Product Installation Guide
nterprise branch and head offices
NANO-PV-D5251
www.enochsystems.com
1-877-722-1116
sales@enochsystems.com
Copyright © 2013 Enoch Systems, LLC, Enoch Systems and the Enoch Systems logo are trademarks or registered trademarks of Enoch Systems, LLC and/or its affiliates in the U.S. and other countries.
Third-party trademarks mentioned are the property of their respective owners. All rights reserved.
Advertisement
Related Manuals for Enoch Systems NANO-PV-D5251
Summary of Contents for Enoch Systems NANO-PV-D5251
- Page 1 Copyright © 2013 Enoch Systems, LLC, Enoch Systems and the Enoch Systems logo are trademarks or registered trademarks of Enoch Systems, LLC and/or its affiliates in the U.S. and other countries. Third-party trademarks mentioned are the property of their respective owners. All rights reserved.
- Page 2 All manuals and user guides at all-guides.com EPIC SBC with Intel® Atom™ D425/ D525/N455, VGA/LVDS, Dual GbE, USB2.0, CF II, Audio and SATA II, RoHS NANO-PV-D4251-R10 NANO-PV-D5251-R10 NANO-PV-N4551-R10 Quick Installation Guide Version 1.0 Oct. 28 , 2010 Package Contents NANO-PV-D4251/D5251/N4551 package includes the following items:...
- Page 3 All manuals and user guides at all-guides.com Specifications CPU: D425: Intel® Atom™ 45nm 1.8GHz Single Core Processor with 512KB L2 Cache D525: Intel® Atom™ 45nm 1.8GHz Dual Core Processor with 1MB L2 Cache N455: Intel® Atom™ 45nm 1.66GHz Single Core Processor with 512KB L2 Cache System Chipset: Intel ICH8M BIOS: UEFI BIOS...
- Page 4 Dimension: 165 mm x 115 mm Weight: GW: 850g; NW: 350g Ordering Information NANO-PV-D5251-R10: EPIC with Intel® Atom™ D525 1.8GHz, DDR3, VGA/LVDS, Dual GbE, USB2.0, CF II, Audio and SATA II, RoHS NANO-PV-D4251-R10: EPIC with Intel® Atom™D425 1.8GHz, DDR3, VGA/LVDS, Dual GbE, USB2.0, CFII, Audio and SATA II,RoHS...
- Page 5 All manuals and user guides at all-guides.com Jumpers setting LABEL FUNCTION J_AUTOPWR1 AT/ATX mode selection J_ATXCTL1 AT/ATX mode selection J_CMOS1 Clear CMOS J_VLVDS1 LCD Voltage Selection RS232/RS422 or RS485 Type Selection RS422/RS485 type selection RS422 terminal selection RS485 terminal selection JCF1 CF master/slave selection J_VCF1...
- Page 6 All manuals and user guides at all-guides.com Compact Flash Master/Slave Function Selection. JCF1 DESCRIPTION Short Master Open (default) Slave (default) PIO_VCC:PCI-104 device voltage selection DESCRIPTION 2-3(default) 3.3V(default) CF voltage selection J_VCF1 DESCRIPTION 2-3(default) 3.3V(default) LCD Voltage Selection J_VLVDS1 DESCRIPTION 1 -2(default) 3.3V( default) 3 -4 5 -6...
- Page 7 All manuals and user guides at all-guides.com Table of Connectors LABEL FUNCTION 6 pin PS/2 KB/MS Connector KB/MS1 Internal KB/MS Connector COM1 COM 9pin Female Connector COM2,4,5 Internal Serial Pin Header (RS-232) COM3 Internal Serial Pin Header (RS-232/422/485) VGA1 VGA 15-pin Female Connector LAN1,2 RJ45 LAN Connectors AUDIO1...
- Page 8 All manuals and user guides at all-guides.com COM 2,COM4,COM5: Serial port connector.(PIN HEADER 2*5,10PIN,P:2.0mm) PIN NO DESCRIPTION PIN NO DESCRIPTION COM3 : Serial port connector.(PIN HEADER 2*7,14PIN,P:2.0MM) DESCRIPTION DESCRIPTION DCD3 DSR3 RXD3 RTS3 TXD3 CTS3 DTR3 RS422 TX2 +/485 RS422 TX2-/485 RS422 RX2+ RS422 RX2- KB_MS1: 6-pin Mini-DIN Keyboard Connector...
- Page 9 All manuals and user guides at all-guides.com VGA1: 15-pin Female Connector PIN NO. DESCRIPTION P IN NO. DESCRIPTION GREEN BLUE Display_ GND DDCDAT HSYNC VSYNC DDCCLK LAN1 ,2: RJ45 LAN Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDI0+ MDI2+ MDI0- MDI3- MDI1+ MDI3+...
- Page 10 All manuals and user guides at all-guides.com AUDIO1: AUDIO Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Line out_R Line in_R Line out_L Line in_L MIC_R MIC_L CPU12V1: Power input connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION EXT_12VIN EXT_12VIN SYS_FAN1:Fan Connector PIN NO.
- Page 11 All manuals and user guides at all-guides.com SMBCLK SMBDATA INT_SERIRQ VCC3S DIO 1 : 10-pin Digital I/O Connector. PIN NO DESCRIPTION PIN NO. DESCRIPTION VCC5S OUTPUT3 OUTPUT2 OUTPUT1 OUTPUT0 INPUT3 INPUT2 INPUT1 INPUT0 CN1：SMBUS CONNECTOR PIN NO. DESCRIPTION PIN NO. DESCRIPTION SDAT SCLK...
- Page 12 All manuals and user guides at all-guides.com LPT1: Parallel Port Connector DESCRIPTION DESCRIPTION PTD0 ERROR# PTD1 INITIALIZE PTD 2 SLIN PTD3 PTD 4 PTD 5 PTD 6 PTD7 BUSY SLCT INV1 : Inverter Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Brightness Adjust Backlight Power Backlight Enable...
- Page 13 All manuals and user guides at all-guides.com Board Layout: Dimensions (Unit: MM)
- Page 14 All manuals and user guides at all-guides.com Board Layout: Jumper and Connector Locations...
- Page 15 All manuals and user guides at all-guides.com Bottom Side： ： ： ：...
