dB 6 Tone Siren
Last Door Automatic Arming
Door Locking & Unlocking W/ Ign. Key
MADE IN USA
Remote Start
Vacuum System Sense (Optional )
Factory Alarm Disarm
Double Pulse Unlock
2nd Ignition Relay On Board
Tach & Spark Plug Sense
Flashing Parking Lights
Valet Override Switch Plug-In
Remote Door Lock/Unlock Plug-In
Cold Start Every 2 Hours
Stop & Go By Remote

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Combo and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Commando Combo

Summary of Contents for Commando Combo

  • Page 1: Limited Lifetime Warranty

    Thank You For Choosing Dome Light Supervision Flashing Parking Lights Five Function LED Plug-In Valet Override Switch Plug-In COMMANDO VEHICLE SECURITY 120dB 6 Tone Siren Remote Door Lock/Unlock Plug-In Last Door Automatic Arming Cold Start Every 2 Hours GNU Industries INC.

  • Page 2: System Contents

    SYSTEM CONTENTS TROUBLE SHOOTING Each system contains the following components: Suggestions Problem Probable Cause 1- Brain Module 2- 4 Button Transmitters Main inputs heavy gauge red All power inputs are not Unit will not operate wires and red fused wire on connected to 12V+ 1- External Receiver W/ harness main harness must be...

  • Page 3: Programming The Unit

    PASSKEY & P.A.T.S. BYPASS PROGRAMMING THE UNIT The GM PASSKEY 3 AND FORD P.A.T. Antitheft system works with a glass tube called ACTIVE ARMING MODE: a transponder located in the ignition key that sends and receives data via a coil on the Arm the alarm system by pressing the transmitter button #1, once momentarily.

  • Page 4: Before Installation

    BEFORE INSTALLATION PROGRAMMING THE UNIT BEFORE PROGRAMING ANY TRANSMITTERS OR TESTING THE UNIT MAKE SURE THE 1- Before you start installation: ANTENNA - RECEIVER IS PLUGED IN TO THE UNIT. !!!!!!!! Verify that the vehicle is equipped with an electronic fuel injection and automatic 1- CODE TEACHING: transmission.

  • Page 5: Remote Start Features

    DOOR LOCK WIRING DIAGRAM REMOTE START FEATURES 3 Wire Negative Door Lock System 3 Wire Positive Door Lock System REMOTE START FUNCTIONS: Alarm Door Unlock Wire Alarm Door Lock Wire Alarm Door Lock Wire 1.- Press button #4, Siren will cherp 3 times parking lights will turn on solid, LED 12V Power (+) will begin to flash rapidly to verify that the vehicle is about to start remotely.
  • Page 6 Plug in Door Lock Unlock Wire. 3- PIN WHITE CONNECTOR:--------- Yellow---- Brake Light Switch Plug in LED and mount in a desirable location. 2- PIN RED CONNECTOR:------------ COMBO 2- PIN BLUE CONNECTOR:---------- Plug in PROGRAM/VALET Switch. Violet - Starter 2- PIN BLUE CONNECTOR:---------- Orange - Accessory Plug in Horn / Dome Light Wire.
