DR
FIELD and BRUSH MOWER
SAFETY & OPERATING INSTRUCTIONS
Serial No.
Order No.
Read and understand this manual and all instructions before operating the DR FIELD and BRUSH MOWER.
Original Language
DR Power Equipment
Toll-free phone: 1-800-DR-OWNER (376-9637)
Fax: 1-802-877-1213
Website: www.DRpower.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FIELD and BRUSH MOWER and is the answer not in the manual?

Questions and answers

Dick
April 2, 2025

Greese the drive belts

0
1 comments:
Mr. Anderson
April 2, 2025

The context does not mention greasing the drive belts. Instead, it provides steps to replace the drive belt. Belts generally should not be greased, as lubrication can cause them to slip or degrade. Therefore, you should not grease the drive belts on a DR Field and Brush Mower.

This answer is automatically generated

0

Related Manuals for DR FIELD and BRUSH MOWER

Summary of Contents for DR FIELD and BRUSH MOWER

  • Page 1 FIELD and BRUSH MOWER SAFETY & OPERATING INSTRUCTIONS DR Power Equipment Toll-free phone: 1-800-DR-OWNER (376-9637) Serial No. Fax: 1-802-877-1213 Original Language Order No. Website: www.DRpower.com Read and understand this manual and all instructions before operating the DR FIELD and BRUSH MOWER.

  • Page 2: Table Of Contents

    Additional Information and Potential Changes DR Power Equipment reserves the right to discontinue, change, and improve its products at any time without notice or obligation to the purchaser. The descriptions and specifications contained in this manual were in effect at printing. Equipment described within this manual may be optional.

  • Page 3: Chapter 1: General Safety Rules

    Labels Your DR FIELD and BRUSH MOWER carries prominent labels as reminders for its proper and safe use. Shown below are copies of all the Safety and Information labels that appear on the equipment. Take a moment to study them and make a note of their location on your Mower as you set up and before you operate the unit.
  • Page 4 Do not use flammable solutions to clean the air filter. • The muffler and engine become very hot and can cause a severe burn; do not touch. Allow the engine to cool before doing maintenance or making adjustments. ® FIELD and BRUSH MOWER...

  • Page 5: Slope Operation

    Never reach under the deck or grab hold of any part of the deck when the engine is running. • Your DR FIELD and BRUSH MOWER is a powerful tool, not a plaything. Exercise extreme caution at all times. The design of this machine is to cut grass and vegetation. Do not use it for any other purpose.
  • Page 6 No list of warnings and cautions can be all-inclusive. If situations occur that are not covered by this manual, the operator must apply common sense and operate this DR FIELD and BRUSH MOWER in a safe manner. Contact us at www.DRpower.com or call 1-800-DR-OWNER (376-9637) for assistance.

  • Page 7: Chapter 2: Setting Up The Dr Field And Brush Mower

    Chapter 2: Setting Up The DR FIELD and BRUSH MOWER It may be helpful to familiarize yourself with the controls and features of your DR FIELD and BRUSH MOWER as shown in Figure 1 before beginning these procedures. If you have any questions at all, please feel free to contact us at www.DRpower.com.

  • Page 8: Specifications

    At this point, the Lawn Deck (if ordered) is free standing and you can lift it off the pallet. 5. Roll the Power Unit off the pallet. Do not discard the cardboard and pallet until you are fully satisfied with your new DR FIELD and BRUSH MOWER.
  • Page 9 Before attaching the deck, be sure the spark plug wire(s) is disconnected. 6. Attach the Deck to the Power Unit following the directions in the next Collar section. The Belt is stored below the black Pulley Cover. 7. If assembling the Lawn Deck, mount the front Caster Wheels before attaching the Deck to the Power Unit.
  • Page 10 4. Open the Fuel Shut-Off Valve, which is located on the bottom of the Fuel Tank and accessed from the rear (Figure 1), if your model is equipped with one. Check the Tire Pressures The maximum Tire pressure is marked on the side of each Tire. Do not exceed the manufacturer’s recommended maximum pressure ® FIELD and BRUSH MOWER...

