Product Installation Guide
nterprise branch and head offices
WAFER-US15WP-Z510P-R10
www.enochsystems.com
1-877-722-1116
sales@enochsystems.com
Copyright © 2013 Enoch Systems, LLC, Enoch Systems and the Enoch Systems logo are trademarks or registered trademarks of Enoch Systems, LLC and/or its affiliates in the U.S. and other countries.
Third-party trademarks mentioned are the property of their respective owners. All rights reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Enoch Systems WAFER-US15WP-Z510P-R10
Summary of Contents for Enoch Systems WAFER-US15WP-Z510P-R10
- Page 1 Copyright © 2013 Enoch Systems, LLC, Enoch Systems and the Enoch Systems logo are trademarks or registered trademarks of Enoch Systems, LLC and/or its affiliates in the U.S. and other countries. Third-party trademarks mentioned are the property of their respective owners. All rights reserved.
-
Page 2: Quick Installation Guide
3.5" SBC with Intel® Atom™ Processor Z510P/Z530P WAFER-US15WP Quick Installation Guide Version 1.0 June. 9, 2009 Package Contents WAFER-US15WP package includes the following items: 1x WAFER-US15WP Single board computer 1x KB/MS Cable 1x IDE Flat Cable 44p/44p 1x Audio Cable 1x Mini Jumper Pack 1x Utility CD 1 x QIG (Quick Installation Guide) - Page 3 Specifications ® CPU: Intel Atom™ Processor Z530P 1.6GHz with a 533MHz FSB ® Intel Atom™ Processor Z510P 1.1GHz with a 400MHz FSB ® System Chipset: Intel US15WP BIOS: AMI BIOS System memory: One 200 pin 400/533MHz DDR2 SDRAM SO-DIMM Supported (system max.2GB) Ethernet: One PCIe Intel®...
- Page 4 Ordering Information WAFER-US15WP-Z530P-R10: 3.5" SBC with Intel ATOM Z530P 1.6GHz, VGA/24 bit LVDS, GbE,CFII, USB, Audio WAFER-US15WP-Z510P-R10: 3.5" SBC with Intel ATOM Z510P 1.1GHz, VGA/24 bit LVDS, GbE,CFII, USB, Audio 32000-070301-RS : Dual ports USB cable 32200-026500-RS : RS232/422/485 cable 32100-052100-RS : ATX power cable ITS-44-R10 : 2.5"...
- Page 5 JP1 : LVDS LCD Voltage Select DESCRIPTION +3.3V 1-2 (Default) JP2 : Compact Flash Master/Slave Function Setting DESCRIPTION Short Master Open(Default) Slave JP3 : COM2 RS-232/RS-422 or RS-485 Type Select DESCRIPTION 1-2 (Default) RS-232 RS-422 or RS-485 AT/ATX1: ATX/AT mode setting AT/ATX1 DESCRIPTION Short(Default)
- Page 6 Table of Connectors LABEL FUNCTION VGA1 VGA 15-pin female connector COM1 Serial port connector LAN1 RJ45 LAN connector USB1,USB2 External USB connectors AUDIO1 AUDIO connector F_PANEL1 External switches and indicators panel LPC1 LPC (Low Pin Count ) interface connector COM2 Serial port connector KB/MS1 Keyboard/Mouse connector...
- Page 7 COM1: Serial port connector PIN NO. DESCRIPTION DCD1 DTR1 DSR1 RTS1 CTS1 LAN1: RJ45 LAN connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDI0+ MDI2+ MDI0- MDI2- MDI1+ MDI3+- MDI1- MDI3- USB1: USB connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC (+5V) VCC (+5V) DATA5- DATA4-...
- Page 8 AUDIO1 : AUDIO connector PIN NO. DESCRIPTION PIN No. DESCRIPTION Speaker_R Line_In_R Speaker_L Line_In_L MIC_R MIC_L F_PANEL1: External switches and indicators panel PIN No. DESCRIPTION PIN No. DESCRIPTION Power_LED+ HD_LED+ Power_LED- HD_LED- Speaker+ Reset_BT+ Speaker- Reset_BT- PWRBTN+ PWRBTN- LPC1 : LPC (Low Pin Count ) interface connector PIN No.
- Page 9 KB/MS1: Keyboard/Mouse connector PIN No. DESCRIPTION MS_DATA MS_CLOCK KB_DATA KB_CLOCK DIO1: 8-bit Digital I/O connector PIN No. DESCRIPTION PIN No. DESCRIPTION OUTPUT3 OUTPUT2 OUTPUT1 OUTPUT0 INPUT3 INPUT2 INPUT1 INPUT0 FAN1: Fan connector PIN No. DESCRIPTION +12V Sensor LVDS1: LVDS LCD connector DESCRIPTION DESCRIPTION LVDS data0 output +...
- Page 10 INVERTER1 : Inverter connector PIN No. DESCRIPTION +12V +12V ENABKL BRIGHTNESS ATXCTL1: ATX 5VSB and PSON connector PIN No. DESCRIPTION 5VSB PS_ON- ATXPWR1: Power input connector PIN No. DESCRIPTION USB3: Internal 2 ports USB connector PIN No. DESCRIPTION PIN No. DESCRIPTION VCC (+5V) DATA0-...
- Page 11 CF1:Compact flash storage card socket PIN No. DESCRIPTION PIN No. DESCRIPTION GROUND PULL DOWN CS1# CS3# GROUND IOR# IOW# IRQ15 MASTER/SLAVE RESET# IORDY ACTIVE# PDIAG# PULL DOWN GROUND...
- Page 12 IDE1: IDE connector PIN No. DESCRIPTION PIN No. DESCRIPTION RESET# DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 (KEY) IOW#...
- Page 13 MINI-PCIE1: PCI-E Mini Card Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCIE_WAKE# VCC3 1.5V CLKREQ# CLK- CLK+ PCIRST# PCIE_RXN1 VCC3A PCIE_RXP1 1.5V SMBCLK PCIE_TXN1 SMBDATA PCIE_TXP1 USBD- USBD+ 1.5V VCC3...
- Page 14 Layout...
- Page 16 Dimension...
