Product User Manual
and enterprise branch and head offices JNC9B-F
www.enochsystems.com
1-877-722-1116
sales@enochsystems.com
Copyright © 2013 Enoch Systems, LLC, Enoch Systems and the Enoch Systems logo are trademarks or registered trademarks of Enoch Systems, LLC and/or its affiliates in the U.S. and other countries.
Third-party trademarks mentioned are the property of their respective owners. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JNC9B-F and is the answer not in the manual?

Questions and answers

Related Manuals for Enoch Systems JNC9B-F

Summary of Contents for Enoch Systems JNC9B-F

  • Page 1 Copyright © 2013 Enoch Systems, LLC, Enoch Systems and the Enoch Systems logo are trademarks or registered trademarks of Enoch Systems, LLC and/or its affiliates in the U.S. and other countries. Third-party trademarks mentioned are the property of their respective owners. All rights reserved.
  • Page 2 TECHNICAL MANUAL Intel HM67 Express Chipset Based Mini-ITX M/B No：G03-NC9B-F Revision: 2.0 Release date: September 19, 2012 Trademark: * Specifications and Information contained in this documentation are furnished for information use only, and are subject to change at any time without notice, and should not be construed as a commitment by manufacturer.
  • Page 3 Environmental Protection Announcement Do not dispose this electronic device into the trash while discarding. To minimize pollution and ensure environment protection of mother earth, please recycle.

  • Page 4: Table Of Contents

    TABLE OF CONTENT ENVIRONMENTAL SAFETY INSTRUCTION................iii USER’S NOTICE ........................iv MANUAL REVISION INFORMATION ..................iv ITEM CHECKLIST ........................iv CHAPTER 1 INTRODUCTION OF THE MOTHERBOARD FEATURE OF MOTHERBOARD................1 SPECIFICATION ......................2 LAYOUT DIAGRAM....................3 CHAPTER 2 HARDWARE INSTALLATION JUMPER SETTING .....................

  • Page 5: Environmental Safety Instruction

    Environmental Safety Instruction Avoid the dusty, humidity and temperature extremes. Do not place the product in any area where it may become wet. 0 to 60 centigrade is the suitable temperature. (The figure comes from the request of the main chipset) Generally speaking, dramatic changes in temperature may lead to contact malfunction and crackles due to constant thermal expansion and contraction from the welding spots’...

  • Page 6: User's Notice

    USER’S NOTICE COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN PERMISSION OF THE MANUFACTURER.

  • Page 7: Chapter 1 Introduction Of The Motherboard Feature Of Motherboard

    Chapter 1 Introduction of the Motherboard Feature of Motherboard Intel HM67 express chipset Intel rPGA988B CPU socket supporting compatible Intel Core™ i3, i5, i7 Mobile Processors Support DDRIII DIMM 1066/1333 up to GB and dual channel function Onboard Intel 82579 LM Gigabit Ethernet LAN Integrated VIA VT 1705 6-channel HD Audio Codec Support USB 2.0 data transport demands Support USB 3.0 data transport demands...

  • Page 8: Specification

    1-2 Specification Spec Description Design Mini-ITX form factor 6 layers ; PCB size: 17.0x17.0cm Intel HM67 Express Chipset Chipset Intel socket G (rPGA 988B) CPU Socket Support up to Intel Core™ i3, i5, i7 Mobile Processors 2 * SODIMMs Sockets Support two DDRIII 1333/1066 MHz SODIMMs expandable Memory Socket to 16 GB...

  • Page 9: Layout Diagram

    Optical S/PDIF Connector x1 Front panel audio header x1 SATAIII Connector x2 SATAII Connector x3 CDIN header x1 LVDS header x1 LVDS Inverter x1 HDMI_SPDIF header x1 Serial port header x1 RS422/RS485 header x1 Front panel header x1 CIR header x1 GPIO header x1 Layout Diagram RJ-45 LAN Connector...
  • Page 10 SATAII Ports (SATA1/2/3/4/5) PS/2 KB Port over USB 3.0 Ports Headers ATX Power HDMI Connector Connector GPIO Header CPUFAN Intel HM 67 Chipset SYS FAN1 Header Header LVDS Header DVI Connector over VGA ATX 12V Power Connector Connector LVDS Inverter Intel DDRIII Memory Modules CPU Socket...
  • Page 11 JP 4 JBAT 1...
  • Page 12 Jumper Jumper Name Description JBAT1 CMOS RAM Clear Function Setting 3-pin Block KB/MS Power On Function Setting 3-pin Block LVDS PVCC 5V/3.3V Select 3-pin Block USB Power On Function Setting 3-pin Block Inverter power 5V/12V Select 3 pin Block USB Power On Function Setting 3 pin Block COM1 Header RS232/485/422 Function Select 6-pin Block...
  • Page 13 Headers Header Name Description FP_AUDIO Front panel audio Headers 9-pin block CDIN CD Audio-In Header 4-pin Block INVERTER LVDS Inverter Connector 7-pin Block LVDS LVDS Header 32-pin Block HDMI-SPDIF SPDIF-Out header 2-pin Block COM1 Serial Port Header 9-pin Block TX-RXCOM RS 22/485 Port Header 4-pin block USB1/USB2...

