Note
You must have RAID-1 implemented to use the hot swap feature.
1. Locate the hard-disk drive to remove.
2. Press the hot swap button on the hard-disk drive with an open paper clip or similar device
and wait for the hot swap LED to illuminate solid blue.
3. Loosen the retaining screws on both sides of the hard-disk drive.
Caution
To avoid damage to the ejector and locking lever, loosen the retaining screw behind
each ejector and locking lever before you remove the hard-disk drive.
IP1280 Security Platform Installation Guide
HARD DRIVE
STATUS
ACTIVITY
Installing or Replacing Hard-Disk Drives
POWER
HOT SWAP
READY
REQUEST
Hot swap button
and hot swap LED
00621
