H
FILTERS
1. METAL FILTERS
To remove the metal grease-trapping filter, using the handle A until releas-
ing it from the guide. To reposition the filter, repeat the operation in the
reverse order.

2. CHARCOAL FILTERS

To replace the charcoal filters, proceed as follows: remove the metal filters
as described above. The two filters located at the ends of the motor can now
be easily accessed.
To install the new fi lters see picture.
In case of hood with the motor box the fi lter is located on the botton part of
the motor box.
To install the new fi lters see picture.
To order new charcoal fi lters contact the distributor/retailer.
VALID ONLY FOR ITALY: download the appropriate order form from: www.
falmec.com (access the assistance drop-down menu).
I
LIGHTING
SPOTLIGHT
How to replace a square halogen light:
a) Check that the equipment is disconnected from the power supply.
b) Open the panel completely till 90° (see figure) pressing the PUSH button.
c) Replace the lamp with a similar one (halogen, max 20W, 12 Volt, G4 connec-
tion).
d) Close the panel. If the panel does not close correctly repeat the operation at
point b.
REMOVING AND REPLACING'S INSTRUCTIONS
ASSEMBLY AND REPLACEMENT
9