  • Page 14: Hardware Installation

    Chapter 2 Hardware Installation 2-1 Jumper Setting (1) Clear CMOS (3-pin): JBAT1 JBAT1 1-2 Short： Normal 2-3 Short： Clear CMOS CMOS Clear Setting (2) KB/MS Power On Function Setting (3-pin):JP1 1-2 Closed: KB/MS Power-on Disabled(Default) 2-3 closed: KB/MS Power-on Enabled...
  • Page 15 (3) LVDS PVCC 5V/3.3V Select (3-pin): JP3 1-2 closed : panel power 5v 2-3 closed: panel power3.3v (4) USB Power On Function Setting (3-pin): JP4 1-2 closed : USB Power-on Disable (Default) 2-3 closed: USB Power-on Enable (5) Inverter power 5V/12V Select (3-pin):JP5 1-2 closed: Inverter power 5V 2-3 closed : Invertet power 12V...
  • Page 16 (6) USB Power On Function Setting (3-pin): JP6 1-2 closed: USB Power On Disable 2-3 closed: USB Power On Enable (7) COM1 Header RS232/485/422 Function Select (6-pin): JP7 1-2 closed: RS232 3-4 closed : RS485 5-6 closed : RS422 (8) COM1 Header Pin9 function Select (6-pin): JP8 1-2 closed: RS232 3-4 closed : +12V 5-6 closed : +5V...

  • Page 17: Connectors And Headers

    (9) Mini PCI-E Slot Power 3.3V/3V Select (3-pin): JP9 2-3 closed ： MINI PCI-E 1-2 closed ： MINI PCI-E Slot Power 3VSB Slot Power 3.3V Connectors and Headers 2-2-1 Connectors (1) Rear Panel Connectors RJ-45 LAN Connector PS/2 Keyboard E-SATA Connecter Line-IN Connector...

  • Page 18: Headers

    SATA 4 SATA 2 SATA 1 SATA 3 SATA 5 Serial-ATAII Connectors 2-2-2 Headers (1) Line-Out, MIC-In Header (9-pin): FP_AUDIO This header connects to Front Panel Line-out, MIC-In connector with cable. FP_AUDIO Pi n 1 Line-Out, MIC Headers...
  • Page 19 (2) CD AUDIO-In Headers (4-pin): CDIN CDIN are the connectors for CD-Audio Input signal. Please connect it to CD-ROM CD-Audio output connector. CD-L CD-R CDIN CD Audio-In Headers (3) LVDS Inverter headers: INVERTER Pin 1 and pin2: VCC of inverter Pin3, pin4 and pin6: GND Pin5: Backlight Pin7: Brightness...
  • Page 20 (4) LVDS Headers(32 Pin): LVDS Pin NO. Pin Define Pin NO. Pin Define Pin 1 Pin 2 LVDSB_DATAN3 LVDSB_DATAP3 Pin 3 Pin 4 LVDS_CLKBN LVDS_CLKBP Pin 5 Pin 6 LVDSB_DATAN2 LVDSB_DATAP2 Pin 7 Pin 8 LVDSB_DATAN1 LVDSB_DATAP1 Pin 9 Pin 10 LVDSB_DATAN0 LVDSB_DATAP0 Pin 11...
  • Page 21 (5) HDMI SPDIF Out header (2-pin): HDMI_SPDIF The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder. Use this feature only when your stereo system has digital input function. HDMI_SPDIF_OUT1 HDMI_SPDIF Header (6) Serial Port Connectors (9-Pin female): COM1...
  • Page 22 (7) RS422/485 Header: TX-RXCOM Pin 1 TX-RXCOM TX-RXCOM Header USB 2.0 Port Headers (9-pin): USB1/USB2 Pin 1 USB Port Header (9) Power LED: PWR LED The Power LED is light on while the system power is on. Connect the Power LED from the system case to this pin.
  • Page 23 PWRLED Pin 1 PERLED Header Pin 1 Speaker Header Pin 1 CIR Header (12) Front Panel Header: JW-FP JW_FP Pin 1 System Case Connections...
  • Page 24 (13)FAN Speed Headers (3-pin): CPUFAN1, SYSFAN1/SYSFAN2 Pin1: GND Pin2: +12V fan power Pin3: Fan Speed SYSFAN1 CPUFAN SYSFAN2 (14) GPIO Header (10-pin): GPIO_CON Pin 1 GPIO_CON Header...

  • Page 25: Chapter 3 Introducing Bios

    Chapter 3 Introducing BIOS Notice! The BIOS options in this manual are for reference only. Different configurations may lead to difference in BIOS screen and BIOS screens in manuals are usually the first BIOS version when the board is released and may be different from your purchased motherboard. Users are welcome to download the latest BIOS version form our official website.

  • Page 26: Bios Menu Screen

    BIOS Menu Screen The following diagram show a general BIOS menu screen: Menu Bar General Help Items Current Setting Value Menu Items Function Keys BIOS Menu Screen Function Key In the above BIOS Setup main menu of, you can see several options. We will explain these options step by step in the following pages of this chapter, but let us first see a short description of the function keys you may use here: Press←→...