  • Page 11: Chapter 3: Operating The Dr Field And Brush Mower

    This chapter covers the procedures for starting and stopping your new DR  F IELD and BRUSH MOWER and discusses basic operation features. You may find it helpful to review the DR FIELD and BRUSH MOWER Controls and Features in Figure 1 on page 8 before reading this chapter.

  • Page 12: Stopping The Engine

    Engaging the Wheel Drive The DR FIELD and BRUSH MOWER has a four-speed Forward and single-speed Reverse Transmission. Forward speeds range from 1.1 mph in 1st Gear to 4.5 mph in 4th Gear. Use the lower gears for mowing in thick, woody vegetation and the higher gears for wide-open areas and lighter vegetation, or as "travel gears".
  • Page 13 • Do not use the DR FIELD and BRUSH MOWER on slopes greater than 20 degrees. Doing so could result in serious injury or damage to your machine. 1. If you have to mow on sloping terrain, mow across the slope, not up and down, for better control.

  • Page 14: Cold Weather Operation

    Please have your DR FIELD and BRUSH MOWER Model# and Serial# at hand when the call is placed. Tip: As a preventative measure to prevent control cable freeze up; prior to using your DR FIELD and BRUSH MOWER in cold weather, inject “dry gas”...

  • Page 15: Chapter 4: Maintaining The Dr Field And Brush Mower

    Replace Fuel Filter * SAE 30 oil. NEVER use penetrating oil. ** The Engine on your DR may not have a Precleaner or Oil Filter. Battery Care Proper care can extend the life of a Battery. Follow these recommendations to ensure your Battery’s best performance and long life: •...

  • Page 16: Charging The Battery

    Operate the Mower Engine for at least 45 minutes to maintain proper Battery charge. If the Battery loses its charge, you'll need to use a trickle Charger (like the DR Battery Charger) to recharge it. The Charger should have an output of 12 volts at no more than 2 amps.

  • Page 17: To Replace The Blade Belt

    (5) minutes to allow all parts to cool. Disconnect the spark plug wire(s), keeping it away from the spark plug(s). Use only DR belts on your machine. They have been thoroughly tested and proven for many hours of use.
  • Page 18 (5) minutes to allow all parts to cool. Disconnect the spark plug wire(s), keeping it away from the spark plug(s). Figure 16 Remove Pin and Collar Use only DR belts on your machine. They have been thoroughly tested and proven for many hours of use. Tools and Supplies Needed: •...
  • Page 19 9. Loosen the Belt Retainer Bolts on the outside of the Frame (one on each side) and slide the Retainer back (Figure 20). 10. Remove the Belt. 11. To mount the new Belt, reverse the above procedure. Removing and Replacing the Blade Before performing any maintenance procedure or inspection, stop the Loosen Bolt and Slide Back engine, wait five (5) minutes to allow all parts to cool.
  • Page 20 6. Add the Master Chain Link (Figure 25) in the reverse order of step 3. 7. Replace the Tensioner Spring (Figure 24). 8. Replace the Chain Cover and tighten the Lock Nuts. Tensioner Spring Chain Routing Figure 24 Master Link Lock Clip Side Plate Figure 25 ® FIELD and BRUSH MOWER...
  • Page 21 Adjusting the Differential Lock In/Out Cable Hex Flat In-Line Adjuster Before performing any maintenance procedure or inspection, stop the engine, wait five (5) minutes to allow all parts to cool. Disconnect the spark plug wire(s), keeping it away from the spark plug(s). NOTE: If the Differential will not Lock In or Out, the Cable may need adjustment.
  • Page 22 3. Remove the Belt from the Pulley (Figure 30). 4. Remove the Pin and Collar (Figure 31), and then pull the Power Unit away Figure 29 from the Deck. Collar Belt Removed Figure 31 Figure 30 ® FIELD and BRUSH MOWER...
  • Page 23 Disposing of the Battery Responsibly The Battery is a sealed lead-acid Battery. Recycle or dispose of it in an environmentally sound way. • Do not dispose of a lead-acid Battery in a fire; the Battery may explode or leak. • Do not dispose of a lead-acid Battery in your regular, household trash.