  • Page 27: Getting Help

    Press <Enter> to select. Press <+>/<–> keys when you want to modify the BIOS parameters for the active option. [F1]: General help. [F2]: Previous value. [F3]: Optimized defaults. [F4]: Save or Reset Press <Esc> to quit the BIOS Setup. Getting Help Main Menu The on-line description of the highlighted setup function is displayed at the top right corner the screen.

  • Page 28: Main Menu

    Main Menu Main menu screen includes some basic system information. Highlight the item and then use the <+> or <-> and numerical keyboard keys to select the value you want in each item. System Date Set the date. Please use TAB to switch between data elements. System Time Set the time.

  • Page 29: Advanced Menu

    3-7 Advanced Menu Launch PxE OpROM Use this item to enable or disable boot option for legacy network devices. Launch Storage OpROM Use this item to enable or disable boot option for legacy mass storage devices with option ROM. ► PCI Subsystem Settings Press [Enter] to enter and make settings for the following sub-items ：...
  • Page 30 Use this item to enable or disable PCI express device relaxed ordering. Extended Tag If set as [Enabled] it will allow device to use 8-bit tag filed as a requester. No Snoop Use this item to enable or disable PCI Express device No Snoop option. Maximum Payload Use this item to set maximum payload of PCI Express device or allow system BIOS to select the value.
  • Page 31 CIR Wakeup Use this item to enable or disable CIR wakeup. PS2 KB/MS Wakeup Use this item to enable or disable PS2 KB/MS wakeup function. ► CPU Configuration Hyper-Threading The optional settings are: [Disabled]; [Enhanced]. Active Processor Cores Use this item to select number of cores to enable in each processor package. Limit CPUIO Maximum This item should be set as [Disabled] for Windows XP.
  • Page 32 ► SATA Configuration SATA Controller(s) Use this item to enable or disable SATA Device. SATA Mode Selection Use this item to determine how SATA controller(s) operate. The optional settings are: [IDE Mode]; [AHCI Mode]; [RAID Mode]. ► PCH-FM Configuration Use this item to enable or disable Me FM Image Re-Flash fuction. ►...
  • Page 33 Use this item to select the primary connect. The optional settings are：[Keyboard First]; [Mouse First]. Serial Port Use this item to enable or Disable serial port (COM). Change Settings Use this item to select an optimal setting for super IO device. Serial Port Mode Select Use this item to set serial port as RS232 or RS485.
  • Page 34 CPU IO Voltage Select Use this item to select a value for CPU IO Voltage. PCH Core Voltage select Use this item to select a value for PCH core voltage. CPU SA Voltage Select Use this item to select a value for CPU SA Voltage. DRAM Voltage select Use this item to select a value for DDR3 DRAM voltage.

  • Page 35: Chipset Menu

    3-8 Chipset Menu ► System Agent (SA) Configuration. VT-d The optional settings: [Enabled]; [Disabled]. Enable NB CRIO The optional settings: [Enabled]; [Disabled]. ► Intel IGFX Configuration Primary Display Use this item to select which of IGFX/PEG/PCI Graphics device should be Primary Display or select SG for Switchable GFX.
  • Page 36 The optional settings are: [Enabled]; [Disabled]; [Auto]. GTT Size Use this item to select the GTT Size The optional selecting are：：[1MB]; [2MB]. Aperture Size Use this item to select the Aperture Size The optional selecting are：[128MB]; [256MB];[512MB]. DVMT Pre-Allocated Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device.
  • Page 37 Use this item to enable the PEG slot. The optional settings are: [Enabled]; [Disabled]. PEG ASPM Use this item to control ASPM support for the PEG Device. This has no effect if PEG is not the currently active device. The optional selecting are: [Disabled]; [Auto] [ASPM LOS]; [ASPM L1];[ASPM LOSL1].
  • Page 38 The optional settings are: [Enabled]; [Disabled]. Enable SB CRIO Use this item to enable SB Compatible IO. The optional settings are: [Enabled]; [Disabled]. High Precision Timer Use this item to enable or disable the High Precision Event Timer. The optional settings are: [Enabled]; [Disabled]. SLP_S4 Assertion width Use this item to select a minimum assertion width of the SLP_S4# signal.

  • Page 39: Boot Menu

    3-9 Boot Menu Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key. Bootup Numlock State Use this item to select keyboard numlock state. The optional settings are: [On]; [Off]. Quiet Boot Use this item to enable or disable Quiet Boot option. The optional settings are: [Enabled];...

  • Page 40: Security Menu

    Option ROM Message Use this item to set display mode for option ROM. The optional settings are: [Force BIOS]; [Keep Current]. Interrupt 19 Capture The optional settings are: [Enabled]; [Disabled]. 3-10 Security Menu Security menu allow users to change administrator password and user password settings.

  • Page 41: Save & Exit Menu

    3-11 Save & Exit Menu Save & Exit menu allows user to load optimal defaults, save or discard your changes to BIOS items.