  • Page 24: Chapter 5: Troubleshooting

    Most problems are easy to fix. Consult the Troubleshooting Table below for common problems and their solutions. If you continue to experience problems, contact us at www.DRpower.com or call toll-free 1-800-DR-OWNER (376-9637) for support. Before performing any maintenance procedure or inspection, stop the engine, wait five (5) minutes to allow all parts to cool.
  • Page 25 Nut. Be sure to turn OFF the Engine and remove the Spark Plug wire(s) before performing this operation. ⇒ The Spindle Bearings may be bad. Call 1-800-DR-OWNER (376-9637) for assistance. ⇒ Check and retighten all of the fasteners as required.
  • Page 26 ⇒ The Differential Lock In/Out Cable is broken or out of adjustment. See page 22. In/Out will not Lock In ⇒ If the problem persists, visit our web site at www.DRpower.com for assistance. (stays in the Lock Out position) ® FIELD and BRUSH MOWER...
  • Page 27 CONTACT US AT www.DRpower.com...

  • Page 28: Chapter 6: Parts Lists, Schematic Diagrams And Warranty

    Chapter 6: Parts Lists, Schematic Diagrams And Warranty Parts List - Handlebar Assembly NOTE: Part numbers listed are available through DR Power Equipment. Ref# Part# Description Kit# Part# Description 112381 Washer, Flat, 1/4" USS 151311 Plug, Hour Meter Hole, 2" x 1.4"...
  • Page 29 Schematic – Handlebar Assembly 081008 CONTACT US AT www.DRpower.com...

  • Page 30: Parts List Power Assembly

    Parts List – Power Assembly NOTE: Part numbers listed are available through DR Power Equipment. Ref# Part# Description Ref# Part# Description 189161 Muffler, 18 HP Honda 191261 Bracket, Anti-Rotation 271511 Muffler, 16 & 18HP (Kawasaki) 112311 Spacer, .327" ID x .50" OD x 1.5" L 110691 Nut, 5/16"-18...
  • Page 31 Schematic – Power Assembly 031810 CONTACT US AT www.DRpower.com...
  • Page 32 Parts List – Brush Deck Assembly NOTE: Part numbers listed are available through DR Power Equipment. Ref# Part# Description Ref# Part# Description 150911 Spindle Housing, Brush Deck 101891 Fitting, Grease, Zerk, 1/4"-28, Straight 150641 Anti-Wrap Guard, 4 Hole Mount 150711 Bushing, Idler, .386"...
  • Page 33 Schematic – Brush Deck Assembly 080912 CONTACT US AT www.DRpower.com...
  • Page 34 Parts List – Frame and Drive Assembly NOTE: Part numbers listed are available through DR Power Equipment. Ref# Part# Description Ref# Part# Description 150261 Frame, Main 110761 Nut, Nylon Lock, 5/16"-18 111581 Bolt, 5/16"-18 x 1", HCS, GR2 123211 Bolt, 5/16"-18 x 3/4", HCS, GR5...
  • Page 35 Schematic – Frame and Drive Assembly 081008 CONTACT US AT www.DRpower.com...
  • Page 36 Wiring Diagram – Briggs and Stratton Electric Start 031810 ® FIELD and BRUSH MOWER...
  • Page 37 Wiring Diagram – Kawasaki Electric Start 031810 CONTACT US AT www.DRpower.com...
  • Page 38 Notes: ® FIELD and BRUSH MOWER...
  • Page 39 ® The DR FIELD and BRUSH MOWER is warranted for two (2) years against defects in materials or workmanship when put to ordinary and normal consumer use; ninety (90) days for any other use. For the purposes of all the above warranties, “ordinary and normal consumer use” refers to non-commercial residential use and does not include misuse, accidents or damage due to inadequate maintenance.
  • Page 40 • If your DR FIELD and BRUSH MOWER will be idle for more than 30 days, we recommend using a gas stabilizer. This will prevent sediment from gumming up the Carburetor. If there is dirt or moisture in the gas or Tank, remove it by draining the Tank.
